ApexDesk Flex Series User manual

9-2018
ApexDesk Flex Series Electric Height
Adjustable Desk Assembly Guide
ELECTRIC HEIGHT-ADJUSTED SIT TO STAND DESK

1
Table of Contents
CAUTION, USE & LIABILITY .................................................................................................................... 2
PARTS / COMPONENT DIAGRAMS ................................................................................................... 3
PARTS / COMPONENT LIST ................................................................................................................. 4
TOOLS & HARDWARE LIST .................................................................................................................... 5
ASSEMBLY INSTRUCTIONS .................................................................................................................. 6
1) UNFOLD FRAME & INSTALL DESK SUPPORT BRACKET ............................................................................ 6
2) ALIGN/EXTEND DESK FRAME & MOUNT DESKTOP ................................................................................. 8
2A) Mounting the ApexDesk Elite 60” Top ................................................................................................ 8
2B) Mounting the ApexDesk Vortex 60” Top ........................................................................................... 11
2C) Mounting Non-ApexDesk Tabletops ................................................................................................. 12
3) INSTALL DESK FEET .................................................................................................................................. 13
4) CONNECTING CABLES .............................................................................................................................. 14
INITIALIZING DESK & SETTING HEIGHT POSITIONS ................................................................ 15
TROUBLESHOOTING ............................................................................................................................. 16
ERROR CODES ......................................................................................................................................... 17
WARRANTY INFORMATION ................................................................................................................. 18

2
CAUTION, USE & LIABILITY
CAUTION
Make sure no obstacles are in the desk’s path. Make sure the desk top is not touching any walls. Make sure all cords
are of appropriate lengths to accommodate the change in desk height.
Read and understand this manual before attempting to install or
operate
.
This product is not intended for use by young children or for those
who
require
supervision
Do not sit or stand on the desk. Do not crawl or lie under the desk.
Do not place any objects taller than 20” underneath the desk.
Do not open any of the components – lifting columns, control box, or controller. There is a risk of
electric shock.
THE DESK MUST BE INITIALIZED BEFORE USE.
USE & LIABILITY
This sit-to-stand adjustable desk has electric motors and is designed for use in an indoor environment and dry work
areas only. The desk height is adjustable so that it can be positioned at the most suitable height. Any other use is at
user’s risk. Under no circumstances does the manufacturer accept warranty claims or liability claims for damages
caused from improper use or handling of the desk.

3
PARTS / COMPONENT DIAGRAMS
ST5x12mm Hexagon
Washer Screw (F)
Support
Bracket (#4)
Support
Bracket (#4)
Desk Leg (#3)
M6x6 Screws (D)
Pre-installed
M6x40 Screws (C)
M6x40
Screws (C)
Desk Feet
(#2)
M8x25 Screw &
Bolt Sleeve (A)
M8x25 Screw &
Bolt Sleeve (A)
M8x25 Screw &
Bolt Sleeve (A)
Pre-installed
M8x25 Screw &
Bolt Sleeve (A)
Pre-installed

4
PARTS / COMPONENT LIST
NOTE: Please verify that you have all the parts on below list. If you are missing or have damaged parts, please
contact customer support at [email protected].
No. PARTS / COMPONENT LIST PICTURE / QTY
1 Desk top (optional) X 1
2 Foot X 2
3 Desk Leg / Lifting Column (Pre-installed) X 2
4 Desk Support Bracket X 2
5 Crossbeam X 1
6 Control Box (Pre-installed) X 1
7 Memory Controller X 1

5
TOOLS & HARDWARE LIST
NOTE: Please verify that you have all the parts on below list. If you are missing or have damaged parts, please
contact customer support at [email protected] for faster service.
No. HARDWARE LIST PICTURE / QTY
A M8x25mm Hexagon Screw & Bolt Sleeves
(For securing legs to crossbeam)
4 Sets
B M6x16 Hexagon Screw
(For securing top to support brackets)
X 8
C M6x40 Hexagon Screw
(For securing feet to lifting columns)
X 8
D
M6x6 Hexagon Screw
(Pre-installed. For securing connecting bars to lock frame
width)
X 8
E ST4.8x13mm Pan Head Screw
(For securing memory controller to underside of top)
X 2
F ST5x12mm Hexagon Head Washer Screw
(For securing crossbeam to top)
X 8
G Phillips Screwdriver X 1
H 3mm Allen Wrench
X 1
I 5mm Allen Wrench
X 1
J 6mm Allen Wrench
X 1

6
ASSEMBLY INSTRUCTIONS
BEFORE YOU BEGIN
1. Lay out all components and hardware to ensure that you have everything listed on Page 4 & 5.
2. The desk weighs over 100 lbs. Two people are needed to turn or move desktop and some components.
When turning or moving the assembled desk, grab it by SUPPORT BRACKETS (not the desk top).
3. Assemble on soft and non-abrasive surface to avoid scratch or damage to the desk top.
1) UNFOLD FRAME & INSTALL DESK SUPPORT BRACKET
1) Unfold legs (Part #3) until the holes on the legs line up with the Crossbeam (Part #5).
2) Slide in Support Bracket (Part #4) into Crossbeam (Part #5).
Unfold 90
°
to the right
Unfold 90
°
to the left

7
3) Insert Bolt Sleeves through holes on the Crossbeam (#5) and Leg (#3).
4) Insert M8x25 Screws (A) into sleeves and tighten with 6mm Allen Wrench (J).
5) Tighten two pre-installed M8x25 Screws with 6mm Allen Wrench (J).

