ASRock Industrial COM-652 User manual

1
COM-652
User Manual
Version 1.0
Published December 2, 2022
Copyright©2022 ASRockInd INC. All rights reserved.

2
Version 1.0
Published December 2, 2022
Copyright©2022 ASRockInd INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRockInd Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished
for informational use only and subject to change without notice, and should
not be constructed as a commitment by ASRockInd. ASRockInd assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRockInd does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRockInd, its directors, ocers, employees, or agents be liable
for any indirect, special, incidental, or consequential damages (including damages
for loss of prots, loss of business, loss of data, interruption of business and the
like), even if ASRockInd has been advised of the possibility of such damages arising
from any defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRockInd Website: http://www.asrockind.com

3
Contents
1 Introduction ....................................................... 4
1.1 Package Contents ......................................................... 4
1.2 Specications................................................................. 5
1.3 Layout ............................................................................ 7
2 Installation ......................................................... 9
2.1 Screw Holes................................................................... 9
2.2 Pre-installation Precautions ........................................... 9
2.3 Installation of Memory Modules (SO-DIMM).................. 10
2.4 Pin Denition.................................................................. 11
3 Software Support .............................................. 23
3.1 Install Operating System................................................ 23
3.2 Support CD Information ................................................. 23
3.2.1 Running Support CD ............................................ 23
3.2.2 Drivers Menu........................................................ 23
3.2.3 Utilities Menu........................................................ 23
3.2.4 Contact Information.............................................. 23

4
Chapter 1: Introduction
Thank you for purchasing ASRockInd COM-652 board, a reliable board produced
under ASRockInd’s consistently stringent quality control. It delivers excellent per-
formance with robust design conforming to ASRockInd’s commitment to quality and
endurance.
Because the motherboard specications and the BIOS software might be
updated, the content of this manual will be subject to change without no-
tice. In case any modications of this manual occur, the updated version
will be available on ASRockInd website without further notice. You may
nd the latest VGA cards and CPU support lists on ASRockInd website
as well. ASRockInd website http://www.asrockind.com
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
www.asrockind.com/support/index.asp
1.1 Package Contents
ASRock COM-652 Board (95 x 95mm (3.74-in x 3.74-in))

5
1.2 Specications
Form
Factor Dimensions COM Express Type6 (3.74-in x 3.74-in x 0.52-in,
9.5 cm x 9.5 cm x 1.3 cm)
Processor
System
CPU
COM Express Compact Size Type 6 Module
with Intel®8th Gen (Whiskey Lake-U) Core™
Processors
- COM-652P (i7-8665UE, QC, 1.7GHz, 15 W)
- COM-652M (i5-8365UE, QC, 1.6GHz, 15 W)
- COM-652V (i3-8145UE, DC, 2.2GHz, 15 W)
Chipset SoC
Socket BGA1528
BIOS AMI SPI 128 Mbit
Expansion PCIe 8 x PCIe x1 (Gen3)
Memory
Technology Dual Channel DDR4 2400 MHz
Capacity 32 GB (16 GB per DIMM)
Socket 2 x 260-pin SO-DIMM
Graphics
Controller Intel® Gen9 Graphics DX 11/12
HDMI HDMI 1.4b
Max resolution up to 4096x2160p 24Hz
DisplayPort DisplayPort 1.2, DP++
Max resolution up to 4096x2160@60Hz
VGA 1920x1200@60Hz
LVDS Dual channel 24 bit up to 1920x1200@60Hz
eDP eDP 1.4
Max resolution up to 3840 x 2160@60Hz
MultiDisplay Triple Display
Ethernet Ethernet
COM-652P/COM-652M:
1 x Intel®I219LM with 10/100/1000 Mbps,
supports AMT/vPro
COM-652V:
1 x Intel®I219V with 10/100/1000 Mbps
Controller N/A

6
I/O Interface
HDMI DD1 support HDMI/DP or VGA (optional)
DisplayPort DDI2 support HDMI/DP
USB 4 x USB 3.1 Gen1, 8 x USB 2.0
VGA 1
LVDS 1 (optional)
eDP 1 (optional)
TPM TPM 2.0 onboard IC (optional)
GPIO 4 x GPI, 4 x GPO
Ethernet 1
Storage
SATA 3 x SATA3 (6Gb/s)
RAID Intel®SATA RAID 0/1
eMMC 32GB (Optional)
Watchdog
Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR ATX: 12V±5%/5Vsb±5%
AT: 12V±5%
Power On
AT/ATX Supported
- AT: Directly PWR on as power input ready
- ATX: Press button to PWR on after power
input ready
Environment
Operating
Temp 0ºC ~ 60ºC
Storage
Temp -40°C ~ 85°C
Operating
Humidity 5% ~ 90%
Storage
Humidity 5% ~ 90%

