Aspire BTC066000 User manual

USER MANUAL
MOBILE SHOWER COMMODES

3
Thank you for choosing this Stainless Steel
Commode from our Aspire Mobile Shower
Commode Range.
This product has been specifically designed
to oer comfort, support and safety.

4 5
TABLE OF CONTENTS
1. Introduction
2. Safety Precautions
3. Product Overview
4. Unpacking & Inspection
5. Assembly Instructions
6. Operation
7. Accessories
8. Troubleshooting
9. Cleaning
10. Service & Maintenance
11. Specifications
12. Warranty
5
6
8
11
15
19
21
22
23
24
25
26
1. INTRODUCTION
The Aspire Mobile Shower Commode range is designed for a healthcare
environment such as a facility or hospital. The commodes have a fabricated stainless
steel frame and utlise plastic and PU components of various material specifications.
Clinical Applications and Area of Use
These commodes are appropriate for adult patient care and should only be used
under the instruction of a carer or health professional.
Key Features
• Maximum Safe Working Load (SWL) of 200kg, 250kg & 400kg (dependent on
model)
• Attendant propelled and self propelled options available
• Height adjustability to accommodate dierent users (TIS model only)
• Stainless steel finish
• Swing back safety arms for ease of cleaning and transfer
• Soft PU seat range in open or closed variations (sold separately)
• Easy slide weight bearing platform or swing away legrest options available
• Access trough with improved over toilet clearance for easy hygiene access
• 8º - 18º backrest angle ensures patient comfort
• Angle adjustable backrest (swing away models only) for improved seating
comfort
• Ultra low seat height of 590mm or down to 490mm when customised (swing
away models only)

6 7
2. SAFETY PRECAUTIONS
It is important that this User Manual is read in its entirety prior to using the
commode. The manual is designed to ensure that users are equipped with the
information required to competently and responsibly operate this commode.
It is recommended that the User Manual be kept in an easily accessible place for
quick reference. If required, Aspire product specialists can provide additional
training.
All warnings and cautions within this manual should be strictly adhered to. Failure to
do so could result in harm to the patient or operator.
Warnings highlighted throughout this manual identify possible hazards in
procedures or conditions which if not followed correctly could result in serious
injury or fatality.
Cautions highlighted throughout this manual identify possible hazards in
procedures or conditions, which if not followed correctly could result in equipment
damage or failure.
GENERAL
• This commode is designed to be used indoors
• Suitable for wet areas but not pools
• The clinically qualified person responsible should consider the age, size and
condition of the patient before using the commode
• The maximum user weight is 200kg, 250kg or 400kg (dependent on model)
• ALWAYS check with your healthcare professional prior to using this commode.
• ALWAYS apply the brakes when the commode is stationary.
• ALWAYS ensure brakes remain locked when transferring into or out of the
commode.
• ALWAYS ensure that the legrests are swung away when transferring into and out
of the commode.
• ALWAYS ensure that attendant and patient limbs are free from potential
entrapment areas before operating any functions.
• DO NOT stand on the product.
• DO NOT use outdoors.
• DO NOT use this product without reading the user manual in its entirety.
• DO NOT use if defective.
• DO NOT make any changes or modifications to this product without consultation
from your Aspire Dealer.

8 9
3. PRODUCT OVERVIEW
The Aspire Mobile Shower Commode range is designed specifically for
the Aged Care and Hospital environments. Please take time to familiarise
yourself with key components shown below:
Swing back
Safety Arms
Swing back
Safety Arms
Adjustable Safety
Arms
Adjustable Safety
Arms
Self Propelled Wheels
(selected models only)
Access trough with
improved over toilet
clearance for easy
hygiene access
Swing Away
Legrests
Adjustable Height
Legrests
4 x Stainless Steel
Lockable Castors
4 x Stainless Steel
Lockable Castors
Soft PU Seat (Sold
Seperately)
Soft PU Seat (Sold
Seperately)
SWING AWAY LEGREST MODELS
WEIGHT BEARING PLATFORM MODELS
Access trough with
improved over toilet
clearance for easy
hygiene access
Easy-Slide Weight
Bearing Platform
Self Propelled Wheels
(selected models only)