8
2) ALIGN/EXTEND DESK FRAME & MOUNT DESKTOP
2A) Mounting the ApexDesk Elite 60” Top
1) Place desktop on a flat and non-abrasive surface with screw holes facing up. With two people, carefully place
assembled frame onto the desk top. The frame is heavy. Two people are needed to move it and to turn the desk
over after it is fully assembled.
2) Align left Support Bracket (#4) with pre-installed anchors on the top and secure it half-way with 3 Screws (B). Do
not tighten the screws yet.
Left Support
Bracket
Right Support
Bracket

9
3) Loosen 8 pre-installed M6x6 Hexagon Screws (D) as shown in the diagram below with 3mm Allen Wrench (H).
This unlocks connecting inner bars in the middle section of the crossbeam and allows the crossbeam to be extended
or retracted to accommodate different top widths.
4) Grab the right lifting column, pull/ push to align the right Support Bracket (#4) with the pre-installed anchors on
the top.
Use 3mm
Allen
Wrench (H)
to unscrew

10
5) Tighten all screws once every part is lined up correctly. If you are unable to tighten Screw (D) or if Screw (D) falls
into the crossbeam, it is because the connecting bars of the crossbeam are out of position. Correct it by sliding the
bar to the left or right and make sure the bars are directly under the screw holes.
6) Optional. Eight Washer Screws (F) are included for tops larger than 72” or for extra security. However, most users
don’t install those screws. For those who do, they rarely use all eight screws. Please note pilot holes are not pre-
drilled on the ApexDesk Elite and Vortex tops. The Washer Screws are self-drilling. Use a power tool to install.
7) Use two ST4.8x13 pan head screws (E) to secure the memory controller to the desktop. Please note pre-drilled
pilot holes are only available on the right side of the desk.
Use ST5x12 Hexagon
Washer Screw (F) to secure
Crossbeam to tabletop
Use M6x16
Hexagon Screw (B)

11
2B) Mounting the ApexDesk Vortex 60” Top
Follow the same basic steps from 2A-1 thru 2A-5. The only difference is that Vortex top requires four screws on
each side.
Left Support
Bracket
Right Support
Bracket
Optional:
Use 8pcs of ST5x12
Hexagon Washer Screw (F) to
secure Crossbeam

12
2C) Mounting Non-ApexDesk Tabletops
If you are using your own top, we recommend that you use a top between 48” to 78” in width and 28” to 38” in
depth. Top can be installed either with anchor/screw or wood screws. Please make sure the lenth of screw does not
exceed the thickness of your top when wood screws are used. For best stability, the crossbeam should be centered
with support brackets about 2” to 3” from the edge.
Optional:
Use 8pcs of ST5x12
Hexagon Washer Screw (F) to
secure Crossbeam

13
3) INSTALL DESK FEET
Attach each foot to each Desk Leg (#3) with four M6x40 screws (C). Use 5mm Allen Wrench (I) to tighten
screws.

14
4) CONNECTING CABLES
1. Connect memory controller (#7) cable to the left plug on control box (#6).
2. Connect motor cables to control box (#6) by threading them thru the cable guards. Motor cables can be
connected to either port and interchangeably. Switching cables from one port to another may be needed
when troubleshooting. Please refer to trouble-shooting section for details.
3. Plug power cord to control box.
4. Plug power cord to a power outlet.
5. Your desk is now fully assembled. Proceed with initializing (see next section) before turning desk over.
Controller
Cable
Motor Cable
110
-
120V Power
Cable Guard
Control Box

15
INITIALIZING DESK & SETTING HEIGHT POSITIONS
DESK MUST BE INITIALIZED BEFORE FIRST USE
To Initialize or Reset
Press and hold UP and DOWN arrow buttons until three blinking zeros (“000”) appear on the display, then release
the buttons. The desk will automatically go to the lowest position, then to the highest position and travels down
again and stop at mid height. Display will show 38 (+/- 1). The desk is now initialized and is ready to use.
Tips: Your desk may need to be re-initialized (reset) from time to time to work properly.
To Preset Preferred Heights
You can preset up to four positions. Use UP and DOWN arrow buttons to move desk to your desired position.
Press/hold the ‘M’ button AND one of the number buttons together for 1 to 3 seconds until displayed
height starts blinking, and then release the buttons. To go to your preset height, simply press the number
button TWICE or press and hold the button.
Preset
‘M’ Button
Memory Preset Options
1 / 2 / 3 / 4
LED DISPLAY
UP
/ DOWN
Buttons

