Arjo MAXI SKY 600 Installation guide

MAXI SKY
600
OPERATING AND
PRODUCT CARE INSTRUCTIONS
001.14150.33.EN rev.4
February 2006

© ARJO AB 2005
ARJO products are patented or patent pending. Patent information is available by
contacting ARJO AB.
Our policy is one of continous development, and we therefore reserve the right to
make technical alterations without notice. The content of this publication may not
be copied either whole or in part without the consent of ARJO AB

3
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Foreword. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Please read this manual thoroughly . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Service and support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Supplier information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
How to use this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Symbols used in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Key to symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operational life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Equipment identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Verifying the package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Important safety advices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Shock prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Fire and explosion prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Human and environment safety practices . . . . . . . . . . . . . . . . . . . . . 11
Battery and battery charger safety practices . . . . . . . . . . . . . . . . . . . 11
Equipment warning labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Labels on the Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Serial number label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Approval label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Labels on the Battery & Battery Charger. . . . . . . . . . . . . . 14
Battery label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Battery charger label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Part Designation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Lift cassette and charger station . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hand control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4
Table of Contents
How to use the Maxi Sky
600
. . . . . . . . . . . . . . . . . . . . . . . . 18
Return to charge (RTC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Emergency stop (Red cord) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Emergency lowering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Emergency brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Battery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Charging the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Using the FIDO function (pre-programmed positions) . . . . . . . . . . .24
Programming the ceiling lift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
A) Enter into the “Program” mode . . . . . . . . . . . . . . . . . . . . . . . . . .24
B) Speed adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
C) Adjust the height of the spreader bar when it returns to charger .25
D) Enable / Disable - Return to charge . . . . . . . . . . . . . . . . . . . . . . .25
Use of Slings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Dynamic Positioning System (DPS),
spreader bars and stretcher frame . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Slings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Before approaching the resident . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Installing the sling on the Dynamic Positioning System (DPS). . . . 28
To lift a resident from a bed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
To lift a resident from a chair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
To lift a resident from the floor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Procedure for using loop slings with two point spreader bar . . . . . . 34
Procedure for attaching loop slings to the two point spreader bar . . .34
To lift a resident from a bed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
To lift a resident from a chair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
To lift a resident from the floor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Before transporting a resident . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Using stretcher frames and stretchers . . . . . . . . . . . . . . . . . . . . . . . .36
Operating the DPS Spreader Bar . . . . . . . . . . . . . . . . . . . . 38
Operating the DPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DPS function cut out system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Care Of Your DPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

5
Table of Contents
DPS Spreader Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Use of the Exchanger / Turntable . . . . . . . . . . . . . . . . . . . 40
Operating the exchanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Operating the turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Preventive maintenance schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Daily checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Inspection and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Strap inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Handling and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Battery replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Verification of charger power source . . . . . . . . . . . . . . . . . . . . . . . . 47
Sling inspection and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Annual inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Maintenance requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

