Installation, Assembly and Operation Instructions
400 LBS [181 kg] MAXIMUM LIFTING CAPACITY
EZ POOL LIFT™
-
WARNING
-
IMPORTANT SAFETY INSTRUCTIONS
1. REA AN FOLLOW ALL INSTRUCTIONS. LIFT SAFETY CAN ONLY BE ENSURE IF THE
LIFT IS INSTALLE AN OPERATE PROPERLY – ACCOR ING TO THESE INSTRUCTIONS.
2. TO RE UCE THE RISK OF INJURY, O NOT PERMIT CHIL REN TO USE THIS PRO UCT
UNLESS THEY ARE CLOSELY SUPERVISE AT ALL TIMES.
3. O NOT PERMIT CHIL REN TO PLAY ON OR AROUN THIS PRO UCT.
4. NEVER APPLY IRECT WATER PRESSURE TO THE ELECTRONIC COMPONENTS.
5. SA
VE A COPY OF THESE INSTRUCTIONS IN A SAFE AN EASILY ACCESSIBLE PLACE.

EZINST-11/22/10 Page 2 of 12
© Aqua Creek Products LLC 2003-2010
TABLE OF CONTENTS
EZ Pool Lift™ Parts Lists 3
Retro-fit anchor Installation Instructions
New construction anchor installation instructions 6
EZ Pool Lift
TM
Assembly Instructions 7
EZ Pool Lift
TM
Operating Instructions 9
Safety, cleaning and maintenance 10
EZ Pool Lift
TM
Detailed Parts List 11
Warranty 12

EZINST-11/22/10 Page 3 of 12
© Aqua Creek Products LLC 2003-2010
THE EZ POOL LIFT™
The EZ Lift™ and Power EZ Lift™ arrive partially assembled in multiple boxes. Begin by
removing all parts from the boxes and locating the parts for your lift in the parts lists below.
Refer to the parts breakdown drawings in the back of this manual for assistance.
PARTS LIST – EZ POOL LIFT™
BOX
“
A
”
CONTENTS
(ANCHOR INCLU E )
ITEM # QTY. DESCRIPTION
1 1 BOOM/MAST ASSEMBLY
2 1 HYDRAULIC RAM
BOX
“
B
”
CONTENTS
(ANCHOR INCLU E )
ITEM # QTY DESCRIPTION
1 1 EZ SLING
2 1 EZ CHAIN SET
3 1 EZ HANGER
1 EZ SLING BARS
5 1 EZ TURN BAR
6 1 ANCHOR (IF ORDERED WITH
LIFT)
7 1 HARDWARE BAG
HAR WA
RE BAG
ITEM # QTY DESCRIPTION
1 1 3/8” X 1-3/ ” S.S. HEX BOLT
2 1 3/8” X 1-1/2” S.S. HEX BOLT
3 3/8” S.S. FLAT WASHER
2 3/8” S.S. NYLOCK NUT
- REA CAREFULLY-
heck entire box and inside all packaging materials for parts. Before beginning assembly, read
the instructions and identify parts using the figures and parts lists in this document. It is critical
that all parts be carefully inspected by the installer prior to installation to ensure that no damage
occurred in transit and that a damaged part is not used. If any damage occurred in transit or you
are missing parts, notify Aqua reek Products Immediately! Failure to notify Aqua reek of
damaged or missing parts within 3 days of receipt of shipment may affect your ability to receive
replacement parts. Proper installation cannot be overstressed – improper installations will void the
warranty and may affect the safety of the user.

