Aspire LITE User manual

USER MANUAL
LITE WHEELCHAIRS
TABLE OF CONTENTS
1. Key Specifications
2. Components & Features
3. Assembly & Use
4. Troubleshooting
5. Care & Maintenance
6. Warnings
7. Warranty
8. Compliance
9. Service Maintenance & Customisation
3
4
6
7
8
7
9
9
10
ASPIRE LITE TRANSIT
ASPIRE LITE

2
Thank you for choosing this Aspire LITE
wheelchair.
This product has been designed to oer the
maximum in comfort, safety and portability.
Aspire LITE and Transit wheelchairs are
suitable for indoor and outdoor use. They are
easy to fold and extra light for putting in the
boot of a car.
It is important that you read this user manual
carefully before using your new wheelchair.

3
1. KEY SPECIFICATIONS
Aspire LITE
Aspire LITE Transit
Item Code MWS442300
Max. User Weight 120kg
Weight 9.5kg (chair weight) 8kg (transport weight)
Seat Height - adjustable
(floor to top of fabric) FRONT: 460mm REAR: 435mm
Seat Width 458mm (18”)
Seat Depth 400mm (16”)
Backrest Height (top of seat
to top of backrest handle) 465mm
Overall Width 550mm
Armrest Height (top of seat to
top of armrest pad) 234mm
Approvals TGA# 229423 AS/NZS tested and approved
Colour Blue frame with black upholstery
Rear Wheel 8” black
Item Code MWS442301
Max. User Weight 120kg
Weight 11.6kg (chair weight) 10.1kg (transport weight)
Seat Height - adjustable
(floor to top of fabric) FRONT: 460mm REAR: 445mm
Seat Width 458mm (18”)
Seat Depth 400mm (16”)
Backrest Height (top of seat
to top of backrest handle) 455mm
Overall Width 600mm
Armrest Height (top of seat to
top of armrest pad) 234mm
Approvals TGA# 229423 AS/NZS tested and approved
Colour Green frame with black upholstery
Rear Wheel 12.5” black

4
2. COMPONENTS & FEATURES
Aspire LITE
1. 8” Rear Wheels
2. Adjustable Armrests
3. Swing Away Legrests (Removable)
4. Castor Fork
5. 6” Front Castors
6. Folding Foot Plates
7. Attendant Hand Grips
8. Hand Brakes
9. Cross Bar
10. Folding Backrest & Upholstery
11. Seat Upholstery and Lap Belt
12. Carry Pouch on Seat Back
1
2
3
4
7
8
9
5
6
10
11

5
Aspire LITE Transit
1. 12.5” Rear Wheels
2. Adjustable Armrests
3. Swing Away Legrests (Removable)
4. Castor Fork
5. 6” Front Castors
6. Folding Foot Plates
7. Attendant Hand Grips
8. Attendant Hand Brakes
9. Cross Bar
10. Folding Backrest & Upholstery
11. Seat Upholstery and Lap Belt
12. Carry Pouch on Seat Back
1
2
3
4
5
6
7
9
10
8
11

6
3. Insert the footrests into
the top of the frame
receivers at a 90° angle
to the chair and swing
towards the centre of
the chair until the release
button engages with a
“click” sound
3. ASSEMBLY & USE
Open the carton carefully. DO NOT USE a box cutter or sharp implement as this may
damage the product. For OH&S, lay the carton on its side with the top of the carton
open and slide the plastic bag out containing the wheelchair.
1. Stand the wheelchair in
an upright position on the
ground
2. Push down on the
side seat rails of the
wheelchair until the seat
is flat to unfold the frame

7
Wheelchair is steering/pulling to one side
• Make sure the end user is able to evenly distribute his/her weight on the wheelchair
The wheelchair moves slowly
• Remove any hair or dirt from castor and rear wheel axles
• Make sure there is not too much weight applied to the castors, otherwise adjust the
centre of gravity
• Ensure user clothing is not interfering with movement of the rear wheels
• Ensure both brakes are disengaged
The wheelchair does not turn smoothly
• Make sure the front fork bolts are not over tightened which can restrict front castor
wheel rotation
• Remove any hair or dirt from castor axles
• Ensure both brakes are disengaged
The brakes do not work properly
• Check distance between tyres and brake foot is sucient such that the requisite
amount of force can be applied to the tyre surface to stop it moving when the brake
is in the engaged position
The wheelchair cannot be opened or folded easily
• Clean the crossbar under the seat and apply some grease
• Check that nothing has become lodged under the seat or in and around the cross
bar mechanism.
• Check foot plates are folded up
Correct adjustment of the wheelchair is essential for the successful and safe use of
this product.
Should assistance be required, contact the Aidacare Service Department on
1300 133 120.
4. TROUBLESHOOTING