6
Introduction
Thank you for purchasing ARJO
equipment.
Your Maxi Sky
600
is part of a
series of quality products
designed especially for acute
care hospitals, elderly care
facilities and other health care
use.
We are dedicated to serving your
needs and providing the best
products available along with
training that will bring your staff
maximum benefit from every
ARJO product.
Please contact your local ARJO
representative if you have any
questions about the operation or
maintenance of your ARJO
equipment.
Foreword
Please read this manual thoroughly
Please read this manual in its entirety before using your
Maxi Sky
600
. Information in the manual is crucial to the
proper operation and maintenance of the equipment, and
will help protect your product and ensure that the equipment
performs to your satisfaction. Lifting and transferring a
person always present a potential risk. Some of the
information in this manual is important for your safety and
must be read and understood to help prevent possible injury.
ARJO strongly advise and warn that only ARJO designed
parts, which are designed for the purpose, should be used on
equipment and other appliances supplied by ARJO, to avoid
injuries attributable to the use of inadequate parts.
Unauthorized modifications on any ARJO equipment may
affect its safety. ARJO will not be held responsible for any
accidents, incidents or lack of performance that occur as a
result of any unauthorized modification to its products.
Tested according to standards by:
TÜV, Product Service and
Service and support
A service routine has to be done on your Maxi Sky
600
by
ARJO authorized service personnel to ensure the safety and
operating procedures of your product.
See chapter Care and Maintenance.
If you require further information, please contact your local
ARJO representative which can offer comprehensive
support and service program to maximize the long-term
safety, reliability and value of the product. Contact your
local ARJO representative for replacement parts. Your
service representative stocks the parts you will need.
The telephone number appears on the last page of this
manual.
Supplier information
This product has been manufactured for ARJO by:
BHM Medical Inc.
2001 Tanguay Street
Magog (Quebec)
Canada J1X 5Y5
Authorized representative in Europe:
ARJO Hospital Equipment AB
Box 61
S-241 21 Eslöv
Sweden

7
Introduction
How to use this manual
WARNING:
Do not attempt to use this equipment
without understanding this manual.
To ensure safe operation, read the entire manual
carefully, especially the section on “Safety
Instructions and Warnings”, before installing,
operating, or servicing this equipment.
If anything is not completely understood, please
contact your local ARJO representative for more
details. Failure to comply with warnings in this
manual may result in injury.
Keep this manual with the lift and refer to it as
required. Make sure that all operators are regularly
trained in the use of the equipment according to this
manual.
Symbols used in this manual
Throughout this manual the following symbols are
used. Pay particular attention to the information
provided under these headings. These special
annotations are easily recognized as follows:
WARNING:
This symbol is intended to alert the user to
hazards or unsafe practices, which could
result in serious injuries.
Failure to understand and obey this warning
may result in injury to you or to others.
NOTE!
This symbol is intended to alert the user of
the presence of important operating and
maintenance instructions, which could
prevent product damage or possible
personal injury.
This is important information for the correct
use of this system or equipment.
CAUTION
This symbol offers helpful information
concerning certain operating procedures.
Failure to follow these instructions may
cause damage to all or parts of the system.
Additional copies of this manual can be purchased
from your local ARJO representative. Include the
User Manual product number and equipment
identification number, see front page .
Key to symbols
The following symbols are used on the Maxi Sky
600
ceiling lift cassette:
The symbol indicates the power-on
indicator light.
The symbol indicates the charging
indicator light.
The symbol indicates the “Service”
indicator light.
The symbol represents the emergency
stop.

8
Introduction
Intended use
The Maxi Sky
600
is intended for lifting residents at
acute care hospitals, elderly care facilities and other
health care facilities under the supervision of
appropriate trained caregiver staff in accordance with
the instructions outlined in this Operating and
Product Care Instructions. All other uses must be
avoided.
The equipment must only be used for the purposes
stated above, and must be installed by ARJO
authorized personnel and in accordance with local
codes.
Operational life
WARNING:
The manufacturer cannot ensure full safety
for a ceiling lift or an accessory of which the
lifespan is exceeded.
The equipment is designed and tested for a useful life
of seven (7) years or 10 000 transfers, whatever
comes first, subject to preventative maintenance as
specified in the Operating and Product Care
Instructions, the Assembly and Installation
Instructions and the Spare Part Instructions. Time
equivalence between number of transfers / number of
years is made clear in the table in figure 1. The red
indicator on the ceiling lift will blink for a while
when it is halfway to its useful life, and again to
indicate the end of the useful life period.
The operating life of this equipment corresponds
directly to the safe operating time period before a
complete overhaul is required. Age of the cassette,
frequency of use (number of beds / transfers per day),
resident weight and maintenance frequency are
factors that have an impact on the Maxi Sky
600
lifespan. A transfer is defined as the displacement of
a resident from one point to another. A transfer cycle
includes a lifting and a descent action.
The expected operational life for fabric slings and
fabric stretchers is approximately 2 years from date
of purchase. This life expectancy only applies if the
slings and stretchers have been cleaned, maintained
and inspected in accordance with the “ARJO Sling
Information” documents, the “Operating and Product
Care Instructions” and the “Preventive Maintenance
Schedule”.
The expected life for other consumable products,
such as batteries, fuses, lamps, slings, straps and
cords is dependent upon the care and usage of the
equipment concerned. Consumables must be
maintained in accordance with published “Operating
and Product Care Instructions” and the “Preventive
Maintenance Schedule”.
Equipment identification
The unit's identification number (specification,
model, serial number) appears on a silver nameplate
attached at the end of the lift.
Verifying the package contents
Always ensure that the ceiling lift shall be installed
by an ARJO authorized contractor or installer.
Upon receipt of the equipment, verify it against the
packing list to ensure it is complete and inspect the
equipment for possible damage due to shipping. If
there is any damage, notify the carrier immediately to
file a claim. Provide complete information
concerning damage claims or shipping errors to your
local ARJO representative. Include all equipment
identification numbers and group part numbers (if
any) as described above along with a full description
of damaged parts.
Figure 1
Transfers per day Years (10 000 transfers)
47
6 4.5
8 3.5