EZINST-11/22/10 Page of 12
© Aqua Creek Products LLC 2003-2010
EZ POOL LIFT™ ANCHOR INSTALLATION
EZ POOL LIFT
TM
RETRO-FIT ANCHOR INSTALLATION
STEP 1:
Determine the best location for the lift. Be sure to mount the lift at a location that provides
at least 8” [122 cm] from deck level to the bottom of the pool. Make sure the location
includes enough clear deck space to easily transfer into the lift seat. Keep in mind this lift
will require assistance from another person to operate and you should locate it in an area
that can accommodate another person. The lift should also be located so as to provide at
least 6’ [1.8 m] of unobstructed deck to each side of the lift to accommodate easy
maneuvering of the lift over the water and back.
STEP 2:
Locate the concrete anchor socket that came with your
lift. Be careful to not lose the protective cap on the
anchor. This will be used to keep dirt and debris out of
the socket when the lift is not installed in the anchor.
STEP 3:
The setback to the center of the anchor must be no less
than 12” [30.5 cm] and more than 20” [51 cm] from the
pool wall. The anchor location must also be at least 6” [15 cm] from any control joint or
edge of concrete slab. Measure the location out using your tape measure and marking
pen. (Reference the drawing on the next page for details).
NOTE:
The EZ Pool Lift™ comes standard with a 6” deep anchor socket that is
installed into a concrete deck. Anchor options include a surface mount anchor
and a wood deck anchor system both purchased separately. The EZ Pool Lift™
standard 6” anchor system can be installed in an existing pool deck (Retro-fit
installation) or when pouring a new concrete pool deck (New construction
installation). If the anchor has already been installed you can move on to the
assembly section of this manual that is appropriate to the lift you purchased.
REQUIRE TOOLS
(Core rilling Method)
Tape Measure Core Drill
” [10 cm] Core Drill Bit Electrical tape
2-part Epoxy or Hydraulic Cement Small Carpenters Level
Felt Tip Marking Pen Vacuum or compressed air source
CONCRETE ANCHOR
SOCKET
NOTE:
The concrete deck around the anchor system should be a minimum of 8”
thick and should be reinforced with # reinforcing bars spaced on 10” centers in
each direction. The total concrete pad area should be at least 60” wide
(measured away from the pool edge) and 60” long (parallel with the pool edge).

EZINST-11/22/10 Page 5 of 12
© Aqua Creek Products LLC 2003-2010
STEP 4:
Core drill at least a ” [10 cm] diameter hole at the desired location for the lift anchor
socket. The hole will need to be at least 7” [18 cm] deep to allow for the grounding lug
which protrudes from the bottom of the anchor. Depending on the thickness of your
concrete slab, you may drill completely through the slab and into the underlying dirt. If you
have drilled all the way through your deck you may need to saw cut the deck and pour a
new footing according to the deck requirements at the beginning of this section.
TIP: Use the electrical tape to make a mark on your drill bit at 7” [18 cm] as a
depth mark to tell you when to stop drilling.
STEP 5:
Clean out the hole and make sure your hole is deep enough to allow the anchor to be flush
with the finished deck surface. If you have drilled completely through the deck you can
remove some of the dirt under the slab to create a “pocket” under the slab to be filled with
epoxy or hydraulic cement if needed.
STEP 6:
Ground the anchor according to your local code requirements. (This may require
additional drilling and/or other tools).
STEP 7:
Carefully insert the anchor into the hole and pour some cement or epoxy around the
anchor to provide support enough to check for plumb.
TIP: Fill the hole about a ¼ full of cement or epoxy prior to inserting the anchor.
As you insert the anchor rotate it back and forth so that you can evenly distribute
the cement or epoxy around the anchor.
STEP 8:
Check the anchor for
level and plumb and pour
hydraulic cement or high
strength epoxy into the
remaining space around
the anchor making sure
there are no void spaces.
Let cement or epoxy cure
for 2 hours (or minimum
manufacturer’s
recommendations) before
using lift.

EZINST-11/22/10 Page 6 of 12
© Aqua Creek Products LLC 2003-2010
NEW CONSTRUCTION ANCHOR INSTALLATION
STEP 1:
Determine the best location for the lift. Be sure to mount the lift at a location that provides
at least 8” [122 cm] from deck level to the bottom of the pool. Make sure the location
includes enough clear deck space to easily transfer into the lift seat. Keep in mind this lift
will require assistance from another person to operate and you should locate it in an area
that can accommodate another person. The lift should also be located so as to provide at
least 6’ [1.8 m] of unobstructed deck to each side of the lift to accommodate easy
maneuvering of the lift over the water and back.
STEP 2:
Locate the concrete anchor socket that came with your
lift. Be careful to not lose the protective cap on the
anchor. This will be used to keep dirt and debris out of
the socket when the lift is not installed in the anchor.
STEP 3:
The setback to the center of the anchor must be no
more than 20” [51 cm] from the pool wall and at least 6”
[15 cm] from any control joint or edge of concrete slab. Measure the location out using
your tape measure. (Reference the drawing on the previous page for details).
STEP 4:
Ground the anchor according to your local requirements.
STEP 5:
Place the anchor in the proper location using the string level and string line to make sure
the top of the anchor will be flush with the finished surface of the new deck. Place a small
amount of concrete at the location of the anchor to hold it in place.
STEP 6:
Verify all your measurements for accuracy and pour the deck as you normally would,
making sure not to get any concrete inside the anchor system. Allow the concrete to cure
before installing and using the lift.
REQUIRE TOOLS
Tape Measure Small Carpenters Level
String Level String Line
CONCRETE ANCHOR
SOCKET
NOTE:
The concrete deck around the anchor system should be a minimum of 8”
thick and should be reinforced with # reinforcing bars spaced on 10” centers in
each direction. The total concrete pad area should be at least 60” wide
(measured away from the pool edge) and 60” long (parallel with the pool edge).