10 11
TILT & RECLINE MODELS
Backrest Recline & Tilt
in Space Functionality
Swing Back
Safety Arms
Deep Access Trough
for Hygiene
Management
Swing Away Legrests
(Elevating Optional)
4 x Stainless Steel
Lockable Castors
Soft PU Seat
(Sold Seperately)
4. UNPACKING & INSPECTION
Aspire Mobile Shower Commodes come packaged in 1 box for maximum
protection. Check box to ensure no components are missing and contact
Aidacare if this occurs on 1300 133 120.
• Commode frame with backrest, safety arms & locking castors
• Swing away legrests (pair)
• User manual (in plastic bag)
• Seat mounting hardware (in plastic bag)
• Open or closed seat
• Pan carrier
• Commode bowl/bed pan
1
2
3
4
5
6
7
SWING AWAY LEGREST MODELS
IN CARTON
IN CARTON
13 2
4
7
5 6
SOLD SEPARATELY
SOLD SEPARATELY
Seat height
adjustment

12 13
• Commode frame with backrest, safety arms & locking castors
• User manual (in plastic bag)
• Seat mounting hardware (in plastic bag)
• Open or closed seat
• Pan carrier
• Commode bowl/bed pan
13
5
2
46
1
2
3
4
5
6
WEIGHT BEARING PLATFORM MODELS TILT & RECLINE MODELS
13
5 7
2
4
6
• Commode frame with backrest, safety arms, locking castors
• Swing away legrests (pair)
• User manual (in plastic bag)
• Seat mounting hardware (in plastic bag)
• Open or closed seat
• Pan carrier
• Commode bowl/bed pan
1
2
3
4
5
6
7
IN CARTON
SOLD SEPARATELY
SOLD SEPARATELY
IN CARTON
IN CARTON
IN CARTON
SOLD SEPARATELY
SOLD SEPARATELY

14 15
• Commode frame with backrest, safety arms, locking castors
• Swing away legrests (swing away legrest models only) (pair)
• Seat mounting hardware (in plastic bag)
• User manual (in plastic bag)
• Self propelling kit (wheels, brakes & anti-tippers)
• Open or closed seat
• Pan carrier
• Commode bowl/bed pan
1
2
3
4
5
6
7
8
SELF PROPELLING MODELS
13
5
7 8
2
4
6
5. ASSEMBLY INSTRUCTIONS
Step 1
Remove commode from box & clear
away all packaging materials.
Step 3
Attach legrests into lugs mounted
on commode frame & tighten with
screws underneath top lug
Step 5
Slide in pan carrier & bowl (sold separately).
Step 2
Detach screws that are fitted into
backrest, swing arms and backrest into
position and secure in place with screws.
Step 4
Using seat mounting hardware, ax the
seat (sold seperately) to the top of the
frame and screw in place until tight
SWING AWAY LEGREST MODELS
IN CARTON
IN CARTON
SOLD SEPARATELY
ASSEMBLY REQUIRED
SOLD SEPARATELY
ASSEMBLY REQUIRED
4
4
2
2
3
3
1
1

16 17
Step 1
Remove commode from box & clear
away all packaging materials.
Step 3
Using seat mounting hardware,
ax the seat (sold seperately)
to the top of the frame and screw
in place until tight
Step 2
Detach screws that are fitted into
backrest, swing arms and backrest into
position and secure in place with screws.
Step 4
Slide in pan carrier & bowl (sold
separately).
WEIGHT BEARING PLATFORM MODELS
Step 1
Remove commode from box & clear
away all packaging materials.
Step 2
Raise backrest into desired position , it
will click into place when secure. Slide in
top frame and secure with C Clips
Step 4
Using seat mounting hardware, ax the
seat (sold seperately) to the top of the
frame and screw in place until tight
Step 5
Slide in pan carrier & bowl (sold
separately).
TILT & RECLINE MODELS
1
2
1
2
1
1
2
2
6
6
5
543
Step 3
Attach legrests into lugs mounted
on commode frame & tighten with
screws underneath top lug 4
3

