Arbor Technology FPC-7600 Series User manual

1
FPC-7600 Series
Robust Box PC with 3rd Generation Intel®
Core™ i5/i3 or Celeron®Processor Platform
User’s Manual
Version 1.2
2017.01P/N: 4012760000120P

- 2 -
This page is intentionally left blank.

- i -
Revision History
Version Release Time Description
1.0 2015 August Initial release
1.1 2015 October Add FPC-7600 model
1.2 2017 January Add "Windows 10" to OS support & driver path

- ii -
Contents
Revision History ............................................................................. i
Contents......................................................................................... ii
Preface............................................................................................ v
Copyright Notice.................................................................................. v
Declaration of Conformity.................................................................... v
CE ............................................................................................... v
FCC Class A................................................................................ v
RoHS...........................................................................................vi
SVHC / REACH...........................................................................vi
Important Safety Instructions .............................................................vii
Warning.............................................................................................viii
Replacing Lithium Battery .................................................................viii
Technical Support..............................................................................viii
Warranty..............................................................................................ix
Chapter 1 - Introduction................................................................ 1
1.1. The Computer .............................................................................. 2
1.2. About this Manual......................................................................... 2
1.3. Specications............................................................................... 3
1.4. Inside the Package....................................................................... 4
1.5. Ordering Information .................................................................... 5
1.5.1. Optional Accessories......................................................... 5
1.5.2. Congure-to-Order Service............................................... 6
Chapter 2 - System Overview....................................................... 7
2.1. Dimensions .................................................................................. 8
2.1.1. FPC-7600.......................................................................... 8
2.1.2. FPC-7601/7602/7603........................................................ 9
2.1.3. FPC-7604........................................................................ 10
2.2. Take A Tour................................................................................. 11
2.2.1. Front Views ..................................................................... 11
2.2.2. Rear Views...................................................................... 14
2.3. Driver Installation Notes............................................................. 16
Chapter 3 - System Conguration ............................................. 19
3.1. Board Layout.............................................................................. 20
3.2. Jumpers and Connectors........................................................... 22
3.2.1. Jumpers .......................................................................... 22
3.2.2. Connectors...................................................................... 26
Chapter 4 - Installation and Maintenance.................................. 39
4.1. Install Hardware ......................................................................... 40
4.1.1. Open the Computer......................................................... 40
4.1.2. Install/uninstall Memory Modules.................................... 44
Contents

- iii -
Contents
4.1.3. Install CPU ...................................................................... 52
4.1.4. Install SATA Storage Devices.......................................... 53
4.1.5. Install PCI and PCI Express Cards ................................. 56
4.1.6. Install Wireless Modules ................................................. 58
4.2. Mount the Computer .................................................................. 59
4.3. Ground the Computer ................................................................ 60
4.4. Wire DC-in Power Source.......................................................... 61
Chapter 5 - BIOS.......................................................................... 63
5.1. Main ........................................................................................... 66
5.2. Advanced ................................................................................... 67
5.2.1. ACPI Settings.................................................................. 68
5.2.2. S5RTC Wake Settings ................................................... 69
5.2.3. CPU Conguration .......................................................... 70
5.2.4. SATA Conguration ......................................................... 71
5.2.5. Intel(R) Anti-Theft Technology Conguration .................. 72
5.2.6. USB Conguration .......................................................... 73
5.2.7. F81866 Super IO Conguration ...................................... 74
5.2.8. F81866 H/W Monitor....................................................... 76
5.2.9. Intel ICC .......................................................................... 77
5.2.10. CPU PPM Conguration ............................................... 78
5.3. Chipset....................................................................................... 79
5.3.1. PCH-IO Conguration ..................................................... 80
5.3.2. System Agent (SA) Conguration ................................... 82
5.4. Boot............................................................................................ 85
5.4.1. CSM Paramenters........................................................... 86
5.5. Security ...................................................................................... 88
5.6. Save & Exit................................................................................. 89
Appendices .................................................................................. 91
A: Digital I/O Setting.......................................................................... 92
B: Watchdog Timer (WDT) Setting.................................................... 95
C: Wi-Fi Module WIFI-AT2300 Hardware Installation ....................... 96
C.1. Install WIFI-AT2300 ........................................................... 96
D: Install Internal USB Drives.......................................................... 103

- iv -
This page is intentionally left blank.

