Apollo MCP1A-R470SF-A071-01IS User manual

1
Conventional I.S. Indoor Manual Call Point
Installation Guide
General
Conventional I.S. Indoor Manual Call Point is available in two versions:
Part Number Model Number Product Name
55100-031 MCP1A-R470SF-A071-01IS Conventional I.S. Indoor Manual Call Point-Red
Conventional Indoor Manual Call Point
The Conventional I.S. Indoor Manual Call Point is supplied with a backbox for surface
mounting. The call point is ‘Type A’ and is suitable for indoor use only. For  ush mounting,
a standard electrical outlet box with a minimum depth of 25mm is required.
Installation – General
The installation must conform to BS5839: Part 1 (or applicable local codes).
Installation
1. Fit the backbox (Fig 1) to the wall.
2. Run the cables into the backbox and connect them to the terminal block as shown in
Fig 2. Ensure that functional earth/screen continuity is maintained.
3. Unlock the small front cover by inserting the forked key and pushing it home. Remove
key, slide the cover down and remove the deformable element. Connect the terminal
block as shown in Fig. 2, secure the call point to the backbox and re t the deformable
element as required. Finally, replace the front cover in the reverse order in which it was
removed and push it up until it locks.
The call points should be installed in a position where they will not be subjected to
mechanical stresses and where the temperature is within operating temperature range.
Areas where there are, or are likely to be, aggressive substances should be avoided.
4
© Apollo Fire Detectors Limited 2021
Apollo Fire Detectors Limited, 36 Brookside Road, Havant, Hants, PO9 1JR, UK
Tel [phone]
Website: www.apollo- re.co.uk
39214-591/Issue 3
IMPORTANT NOTICES
These call points carry the following approvals:
II 1 G Ex ia IIC T4 Ga -10°C to +55 °C
Ui=30 V, Ii=500 mA, Pi=1 W 2813
Sira 04ATEX2350X 2831
They are designed and manufactured to protect against other hazards as de ned in
paragraph 1.2.7 of Annex II of the ATEX Directive 2014/34/EU.
They are intended for indoor use within Intrinsically Safe (I.S.) Systems utilising suitable Safety
Barriers.
Special conditions for safe use (denoted by X after the certi cate number)
The enclosure is non-conducting and may generate an ignition-capable level of
electrostatic charges under certain extreme conditions. The user should ensure that the
equipment is not installed in a location where it may be subjected to external conditions
(such as high-pressure steam) which might cause a build-up of electrostatic charges on
non-conducting surfaces. Additionally, cleaning of the equipment should be done only
with a damp cloth.
The equipment may be used in an ambient temperature range of -10°C to +55°C.
These call points must not be modi ed in any way as doing so may invalidate the
Certi cation and may compromise the safety of the product.

2
Transparent Hinged Cover ( ip lid)
To provide additional protection against accidental operation of call points, a transparent
hinged cover, part no. 26729-152 is available.
To prevent against malicious activations of call points, locking tags are also avaliable, part
no. 26729-179 (pack of 5).
Please note that the call point does not conform to EN54–11 : 2001 when the hinged cover is
secured with the locking tag.
Commissioning
Test each MCP using the test key provided. Ensure the control panel enters the alarm state.
Wiring Details
All wiring terminals accept solid or stranded cables up to 2.5mm².
Technical Data
Maximum Voltage 30V
Maximum Switching Current 500mA
Alarm Resistor 470 Ω
IP rating IP24D
Operating Temperature -10°C to +55°C
Wattage 1W
Note: These ratings must not be exceeded
Troubleshooting
Before investigating individual units for faults, ensure the system wiring is fault free.
Routine Testing
Insert the test key into the hole at the bottom of the call point and push home. Observe
routine test requirements as speci ed in the applicable local codes.
Apart from regular testing, as part of the scheduled maintenance of the  re alarm system,
no additional maintenance is required.
Resetting
After testing, reset the call point by removing the test key and pushing up the front cover
until it clicks home.
Important Information
The use of lubricants, cleaning solvents or petroleum based products should be avoided.
Do not over tighten  xing screws.
Fault Finding
Problem Possible Cause
Control panel reports zone fault Incorrect zone wiring
Detector removed
EOL device missing or incorrectly  tted
Control panel reports alarm MCP not reset
Test key not removed
Incorrect EOL device
MCP does not activate alarm Incorrect wiring
Incompatible control panel
For further information, please refer to PP2418.
3
Fig. 1 Backbox
87mm
87mm
Fig. 2 Terminal block connections
