Argos Under Basin Unit 833/2763 User manual

Under Basin Unit
Dimensions
Width - 48cm
Depth - 30cm
Height - 60 cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Assembly Instructions- please keep for future reference
Issue 2 - 09/09/10
833/2763

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Care and maintenance
• Check you have all the
components and tools listed on
pages 1 and 2.
• Remove all ttings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its nal position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your oor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp
cloth and mild detergent, do
not use bleach or abrasive
cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.

Components - Panels
Please check you have all the panels listed below
1 Top x 1
(48(w)cm x 30(d)cm)
2 Left side x 1
(58.5(h)cm x 28.5(d)cm)
3 Right side x 1
(58.5(h)cm x 28.5(d)cm)
4 Base x 1
(40(w)cm x 28(d)cm)
5 Bottom rail x 1
(6.9(h)cm x 40(w)cm)
6 Left door x 1
(49.2(h)cm x 19.7(w)cm)
7 Right door x 1
(49.2(h)cm x 19.7(w)cm)
8 Back panel x 2
(52(h)cm x 10(w)cm)
9 Internal shelf x 1
(42(w)cm x 25.6(d)cm)
1

2
Components - Fittings If you have damaged or missing components,
call the Customer Helpline: 0845 640 0800
Please check you have all the ttings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
A B C D
35mm Male camlock x 8 Female camlock x 8 14mm Screw x 2 Magnetic catch x1
E F G H
Back panel screw x 10 Wooden dowel x 5 Hinge x 4 Knob x 2
I J K L
16mm Screw x 2 Catch plate x 2 10mm Screw x 2 Shelf bracket x 4
Tools required
Phillips screwdriver
(medium & large)
Ruler – Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Assembly Instructions
Step 1
Screw 4 x 35mm male
camlock A into the
underside of the top
panel 1 as shown.
Connect the magnetic
catch D using 2 x 14mm
screw C.
A
1
DC

Additional Components
Please check you have all the ttings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
M N O P
30mm Screw x 1 Rawl plug x 1 Safety strap x1 20mm Screw x 1
Tools required
Drill
(for wall drilling only)
Supplementary Assembly Instructions
O
P
M
N
833/2763 • 833/2811
Step 1
In order to prevent
accidental toppling it is
recommended to secure
the unit to a wall using
the supplied safety strap.
Connect safety strap
O to rear of the unit as
shown using 1 x 20mm
screw P (note: this
screw replaces the back
panel screw E detailed
in the main instructions).
Step 2
Secure safety strap to
wall using 30mm screw
M and rawl plug N as
shown.
Note: please refer to the
reverse of this instruction
sheet for additional wall
xing options.
Warning:
Before drilling,
check wall for
hidden pipes
and cables.

3
Assembly Instructions
Step 2
Insert 4 x female
camlock B into the
underside of base 4 as
shown.
Step 3
Screw 2 x 35mm male
camlock A into the
holes at the bottom of
the left side 2 and right
side 3 as shown.
Insert 2 x female
camlock B into the
holes at the top of the
left side 2 and right
side 3 as shown.
Step 4
Insert 5 x wooden dowel
F into the bottom rail 5
as shown.
B
4
A
B
3
A
B
2
F
5

4
Assembly Instructions
Step 5
Connect bottom rail 5
to underside of base 4
as shown.
Step 6
Connect assembly
completed in Step 5 to
left side 2 as shown.
Tighten female camlocks
in underside of base 2
with a screwdriver (a:).
Note: you should feel a
click when the camlocks
are secured.
Step 7
Connect right side 3 to
other end of assembly
completed in Step 5 as
shown.
Tighten female camlocks
in underside of base 2
with a screwdriver (see
Step 6 a:).
Note: you should feel a
click when the camlocks
are secured.
Note: it may be helpful
to have assistance from
another person with this
stage.
5
4
a:
2
3
2

5
Assembly Instructions
Step 8
Connect knobs H to
doors 6 and 7 using
16mm screws I as
shown.
Connect catch plates
J to doors 6 and 7
using 10mm screws K
as shown.
Insert a hinge G into the
top and bottom of doors
6 and 7 as shown.
Note: it may be helpful
to have assistance from
another person with the
next stage.
Locate door hinges in
place in base as shown,
then connect the top
panel 1 ensuring that
top hinges of doors
slot into place (b:), and
tighten female camlocks
on inside of left and right
side with a screwdriver
(see Step 6 a:).
Note: you should feel a
click when the camlocks
are secured.
b:
H
H
6
7
I
J
K
G
1

LP 255.96.799
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Assembly Instructions
Step 9
Connect back panels 8
using 10 x back panel
screw E as shown.
Step 10
Insert 4 x shelf bracket
L inside the unit at the
desired height as shown
and set internal shelf 9
in place.
Assembly complete.
8
8
E
L
9

A Guide to Wall Mounting & Fixings
Important note:
If plastic wall plugs (rawl plugs)
are supplied with your product,
e.g.:
- these are only suitable for use in
masonry walls.
If you are in any doubt about the
correct wall plugs for your wall,
seek professional advice.
Failure of the product due to
using the incorrect xings is the
responsibility of the installer.
Important: when drilling into walls always check
that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used are suitable for
supporting your unit. Consult a qualied tradesperson if you
are unsure.
Hints:
1: General rule: always use a larger screw and wall plug if you are
not sure.
2: Ensure you use the recommended drill bit to match the wall plug and
hole size.
3: Ensure you drill the hole horizontally; do not force the drill or enlarge
the hole.
4: Take extra care when drilling high walls, ceilings and ceramic tiles.
Ensure wall plugs are inserted beyond the thickness of the ceramic
tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
Types of walls
No.1 “General Purpose” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For
light loads, general purpose
wall plugs can be used.
No.3 “Cavity Fixing” wall plug
For use with plasterboard partitions
or hollow wooden doors.
No.5 “Hammer Fixing” wall plug
For use with walls stuck with
plasterboard. The hammer xing
allows it to be xed to the wall
rather than the plasterboard.
Always check the xing is secure
to the retaining wall.
No.2 “ Plasterboard”
wall plug
For use when attaching light loads
onto plasterboard partitions.
No.4 “ Cavity Fixing – Heavy Duty”
wall plug
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
No.6 “ Shield Anchor” wall plug –
heavy loads
For use with heavier loads such as
TV and HiFi speakers and satellite
dishes etc.
Care &
Maintenance
Safety: always check the tting and
location to ensure your safety in and
around the home.
Fitting: from time to time check the
tting to ensure the wall plugs or
screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
