ARCBRO Spark Series User manual

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
1
Spark SERIES
CNC Plate Cutting Machine install Manual
Operator Manual
ARCBRO| Revision 2 | English
Date of issue: January, 2023

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
2
Technical Support
Thank you very much to choose ARCBRO product, our whole engineer department work for you
since the day you receive machine. When you have any questions during assembling or operating, it
is free to contact us by Call, Email, Online help 7x24 hours.
Wish you enjoy a wonderful CNC cutting travel.
ARCBRO CNC Technical Support & Solutions
7x24 Hours
[phone]
[email protected]
www.arcbro.com/about-arcbro-cnc-cutting-solutions/

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
3
v Changes may be made periodically to the information in this manual without
obligation to notify any person of such revisions or changes. Such changes will be
incorporated in new editions of this manual or supplementary documents and
publications. This company makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically disclaims
the implied warranties of merchantability or fitness for a particular purpose.
v No parts of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronically, mechanically, by
photocopy, recording or otherwise, without the prior written permission of
ARCBRO Company.
v This User’s Manual is only available for Spark CNC Plate Cutting Machine.
v Ensure that the operator has read and understood this User’s Manual before any
operation on Spark CNC Plate Cutting Machine.
v There may be few differences between the pictures in this User’s Manual and the
machine you received.
v Never hesitate to contact us for on-line technical service when you have any
questions or you need help, and it's our pleasure to be there for help.
Contents
Technical Support ................................................................................................................................. 2
Technical Parameters ............................................................................................................................ 4

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
4
Notes .................................................................................................................................................... 5
Safety .................................................................................................................................................... 6
1.Information for your safety ....................................................................................................... 6
1. Stinger Description ........................................................................................................................ 8
1.1. What is Stinger? ..................................................................................................................... 8
1.2. Application ............................................................................................................................. 9
1.3. Programming and Nesting ..................................................................................................... 9
2. Packing List ....................................................................................................................................... 9
2.1. Introduction ........................................................................................................................... 9
2.2. Packing List ............................................................................................................................ 9
3. Installation ...................................................................................................................................... 11
3.1 Mechanical Assemble Steps ................................................................................................. 11
3.2 Basic assemble steps: ........................................................................................................... 12
Step: Unpack the equipment box and remove all items ............................................................. 12
Step 1: Assemble the legs of the Equipment steel frame. .......................................................... 13
Step 2: Assemble the Water Table and fixture. .......................................................................... 16
Step 3: Assemble Y axis Frames and tracks to the Equipment steel frame. ................................ 18
Step 4: Install X axis Frames and tracks to Y axis Frames. ........................................................... 20
Step 5: Install drag chain Brackets and drag chain. ..................................................................... 22
Step 6: Install DIV Box to the Equipment steel frame. ................................................................ 24
Step 7: Connect CNC controller box ........................................................................................... 25
Step 8: Adjust the diagonal of the Spark. ................................................................................... 26
Step 9: Spark is wired with plasma. ............................................................................................ 27
Technical Parameters
Type
Spark

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
5
Effective cutting range
X-Aixs:1200mm, Y-Axis1200mm, Z-Axis: Auto sensing
Input power supply
1 phase, 110V, 220V, 50Hz/60Hz
Input capacity
480W
Cutting model
Plasma cutting
Max travel speed
12000mm/min
Drive motor
Smart servo motor
CNC SYSTEM
Display
7’’ color LCD screen
CPU
Industrial ARM9 chip
Internal library
24 kinds of shapes
External format
TXT or NC format
Language
English, Spanish, Russian, French, Japanese, Czech, Slovenia
PLASMA CUTTING MODE
Max cutting speed
12000mm/min
Max cutting thickness
Depends on plasma power source
THC
Arc voltage Auto Torch Height Controller
Accuracy
Cutting tolerance smaller than ±0.3mm
Notes
Note 1: Nesting software standard Wizard is included in standard package.
Note 2: The machine must be grounded reliably when it is working. (Connect the plate and the earth)