9
Safety Instructions
The equipment must be used in
accordance with these Safety
Instructions.
Anyone using the equipment
must also have read and
understood the instructions in
this manual.
If there is anything you are not
sure about, contact your local
ARJO representative.
General
Keep these Safety Instructions with the ceiling lift at all
times.
Read Operation and Product Care Instructions in this
manual before installing, operating, or servicing this
equipment.
WARNING:
Maxi Sky
600
is for transferring residents only. Do
not use the lift for any other purpose.
WARNING:
Maxi Sky
600
is intended to be used for residents
within the specified weight limit indicated for the
lift. Do not attempt to lift more than the weight limit
indicated.
WARNING:
Always place the sling around the resident
according to the instructions enclosed. Failure to
do so may result in injury to you or to others.
CAUTION
DO NOT drop the ceiling lift cassette or batteries,
since that may cause internal damage that is not
easily seen. If the ceiling lift is suspected to be
damaged, contact your local ARJO representative
for servicing.

10
Safety Instructions
Important safety advices
Always ensure that:
• The ceiling lift is installed by an authorized
contractor or installer.
• The equipment is used by trained staff.
• Installation is conformed to accept a 272 kg
(600 lbs) load, this will be done by the ARJO
installation team.
•The resident is assessed by qualified professional
before attempting to move the resident.
•You are prepared before attempting to transfer
a resident.
• An assessment of the suitability for transfer
of a patient who is connected to electrodes,
catheters or other medical devices must be
conducted by qualified personnel before
performing the transfer.
•Violent impact during transportation is avoided.
• The sling is intended to be used for this lift and
can take the weight of the resident.
• The sling is not damaged, torn or frayed.
•The lifting procedures outlined in this manual are
followed.
• All controls and safety features are used only
according to the rules specified in this manual.
Never attempt to force a control or button on the
lift.
• The charger is not stored in a shower, bath or
other areas with high humidity.
• The safety straps are in good condition and
properly fastened.
•The daily maintenance is carried out before using
the lift.
•Any precautionary or instruction labels that
cannot be easily read is replaced.
• The humidity when storing the Maxi Sky
600
,
when not in use, not exceeds 80 % at 20°C
(68°F).
• The ambient temperature range when storing
Maxi Sky
600
should be –10°C to +50°C (+14°F to
+122°F).
NOTE!
ARJO ceiling lifts are specifically designed
for ARJO KwikTrak ceiling rail systems,
slings and accessories. If slings of any other
manufacturer for some reason are used,
always make sure these slings are CE-
marked and are attended by the manufac-
turer of the sling to be used on the Maxi
Sky
600
.
CAUTION
Keep all components of the lift clean and
dry, and have electrical and mechanical
safety checkpoints done as instructed in the
Care and Maintenance section of this
manual.
Shock prevention
•Do not touch or use a lift with bare conductors or
a damaged power cord. Electrically live
equipment can result in serious injuries. If the lift
or charger has any exposed or damaged wires
contact your local ARJO representative immedi-
ately.
• Do not splash or expose electric parts of the
device to water or moisture.
• Check nameplate for voltage and cycle require-
ments. These requirements differ by country. Do
not attempt to use the lift in an area that has a
different voltage and cycle requirement.
• Do not attempt to expose, service or repair the
lift, battery or charger. If any unit is malfunction-
ing, contact your local ARJO representative.
• Read batteries and charger instructions
thoroughly before using or storing them.

