Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs
for many years to come. Scandinavian design combines clean
lines, everyday functionality and high quality. These are key
characteristics of all our products and the reason they are
greatly appreciated throughout the world.

- 4 -
GENERAL
Carefully read the following important information regarding installation safety and maintenance. Keep this
information booklet accessible for further consultations.The appliance has been designed for use in the ducting
version (air exhaust to the outside – Fig.1B), ltering version (air circulation on the inside – Fig.1A) or with
external motor (Fig.1C).
SAFETY PRECAUTION
1.Take care when the cooker hood is operating simultaneously with an open replace or burner that depend on
the air in the environment.The cooker hood removes air from the environment which a burner or replace need
for combustion.The negative pressure in the environment must not exceed 4Pa (4x10-5 bar). Provide adequate
ventilation for a safe operation. Follow the local laws applicable for external air evacuation.
Before connecting the model to the electricity network:
- Check the data plate (positioned inside the appliance) to ascertain that the voltage and power correspond to
the network and the socket is suitable. If in doubt ask a qualied electrician.
- If the power supply cable is damaged, it must be replaced with another cable or a special assembly, which may
be obtained direct from the manufacturer.
2. Warning !
In certain circumstances electrical appliances may be a danger hazard.
A) Do not check the status of the lters while the cooker hood is operating
B) Do not touch bulbs or adjacent areas, during or straight after prolonged use
C) Flambè cooking is prohibited underneath the cooker hood
D) Avoid free ame, as it can damage the lters and is a re hazard
E) Constantly check food fr ying to avoid overheated oil becoming a re hazard
F) Disconnect the electrical plug prior to any maintenance
G) This appliance is not intended for use by young children or inrm persons without supervision
H) Young children should be supervised to ensure they do not play with the appliance
I) There shall be adequate ventilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels
L) There is a risk of re if cleaning is not carried out in accordance with the instructions
This appliance conforms to the European Directive EC/2002/96, Waste Electrical and Electronic Equipment
(WEEE). By making sure that this appliance is disposed of in a suitable manner, the user is helping to prevent
potential damage to the environment or to public health.
The symbol on the product or on the accompanying paperwork indicates that the appliance should not
be treated as domestic waste, but should be delivered to a suitable electric and electronic appliance recycling
collection point. Follow local guidelines when disposing of waste. For more information on the treatment, re-
use and recycling of this product, please contact your local authority, domestic waste collection service or the
shop where the appliance was purchased.
INSTALLATION INSTRUCTIONS
Assembly and electrical connections must be carried out by licenced personnel.
• Electric Connection
The appliance has been manufactured as a class II, therefore no earth cable is necessary.
The plug must be easily accessible after the installation of the appliance.
If the appliance is equipped with power cord without plug, a suitably dimensioned omnipolar switch with 3
mm minimum opening between contacts must be tted between the appliance and the electricity supply in
compliance with the load and current regulations.
The connection to the mains is carried out as follows:
BROWN = Lactive

