Arkon SVE14A User manual

IPM525-S
|Flexible Gooseneck Seat Bolt or Floor Mount for Apple iPhone® and iPod touch®
CM088-TS-2
15” Flexible Floor Mount
SP-CM088-SBH
360º Swivel SBH Head
(optional)
Floor Mount
Console Mount
Screw the flexible steel shaft into the seat track bolt bracket.
With a socket wrench, loosen the passenger seat track bolt, in-
sert the seat track bolt bracket, and retighten the seat track bolt.
Step 1.
Step 2.
Position the Floor/Console Bracket and drill into the floor or console.
Attach the Floor / Console Bracket with screws and cover with
plastic caps.
Screw the steel shaft into the Floor / Console Bracket.
Step 1.
Step 2.
Step 3.
Adjust the steel shaft by bending with both hands to the
desired location of the male dual T head.
Use the adjustment knob and wing nut on the pedestal head to
swivel or rotate the head position if necessary.
Step 1.
Step 2.
Passenger Seat Bolt Mounting
Floor or Console Mounting
For a more permanent mount, connect the Floor /Console Mount Bracket
to the floor or console. This will require drilling into your vehicle’s
interior surface.
Pedestal Head Adjustments
Continued on other side...
For a simple mount that can be easily moved to another vehicle, install
using the passenger seat track bolt.
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and /or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
!
!Drilling into the dash, floor, or console will permanently damage
the vehicle. Use caution and consult a mobile install professional
to avoid drilling into the gas tank, electrical system or other highly
sensitive vehicle components.
1
2
3
Do not place mount in or near an air bag deployment zone or
where it will obstruct view of the road.
!
Compatible with the following devices:
Apple iPhone® 4•
Apple iPhone® 3GS•
Apple iPhone® 3G•
Apple iPhone® Original•
Apple iPod touch® - All models•
*Apple®, iPhone®, and iPod touch®are trademarks of Apple Computer, Inc. Arkon Resources, Inc. is not affiliated with Apple Computer, Inc.
Do not place mount in or near an air bag deployment zone or where it
will obstruct view of the road.
!
Package Contents:
(1) CM088-TS-2 - 15” Flexible steel gooseneck floor or console mount
Includes: (1) Seat Bolt Bracket, (1) Floor / Console Bracket, (4)Screws,
(4) Plastic Caps, and (1) Flexible Steel Shaft with Plastic Tubing
(1) SM050-2 - Slim-Grip™ holder for Apple iPhone and iPod touch®
(1) SP-CM088-SBH - 360º Swivel SBH Head (optional)
SM050-2
Slim-Grip™ Holder for
iPhone & iPod touch
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China and Taiwan
© Copyright 2010 Arkon Resources, Inc.

Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and /or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
!
IPM525-S
|Flexible Gooseneck Seat Bolt or Floor Mount for Apple iPhone® and iPod touch®
Step 1. Connect the dual T-slots (C) on the back of the holder to the
dual T-tabs (D) on the mount pedestal head.
A
A
A
A
B
B
Install the Support Legs to the Holder
Step 1. Insert the holder support legs (A) by sliding them into the
support leg grooves (B) on the top and bottom of the holder.
iPhone Holder Attachment
(C) T-slots
(D) T-tabs
(iPhone device
not included)
F
E
Secure holder with your hand for support, as spring-loaded
mechanism requires significant force to operate. Hold your
phone and insert into universal holder by pushing down on the
bottom spring-loaded support legs with moderate amount of
pressure (E). Slide the top of the device under the top support
legs (F) until it fits snuggly in the holder.
Insert Phone into Holder
Step 1.
Adjusting Holder to Fit Phone
Using the Optional 360° Swivel SBH Head for Landscape Viewing
G
G
If necessary, adjust the support legs (G) on top and bottom by
sliding them laterally to avoid any buttons or ports that may be
on your phone.
To rotate your device in landscape view, install the optional
SP-CM088-SBH 360° swivel SBH head. Unscrew the wing
nut on the gooseneck and remove the already installed tilt
swivel head. Insert the SP-CM088-SBH 360° swivel SBH head
and retighten the gooseneck wing nut. Adjust the angle of
the 360° swivel SBH head with the head wing nut and swivel
adjustment ring as necessary.
Step 1.
Step 1.
Wing Nut
Swivel
Adjustment
Ring
Wing Nut
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China and Taiwan
© Copyright 2010 Arkon Resources, Inc.