18 19
Step 1
Remove commode from box & clear
away all packaging materials.
Step 5
Slide in pan carrier & bowl (sold
separately).
Step 2
Detach screws that are fitted into
backrest, swing arms and backrest into
position and secure in place with screws.
Step 4
Using seat mounting hardware, ax the
seat (sold seperately) to the top of the
frame and screw in place until tight
Step 6
Remove locking pin from frame , insert
through centre of wheel , mount brake
with clamp onto each side of frame
detach rear castors and replace with anti-
tippers
SELF PROPELLING MODELS 6. OPERATION
Activating the Locking Castors - Attendant Propelled Models
• To engage, press the ON lever down with your foot
• To disengage, press the OFF lever down with your foot
Installing the Commode Seat (sold separately)
• Place seat onto top of frame and align along guides
• Using tri-wheel mounting kit (supplied with commode) screw the tri-
wheels firmly into place until seat is secured onto the frame
Activating the Brakes - Self Propelled Models
• Push down and forward on the black hand levers on both sides of the
commode to lock rear wheels in place
• Pull back on the hand lever to disengage brakes
1
1
1
5
5
7
7
1
2
2
1
1
2
2
2
2
3
3
4
4
2
1
Step 3
Attach legrests into lugs mounted
on commode frame & tighten with
screws underneath top lug
(swing away legrest models only).
2
1
6
6
8
8

20 21
Installing & Removing Pan Carrier & Commode Bowl/Pan
(sold separately)
• Holding the handle of pan carrier, insert the front end into the mounting rails
at the rear of the commode
• Place commode bowl or pan into pan carrier before sliding pan carrier
underneath seat
1
1
1
2
Adjusting the Legrests (Swing Away Legrest Models Only)
• Lift and swing the legrests to desired position
• If the user wishes to vacate the chair, swing the footrests outwards for
clearance. They can be completely removed by removing locking screw &
lifting upwards
Using Safety Armrests
• Swing armrests to desired position and ensure spring pin locks
into place
1
2
2
1
1
1
2
7. ACCESSORIES
Open Seat
BTC066600 - 460mm
BTC066750 - 530mm
BTC066800 - 600mm
Commode Bowl Carrier
BTC066400 -
460 - 600mm Commodes
Adjustable Thoracic
Support WCA867010
Advanced Headrest
BTC067050
Adjustable Pelvic Strap
BTC06710 0
Stump/Footrest Support
BTC067105
Self Propelling
Conversion Kit
BTC08290 0
Elevating Legrests
BTC067110 - Left
BTC067115 - Right
Adjustable IV Pole
BTC067103
Closed Seat
BTC066700 - 460mm
Oxygen Bottle Carrier
BTC067200
Hand Made Pressure
Reducing Seat - 460mm
BTC089130 - Open Front
BTC089140 - Closed Front
BTC089150 - Open Left
BTC089160 - Open Right
Armrest - Padded Offset
BTC067000
Commode Bowl
& Bed Pan
BTC081610 - Bowl & Lid
BTT151800 - Bed Pan

22 23
8. TROUBLESHOOTING
Fault Cause Solution
Difficulty in
removing/
adjusting
footrests
Build up of
material in
receivers
• Remove footrests, clean receivers and footrest
mounts
Difficulty
adjusting the
seat height
Build up of
material in
seat frame
adjustment
point
• Remove upper from lower frame and clean
thoroughly
Difficulty in
maneuvering
castors
Build up of dirt
between fork
and castor
• Clean castors thoroughly
Difficulty in
adjusting
commode seat
Build up of
material
between frame
and seat
• Remove seat and clean thoroughly
Should problems persist contact Aspire Service on 1300 133 120.
9. CLEANING
WARNING
Note: It is strongly recommended that protective clothing be used when cleaning.
• Frame and metal components - Always keep the commode clean for greater
comfort and long-lasting performance. Clean stainless steel components with
water and a mild detergent. Wipe dry.
• Brakes - The braking eect depends on the state of the tyre tread. Excessive
dirt build-up may negatively aect the application of the brakes. If necessary,
clean tyres with a small brush to remove dust and waste.
• Seat and backrest padding - Easy clean material that can be washed with water
and neutral soap/detergent.
• Commode Bowl - Remove and clean with water and a neutral soap/detergent.
CAUTION
Do not use abrasive Hypocarbonate or Phenolic compounds or pads.