8
5. CARE & MAINTENANCE
6. WARNINGS
Weekly Periodically Yearly Serviceable Components
• Check brakes
are functioning
properly
• Check for signs
of wear on front
castors
• Check for signs of
wear on rear tyres
Service to be
completed by
authorised Aspire
service agent
• Wheels
• Forks
• Axles
• Armrest receivers
• Seat sling
• Footrest mounts
• Brakes
MAINTENANCE SCHEDULE
CARE FOR YOUR CHAIR
• The nylon seat and backrest upholstery can be removed by simply loosening
the screws and washed with a wet sponge and a mild detergent. All other
components can be cleaned with a damp cloth.
• Always keep rear wheel axles free from dirt and hair buildup.
• Brakes should be checked regularly.
• If you have any doubts about the correct functioning of the wheelchair or of
any its components, please contact AIDACARE on 1300 133 120 or your local
Aspire distributor.
MAXIMUM WEIGHT CAPACITY: 120kg - NEVER EXCEED THIS WEIGHT LIMIT
• The foot plates are not designed to be a weight bearing surface. Never stand
on the footplates as the wheelchair may tip over.
• Pay attention to your fingers when folding or opening the wheelchair.
• Do not use the brakes to stop a moving wheelchair.
• Never use the wheelchair on escalators, even if accompanied by an attendant.

9
7. W A R R A N T Y
8. COMPLIANCE
Aspire Lite wheelchairs are manufactured in ISO compliant production facilities to
strict quality control standards.
As part of Australian Standards compliance, safety stickers are located on the frame
of this wheelchair. Please ensure that you familiarize yourself with these prior to use.
This product complies with Australian Standard AS/NZS 3695.1:2011. As the importer
of this product, Aidacare maintains records of all testing reports and compliance
certificates. All testing was completed by Novitatech Children’s Services in South
Australia.
Novitatech is an independent NATA accredited laboratory.
Aspire LITE wheelchairs have a one year warranty. Please keep the purchase invoice
as proof of warranty commencement.
Aidacare is bound by Australian Consumer Law in respect to ‘Warranty against
Defects’ on this product.A copy of the Aidacare ‘Warranty against Defects’ statement
is available o the Home page of our website at www.aidacare.com.au Any contact
in regard to warranty matters should be made to Aidacare Customer Service sta on
1300 133 120 or where support will be provided.
Aidacare does not warrant against excessive or incorrect use, modification or any
situation that could be deemed as fair wear and tear. Tyres and castor wheels carry
a 12 month warranty against manufacturer defects only, NOT wear and tear from
reasonable use.
The warranty on this product is a back to base warranty and does not cover
any freight costs pertaining to the return of any items under warranty. Aidacare
acknowledges and conforms to all ACCC guidelines around consumer rights. For
further information contact Aidacare 1300 133 120.
Aidacare will not guarantee the safety and the correct functioning of the wheelchair
in the case that any of the original components have been changed or modified and
or replaced with non-original Aidacare approved parts. If any faults are detected
upon receiving the wheelchair please phone Aidacare to arrange a replacement.
Any faults that are detected during normal use should be reported to Aidacare
immediately to determine if warranty conditions apply and organise repair and/or
replacement as applicable.

10
9. SERVICE MAINTENANCE
& CUSTOMISATION
When sending the chair back for warranty, service or repair work please include
all components such as leg rests. Please ensure wheelchair is clearly marked with
owner’s name and contact details.
To organise pickup by Aidacare, please call 1300 133 120, standard pickup and
delivery charges apply.
SPARE PARTS
Aidacare stocks replacement parts for the Aspire wheelchair range. All replacement
of parts should be completed by Aidacare or Aspire service technician. The term
parts includes but is not limited to: tyres, tubes, brakes, armrests, footrests and
upholstery.
A complete parts list is available upon request.
CUSTOMISATION AND MODIFICATION
All wheelchair customisation, modifications and or alterations made to this product
are considered as “custom” changes and will void the warranty term. These may
cause the product to no longer satisfy Australian Standards and should be considered
prior to commencement.
For customisation or modification work, contact AIDACARE on 1300 133 120. Our
team of qualified Rehab Engineers are available to assist if required.
FOR ALL ENQUIRIES, PLEASE CALL 1300 133 120

AIDACARE PTY LTD
4 Noonan Road, Ingleburn NSW 2565
1300 133 120
www.aidacare.com.au
MADE IN CHINA