16
TROUBLESHOOTING
Issues
Solution
Desk does not go up or down. The
memory controller does not illuminate
when any button is pressed.
Check all connections. Make sure power cord is plugged into the
control box and a power outlet. Press any button on the
controller and make sure it illuminates. Re-initialize the desk.
Desk does not go up or down. The
memory controller illuminates when any
button is pressed.
Unplug the power cord and re
-
plug after 10 seconds. Re
-
initialize
the desk. If the problem persists, switch motor cables from one
port to another at control box and re-initialize one more time.
Columns do not go up evenly.
Unplug the power cord and re
-
plug after 10 seconds. Re
-
initialize
the desk. If the problem persists, switch motor cables from one
port to another at control box and re-initialize one more time.
Desk wobbles pretty excessively.
It is normal that desk
wobble
s
slightly at standing height
when in
use. Make sure all the screws are tightened and adjust leveling
studs if the floor is uneven.
HO
T
is displayed on the panel
The desk overheats. Stop using the desk for 10 minutes and let it
cool down.
Desk is unusually noisy
Lift column consists of two stages. It is normal that the desk is
noisier when one stage extends into the other. Apply silicon
based lubricant if it is unusually noisy.

17
ERROR CODES
Error Code Solution
--- Not initialized. Initialize desk. Press/hold up and down buttons at same time and release
both when 000 appears on the panel.
E0 Control system malfunction. Contact dealer.
E1 Voltage irregularity. Contact dealer.
E3 Over-load protection activated. Reduce load on the desk.
E4 Over-heat or power supply failure. Let desk cool down for 10 minutes.
E5
Irregular Hall signal on Motor A. Unplug/re-plug power cord, and reset desk. If the
problem persists, switch motor cables at control box and attempt another reset. Contact
dealer if error code changes after switching cables.
E6
Motor A malfunction
.
Unplug/re
-
plug power cord, and reset de
sk. If the problem
persists, switch motor cables at control box and attempt another reset. Contact dealer if
error code changes after switching cables.
E7
Motor B malfunction
.
Unplug/re
-
plug power cord, and reset desk. If the problem
persists, switch motor cables at control box and attempt another reset. Contact dealer if
error code changes after switching cables.
E8
Loose connection or irregular Hall signal
.
Check all connect
ion. Reset desk after
switching motor cables at control box. Contact dealer if error code changes after
switching cables.
E9
Irregular Hall signal on Motor B. Unplug/re-plug power cord, and reset desk. If the
problem persists, switch motor cables at control box and attempt another reset. Contact
dealer if error code changes after switching cables.
E11 Anti-collision protection activated. Reduce sensitivity or turn off anti-collision function

9-2018
WARRANTY INFORMATION
SCOPE OF WARRANTY
Apex Furniture LLC (“ApexDesk”) warrants to the original purchaser its new desk (except for components not
warranted under “Exclusions”) manufactured by ApexDesk to be free from defects in material and
workmanship under normal use and service. ApexDesk’s obligation under this warranty is limited to the repair
or replacement, at ApexDesk’s sole option, of the parts or products the defect of which are reported to
ApexDesk within the applicable warranty period and which, upon examination by ApexDesk, prove to be
defective.
APPLICABLE WARRANTY PERIOD
The applicable warranty period, measured from the date of delivery to the original user, shall be two (2) years
on the lifting mechanism and electronic parts.
EXCLUSIONS
This limited warranty does not cover and ApexDesk shall not be liable for the following: (1)repairs and
replacements because of misuse, abuse, negligence, alteration, accident, freight damage, or tampering; (2)
products which are not installed, used, stored and properly cleaned as required in the ApexDesk “Assembly
Guide” for this product; (3) products considered to be of a consumable nature; (4) Shipping to or from repair
center; (5) accessories or parts not manufactured by ApexDesk; (6) charges by anyone for adjustments, repairs,
replacement parts, installation, or other work performed upon or in connection with such products which is not
expressly authorized in writing in advance by ApexDesk.
EXCLUSIVE REMEDY
ApexDesk’s only obligation under this warranty is the repair or replacement of defective parts. ApexDesk shall
not be liable for any direct, special, indirect, incidental, exemplary, or consequential damages or delay,
including, but not limited to, damages for loss of profits or loss of use.
CUSTOMER SUPPORT
For technical assistance, please visit us at www.apexdesk.com/support. Return the affected part(s) postage
prepaid to ApexDesk pursuant to our customer service representative; and Include in the package:
1. A copy of the original bill of sale, your charge or credit receipt, or other satisfactory proof of the date of
the original purchase date of the product, and the price paid; and
2. A short detailed description of the problem, the name and phone number of the contact person.
CONTACT INFORMATION
Apex Furniture LLC (“ApexDesk”)
18467 Railroad Street, City of Industry, CA 91748
Email: [e-mail]
(877) 516-DESK
www.apexdesk.com
For technical assistance, please call us or visit us at www.apexdesk.com/support.