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
6
Note 3: Clean dust regularly to keep the rail and rack clean for smooth movement.
Note 4: Avoid damage for the LED display screen of CNC system.
Note 5: Equipment use environment:
Ambient temperature: -10℃—+50℃
Environment humidity: 90﹪RH below
Storage temperature: -20℃—+65℃
Sea level elevation: An altitude of 1000 m below
Safety
1.Information for your safety
The operator must read and understood the contents of this user’s manual before any operation
on Spark
Never hesitate to contact us for assistance when you have any questions or you need help, and you
can reduce the account of time your troubles takes and solve your problem efficiently.
Note: Each of the following description must be verified before any operation on Stinger.

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
7
- 1. The operator should wear face shield, welding gloves, caps, membrane filter dust mask and sound
insulation earmuff. It is strictly forbidden to observe directly or approach to the plasma arc with
exposed skin.
-2. The operator can’t load external program in internal storage of
the machine in case of the virus. Only the special software
recognized by ARCBRO can be applied.
-3. During cutting period, when the floating voltage is too high, the
operator should check the ground connection, neutral connection
and insulation of the torch handle. Then isolate the workbench
from the ground, Or install no-load open-circuit relay in the
electrical control system.
-4. The cutting operator and assistant must wear labor protection articles by regulation and take
safety measures to prevent electric shock, high-altitude falling, gas poisoning, fire or any other
accidents.
-5. The site should build rain-proof, damp-proof and sun-proof machine shed, and install
corresponding fire equipment. The machine should keep away from flammable and combustible
materials.
-6. As the operation and maintenance has potential dangerous, operator should be careful in case
getting injured. It’s forbidden to wear loosen cloths or cotton ropes in case being entangled by the
machine.
-7. The high voltage of plasma CNC cutter is fatal, so operator should install the machine step by step
as the manufacturer stipulate.

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
8
-8. Only trained personnel can be allowed to operate the equipment. Any maintenance should obey
the user’s manual and before that the power should be cut off. Only experience technicist is allowed
to change assemblies.
1. Stinger Description
1.1. What is Stinger?
The CNC plasma cutting machine, Spark Pro, has a very lightweight structure. The total weight is
just 200kg, but it is in a higher working size. And it is also higher configured with THC for plasma
cutting. It is a very good choice for the studio and for the university and for smaller workshops.
If you have such a working scene, for small parts production, furniture decoration, or any other
metal works, stop outsourcing your cutting needs and put a production-capable machine in your shop
at a fraction of the price. COMPACT, SMART, AND AFFORDABLE. Spark Pro takes its advantages to the
limit.

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
9
1.2. Application
Spark is an ideal CNC Plate Cutting Machine widely used in industry field, such as shipbuilding
industry, metallurgic industry, petrochemical industry and water resources & electric power. It can cut
various metal plates in seconds, for instance: copper and aluminum (plasma cutting).
1.3. Programming and Nesting
Using ARCBRO plate nesting software, you can edit and do the nesting process for your pattern
designed by CAD, then generate a G-code cutting file in txt format. This txt cutting file can be
recognized and carried out by our CNC system when you import it by a USB drive. Now, running Spark ,
you can achieve accurate profiling of this pattern automatically.
2. Packing List
2.1. Introduction
Spark is packed carefully in one wooden boxes. All equipment in the boxes are protected fully to
avoid any damages during transportation.
The boxes have to be carried with care always and with the top cover up during handling and
transportation.
2.2. Packing List
Open the top cover of the boxes. And remove all the screws fixing the cover to the box body.
The Stinger transportation boxes contain:
X This accessory is standard configuration, if your machine is customized, the accessories are
according to the order requirements.

