Arthrex Synergy ID System User manual

Synergy
ID™System
Quick Set Up Guide
Product Items
SYNERGY LASER LIGHT SOURCESYNERGYID SYSTEM
SynergyID Console, Tablet,
Autoclavable Camera Head,
and Cables
SYNERGY TABLET
AND DOCKING STATION
SYNERGY MONITOR
Arthrex Synergy 4K Monitor
and Cables
VIDEO CART AND BOOM ARM
Optional
PRINTER Optional
Sony™ UP-DR80MD Printer
and Cables

www.arthrex.com
© 2020 Arthrex, Inc. All rights reserved. LI1-000123-en-US_A
1. Place SynergyID console (CCU) on tower shelf and
connect power cord to the back of the console
2. Attach monitor to the tower and connect monitor DC
power cable to the rear panel of the monitor
3. Attach Synergy tablet to tablet arm and connect the
cable from the docking station to the rear panel of the
Synergy console labeled “TABLET” as shown
4. Using the provided video cable, connect one end to
the rear panel of the console labeled “DISPLAY PORT 1”
as shown
5. Connect the other end of the video cable to the rear
panel of the monitor labeled “VIDEO INPUT”
6. Attach provided trigger cable from back of laser light
source to the console labeled “LASER” (only needed if
fluorescence imaging is desired)
7. Connect the laser light source to power (only needed if
fluorescence imaging is desired)
8. Place printer on tower shelf and connect power
cord to power supply and USB cable to the rear of the
SynergyID console
9. Press the LED “ON” button on the front of the CCU to
turn the light source on
SynergyID™Quick Set Up Guide
Printer
Synergy Laser Light Source Synergy 4K Monitor Tablet