24 25
10. SERVICE & MAINTENANCE
To prolong the working life of the commode and for trouble free operation it is
recommended that routine inspections should be performed by a person who is
suitably qualified and well acquainted with the design, use and care of Aspire Mobile
Shower Commodes.
If inspection reveals that the safety of the commode is compromised in any way, it
should be IMMEDIATELY WITHDRAWN FROM SERVICE, tagged as such and the
owner notified, until repair or replacement has occurred.
Inspection:
A visual and functional inspection should be performed monthly and every time the
commode changes user.
• Visually inspect mechanical components: Can you see damage, chips or
deformation to the frame, armrests, seat, backrest, legrests or commode bowl?
• Are the castors, wheels and brakes functioning as they should?
• Are all frame securement hand wheels present and tightened?
11. SPECIFICATIONS
200kg
200kg
200kg
200kg
400kg
200kg
200kg
200kg
200kg
250kg
250kg
200kg
200kg
560mm
560mm
560mm
560mm
560mm
560mm
560mm
560mm
560mm
460-
620mm
460-
620mm
560mm
560mm
590mm
590mm
590mm
590mm
590mm
490-
590mm
490-
590mm
490-
590mm
490-
590mm
460-
630mm
460-
630mm
490-
590mm
490-
590mm
225mm
225mm
225mm
225mm
290mm
225mm
225mm
225mm
225mm
275mm
275mm
225mm
225mm
305mm
305mm
305mm
305mm
300mm
305mm
305mm
305mm
305mm
900mm
900mm
305mm
305mm
995mm
995mm
995mm
995mm
995mm
895 -
995mm
895 -
995mm
995mm
995mm
1315-
1485mm
1315-
1485mm
995mm
995mm
535mm
665mm
605mm
735mm
725mm
535mm
665mm
675mm
805mm
560mm
630mm
605mm
735mm
460mm
460mm
530mm
530mm
600mm
460mm
460mm
600mm
600mm
460mm
530mm
530mm
530mm
BTC066000
Attendant Propelled - WB Platform
BTC066200
Self Propelled - WB Platform
BTC066050
Attendant Propelled - WB Platform
BTC066055
Self Propelled - WB Platform
BTC061400
Attendant Propelled - WB Platform
BTC065900
Attendant Propelled - Swing Away
Footrests
BTC066100
Self Propelled - Swing Away
Footrests
BTC061300
Attendant Propelled - Swing Away
Footrests
BTC061305
Self Propelled - Swing Away
Footrests
BTC066030
Attendant Propelled - Tilt &
Recline
BTC066040
Attendant Propelled - Tilt &
Recline
BTC066060
Attendant Propelled - Swing Away
BTC066065
Self Propelled - Swing Away
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
OVERALL
HEIGHT
BACKREST
HEIGHT
ARMREST
HEIGHT
UNIT
WEIGHT S.W.L
ANTERIOR
SEAT HEIGHT
POSTERIOR
SEAT HEIGHT
SEAT
WIDTH
OVERALL
WIDTH
SEAT
HEIGHT
OVERALL
HEIGHT
SEAT TO TOP
OF BACK
SEAT
WIDTH
SEAT
DEPTH
DISTANCE
FROM WALL
S.W.L
USER HEIGHT
GUIDE
kg
OVERALL
DEPTH
OVERALL
WIDTH
*Swing away model are only adjustable when customised

26
12. WARRANTY
Warranty
Aspire Mobile Shower Commodes come with a five year corrosion resistance
warranty on the external frame surface. If the product surface becomes damaged
this will void the warranty. A general one year warranty also applies covering faulty
workmanship or defective materials. This warranty is valid for twelve months from
the original purchase date, and to the original customer.
Aidacare is bound by Australian Consumer Law in respect to ‘Warranty against
Defects’ on this product. A copy of the Aidacare ‘Warranty against Defects’
statement is available at www.aidacare.com.au.
Please contact Aidacare directly for support in regard to warranty matters on
1300 133 120.
Aidacare does not warrant against faults caused by incorrect use, unauthorised
modification or any situation that could not be deemed as fair wear and tear.
The warranty on this product is a back to base warranty and does not cover
any freight costs pertaining to the return of any items under warranty. Aidacare
acknowledges and conforms to all ACCC guidelines around consumer rights. For
further information contact Aidacare 1300 133 120.
Aidacare will not guarantee the safety and the correct functioning of the product in
the case that any of the original components have been changed or modified and or
replaced with non–original Aspire approved parts. If any faults are detected upon
receiving the product please phone Aidacare to arrange a replacement. Any faults
that are detected during normal use should be reported to Aidacare immediately to
determine if warranty conditions apply and organise repair and/or replacement as
applicable.
For servicing, preventative maintenance and any other questions regarding this or
any other Aidacare product please contact:
Aidacare Pty Ltd
4 Noonan Rd, Ingleburn NSW 2565
T – 1300 133 120
W – www.aidacare.com.au
E – [e-mail]
Spare parts list available on request.

AIDACARE PTY LTD
4 Noonan Road, Ingleburn NSW 2565
1300 133 120
www.aidacare.com.au
MADE IN PR CHINA
ASUM22.20 231018