11
Safety Instructions
Fire and explosion prevention
WARNING:
Do not place or store the battery under direct
sunlight or near a heat source. Do not
expose the batteries or battery charger to
flames. Do not use the charger in presence
of inflammable anaesthetic gases.
• Do not short-circuit the battery terminals.
• Do not incinerate the battery.
Human and environment safety
practices
• Should the battery casing crack and cause con-
tents to come in contact with skin or clothing,
rinse immediately with water. If contents come in
contact with the eyes, rinse immediately with
plenty of water and seek medical attention.
• Inhalation of the contents can cause respiratory
irritation. Sensitivity of nickel can cause allergic
asthma. Provide fresh air and medical attention.
•For recycling and disposal of the batteries the
rules according to the WEEE directive (Waste of
Electronic and Electrical Components) and local
rules and regulations must be followed. If not
they may explode, leak and cause personal injury.
When returning batteries, insulate their terminals
with adhesive tape etc., otherwise, the residual
electricity in used batteries may cause fire or
explosion.
Picture 2 below shows the symbols for disposal
and recycling.
Figure 2
Battery and battery charger safety
practices
WARNING:
Do not expose the battery connector or the
battery charger to water. The charger is
designed for dry areas only and for normal
air humidity conditions.
• Be careful not to drop the battery.
• Use only the charger supplied with the
equipment.
• Do not charge batteries in unventilated room
areas.
• The charger must not be covered or exposed to
dust.
• Do not short-circuit the battery.
•Do not crush, puncture, open, dismantle or other-
wise mechanically interfere with the batteries.
•Do not store batteries at a temperature higher than
50°C (122°F).
Equipment warning labels
• Carefully read the labels on the battery and fol-
low the instructions.
•Inspect all precautionary labels on the equipment.
Order and replace all labels that cannot be easily
read.

12
Labels on the Lift
Figure 3

13
Labels on the Lift
On the ceiling lift cassette data labels you will find
the following information. See figure 3:
Serial number label
•Model name and number: MAXI SKY 600
#LDXXXXX.
• Approvals: CAN CSA C 22.2 No. 601.1/
UL No. 2601-1/ISO 10535.
• Charge maximum load: 272 kg (600 lbs).
• Duty cycle: Max 10%, Max 6min/hour.
• Rating: 24 VDC, 15 A Max.
• Serial number.
•Manufacturing date.
•
Type BF.
Applied part: protection against electric shock in
accordance with EN 60601-1, double insulated.
•
Read the operating instructions before use.
•
This symbol is required to be displayed on
regulated products for sale in the European
Market. It indicates that the product complies
with applicable European Directive for Medical
Devices.
•
Canadian Standards Association approval.
•
Safe Working Load represents the maximum load
the ceiling lifter is rated for to ensure safe
operation.
SWL
•
Environmental danger. Not for disposal.
To be recycled in accordance with the European
Directive 2002/96/EG (WEEE).
Approval label
•CE marking in accordance with the Directive 93/
42/EEC (The Medical Device Directive) and
classified to class 1.
• The lift has been safety tested according to:
IEC 60601-1
ISO 10535
CAN CSA C 22.2 No. 601.1.
• The lift has been EMC-tested and fullfils
all requirements according to IEC 60601-1-2.
ARJO is not aware of any reciprocal electro-
magnetic interference between Maxi Sky600 and
other electrical products.