- v -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this document may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Declaration of Conformity
CE
The CE symbol on the computer indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Preface

- vi -
Preface
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products
are in compliance and conform to the European Union’s Restriction of Use
of Hazardous Substances in Electrical and Electronic Equipment (RoHS)
Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed
a maximum concentration value of 0.1% by weight or for cadmium exceed
0.01% by weight, per homogenous material. Homogenous material is dened
as a substance or mixture of substances with uniform composition (such as
solders, resins, plating, etc.). Lead-free solder is used for all terminations
(Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth
we live, Arbor hereby conrms all products comply with the restriction of SVHC
(Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration,
Evaluation, Authorization, and Restriction of Chemicals) regulated by the
European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- vii -
Preface
Important Safety Instructions
Read these safety instructions carefully
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment
and should be easily accessible.
5. Keep this equipment away from humidity.
6. The openings on the enclosure are for air convection and protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
7. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
8. Never pour any liquid into opening. This may cause re or electrical shock.
9. Never open the equipment. For safety reasons, the equipment should be
opened only by qualied service personnel.
10. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
11. Keep this User’s Manual for later reference.

- viii -
Preface
Warning
The Box PC and its components contain very delicately Integrated Circuits (IC).
To protect the Box PC and its components against damage caused by static
electricity, you should always follow the precautions below when handling it:
1. Disconnect your Box PC from the power source when you want to work
on the inside.
2. Use a grounded wrist strap when handling computer components.
3. Place components on a grounded antistatic pad or on the bag that came
with the Box PC, whenever components are separated from the system.
Replacing Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
http://www.arbor.com.tw
Please do not hesitate to call or e-mail our customer service when you still
cannot nd out the answer.
http://www.arbor-technology.com
E-mail:[e-mail]

- ix -
Preface
Warranty
This product is warranted to be in good working order for a period of one year
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of, or
inability to use this product. Vendor will not be liable for any claim made by any
other related party.
Vendors disclaim all other warranties, either expressed or implied, including but
not limited to implied warranties of merchantability and tness for a particular
purpose, with respect to the hardware, the accompanying product’s manual(s)
and written materials, and any accompanying hardware. This limited warranty
gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.

- x -
This page is intentionally left blank.

- 1 -
1Chapter 1
Introduction
Chapter 1 - Introduction

- 2 -
Introduction
1.1. The Computer
• Fanless Design
• Wide Range DC Power Input
(9~36V)
• Triple Independent display
(DisplayPort x2 + VGA x 1) supported
• Two-mPCIe for Optional WiFi, GPS
or I/O Expansion supported
• Optional WiFi or HSUPA Wireless
Connectivity supported
• Rugged Design for Shock / Vibration Protection
• Memory Support up to 16GB (DDR3)
1.2. About this Manual
This manual is meant for the experienced users and integrators with hardware
knowledge of personal computers. If you are not sure about the description
herein, consult your vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- 3 -
Introduction
1.3. Specications
System Kernel
Processor 3rd Generation Intel®Core™ i5/i3 or Celeron® Processors in
rPGA988 socket, TDP under 35W
BIOS AMI UEFI BIOS
Chipset Intel®HM76
Graphics Integrated Intel®HD 4000
System Memory 2 x 204-pin DDR3 SO-DIMM sockets, supporting
1333/1600MHz SDRAM up to 16GB
Serial ATA 2 x Serial ATA ports with 600MB/s HDD transfer rate
Ethernet Controller 2 x Intel®WGI210AT GbE controllers
Watchdog Timer 1 ~ 255 levels reset
I/O Ports
Serial Port COM1/ COM2 RS-232
COM3/COM4 RS-232/422/485 Selectable
*Selectable Port 1 x DB25 connector for 1 x digital I/O, 8-in/8-out or I/O
Expansion (either one)
USB Port 2 x USB 2.0 ports, 4 x USB 3.0/ 2.0 ports
Internal USB dongle (Optional)
LAN Port 2 x RJ-45 ports for GbE
Video Port 2 x Display ports
1 x DB-15 Female connector for Analog RGB
Audio Mic-in/Line-out
Expansion Bus 2 x Mini-card for optional WiFI, GPS or I/O Expansion
Storage
Type 2 x 2.5” drive bays
Qualification
Certication CE, FCC Class A
Environment
Operating Temp. -20 ~ 55°C (-4 ~ 131°F), ambience w/ air ow
Storage Temp. -40 ~ 85°C (-40 ~ 185°F)
Operating Humidity 10 ~ 95% @ 55°C (non-condensing)