- 5 -
BLUE = Nneutral
• If the hob is electric, gas, or induction, the minimum distance between the lower part of the hood and the Hob
burners or hotplates must be at least 65 cm.
Exhaust: If a connection tube composed of two parts is used, the upper part must be placed outside or over the
lower part. Do not connect the cooker hood exhaust to any conductor used to circulate hot air or for evacuating
fumes from other appliances.
• We recommend the use of an air exhaust tube which has the same diameter as the air exhaust outlet hole (150
mm). If a pipe with a smaller diameter is used, the eciency of the product may be reduced and its operation
may become noisier.
• Installation
The following instruction should be followed to carry out the correct installation of the cooker hood.
1. Mounting of the cooker hood on the lower side of the
cupboard.
2. Select the version (extraction or ltration)
3. Before starting to x the hood, remove the anti-grease lter for easier handling:
- Open panel B as shown in Fig.2.
- Pull handle C as shown in Fig.3.
• Fitting the cooker hood into the lower part of the wall
cabinet
For all measurements relating to the cooker hood, please refer to Fig.4.
Before xing the cooker hood to the lower part of the cabinet, the following steps should be performed:
1- Remove the 4 screws E xing the two cooker hood lamps H (RHS and LHS) in place as indicated in Fig. 5A.
2- Remove the lamps H and disconnect the connectors W of the halogen lamps to make installation easier, as
indicated in Fig. 5B.
3. Make sure the thickness of the cabinet falls within the range of values listed in Fig. 5C.
Fit the cooker hood in the cabinet (Fig. 6) and make sure the 4 springs are xed in place well.
Fix the cooker hood to the cabinet securely by using a screwdriver to tighten the screws M until the
appliance is ush with the cabinet (Fig. 6).
4. Connect the connectors W of the halogen lamps again and reinstall the lamps H xing them with the 4
screws E that were previously removed.
• Ducted version
This appliance expels fumes, either through a perimeter wall or ceiling. It is therefore necessary to purchase
a non-ammable air exhaust tube (not supplied) which complies with all current legislation and connect it to
ange N (Fig.1B).
• Filter hood
Please note:
In order to transform the hood from ducted to recirculating the carbon lters must be ordered at your distributor
as an accessory.
We have two dierent types of carbon lters: Re-usable part no. ACK62260 (Fig.7) and disposable, part no.
KIT0112 (Fig.8)
- To replace the extractable active carbon lters X, pull lever outwards as shown in Fig.7
- To replace re-usable carbon lters Y, remove the brackets from their seat, pulling them outwards. (Fig.8)
Fix the bracket (included in the product packaging) to the hood using the supplied screws (Fig. 9)
USE AND MAINTENANCE
• We recommend that the cooker hood is switched on before cooking.
We also recommend that the appliance is left running for
15 minutes after the food is cooked, in order to thoroughly eliminate all contaminated air.
The eective performance of the cooker hood depends on constant maintenance; the anti-grease lter and the
active carbon lter both require special attention.
• The anti-grease lter is used to trap any grease particles suspended in the air, therefore is subject to saturation
(the time it takes for the lter to become saturated depends on the way in which the appliance is used).
-To prevent potential re hazards, the anti-grease lters should be washed a minimum of every 2 months (it is

- 6 -
possible to use the dishwasher for this task).
- After a few washes, the colour of the lters may change. This does not mean they have to be replaced.
If the replacement and washing instructions are not followed, the anti-grease lters may present a re hazard.
• The active carbon lters are used to purify the air which is released back into the room.
The lters are not washable or re-usable and must be replaced at least once every four months.
The active carbon lter saturation level depends on the frequency with which the appliance is used, the type
of cooking performed and the regularity with which the anti- grease lters are cleaned.
• Clean the cooker hood frequently, both inside and outside, using a cloth which has been dampened with
denatured alcohol or neutral, non-abrasive liquid detergents.
• The light on the cooker hood is designed for use during
cooking and not for general room illumination.
Extended use of the light reduces the average duration of the bulb.
• Replacing halogen light bulbs (Fig. 10).
To replace the halogen light bulbs B, remove the glass pane
C using a lever action on the relevant cracks. Replace the bulbs with new ones of the same type.
Caution: do not touch the light bulb with bare hands.
• Commands (Fig. 11):
Warning!
- When activating or deactivating the operations or the alarm, the motor and lights must be switched o.
- This product is supplied with an acoustic indicator (buzzer). Each time any button is pressed, this is conrmed
by an acoustic indicator.
- This function can be deactivated or activated, by simultaneously pressing the ON and TIMER buttons for
ve seconds.
- If your product is a recirculating version, it is necessary to activate the active carbon lters indicator function
which you nd in the paragraph regarding this function.
Button A = light (Softlight)
Starting:
A brief pressure on the light button will turn on the light at the maximum intensity, activating the fast softlight
function.
Adjustment:
By keeping the light button pressed, the intensity can be adjusted from maximum to minimum and vice-
versa.
Switching o:
Quick pressure of the light button.
Button B = OFF and Speed reduction
Adjustment:
A brief pressure of the OFF button will reduce the motor speed. For example the indication on the display goes
from speed 3 to speed 2.
speed 3
speed 2
Switching o:
If the operating speed of the motor is set on level 1 of the display, a brief pressure of the OFF button will switch
o the hood.
speed 1

- 7 -
If the OFF button is pressed for at least 2 seconds, regardless from the selected motor speed, the hood will
switch o.
OFF
Button C = Display
The display can alternate GREEN LEDs which indicate the motor speed, with RED LEDs which indicate the
alarm status (See special functions).
speed 1
speed 2
speed 3
speed 4
Button D = ON and Speed Increase
Starting:
In order to turn on the hood press button ON.
Adjustment:
A brief pressure of the ON button will increase the speed of the motor a step at a time.
1-
2-
3-
4-
INTENSIVE speed function:
If the ON button is kept pressed for about 2 seconds, the INTENSIVE speed function is activated for 10 minutes;
after this time, the previously set speed will be restored.
When the function is active LED 4 will ash
If you want to interrupt it before the 10 minutes have expired press the button again.
Button E = Timer
Operation:
The Timer button times the aspiration speed of the hood when it is activated for 10 MINUTES. After this time
has elapsed the appliance will switch o.

