Argos 042 3048 Series User manual

Assembly Instructions -Please keep for future reference
Width - 74.0cm
1 Drawer Display Unit
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 35.8cm
Height - 161.7cm
Rev C - 22/04/2013
042 xx 3048
01709 534123

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furnture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Top (74x35.8cm)
8828 Bottom x5 (63.4x31cm)
8829
Left End Panel
(159.5x35.2cm)
8830
Plinth (63.4x76cm)
8553
Right End Panel
(159.5x35.2cm)
8831
Backpanel (152.1x64.4cm)
8832
Drawer Front
(63x15.7cm)
8581
Drawer Bottom
(61.2x29.8cm)
5671
Left drawer side (30x10cm)
Drawer back (60.1x10cm)
Right drawer side (30x10cm)
622xx7002
624xx7010
623xx7002
Trim x 2
684xx3048

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 0845 0613967 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 28
Code 760001103
Metal dowel x 30
Code 760003004
ABC
E
Drill
D
20mm bolt x 2
Code 700002006
F
H
GI
Handle x 1
Code 653003512
J
Small cam x 2
Code 760003005
9mm bolt x 2
Code 690001078
8mm screw x 4
Code 700003510
Cam cover sticker x 6
Code 682xx2011
K
Runner x 2
Code 760001040
Panel pin x 8
Code 760001012
Panel pin guide x 1
Code 684004501
Support Bracket x 1
Code 760001901
L
M
12mm screw x 2
Code 690001099
01709 534123

Please check you have all the fittings listed below
Exploded View
4
8581
5671
622xx7002
684xx3048
684xx3048
624xx7010
623xx7002
8830
8831
8828
8832
8553
8829

Step 1
Assembly Instructions
5
Fittings you will need for this step:
B
x4
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fittings you will need for this step:
A
x20
Fittings you will need for this step:
Fitting dowels to top
panel.
Fitting cams to the
bottom panels x5.
Step 2
Step 3
Fitting cams to the
plinth panel.
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
B
B
A
A
A
A
8828
8828
B
A
x4
B
REPEAT ON REMAINING BOTTOM PANELS
A
A
A
A
Note: Ensure cam
arrow points towards
the edge with hole.
A

Step 4
Assembly Instructions
6
Fitting cams & dowels
to the end panels.
Note: Ensure cam
arrow points towards
the edge with hole.
A
Step 5
Step a
Step b
K
K
J
J
Attaching runners to
end panels
Position the runner so
that the second hole
from the front of the
runner lines up with the
pre-drilled hole nearest
to the grooved edge of
the panel. Use screws
to secure the runner.
Slide the runner forward
revealing the back of the
runner. The second hole
to the back of the runner
should now line up with
the second pre-drilled
hole.
J
Front of runner
K
x2
J
x4
B
B
B
B
B
B
B
B
B
B
BB
A
A
B
B
B
B
B
B
B
B
B
B
B
B
B
x24
REPEAT ON
8830
8830
8831
8831
A
x4

Assembly Instructions
7
(x2)
(x2)
a: Insert dowels into
drawer front.
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
Drawer assembly
Step 6
c: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
b: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole. Left hand side
Right hand side
Left hand side
Right hand side
Drawer Back
Continued on next page.
622xx7002
624xx7010
623xx7002
622xx7002
623xx7002
622xx7002
623xx7002
623xx7002
624xx7010
622xx7002
A
B
C
8581
B
B
B
C
C
C

Assembly Instructions
8
e:Locate the metal
dowels (already inserted)
in the drawer front into the
small cams in the left and
right hand drawer sides.
Drawer assembly
Continued...
Step 6- Continued
d: Slide drawer bottom
into grooves in the left
and right drawer sides
and the drawer back.
Ensure foil on the
drawer bottom is facing
upwards.
Turn cam 180 degrees
to lock
f: Secure handles to the
drawer front.
SLIDE!
(x2) (x1)
7010
622xx7002
623xx7002
624xx7010
622xx7002
623xx7002
8581
8581
7010
D
E
F
DI
I
D
D
Plain chipboard surface
to underside.

Step 7
Assembly Instructions
9
Attach the top panel
to the right end
panel .
Note: You may need a
small screwdriver.
Connect right hand
and and top panel.
Step 8
Connect right hand
end with bottom
panels x5 and plinth.
Connect the right end
panel to the 5 x
bottom panels and the
plinth.
Note: You may need a
small screwdriver.
Ensure plinth sits
flush.
Ensure plinth is
not overhanging.
8831
8828
8830
8831
8830
8829
8829
8829
8829
8553
8828

Step 9
Assembly Instructions
10
Step 10
Connect the left hand
end panel.
Connect the dowels in
the left end panel
in order from the top
into the bottom panels
and finally the
plinth panel
Slide the back panel
into the grooves
in the left and right hand
ends.
To ensure that the back
panel sittings into the
groove in the top panel,
stand the unit on its
head.
CAUTION: Two people
required to lift the unit.
Slide in back panel
8830
8829
8553
8832
8829
8829
8829
8829
8553
8830
8832

Step 11
Assembly Instructions
11
Step 12
Insert back panel.
Secure the back
panel.
Ensure that the back
panel sits firmly inside all
of the grooves before
laying the unit back down
to secure the bottom
panel.
8832
G
x8
F
x1
8832
Slide the back panel into
the grooves.
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
G

Assembly Instructions
12
Step 13
Turn unit over to
attach the trims
Locate the notch on
the trim into the grooves
in the end panels.
To insert trims use a
hammer, place a
cardboard packing piece
between the hammer
and trims to protect the
trims.
Ensure that the trims
are inserted fully.
8830
8831

Assembly Instructions
13
Stand unit upright to
insert drawers.
Step 14
For this step we
recommend you follow
the helpful hints page.
(x2)
H
2nd HOLE
H

Assembly Instructions
14
Step 16
a: Pull sliding part of
drawer runners out
so they are fully
extended.
Locate drawers helpful
hints
I
K
b: Locate drawer onto
runners.
c: Locate screwdriver
into second threaded
hole in drawer runner .
K
d: Keeping screwdriver
in place push the drawer
closed.The screwdriver
will push against the end
panel and extend the
drawer runner .
K
e: Pull drawer out slowly
and line the hole in the
drawer side with the 2nd
threaded hole in the
runner . Now insert
bolts through the
drawer side and
into threaded hole in
runner .
K
K
f: Now insert bolts
through the drawer side
and into threaded hole in
runner .
K
l
K
K
K
K
2nd hole
2nd hole
H
H
H
D
EF
AB
C

Assembly Instructions
15
Step 16
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
Warning:
2 people to lift.
Lift with care.
With help move the
unit into position.
Warning:
E
x2
L
x1

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
0845 061 3967 8am - 4.30pm (Monday to Thursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[email protected]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
01709 534123

Notes

Notes

Notes