14
Labels on the Battery & Battery Charger
Figure 4
Battery label
Battery charger label

15
Labels on the Battery & Battery Charger
On the ceiling lift cassette battery label and the
battery charger label you will find the following
information. See figure 4:
Battery label
•Type: Sealed RechargeableValve Regulated Lead
Acid Battery.
•Constant Voltage Charge.
• Cycle use: 14.1 - 14.4 V.
• Standby use: 13.5 - 13.8 V.
• Initial current: Less than 2.00 A.
• Rating: 12 V, 5 Ah.
•
CAUTION
Do not short battery terminals.
Avoid charging in a sealed container.
Keep away from sparks and flames.
Keep away from children.
•
Approval of plastic materials according to:
UL No. 2601-1.
•
This symbol is required to be displayed on
regulated products for sale in the European
Market. It indicates that the product complies
with applicable European Directives related to
health, safety and environment and consumer
protection.
•
Environmental danger. Not for disposal.
To be recycled in accordance with the European
Directive 2002/96/EG (WEEE).
•
Recyclable.
Battery charger label
•
This symbol is required to be displayed on
regulated products for sale in the European
Market. It indicates that the product complies
with applicable European Directives related to
health, safety and environment and consumer
protection.
•
Canadian Standards Association approval.
•
Insulation class II
•
CAUTION
Read the operating instructions before use
• Input: 100-240 Vac, 50/60 Hz, 27 VA
• Output: 27-29 Vdc, 1.0 A max.

16
Part Designation
Lift cassette and charger station
A Charger
B Allen key
C Manual lowering
D Door
E Charger station
F Rail
G Lift
H Strap
I Spreader bar
JYellow light
K Green light
L Red light
M Down button
N Up button
O Red emergency
pull cord
Figure 5
A
BCD
E
F
G
HI
JKL
M
N
O

17
Part Designation
The following refer to figure 5 on former page.
• The yellow light "charger" flashes while charging and
illuminates when charge is finished.
• The green light "on" illuminates once the lift is on and
ready for use; the green light flashes when the batteries
are low.
•The red light illuminates to confirm that the lift is in the
programming mode.
• The red light illuminates in the normal mode when the
lift is under overheat protection caused by an overuse.
•The red light "service" flashes when servicing is required
(contact customer service).
Hand control
• The button "Programming mode" allows you to modify
the functions of the lift.
Figure 6
A
B
C
D
E
F
A Programming mode (PROG)
B Left
CUp
D Right
E Down
F Return to charge

18
How to use the Maxi Sky600
WARNING:
Always read the Safety Instructions before
using the Maxi Sky600.
• The track must be installed by ARJO
authorized personnel and in accordance
with local codes.
• All track are closed with end stoppers
or are connected to other closed track
component.
• Before use, make sure all end stoppers
are in place and tightened.
NOTE!
The unit will not lift or lower when it is in
charging position.
1 Attach the resident sling. See Use of Slings
section in the user manual for further informa-
tion.
2Move the ceiling lift directly over the resident.
Use the left and right buttons on the hand control.
See figure 7 on next page.
3Use the down button on the hand control to lower
the spreader bar under the chin of the
resident (to avoid the risk of facial contact caused
by a sudden movement of the spreader bar).
NOTE!
If the ceiling lift does not work, gently pull
the red cord until you hear a click. The green
light should illuminate.
In a laying down position, lower the spreader bar
near the resident’s thorax, then install the straps.
CAUTION
Hold the ceiling lift spreader bar with one
hand at all times when near a resident.
4Attach the straps to the desired position. See Use
of Slings section.
5 Carefully observe the resident to ensure his/her
safety as you press the control buttons.
WARNING:
Before lifting the resident, make sure that all
straps are attached to the spreader bar.
Make sure the sling is not caught on any
obstruction (wheelchair brake or arm of the
chair).
Also make sure that the spreader bar is
correctly fixed to the ceiling lift, see figure 8
on next page.
6To lift the resident, press the UP button.
7Make sure the resident is clear of any obstacles
before moving the resident. Guide the legs if
necessary.
8When the resident is located above the desired
point of transfer, press the DOWN button.
9 Use the handles on the back of the sling to
position the resident when transferring into a
chair. Hold the hand control firmly as the sling
will tilt back to position the resident.
10 Once the resident is properly seated and the straps
are loose, remove the sling from the ceiling lift.
CAUTION
Hold the ceiling lift spreader bar with one
hand at all times when near a resident.
11 Slide the ceiling lift away from the resident.
12 When the ceiling lift is no longer required, return
the lift to the charger station by pressing the
return to charge button. The charging indicator
light must be on for the ceiling lift to detect the
clip on charger station. Please notice that the ceil-
ing lift has memorized the charger station posi-
tion automatically.