- 8 -
Activation:
In order to activate the function apply a light pressure to the Timer button.
When the function is active the LED indicator of the set speed starts ashing.
When the lights are on, at the end of the Timer function, these automatically reduce the light intensity by
30-40%.
In order to deactivate the function, before the predetermined time, a further pressure of the Timer button,
will switch o the appliance.
Warning! If the intensive speed is operating, the Timer cannot be activated.
• Special Functions (Button E)
Clean Air function:
This function guarantees the continuous recycling of the air in the kitchen for a maximum of 12 hours.
By keeping the Timer button pressed for 4 seconds, when the appliance is switched o, the “CLEAN AIR”
function is activated.
This turns on the motor for 10 minutes every hour at the rst speed; LED 4 ashes with an interval of 1
second ON and 2 seconds OFF.
After this time the motor is switched o and LED 4 remains xed on the display; after another 50 seconds the
motor starts again for another 10 minutes and so on.
- In order to deactivate the “clean air” function press any button except for the lights one.
• Alarm indicators
Active carbon/grease lter saturation:
When the LEDs on the display turn Red this means that the lters must be replaced or washed.
A – Anti grease lters:
When on the display the LED 1 is RED and starts ashing, it means that 30 hours have elapsed and that the
anti-grease lters have to be washed.
In order to reset the electronic memory press the OFF button for 5 seconds until LED 1 stops ashing.
B – Active Carbon lters:
When on the display the LED 2 is RED and starts ashing, it means that 120 hours have elapsed and that the
active carbon lters have to be replaced.
In order to reset the electronic memory press the OFF button for 5 seconds until LED 2 stops ashing.
Activation of the function for the indication of inserted active carbon lters:
By pressing simultaneously the OFF and ON buttons for 5 seconds the active carbon lters indicator function is
activated with an acoustic indicator of the Buzzer and the switching on for 1 second of all GREEN LEDs.
Deactivation of the inserted lters indicator function:
By pressing simultaneously the OFF andTIMER buttons for 5 seconds the active carbon lters indicator function
is deactivated with an acoustic indicator of the Buzzer and the switching on for 1 second of all RED LEDs.

- 9 -
- In order to check if the electronic memory has been activated or deactivated on the active carbon lters indica-
tors, press simultaneously the buttons LIGHT and TIMER for 5 seconds.
- if the function is active, the screen will display all the GREEN LEDs for 3 seconds.
- if the function is not active, the screen will display all the RED LEDs for 3 seconds.
Warning!
- Check that the Buzzer function has not been deactivated (see the warning at the beginning of the instructions
of this control).
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR EVENTUAL DAMAGES CAUSED BY BREACHING
THE ABOVE WARNINGS.

- 10 -

�
- 11 -

- 12 -

- 13 -

- 14 -

- 15 -

3LIK0638
Table of contents
Other Asko Ventilation Hood manuals

Asko
Asko CBB861S User manual

Asko
Asko CD4634B/4000 User manual

Asko
Asko CW4936S User manual

Asko
Asko CW4938GCN User manual

Asko
Asko CBB862WC User manual

Asko
Asko CW4931 User manual

Asko
Asko CBB761SC User manual

Asko
Asko A4402TRVS/E01 User manual

Asko
Asko CH060-60 User manual

Asko
Asko CW4939S/WS90FETGG User manual
Popular Ventilation Hood manuals by other brands

DCS
DCS EH-36SS Use and installation guide

ELICA
ELICA ASCENT Instruction on mounting and use

ELICA
ELICA Ciak Lux GRA 56 Instruction on mounting and use

AIRFORCE
AIRFORCE F121 SLIM Instruction on mounting and use

ELICA
ELICA SPOT PLUS Instruction on mounting and use

AIRFORCE
AIRFORCE F164 45 TLC Instruction on mounting and use