EZINST-11/22/10 Page 7 of 12
© Aqua Creek Products LLC 2003-2010
INTERNAL SLING
SUPPORT BAR
ASSEMBLY INSTRUCTIONS – EZ POOL LIFT™
The EZ Pool Lift™ arrives with the boom arm attached to the mast. To complete the
assembly, layout all parts needed on a large
clean area.
STEP 1:
Locate the Hydraulic ram and attach the upper
end of the hydraulic ram to the boom with one
(1) 3/8” x 1-3/ ” hex head bolt, two (2) 3/8" flat
washers, and one (1) 3/8” nylock nut.
STEP 2:
Connect the lower end of the hydraulic ram to
the mast with one (1) 3/8” x 1-1/2” hex head bolt,
two (2) 3/8" flat washers, and one (1) 3/8" nylock
nut.
STEP 3:
Install lift into previously installed anchor socket in the pool deck. Make sure that the mast
is seated at the bottom of the anchor. Check to ensure easy rotation of the lift in nylon-
lined anchor sleeve.
STEP 4:
Locate the four ( ) internal sling support bars
and insert them into the sewn pockets in the
mesh sling.
REQUIRE TOOLS
9/16” Wrench 3/ ” Wrench
!WARNING!
MAKE SURE THAT THE 3/8” ROD END IS ALWAYS
FULLY SEATED WITH THE MAXIMUM ALLOWABLE
THREAD BEING USED.
STEP 4

EZINST-11/22/10 Page 8 of 12
© Aqua Creek Products LLC 2003-2010
C
A
B
STEP 5:
Locate the chain assembly and insert each “S”
hook into the holes in the sling support bars (A).
Attach the hanger to the boom eye on the lift (B).
Attach the chain links to the hanger (C) so that
the sling is at the appropriate height to allow the
user easy access and so that the sling will clear
your pool wall (if applicable).
Assembly is complete. Prior to lifting any
persons in the lift, it is highly recommended that
the lift is operated at least once without a load to
check for proper functioning and that the
instructions for operating the lift be read and incorporated into a training program for the
persons who will be operating the lift.

EZINST-11/22/10 Page 9 of 12
© Aqua Creek Products LLC 2003-2010
OPERATING INSTRUCTIONS –EZ POOL LIFT™
The EZ Pool Lift™ was not designed to be a self-operable unit and as such requires the
use of an operator to assist the lift user with the transfer into and out of the pool.
There are two methods of loading the lift user into the harness. The method of loading will
depend on the physical ability of the lift user. If the user has very limited use of his upper
body, it will be necessary to follow the procedure as outlined below. If the user is
physically able, he can simply place himself into the harness without need for assistance.
However, once in the harness, it will still be necessary for an operator to assist with the
transfer into or out of the pool.
• With the lift in the up position and the boom arm located over the deck, roll the user
under the lift and engage the brakes on the wheelchair.
• With the user facing the assistant, place the mesh seat sling under the seated user
while still in the wheelchair.
• Attach the chain to the mesh sling and the overhead hanger bar. There should not
be any slack in the chain at this time.
• Make sure all chain connections are secure and the mesh seat sling is level on
each side.
• Raise the user by pumping the hydraulic ram handle until the desired height is
achieved. The user should just clear the wheelchair. Move the wheelchair out of
the way if needed.
• Rotate the lift so that the user is above the pool, keeping one hand on the boom and
one hand on the user to stabilize them.
• Lower the user into the water by pressing the handle towards the ram until it
depresses the release pin. The hydraulic ram automatically controls the rate of
descent for safety and control.
• This procedure is repeated to remove a user from the water.
• When the lift is not in use, remove the sling, hanger bar and mast from the anchor
socket and replace the protective anchor cap.
NOTE:
• FOR SAFETY, CHECK FOR WORN PARTS AN LOOSE BOLT CONNECTIONS PRIOR
TO EACH USE.
• ALL OPERATORS SHOUL BE FAMILIAR WITH ALL LIFT COMPONENTS AN THEIR
INTEN E USES.
• OPERATORS SHOUL ALSO BE COMFORTABLE WITH ALL LIFTING PROCE URES
BEFORE ATTAMPTING TO LIFT A PERSON WITH THE LIFT.