7
1.3 Layout
Top Side View:

8
Back Side View:

9
Chapter 2: Installation
Before you install the board, study the conguration of your chassis to ensure that
the board ts into it.
Make sure to unplug the power cord before installing or removing the
board. Failure to do so may cause physical injuries to you and
damages to board components.
2.1 Screw Holes
Place screws into the holes to secure the board to the chassis.
Do not over-tighten the screws! Doing so may damage the board.
2.2 Pre-installation Precautions
Take note of the following precautions before you install board components or
change any board settings.
1. Unplug the power cord from the wall socket before touching any component.
2. To avoid damaging the board components due to static electricity,
NEVER place your board directly on the carpet or the like. Also
remember to use a grounded wrist strap or touch a safety grounded object
before you handle components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded antistatic pad or
in the bag that comes with the component.
Before you install or remove any component, ensure that the power is
switched o󰀨 or the power cord is detached from the power supply.
Failure to do so may cause severe damage to the board, peripherals,
and/or components.

10
2.3 Installation of Memory Modules (SO-DIMM)
COM-652 provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots.
Step 1. Align a SO-DIMM on the slot such that the notch on the SO-DIMM
matches the break on the slot.
The SO-DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the SO-DIMM if you force the SO-DIMM into the slot at
incorrect orientation.
Step 2. Firmly insert the SO-DIMM into the slot until the retaining clips at both
ends fully snap back in place and the SO-DIMM is properly seated.

11
2.4 Pin Denition
Pin List Signal Row A Pwr Rail Level / Pin Description
A1 GND(FIXED) GND
A2 GBE0_MDI3- 3.3V level
A3 GBE0_MDI3+ 3.3V level
A4 GBE0_LINK100# 3.3V level
A5 GBE0_LINK1000# 3.3V level
A6 GBE0_MDI2- 3.3V level
A7 GBE0_MDI2+ 3.3V level
A8 NC NC
A9 GBE0_MDI1- 3.3V level
A10 GBE0_MDI1+ 3.3V level
A11 GND(FIXED) GND
A12 GBE0_MDI0- 3.3V level
A13 GBE0_MDI0+ 3.3V level
A14 GBE0_CTREF 3.3V level
A15 SUS_S3# 3.3V level
A16 SATA0_TX+ AC coupled on Module
A17 SATA0_TX- AC coupled on Module
A18 SUS_S4# 3.3V level
A19 SATA0_RX+ AC coupled on Module
A20 SATA0_RX- AC coupled on Module
A21 GND(FIXED) GND
A22 SATA2_TX+ AC coupled on Module
A23 SATA2_TX- AC coupled on Module
A24 SUS_S5# 3.3V level
A25 SATA2_RX+ AC coupled on Module
A26 SATA2_RX- AC coupled on Module
A27 BATLOW# 3.3V level
A28 SATA_ACT# 3.3V level
A29 AC/HDA_SYNC 3.3V level
A30 AC/HDA_RST# 3.3V level
A31 GND(FIXED) GND
A32 AC/HDA_BITCLK 3.3V level
A33 AC/HDA_SDOUT 3.3V level
A34 NC NC
A35 THRMTRIP# 3.3V level
A36 USB6- 3.3V level
A37 USB6+ 3.3V level
A38 USB_6_7_OC# 3.3V level
A39 USB4- 3.3V level
A40 USB4+ 3.3V level
A41 GND(FIXED) GND
A42 USB2- 3.3V level
A43 USB2+ 3.3V level
A44 USB_2_3_OC# 3.3V level
A45 USB0- 3.3V level
Row A:

12
Pin List Signal Row A Pwr Rail Level / Pin Description
A46 USB0+ 3.3V level
A47 VCC_RTC 3.3V level
A48 NC NC
A49 NC NC
A50 LPC_SERIRQ 3.3V level
A51 GND(FIXED) GND
A52 PCIE_TX5+ AC coupled on Module
A53 PCIE_TX5- AC coupled on Module
A54 GPI0 3.3V level
A55 PCIE_TX4+ AC coupled on Module
A56 PCIE_TX4- AC coupled on Module
A57 GND GND
A58 PCIE_TX3+ AC coupled on Module
A59 PCIE_TX3- AC coupled on Module
A60 GND(FIXED) GND
A61 PCIE_TX2+ AC coupled on Module
A62 PCIE_TX2- AC coupled on Module
A63 GPI1 3.3V level
A64 PCIE_TX1+ AC coupled on Module
A65 PCIE_TX1- AC coupled on Module
A66 GND GND
A67 GPI2 3.3V level
A68 PCIE_TX0+ AC coupled on Module
A69 PCIE_TX0- AC coupled on Module
A70 GND(FIXED) GND
A71 LVDS_A0+ LVDS DATA
A72 LVDS_A0- LVDS DATA
A73 LVDS_A1+ LVDS DATA
A74 LVDS_A1- LVDS DATA
A75 LVDS_A2+ LVDS DATA
A76 LVDS_A2- LVDS DATA
A77 LVDS_VDD_EN 3.3V level
A78 LVDS_A3+ LVDS DATA
A79 LVDS_A3- LVDS DATA
A80 GND(FIXED) GND
A81 LVDS_A_CK+ LVDS CLOCK
A82 LVDS_A_CK- LVDS CLOCK
A83 LVDS_I2C_CK 3.3V level
A84 LVDS_I2C_DAT 3.3V level
A85 GPI3 3.3V level
A86 PWRDN 3.3V level / LVDS Power Down Control
A87 eDP_HPD 3.3V level
A88 PCIE_CLK_REF+ PCIE CLOCK
A89 PCIE_CLK_REF- PCIE CLOCK
A90 GND(FIXED) GND

13
Pin List Signal Row A Pwr Rail Level / Pin Description
A91 SPI_POWER 3.3V level
A92 SPI_MISO 3.3V level
A93 GPO0 3.3V level
A94 SPI_CLK 3.3V level
A95 SPI_MOSI 3.3V level
A96 TPM_PP 3.3V level
A97 NC NC
A98 NC NC
A99 NC NC
A100 GND(FIXED) GND
A101 NC NC
A102 NC NC
A103 LID# 3.3V level
A104 VCC_12V 12V level
A105 VCC_12V 12V level
A106 VCC_12V 12V level
A107 VCC_12V 12V level
A108 VCC_12V 12V level
A109 VCC_12V 12V level
A110 GND(FIXED) GND

14
Pin List Signal Row B Pwr Rail Level / Pin Description
B1 GND(FIXED) GND
B2 GBE0_ACT# 3.3V level
B3 LPC_FRAME# 3.3V level
B4 LPC_AD0 3.3V level
B5 LPC_AD1 3.3V level
B6 LPC_AD2 3.3V level
B7 LPC_AD3 3.3V level
B8 NC NC
B9 NC NC
B10 LPC_CLK 3.3V level
B11 GND(FIXED) GND
B12 PWRBTN# 3.3V level
B13 SMB_CK 3.3V level
B14 SMB_DAT 3.3V level
B15 SMB_ALERT# 3.3V level
B16 SATA1_TX+ AC coupled on Module
B17 SATA1_TX- AC coupled on Module
B18 SUS_STAT# 3.3V level
B19 SATA1_RX+ AC coupled on Module
B20 SATA1_RX- AC coupled on Module
B21 GND(FIXED) GND
B22 NC NC
B23 NC NC
B24 PWR_OK 3.3V level
B25 NC NC
B26 NC NC
B27 WDT 3.3V level
B28 NC NC
B29 NC NC
B30 AC/HDA_SDIN0 3.3V level
B31 GND(FIXED) GND
B32 SPKR 3.3V level
B33 I2C_CK 3.3V level
B34 I2C_DAT 3.3V level
B35 THRM# 3.3V level
B36 USB7- 3.3V level
B37 USB7+ 3.3V level
B38 USB_4_5_OC# 3.3V level
B39 USB5- 3.3V level
B40 USB5+ 3.3V level
B41 GND(FIXED) GND
B42 USB3- 3.3V level
B43 USB3+ 3.3V level
B44 USB_0_1_OC# 3.3V level
B45 USB1- 3.3V level
Row B:

