ApexDesk Elite Series User manual

Elite Series Assembly Guide
REV-1507C
ELECTRIC HEIGHT-ADJUSTED SIT TO STAND DESK

Elite Series Assembly Guide 2 |Page
Table of Contents
CAUTION, USE & LIABILITY .......................................................................................................................... 3
PARTS & HARDWARE LIST........................................................................................................................... 4
PARTS / COMPONENT DIAGRAMS ......................................................................................................... 5
ASSEMBLY INSTRUCTIONS ........................................................................................................................ 6
WARRANTY INFORMATION ....................................................................................................................... 11

Elite Series Assembly Guide 3 |Page
CAUTION, USE & LIABILITY
CAUTION
Make sure no obstacles are in the desk’s path. Make sure the desk top is not touching any walls. Make sure all
cords are of appropriate lengths to accommodate the change in desk height.
Read and understand this manual before attempting to install or operate.
This product is not intended for use by young children or for those who require supervision
Do not sit or stand on the desk. Do not crawl or lie under the desk.
Do not place any objects taller than 20” underneath the desk.
Do not open any of the components – lifting columns, control box, or controller. There is a risk of
electric shock.
The desk must be INITIALIZED before first use.
USE & LIABILITY
This sit-to-stand adjustable desk has electric motors and is designed for use in an indoor environment and dry
work areas only. The desk height is adjustable so that it can be positioned at the most suitable height. Any other
use is at user’s risk. Under no circumstances does the manufacturer accept warranty claims or liability claims for
damages caused from improper use or handling of the desk.

Elite Series Assembly Guide 4 |Page
PARTS & HARDWARE LIST
TOOLS REQUIRED
Phillips screwdriver Allen wrench 4mm x1
Allen wrench 5mm x 1
HARDWARE INCLUDED
14PCS 4PCS 3PCS 4PCS
M6×16 φ8×135mm M5×10 M6×20
No. HARDWARE LIST Qty
A M6x16mm hexagon screw 14
B L-shaped locking lever 4
C M5x10mm hexagon screw 3
D M6x20mm hexagon screw 4
E ST4.8x7mm pan-head screw 2

Elite Series Assembly Guide 5 |Page
PARTS / COMPONENT DIAGRAMS
No. PARTS / COMPONENT LIST Qty
1 Desk top 1
2 Foot 2
3 Lifting column 2
4 Top support bracket 2
5 Beam 1
6 Control box 1
7 Controller 1

Elite Series Assembly Guide 6 |Page
ASSEMBLY INSTRUCTIONS
BEFORE YOU BEGIN
1. Lay out all components and hardware to ensure that you have everything listed on Page 5.
2. The desk weighs over 100 lbs. Two people are needed to turn or move desktop and some components.
When turning or moving the assembled desk, grab it by SUPPORT BRACKETS (not the desk top).
3. Assemble on soft and non-abrasive surface to avoid scratch or damage to the desk top.
STEP 1
Use 5mm Allen wrench to secure foot to column with four Screw A (M6x16mm) on each side.
STEP 2
Use 4mm Allen wrench to secure top support bracket to beam with two Screw D (M6x20mm) on each side.
Note: The Illustrated beam placement allows controller to be on the right side of the desk. If you prefer
controller to be on the left, turn the beam (only) 180° so the two mounting holes for the control box will be on
the left instead. Pre-drilled holes are only available for controller to be installed on the right. You will need to
drill two holes yourself if you want to install the controller on the left.

Elite Series Assembly Guide 7 |Page
STEP 3
Turn assembled beam over. Insert assembled lifting columns from Step 1 into the beam.
STEP 4 (VERY IMPORTANT. READ CAREFULLY)
On the inner side of beam, there are eight holes – two for each locking lever. Each lifting column is to be
secured by two locking levers.
Each locking lever has a long and a short handle. The short handle is to be inserted into the holes on the inner
side of the beam. Insert the end that is away from long handle first, and slide the other end into the hole on the
opposite side. Please make sure the long handle is on your LEFT side when facing the lifting column.

