Apex Digital VARILYMPH 12 PRO User manual

V2.7 06/2019
USER MANUAL
VARILYMPH 12 PRO
CONTENTS
1. ABOUT
2. SAFETY INSTRUCTIONS
3. SCOPE OF SUPPLY
4. FIELD OF APPLICATION
5. OPERATION INSTRUCTION
6. END OF THERAPY
7. CLEANING
8. SERVICE
9. TECHNICAL SPECIFICATIONS

V2.7 06/2019
1. ABOUT
VARILYMPH 12 PRO is an automatic 12-chamber control device for Intermittent Pneumatic Compression Therapy
(IPC). You can use the device combined with the SLK garments for a 12 step physical drainage therapy of chronic venous
and lymphatic diseases.
The device can be used with one or two garments and allows a highly effective therapy on legs, arms and shoulder area.
The device creates an adjustable pressure in the garments. The pressure flow begins in the areas of the body furthest
(foot, hand) areas from the heart and moves in 12 steps to the body nearest areas.
The actual therapy pressure can be adjusted at the controller.
The de- and inflation of the air cells in the correct order is controlled by the VARILYMPH 12 PRO automatically.
The therapy activates the venous and lymphatic circulation.
2. SAFETY INSTRUCTIONS
2.1 Read the instruction manual before use carefully.
2.2 This product is intended only for the purpose described in the instructions for use.
2.3 Before patient change the system must be chemo-thermally treated by SLK or an authorized reseller. This is for
hygienic reasons and for compliance with the Medical Device Regulations (MPG) and guidelines for Hospital Hygiene
of Robert Koch Institute.
2.4 Please use the VARILYMPH 12 PRO ONLY with SLK garments.
2.5 The operation should be done only in closed rooms and by trained personnel or medical personnel.
2.6 Danger when using the system in the presence of easy flammable gasses.
2.7 Keep the control unit from water and moisture (eg.steam) away. If water has penetrated into the control unit,
disconnect it immediately from the power supply.
2.8 Please do not operate the control unit before it warmed up or cooled down to the room temperature.
2.9 Keep the system well away from high temperatures above 50 ° C.
2.10 Avoid damages by sharp objects of the power cord, the flexible hoses and the treatment sleeves.
2.11 When a power cord is damaged, the appliance should be removed from service and the cord replaced as soon
as possible to reduce the risk of electrical shock, electrocution or fire.
2.12 Operate the device only with the specified voltage (230V ~ 250V / 50Hz).
2.13 This system cannot be disposed of like regular trash. Detailed information can be obtained from the local waste
disposal service or the manufacturer.
2.14 In the case of a defect, please contact us. [phone] or contact their local dealer.
2.15 The system meets current safety standards, including: EN60601-1 and IEC 62366.
2.16 Changes or modifications which have not been made by the company SLK are expressly prohibited and will result
in immediate end of the warranty and certification.
3. SCOPE OF SUPPLY
•VARILYMPH 12 PRO compression therapy device
•power cable
•2x connecting tube for 12 chamber garments
•user manual
•cover cap