19
How to use the Maxi Sky600
13 Verify the green light at the charger station and
the yellow light (flashing or light) on the ceiling
lift to ensure that charging function is working
properly.
NOTE!
The Maxi Sky600 is equipped with a security
system to prevent a misuse of the lifting
system. If the use is over the specified duty
cycle, the heat detection system will signal
to the processor to block the lifting of a load
until transmission temperature cools down.
Therefore, it will always be possible to
activate the horizontal displacement and the
down functions.
When the overheat protection is engaged the
red light will illuminate during the cooling
period.
Plus, a buzzer will be heard if the UP button
is engaged and the motor will not lift. The
cooling period is between 10 to 30 minutes
depending on the ambient conditions.
Return to charge (RTC)
At the activation of the Return to charge function, the
spreader bar will raise all the way up to avoid any
obstacles during the run. When the lift is at the
charging station, the spreader bar lowers by itself to
the adjusted height to be easily accessible.
NOTE!
You can stop the Return to charge at any
time by pressing any button on the hand
control or by turning the lift off (pulling the
red cord). Moreover, a weight detector dis-
ables the RTC function to run while a person
is installed in the lift.
A
B
C
D
E
F
Figure 7
1 Programming mode (PROG)
2 Left
3Up
4 Right
5 Down
6 Return to charge
Figure 8

20
How to use the Maxi Sky600
Emergency stop (Red cord)
1The emergency stop can be activated at any time
to stop the function of the ceiling lift.
2To stop the ceiling lift in any emergency, pull the
red emergency cord gently once, until you hear a
“click”. See figure 9.
CAUTION
Do not pull the red cord forcefully. If the cord
is pulled too forcefully, the ceiling lift may
become inoperable.
3To activate the ceiling lift, pull the red cord gently
once. The green light confirms that the ceiling lift
is on and ready for use.
Emergency lowering
In the unlikely event of an electrical failure, the Maxi
Sky600 has an emergency manual lowering feature.
See figure 10.
CAUTION
Only to be used in case of an emergency.
If the ceiling lift malfunctions when a resident is
being transferred, the emergency lower device
provides a safe way of getting the resident onto a
chair, bed or wheelchair.
1 Remove the 8-mm Allen key on the top of the
ceiling lift. See figure 11.
2 Open the side door to access the mechanism.
3Insert the Allen key deep into the axle, visible in
the lateral door. See figure12. Turn it counter
clockwise in order to lower the resident. Each
turn of the key will slowly lower the resident.
4To lower the resident more rapidly, use a ratchet
or a drilling machine with an 8-mm Allen key.
5 Once the resident is lowered and secured onto a
chair, bed or wheelchair, call qualified technician
to inspect the ceiling lift.
Emergency brake
The emergency brake is made of a metal bar fixed to
the drum.
In case of a gear or motor breakage, the centrifugal
force created will block the bar against the frame.
Exactly like a car seat belt.