Elite Series Assembly Guide 8 |Page
STEP 4 – CONT’D
With both ends of the short handle into the holes, push the long handle with your hand toward the lifting
column. You should feel some pressure while pushing it down. Once the long handle is flush with the beam,
use a tool such as a flat-head screwdriver to push it further down. If no pressure is felt while pushing one or
both handles down, check whether the top support bracket is installed and secured properly, and whether the
long handle is on the left.
Each lifting column requires two L-shaped levers to be properly secured. The two L-shaped levers, when
installed correctly, should form a tight lock and secure the lifting columns to the beam. It is normal that you feel
more pressure on one handle than the other when pushing them down. Make sure the levers DO NOT WIGGLE
or DO NOT FEEL LOOSE. If they do, the levers are either defective or not properly installed.
STEP 5
Use Phillips screwdriver to secure control box with two Screw C on one side and one Screw C on the other.
On one end of control box, there are four ports – two for motor cables and two for controller. On the opposite
end, there is only one socket for power cord. If you want controller to be installed on the right side of desk,
make sure the 4-port end is the on right side as well. If you want controller to be on the left side, make sure
that you place the beam according to the note in Step 2 and the 4-port end of control box is on the left. Please
note that there are two pre-drilled holes for controller on the bottom of right side desk top, not on the left side

Elite Series Assembly Guide 9 |Page
STEP 6
This step is a two-person job. Carefully move the assembled frame onto desk top.
Align the holes on the support brackets to those pre-installed anchors on the top. Secure each side with three
Screw A (M6x16mm).
Use a Philips screwdriver to secure controller to the pre-drilled holes on the bottom of the top with two Screw E
(ST4.2x17mm).

Elite Series Assembly Guide 10 |Page
STEP 7
Connect both motor cables to the control box.
Connect controller cable to either plug on the control box.
Connect one end of power cord to the control box, and do not connect the other end to an 110V outlet yet.
With two people, grab the assembled desk by SUPPORT BRACKETS (not desk top) and turn the desk over to
upright position. Adjust leveling studs on the feet as needed.
STEP 8
Motors must be initialized before your first use.
Connect power cord to an 110V outlet. Press and hold the DOWN button from the controller. The lifting
columns will make a short downward motion and reach their lowest position. They will back up slightly and
then stop. This completes the initialization and synchronization process. Your desk is now ready to use.
TROUBLESHOOTING
Issues(s)
Solution
Desk does not go up or down.
Check all connections. Make sure power cord is plugged into the
control box and a power outlet. Make sure that you are pressing
DOWN button not UP button when initializing the desk.
Re-initialize the desk. Contact tech support if the problem persists.
Columns do not go up evenly.
Re-initialized desk. Contact tech support if the problem persists.
Desk wobbles pretty excessively.
It is normal that desk wobbles slightly at standing height. Make
sure all the screws are tightened and adjust leveling studs.

Elite Series Assembly Guide 11 |Page
WARRANTY INFORMATION
SCOPE OF WARRANTY
Apex Furniture LLC (“ApexDesk”) warrants to the original purchaser its new desk (except for components not
warranted under “Exclusions”) manufactured by ApexDesk to be free from defects in material and
workmanship under normal use and service. ApexDesk’s obligation under this warranty is limited to the repair
or replacement, at ApexDesk’s sole option, of the parts or products the defect of which are reported to
ApexDesk within the applicable warranty period and which, upon examination by ApexDesk, prove to be
defective.
APPLICABLE WARRANTY PERIOD
The applicable warranty period, measured from the date of delivery to the original user, shall be two (2) years
on electric parts, five (5) years on non-electric parts.
EXCLUSIONS
This limited warranty does not cover and ApexDesk shall not be liable for the following: (1)repairs and
replacements because of misuse, abuse, negligence, alteration, accident, freight damage, or tampering; (2)
products which are not installed, used, stored and properly cleaned as required in the ApexDesk “Assembly
Guide” for this product; (3) products considered to be of a consumable nature; (4) Shipping to or from repair
center; (5) accessories or parts not manufactured by ApexDesk; (6) charges by anyone for adjustments, repairs,
replacement parts, installation, or other work performed upon or in connection with such products which is not
expressly authorized in writing in advance by ApexDesk.
EXCLUSIVE REMEDY
ApexDesk’s only obligation under this warranty is the repair or replacement of defective parts. ApexDesk shall
not be liable for any direct, special, indirect, incidental, exemplary, or consequential damages or delay,
including, but not limited to, damages for loss of profits or loss of use.
CONTACT INFORMATION
Apex Furniture LLC (“ApexDesk”)
18467 Railroad Street, City of Industry, CA 91748
Email: [e-mail]
(877) 516-DESK
www.apexdesk.com
For technical assistance, please call us or visit us at www.apexdesk.com/support.