EZINST-11/22/10 Page 10 of 12
© Aqua Creek Products LLC 2003-2010
SAFETY AN MAINTENANCE INSTRUCTIONS
CARE OF YOUR LIFT
Routine cleaning is an absolute necessity to ensure the integrity of the lift. Note that the Aqua Creek Pool Lift should
not be stored in a pump room or in a storage room where pool chemicals are kept. Storing the lift near pool chemicals
may cause rusting and other damage to occur. our Aqua Creek stainless steel lift is powder coated to protect the
stainless steel from rusting. Most rusting will occur at weld points, crevices, under gaskets, rivets or bolt heads.
The choice of a proper cleaning product is up to the consumer and there are many to choose from. Depending on the
type of cleaning and the degree of contamination (rusting), some products are better than others. For routine cleaning
the products most recommended are gentle soaps or detergents or dilute mixtures of ammonia. For stubborn spots and
stains try using soft scrub with some brisk rubbing.
DO NOT USE POOL WATER TO CLEAN USE ONLY FRESH WATER
If the lift is used DAILY make sure to wash the lift at the end of the day. Wash the lift off using a mild soap and a soft
cloth. Make sure to pay special attention to weld points and crevices. Do not use a bristled brush or steel wool to clean
the lift. Check that the lift is working properly and then place the battery on the charger. It is recommended that the
battery be charged after every day of use.
If the lift is used WEEKLY follow the same steps as above. Also be sure to check all of the contact points (terminals)
for damage or corrosion. If you notice corrosion gently clean the terminals. To clean corrosion from the terminals use a
q-tip and some rubbing alcohol. If the corrosion is particularly stubborn try using a 3M scotch brite pad, but be careful
not to damage the terminals. Apply dielectric grease to the terminals after cleaning them. This will help to prevent
further corrosion. Do not leave the battery on the lift. Always store the battery on the charger whenever the lift is not
being used.
If the lift is used MONTHLY follow the same steps as above. Also check the nuts and bolts to make sure they are
securely fastened (this is always a good idea, no matter how often or infrequently the lift is used). Also make sure to
store the battery on the charger and not on the lift. Leaving the battery on the lift for extended periods will significantly
shorten the battery’s lifespan.
If the lift is being STORED for an extended period of time follow all of the steps above. Check for rusting at all
crevice and weld points. If you notice rusting spray some WD-40 on the affected area and take a 3M scotch brite pad
and rub briskly. Afterwards be sure to wash and rinse the lift again with soap and water. When storing the lift make
sure it is in a dry area and covered. DO NOT STORE in or around pool chemicals.
●Do not play on or around this lift
●Check the EZ Pool LIFT™ before each use to assure there are no worn parts and that all hardware is
properly tightened. If there are any worn parts, replace them BEFORE using the EZ Pool Lift™. You
can call our customer service at 1-888-687-3552 to order any parts.
●Aqua Creek Products, LLC lifts shall be grounded per local codes.
●At least ONCE A WEEK, the EZ Pool Lift™ must be cleaned with fresh water.
●Wipe all surfaces clean with a damp, non-abrasive cloth. When cleaning the EZ Pool Lift™, use non-
abrasive soap and water. Avoid harsh chemicals and disinfectants.
●Always read the label instructions on any cleaner carefully before applying it to a surface.
●The WARNING & INTENDED USE labels on the EZ Pool Lift™ need to be maintained in readable
fashion. If they become unreadable or faded, please replace the label immediately. Replacement labels
are available from AQUA CREEK PRODUCTS LLC. 1-888-687-3552.

EZINST-11/22/10 Page 11 of 12
© Aqua Creek Products LLC 2003-2010
ITEM # QTY PART NUMBER ESCRIPTION
1 1 SA-080 EZMA EZ MAST ASSEMBLY
2 1 SA-080 EZBA EZ BOOM ASSEMBLY
3 1 F-038EZHB EZ POOL LIFT HANGER
1 F-03 EZS EZ POOL LIFT SLING, MESH
5 1 F-03EZCH EZ POOL LIFT CHAIN SET
6 1 F-033EZA EZ POOL LIFT ANCHOR
7 1 SA-080 HR HYDRAULIC RAM
8 1 BOLT3/8X11/2SSHEX 3/8"-16 X 1-1/2" HEX BOLT, S.S.
9 1 BOLT3/8X13/ SSHEX 3/8"-16 X 1-3/ " HEX BOLT, S.S.
10 5 FLATWASHER3/8SS 3/8" FLAT WASHER, S.S.
11 3 NYLOCK3/816SS 3/8"-16 NYLOCK NUT, S.S.
12 1 BOLT1/2X21/ SSSH 1/2" X 2-1/ " SHOULDER BOLT, S.S.
13 2 CAP1.9X1 5RDUHMW 1.9" X .1 5" WALL CAP, UHMW
1 1 P-0808EZMTB EZ TURN BAR, STAINLESS STEEL
EZ LIFT – PARTS LIST

EZINST-11/22/10 Page 12 of 12
© Aqua Creek Products LLC 2003-2010
Aqua Creek Produc s, LLC Limi ed Warran y:
EZ POOL LIFT
TM
Aqua Creek Products lifts have a Limi ed Life ime Warran y on the frames, not including the powder coat finish.
Aqua Creek Products, LLC (a.k.a. Aqua Creek) also warrants to the original end user that all non-frame components
manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and
properly used and maintained, shall be free from defects in material and workmanship for a period of five (5) years from the
date of original purchase. This is provided that Aqua Creek receives prompt notice in writing of any defect or failure and
satisfactory proof thereof, with the following exceptions:
Excep ion 1:
The hydraulic ram, and mesh sling shall have a warranty period of one (1) year from the date of the original purchase
This warranty specifically excludes reimbursement for labor to remove, repair, or install the product and any return freight
charges. These warranties do not cover any damages due to accident, misuse, abuse, negligence or failure to properly
maintain any products, or normal wear and tear from day to day operations. In the event that any products are altered,
repaired, or improperly installed or improperly used by anyone without the prior written approval by Aqua Creek, all
warranties are void. IMPORTANT: AMOUNT OF WEIGHT PLACED ON LIFT SHALL NOT EXCEED THE RATED
LIFTING CAPACIT OF 400 POUNDS [181 kg] FOR THE EZ POOL LIFT.
To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full
description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. Within
thirty (30) days after receipt of a written warranty claim by Aqua Creek, and barring any unforeseen delays, the place of
purchase will be notified of Aqua Creek’s decision regarding the claim.
If requested by Aqua Creek, any defective product must be returned, freight prepaid, to Aqua Creek’s designated factory
location or duly appointed distributor for inspection and/or repair. Aqua Creek will, at its option, repair or replace the failed
or defective item, and deliver the repaired product or replacement to the buyer of the product, freight prepaid to the
destination provided for in the original order. Products returned to Aqua Creek for which Aqua Creek provides replacement
under this limited warranty shall become the property of Aqua Creek.
A new warranty period shall NOT be established for the repaired or replaced products. Such products shall remain under
warranty only for the remainder of the original warranty period on the original products purchased.
This written limited warranty constitutes the final, complete and exclusive statement of warranty terms. No person or
organization is authorized to make any other specific or implied warranties or representations on behalf of Aqua Creek.
THE WARRANTIES SET FORTH HEREIN ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, WHICH ARE HEREB DISCLAIMED AND EXCLUDED, INCLUDING WITHOUT LIMITATION AN
WARRANT OF MERCHANTABILIT OR FITNESS FOR A PARTICULAR PURPOSE OR USE.
THE SOLE AND EXCLUSIVE REMEDIES FOR BREACH OF AN AND ALL WARRANTIES WITH RESPECT TO
THE PRODUCTS SHALL BE LIMITED TO REPAIR OR REPLACEMENT AT AQUA CREEK’S DESIGNATED
FACTOR LOCATION, OR DUL APPOINTED DISTRIBUTOR, OR IN PLACE AT AQUA CREEK’S OPTION. IN
NO EVENT SHALL AQUA CREEK’S LIABILIT EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK B
THE ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT.
IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR AN INCIDENTAL, CONSEQUENTIAL,
SPECIAL, INDIRECT, PUNITIVE OR EXEMPLAR DAMAGES OR LOST PROFITS FROM AN BREACH OF THIS
LIMITED WARRANT OR OTHERWISE.
Aqua Creek Products
9889 Garrymore Lane
Missoula, MT 59808