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
10
X The bolts of the machine are fixed to the machine.
X Packing List:
No.
Name
No.
Name
1
Equipment steel frame-1Pcs
2
Spark legs-4Pcs
3
Water table and fixture-1pcs
4
CNC controller box-1Set
5
Y axis Frames and tracks -1 Set
6
X axis Frames and tracks -1 Set
7
Drag chains Brackets -1 Set
8
Plasma hold -1Set
9
DIV box-1pcs
10
Line Protective case-1Set
11
ARC start line -1se
12
Feedback line -1set

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
11
3. Installation
3.1 Mechanical Assemble Steps
This part describe how to install Spark portable CNC cutting machine step by step.
Please assemble according to below steps carefully. Any questions or help needed, please do not
hesitate to contact ARCBRO after sale service engineer, we will provide help as soon as possible.
X The installer needs to prepare: electric drill, spirit level, forklift. Two installation
mechanical engineers are needed for faster installation.
X In order to install the machine faster, please read the installation steps carefully
before installation, it will save installation time.
13
ARC+/- Line -1set
14
Spark power line-1se
15
USB disk and Nesting Software-1pcs
16
Manual-1Pcs

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
12
3.2 Basic assemble steps:
u Step 1: Assemble the legs of the Equipment steel frame.
u Step 2: Assemble the Water Table and fixture.
u Step 3: Assemble Y axis Frames and tracks to the Equipment steel frame.
u Step 4: Install X axis Frames and tracks to Y axis Frames.
u Step 5: Install drag chain Brackets and drag chain.
u Step 6: Install DIV Box to the Equipment steel frame.
u Step 7: Connect CNC controller box.
u Step 8: Adjust the diagonal of the Spark.
u Step 9: Spark is wired with plasma.
Step: Unpack the equipment box and remove all items
Remove all the screws which are fixed the box, check and confirm all the spare parts be inside
and well, and then move all the parts out safely.

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
13
Step 1: Assemble the legs of the Equipment steel frame.
Note: Install the machine carefully step by step as the following instructions:
The Equipment steel frame assembly:

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
14
The Equipment steel Frame assembled:
Assemble Step:
1. Lift the Equipment steel frame;
2. Put the steel legs bolted to the frame.
Each support leg is fixed by four bolts;
3. Install 4 support legs;
Note: The marks of the 4 support legs
correspond to the equipment stee frame
one by one;

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
15
Frame assembled

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
16
Step 2: Assemble the Water Table and fixture.
Assemble Step:
1. Lift the whole water table;
2. Insert the water table into the equipment stee frame.
The water table
The water table assembled

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
17
Assemble Step:
3. Put the fixture bolted to the equipment stee frame. Each fixture is fixed by four bolts;
Press the water table with the fixture;
Fixture

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
18
Step 3: Assemble Y axis Frames and tracks to the Equipment steel frame.
Fix each Side Board onto the frame leg by screws.
Assemble Step:
1. Lift the Y axis Frames and tracks;
2. Put the Y axis Frames and tracks bolted to the equipment stee frame. Each Connect the plate
is fixed by four bolts;
NOTE: When installing, the orientation of the Y axis Frames and tracks and the equipment steel
frame is consistent;
Y axis Frames and tracks
Front
Behind
Front
Behind

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
19
The Y axis Frames and tracks assembled:

Service Support Spirit
Unique Solution WWW.ARCBRO.COM
20
Step 4: Install X axis Frames and tracks to Y axis Frames.
Fix each drag chain trough onto the frame leg by screws;-- 3 support frames.
Assemble Step:
1. Remove the two limit stops-- At the back of X axis Frames and tracks.
2. Lift the X axis Frames and tracks;
3. Align the wheels of the X axis Frames and tracks and the guiding rail, Push the X axis Frames
and tracks to slide in along the Guide Rail.
4. Reinstall the two limit stops;
NOTE: Installation requires simultaneous access to the guiding rail
The limit
stops.
Guide Rail