- 4 -
Introduction
Vibration 3 Grms/5 ~ 500Hz/random operation w/ SSD
Shock Operating 40G (11ms); Non-operating 60G w/ SSD
Mechanical
Construction Aluminum alloy
Mounting Wall mounting
Weight
4.0 kg (8.81 lb) for FPC-7600
4.9 kg (10.80 lb) for FPC-7601/7602/7603
4.5 kg (9.92 lb) for FPC-7604
Dimensions
(W x D x H)
195 x 268 x 75 mm for FPC-7600
195 x 268 x 110 mm for FPC-7601/7602/7603
195 x 268 x 90 mm for FPC-7604
OS Support
W7 Pro / WS7E /WE8 STD /Windows 10
Power Requirement
Power Input DC 9~36V input w/ 4-pin terminal block
Power
Consumption Max.65W( w/o I/O Card)
1.4. Inside the Package
Upon opening the package, carefully inspect the contents. If any of the items
is missing or appears damaged, contact your local dealer or distributor. The
package should contain the following items:
FPC-7600
FPC-7601/7602/7603 or FPC-7604
1 x FPC-7600 Series
Robust System
1 x Driver CD
1 x User’s Manual

- 5 -
Introduction
1.5. Ordering Information
FPC-7600 Fanless system w/o expansion
FPC-7601 Fanless system w/ 1 x PCI and 1 x PCIe x16
FPC-7602 Fanless system w/ 1 x PCIe x8 and 1 x PCIe x16
FPC-7603 Fanless system w/ 2 x PCI
FPC-7604 Fanless system w/ 1 x PCIe x16
1.5.1. Optional Accessories
The following items are normally optional, but some vendors may include them
as a standard package, or some vendors may not carry all the items.
PAC-B120W6B-FSP 19V/6.32A 120W AC/DC adapter kit
wit 2 pin/ 3 pin/ 4pin Block
WMK-7000 Wall-mount kit for FPC-7XXX Series

- 6 -
Introduction
1.5.2. Congure-to-Order Service
Make the computer more tailored to your needs by selecting one or more
components from the list below to be fabricated to the computer.
80GB SSD
Intel®2.5” 80GB SATAIII SSD kit
WIFI-AT2300
Atheros AR9462 Wi-Fi module w/ 20cm internal wiring
ANT-D11
1 x Wi-Fi Dual-band 2.4G/5G antenna
3rd Generation Intel®Core™ i3-3120ME, L2/3M, 2.4G
3rd Generation Intel®Core™ i5-3610ME, L2/3M, 2.4G
MK-3C-4G-1
DDR3-1600 4GB SDRAM DIMM1 kit
MK-3C-4G-2
DDR3-1600 4GB SDRAM DIMM2 kit
MK-3C-8G-1
DDR3-1600 8GB SDRAM DIMM1 kit
MK-3C-8G-2
DDR3-1600 8GB SDRAM DIMM2 kit
UDK-7702
Internal USB dongle kit for FPC-7601/7602/7603

- 7 -
2Chapter 2
System Overview
Chapter 2 - System Overview

- 8 -
System Overview
2.1. Dimensions
The following illustration shows the dimensions of each FPC-7601/7602/7603
and FPC-7604, with the measurements in width, depth, and height called out.
2.1.1. FPC-7600
75.5
81.5
194.4
219
207
2
12-R2
20
Unit:mm
112112
40184
205
4-UNC#6-32 NUT
Optional Port Optional Port
ANT. 1 ANT. 2
PWR
RST
Optional
VGA
DISPLAYPORT
DISPLAYPORT COM 1
COM 2
COM 3
COM 4
SW
9-36V
+
DC IN
-