15
Pin List Signal Row B Pwr Rail Level / Pin Description
B46 USB1+ 3.3V level
B47 NC NC
B48 NC NC
B49 SYS_RESET# 3.3V level
B50 CB_RESET# 3.3V level
B51 GND(FIXED) GND
B52 PCIE_RX5+ AC coupled on Module
B53 PCIE_RX5- AC coupled on Module
B54 GPO1 3.3V level
B55 PCIE_RX4+ AC coupled on Module
B56 PCIE_RX4- AC coupled on Module
B57 GPO2 3.3V level
B58 PCIE_RX3+ AC coupled on Module
B59 PCIE_RX3- AC coupled on Module
B60 GND(FIXED) GND
B61 PCIE_RX2+ AC coupled on Module
B62 PCIE_RX2- AC coupled on Module
B63 GPO3 3.3V level
B64 PCIE_RX1+ AC coupled on Module
B65 PCIE_RX1- AC coupled on Module
B66 WAKE0# 3.3V level / WAKE#
B67 WAKE1# 3.3V level / PME#
B68 PCIE_RX0+ AC coupled on Module
B69 PCIE_RX0- AC coupled on Module
B70 GND(FIXED) GND
B71 LVDS_B0+ LVDS DATA
B72 LVDS_B0- LVDS DATA
B73 LVDS_B1+ LVDS DATA
B74 LVDS_B1- LVDS DATA
B75 LVDS_B2+ LVDS DATA
B76 LVDS_B2- LVDS DATA
B77 LVDS_B3+ LVDS DATA
B78 LVDS_B3- LVDS DATA
B79 LVDS_BKLT_EN 3.3V level
B80 GND(FIXED) GND
B81 LVDS_B_CK+ LVDS CLOCK
B82 LVDS_B_CK- LVDS CLOCK
B83 LVDS_BKLT_CTRL 3.3V level
B84 VCC_5V_SBY 5V level
B85 VCC_5V_SBY 5V level
B86 VCC_5V_SBY 5V level
B87 VCC_5V_SBY 5V level
B88 NC NC
B89 VGA_RED Analog
B90 GND(FIXED) GND

16
Pin List Signal Row B Pwr Rail Level / Pin Description
B91 VGA_GRN Analog
B92 VGA_BLU Analog
B93 VGA_HSYNC 3.3V / 5V level (By BOM option)
B94 VGA_VSYNC 3.3V / 5V level (By BOM option)
B95 VGA _I2C_CK 3.3V level
B96 VGA_I2C_DAT 3.3V level
B97 SPI_CS# 3.3V level
B98 BLUP Panel Dynamic Backlight Control (UP)
B99 BLDN Panel Dynamic Backlight Control (DOWN)
B100 GND(FIXED) GND
B101 FAN_PWNOUT 3.3V level
B102 FAN_TACHIN 3.3V level
B103 SLEEP# 3.3V level
B104 VCC_12V 12V level
B105 VCC_12V 12V level
B106 VCC_12V 12V level
B107 VCC_12V 12V level
B108 VCC_12V 12V level
B109 VCC_12V 12V level
B110 GND(FIXED) GND

17
Pin List Signal Row C Pwr Rail Level / Pin Description
C1 GND(FIXED) GND
C2 GND GND
C3 USB_SSRX0- AC coupled on Module
C4 USB_SSRX0+ AC coupled on Module
C5 GND GND
C6 USB_SSRX1- AC coupled on Module
C7 USB_SSRX1+ AC coupled on Module
C8 GND GND
C9 USB_SSRX2- AC coupled on Module
C10 USB_SSRX2+ AC coupled on Module
C11 GND(FIXED) GND
C12 USB_SSRX3- AC coupled on Module
C13 USB_SSRX3+ AC coupled on Module
C14 GND GND
C15 NC NC
C16 NC NC
C17 GPIO_VOL_UP Panel Dynamic Volume Control (UP)
C18 GPIO_VOL_DN Panel Dynamic Volume Control (DOWN)
C19 PCIE_RX6+ AC coupled on Module
C20 PCIE_RX6- AC coupled on Module
C21 GND(FIXED) GND
C22 PCIE_RX7+ AC coupled on Module
C23 PCIE_RX7- AC coupled on Module
C24 DDI1_HPD 3.3V level
C25 NC NC
C26 NC NC
C27 NC NC
C28 NC NC
C29 NC NC
C30 NC NC
C31 GND(FIXED) GND
C32 DDI2_CTRLCLK_AUX+ AC coupled on Module
C33 DDI2_CTRLDATA_AUX- AC coupled on Module
C34 DDI2_DDC_AUX_SEL 3.3V level
C35 NC NC
C36 NC NC
C37 NC NC
C38 NC NC
C39 NC NC
C40 NC NC
C41 GND(FIXED) GND
C42 NC NC
C43 NC NC
C44 NC NC
C45 NC NC
Row C:

18
Pin List Signal Row C Pwr Rail Level / Pin Description
C46 NC NC
C47 NC NC
C48 NC NC
C49 NC NC
C50 NC NC
C51 GND(FIXED) GND
C52 NC NC
C53 NC NC
C54 NC NC
C55 NC NC
C56 NC NC
C57 NC NC
C58 NC NC
C59 NC NC
C60 GND(FIXED) GND
C61 NC NC
C62 NC NC
C63 NC NC
C64 NC NC
C65 NC NC
C66 NC NC
C67 NC NC
C68 NC NC
C69 NC NC
C70 GND(FIXED) GND
C71 NC NC
C72 NC NC
C73 GND GND
C74 NC NC
C75 NC NC
C76 GND GND
C77 NC NC
C78 NC NC
C79 NC NC
C80 GND(FIXED) GND
C81 NC NC
C82 NC NC
C83 NC NC
C84 GND GND
C85 NC NC
C86 NC NC
C87 GND GND
C88 NC NC
C89 NC NC
C90 GND(FIXED) GND

19
Pin List Signal Row C Pwr Rail Level / Pin Description
C91 NC NC
C92 NC NC
C93 GND GND
C94 NC NC
C95 NC NC
C96 GND GND
C97 MFG_NET_CON MFG (RSVD for internal use)
C98 NC NC
C99 NC NC
C100 GND(FIXED) GND
C101 NC NC
C102 NC NC
C103 GND GND
C104 VCC_12V 12V level
C105 VCC_12V 12V level
C106 VCC_12V 12V level
C107 VCC_12V 12V level
C108 VCC_12V 12V level
C109 VCC_12V 12V level
C110 GND(FIXED) GND

20
Pin List Signal Row D Pwr Rail Level / Pin Description
D1 GND(FIXED) GND
D2 GND GND
D3 USB_SSTX0- AC coupled on Module
D4 USB_SSTX0+ AC coupled on Module
D5 GND GND
D6 USB_SSTX1- AC coupled on Module
D7 USB_SSTX1+ AC coupled on Module
D8 GND GND
D9 USB_SSTX2- AC coupled on Module
D10 USB_SSTX2+ AC coupled on Module
D11 GND(FIXED) GND
D12 USB_SSTX3- AC coupled on Module
D13 USB_SSTX3+ AC coupled on Module
D14 GND GND
D15 DDI1_CTRLCLK_AUX+ AC coupled on Module
D16 DDI1_CTRLDATA_AUX- AC coupled on Module
D17 NC NC
D18 NC NC
D19 PCIE_TX6+ AC coupled on Module
D20 PCIE_TX6- AC coupled on Module
D21 GND(FIXED) GND
D22 PCIE_TX7+ AC coupled on Module
D23 PCIE_TX7- AC coupled on Module
D24 NC NC
D25 NC NC
D26 DDI1_PAIR0+ AC coupled o󰀨 Module
D27 DDI1_PAIR0- AC coupled o󰀨 Module
D28 NC NC
D29 DDI1_PAIR1+ AC coupled o󰀨 Module
D30 DDI1_PAIR1- AC coupled o󰀨 Module
D31 GND(FIXED) GND
D32 DDI1_PAIR2+ AC coupled o󰀨 Module
D33 DDI1_PAIR2- AC coupled o󰀨 Module
D34 DDI1_DDC_AUX_SEL AC coupled on Module
D35 NC NC
D36 DDI1_PAIR3+ AC coupled o󰀨 Module
D37 DDI1_PAIR3- AC coupled o󰀨 Module
D38 NC NC
D39 DDI2_PAIR0+ AC coupled o󰀨 Module
D40 DDI2_PAIR0- AC coupled o󰀨 Module
D41 GND(FIXED) GND
D42 DDI2_PAIR1+ AC coupled o󰀨 Module
D43 DDI2_PAIR1- AC coupled o󰀨 Module
D44 DDI2_HPD 3.3V level
D45 NC NC
Row D:
