Argos Malibu 282/2736 User manual

MADE IN
BRITAIN
Dimensions
Width - 75cm
Depth - 40cm
Height - 92.5cm
Malibu - 5 Drawer Wide Chest
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 14/05/14
Important - Please read these instructions fully before starting assembly
ALR3048
282/2736
279/9247
287/2188
274/7536
275/6572

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 31kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.

Components - Panels
Please check you have all the panels listed below
2
1
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
2
Left Side (D2775A)
(911 x 394mm)
Right Side (D2776A)
(911 x 394mm)
7
Left Drawer Side (W370-124LH)
(370 x 124mm) x 5
Right Drawer Side (W370-124RH)
(370 x 124mm) x 5
10
3
4
5
6
8 9
11
Top (D2774A)
(747 x 396mm)
Drawer Front (D2783A)
(710 x 156mm) x 5
Back Rail (D2779A)
(714 x 60mm) x 2
Plinth (D2778A)
(714 x 92mm)
Rail (D2780A)
(714 x 72mm)
Drawer Back (W682-124)
(682 x 124mm) x 5
Drawer Base (T693-367)
(693 x 367mm) x 5
12 Back (X829-738)
(829 x 738mm)

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 12
B
Metal dowel (F901) x 12
C
D
Large locking
nut (F900) x 2
E
Small locking
nut (F3) x 10
F
H I
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Nail (F51) x 22
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Electric drill
(only use when
drilling into walls)
25mm Screw (F50) x 10
K
Handle (F631) x 10
Bracket (F327) x 1
13mm Screw (F79) x 1
G
M
L
J
40mm Screw (F910) x 6
O
Plastic Nail (F91) x 4
P
9mm Screw (F73) x 20
Drawer runner (F1004) x 10
N
Wedgefix (F639) x 20
9mm Screw (F74) x 10
Knock-in Peg (F171GY) x 20

Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
x 5
x 5
x 5
x 5
B
B
F
Step 2
Prepare the 5 drawer
fronts
Screw 2 metal dowels
into each of the drawer
fronts .
Note: Tighten the metal
dowels up fully against
the panels.
B
Prepare the drawer
sides
Insert a small locking
nut into the hole
shown on the left drawer
side and the right
drawer side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
F
8
9
Attach the drawer
sides to the drawer
front
Push the left drawer sides
. and right drawer sides
. onto the back of the
drawer front .
Turn the small locking
nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
8
9
7
F
F
8
9
F
FF
89
9
7
8
B
B
7
7

Assembly Instructions
5
Step 4
7
L
L
Fit the drawer base
Slide the drawer base
down the grooves in the
drawer sides and
and down into the
groove in the drawer
front .
Step 5
Fit the drawer back
Fit the drawer back
between the drawer
sides and .
Make sure that the
drawer base fits into
the groove in the drawer
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
Step 6
8 9
7
11
10
8 9
11
10
10
L
Attach the handles
Attach 2 handles to
each of the drawer fronts
. using 2 screws .
I
H
7
x 5
x 5
x 5
x 5
L
L
9
8
11
11
9
8
10
I
H
I
H
7
N
Fit the wedgefixes
Turn the large drawer
assemblies over and
slide 4 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
N
N
NN
N
Step 7
8 9

Finished
front edge
Finished
front edge
A
Assembly Instructions
6
Step 8
Finished
front edge
P
K
Prepare the left side
a: Place 5 runners on
the left side as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left side .
Insert a large locking
nut into the left side
. .
Note: The arrow on the
locking nuts must point
towards the hole in the
edge of the panel.
Tap a wooden dowel
into the left side .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
1
P
P
1
K
K
E
a:
b:
10mm
A
E
1
A
1
P
K
E
P
K
P
K
P
K
P
K
P
P
P
P
P
1
1

A
Finished
front edge
Assembly Instructions
7
Step 9
Prepare the right side
a: Place runners on
the right side as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the right side .
Insert a large locking
nut into the right side
. .
Tap a wooden dowel
into the right side .
2
P
P
2
K
K
E
2
A
2
Finished
front edge
P
K
a:
Finished
front edge
b:
P
P
P
P
P
E
Step 10
2
2
P
K
P
K
P
K
P
K
P
K
A
A
A
A
A
Prepare the plinth, rail
and 2 back rails
Tap 2 wooden dowels
into the plinth .
Tap 4 wooden dowels
into the rail .
Tap 2 wooden dowels
into each of the 2 back
rails .
The plinth may
have a plain
chipboard surface.
A
A
Plain chipboard
surface
A
The colour of the back
rails may differ from the
main unit colour or may
be plain chipboard.
A
4
A
5
A
6
4
6
5
Finished
front edge
x 2

Assembly Instructions
8
Step 11
2
2
Step 12
Finished
front edge
Finished
front edge
Fit the rail to the right
side
Push the rail onto the
right side as shown .
plain chipboard surface
5
5
2
Fit the plinth and the
back rails
Push the plinth onto
the right side and
secure it with screw .
Push the 2 back rails
onto the right side
and secure them with
screws .
4
2
G
G
4
G
G
6
6
Note: Support the 2
back rails until the left
side has been fitted
in the next step.
6
2
G

Assembly Instructions
9
Step 13
Step 14
B
B
Finished
front edge
J
C
C
Prepare the top
Screw 2 metal dowels
into the top .
Fix a bracket in the
middle of the top and
flush to the back edge
using screw .
3
C
3
J
B
3
6
6
4
5
1
G
G
G
Fit the left side
Push the left side
onto the assembly and
secure it with screws .
1
G

Assembly Instructions
10
Step 15
Step 16
1
Fit the top
Push the top onto
the sides and .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the sides and .
E
3
1 2 3
2
1 2
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
y
y
x
x
12
D
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should be
spaced about 150mm
apart.
12
D
12

Assembly Instructions
11
Step 17
Step 18
Fit the 4 plastic nails
Tap 2 plastic nails
into the bottom edge of
each side and as
shown.
Stand the unit up for
the next step.
O
O
O
1 2
O
O
2
1
Warning: The
unit is heavy.
Lift with care.
Secure unit to a wall
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by use of the metal
bracket fitted to the
top .
Fixings are not supplied
as they will need to suit
the wall type, and the
length of screw will
depend on the distance
of the back of the unit to
the wall.
C
3
WALL
WALL
Top of unit
C
Warning: Take care when
drilling the wall that you do not
drill into any pipes, wires etc.
If in doubt, consult an expert.
3
C

Assembly Instructions
12
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 19
Fit the drawers
Starting with the bottom
drawer, slide both the
runners forward and
locate the drawer
sides and
between them, lining up
the holes in the drawer
wrap with the 2nd
'threaded' holes in the
runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws.
If they catch on the
runner you may need to
loosen them slightly.
Assembly is complete
M
K
K
2nd threaded
hole
K
M
8 9 M
M
8
9

ALR3048

MADE IN
BRITAIN
Dimensions
Width - 75cm
Depth - 40cm
Height - 92.5cm
Malibu - 5 Drawer Wide Chest
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 04/08/14
Important - Please read these instructions fully before starting assembly
ALR3048
282/2736
279/9247
287/2188
274/7536
275/6572
Issue 2 - 04/08/14 - The drillings in the Top panel for the Divider used on other units have been moved back by 3mm - the Top is now D2774B.

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 31kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.

Components - Panels
Please check you have all the panels listed below
2
1
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
2
Left Side (D2775A)
(911 x 394mm)
Right Side (D2776A)
(911 x 394mm)
7
Left Drawer Side (W370-124LH)
(370 x 124mm) x 5
Right Drawer Side (W370-124RH)
(370 x 124mm) x 5
10
3
4
5
6
8 9
11
Drawer Front (D2783A)
(710 x 156mm) x 5
Back Rail (D2779A)
(714 x 60mm) x 2
Plinth (D2778A)
(714 x 92mm)
Rail (D2780A)
(714 x 72mm)
Drawer Back (W682-124)
(682 x 124mm) x 5
Drawer Base (T693-367)
(693 x 367mm) x 5
12 Back (X829-738)
(829 x 738mm)
Top (D2774B)
(747 x 396mm)

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 12
B
Metal dowel (F901) x 12
C
D
Large locking
nut (F900) x 2
E
Small locking
nut (F3) x 10
F
H I
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Nail (F51) x 22
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Electric drill
(only use when
drilling into walls)
25mm Screw (F50) x 10
K
Handle (F631) x 10
Bracket (F327) x 1
13mm Screw (F79) x 1
G
M
L
J
40mm Screw (F910) x 6
O
Plastic Nail (F91) x 4
P
9mm Screw (F73) x 20
Drawer runner (F1004) x 10
N
Wedgefix (F639) x 20
9mm Screw (F74) x 10
Knock-in Peg (F171GY) x 20
