Arthrex SynergyRF AR-9800 User manual

SynergyRF™AR-9800
Quick Start Guide
Unpacking
Carefully unpack and inspect all components for
shipping damage. Save the packaging for later transport
of the device. The footswitch is provided separately. The
probe is provided separately and is in sterile packaging.
Users must read the SynergyRF User’s Manual and
ApolloRF® Probe DFU prior to using these devices. The
User Manual and DFU provide the indications and
contraindications for use, warnings, symbol definitions,
and the full list of product instructions. These
documents can be found on Arthrex.com.
Power Cord
Generator
Footswitch
Probe
Connector
Probe
Suction
Tube
Footswitch
Cable
Connector

2 3 4 5
6 7 8
1 2
APOLLO 90
Place console on a
flat, dry surface
1
Setup
Connect power cord
to console
Connect power cord
to outlet
Power on console Allow console to fully
initialize
Attach probe via
connector to console
For suction probes,
attach suction tube
Attach footswitch
if desired
Change settings using touch panel to set main
screen display
9
APOLLO 90
Device
Recognition
Indicator
Footswitch
Icon
Menu
Button
Ablate
Power
Settings
Coag
Power
Settings
Press menu setting
button
To Adjust Settings
Press desired setting For Language:
Select desired
language and then do
one of the following:
Press HOME to save
setting and return to
main screen
-OR-
Press Setting Button to
save setting and return
to MENU
-OR-
Press Xto return
to MENU without
changing default
For Footswitch
Override:
Select desired option
and then do one of the
following:
Press HOME to save
setting and return to
main screen
-OR-
Press Setting Button to
save setting and return
to MENU
-OR-
Press Xto return
to MENU without
changing default
For Volume:
Select desired volume
using + or – buttons
and then do one of the
following:
Press HOME to save
setting and return to
main screen
-OR-
Press Setting Button to
save setting and return
to MENU
-OR-
Press
Xto return to MENU
without changing
default

1
2
3
arthrex.com
© 2021 Arthrex, Inc. All rights reserved. LI1-00027-en-US_C
Troubleshooting: Faults and Solutions
Fault Solution
Unit does not power on 1. Check the main power plug and wall receptacle.
2. Check the main fuses per the User Guide instructions.
3. Call Arthrex Tech Support at 1-888-420-9393.
Accessory ApolloRF® probe does not work 1. Disconnect and reconnect probe.
2. Turn o console, wait 30 seconds, repower console.
3. If applicable, disconnect and reconnect footswitch, replace if footswitch not
functioning.
4. Open new ApolloRF probe.
Yellow fault message Refer to User Guide for proper disposition.
Red fault message (Critical Failure) 1. Make note of message displayed.
2. Call Arthrex Tech Support at 1-888-420-9393.
To return or repair device: Contact Arthrex Product Surveillance at 1-866-267-9138.
Arthrex, Inc.
1370 Creekside Blvd.
Naples, FL 34108-1945 USA
Toll Free: 1 [phone]
www.arthrex.com
Arthrex Tech Support:
[phone]
Arthrex GmbH
Erwin-Hielscher-Strasse 9
81249 München, Germany
Tel: [phone]
www.arthrex.de
[phone]
Button Activation
1. Ablation power setting
2. Ablate
3. Coag