V2.7 06/2019
4. FIELD OF APPLICATION
INDICATIONS
• thromboembolic prophylaxis • venous oedema
• ulcus cruris • lymphatic oedema
• post-traumatic oedema • mixed forms of oedema
• lipoedema • peripheral arterial occlusive disease (under strict medical supervision)
• sensory disturbance caused by hemiplegia • diabetic foot syndrome
under strict observation
• post-thrombothic syndrome
CONTRA-INDICATIONS*:
• recent myocardial infarct • pulmonary oedema
• kardiac and renal caused oedema • decompensated cardiac insufficiency
• erysipelas • severe unstabilised hypertension
• acute soft-part-trauma of extremities • neuropathy
• occlusive processes in the sector
of lymphatic drainage
• extensive thrombophlebitis,
thrombosis or suspected thrombosis
Relative Kontraindikationen* :
•tumors in draining area
•pain during the therapy with IPC
*ask your attending doctor
5. OPERATION INSTRUCTIONS
To put the device into operation connect the power cable with the power supply and put the plug into the power outlet.
Connect the device and the garments with the connection tubes.
Make sure that the grey plugs of the garments are plugged into the grey socket of the device.
Make sure that the cover cap closes the second tube connector on the device if you are using only one garment.
1 2 3
To put the device into operation, connect the power cord to the appropriate power connector (Figure 1) and insert the plug into the
socket. Connect control unit and cuffs with connecting hoses. The plugs and sockets can be inserted only in one direction due to their
construction. (Fig.2 and Fig.3)
Please note: Remove the protective film from the display before using.
Make sure that the grey connector of the cuff are plugged into the unit in the grey sockets. (Fig.2)
The plug must fully engage on all four edges!

V2.7 06/2019
control unit
•after switching on the device by the power switch the graphic on the display starts automatically
•each possible setting is shown on the display for approx. 10 seconds. Each value can be adjusted by turning the dial.
Confirm the setting with the actual menu button
•each setting can be adjustedeven after the start-up phase. Just press the actual menu button and adjust the value by
turning the dial
Settings
•Keylock: Press and hold the therapy button for 3 seconds to activate or deactivate the keypad lock. This feature is
available after starting the therapy.
•time of therapy: Press the time of therapy button
Adjust the time from 10 to 60 minutes by turning the dial. Press the button again to confirm the setting
•deflation time:Press the deflation time button. Adjust the setting by turning the dial and confirm by pressing the deflation
time button again
•inflation time:Press the inflation time button. Adjust the setting by turning the dial and confirm by pressing the inflation
time button again
* You can also wait for approx. 8 seconds to confirm the settings. The display will switch to the start menu automatically
•target pressure: Adjust the target pressure in the start menu directly
•turn the dial clockwise to increase the target pressure. Turn the dial counter-clockwise to decrease the target pressure
•press the start button to start the therapy
You can adjust the target pressure and all other settings during the therapy by turning the dial anytime.
The display shows the current pressure in the active air chamber.
You can stop the therapy by pressing the start/stop button anytime.
individual adjustments:
•therapy pressure
•time of therapy
Please ask your attending doctor.
front
control dial
tube connector
power switch
power supply
tube connector with
cover cap
inflation time
deflation time
time of therapy
start / stop
back
display

V2.7 06/2019
6. END OF THERAPY
The device turns off automatically when the treatment time is up. The device changes over to standby mode. Disconnect
the tubes to deflate the garments. Always wait till the garments are fully deflated before opening the zipper to get out of
the garments.
For easier transport of the system, please loosen the hose connections to the device. This avoids damage to the control
unit and the pressure cuffs.
Quick - Evacuation
The therapy can be terminated at any time by disconnecting the unit from the mains. Treatment cuffs deflate automatically
during a power failure.
7. Cleaning and disinfection
Please note the attached cleaning instructions for SLK systems.
Cleaning
Clean all exposed surfaces and remove organic deposits by using a neutral detergent and a water-moistened cloth. Avoid
eccess of water or cleaning solution on the surface of the compressor.
The SLK pressure cuffs can also be cleaned with a water-moistened cloth. If heavily soiled, the pressure cuffs can be
washed also in the washing machine at a low spin up to max. 60°C.
Caution: ensure that the connection hoses to the pressure cuff a securely closed with the enclosed plugs before laundry.
They prevent the ingress of water.
Chemical disinfectants
We recommend disinfection with disinfectants based on alcohol (70%).
Moisten all surfaces with disinfection solution, then wipe with a water-moistened cloth and then dry it thoroughly.
For detailed information on cleaning and reprocessing in the SLK-Hygiene Center, please contact your dealer or directly
the company SLK.
The fuse can be changes in the little compartment between power switch and E14 socket:
