Assa Abloy HES 5000 Series Manual

1 of 4
5000 | 5300 Series
Electric Strikes
Installation & Operating Instructions
Product Contents
A 5000/5300 Electric Strike Body
B Trim Enhancer (with screws)
C 12 & 24 Volt Pigtails
Electrical Specifications
Electrical Ratings For Solenoid
CONTINUOUS DUTY INTERMITTENT DUTY*
12 VDC 24 VDC 12-16 VAC 24 VDC
Resistance in Ohms 50 200 50 200
Amps .24 .12 .24-.32 .12
Solenoids are rated at +/- 10% indicated value.
*10% max duty cycle (2 min. max on time) Indoor use only
Minimum Wire Gauge Requirements
SOLENOID VOLTAGE
12 VDC 24 VDC
200 feet or less 18 gauge 20 gauge
200 – 300 feet 16 gauge 18 gauge
300 – 400 feet 14 gauge 16 gauge
A
B
Diagram 1: Product Components
C
CAUTION! Before connecting any device at the installation site, verify input voltage using a multimeter.
Many power supplies and low voltage transformers operate at higher levels than listed. Any input voltage
exceeding 10% of the solenoid rating may cause severe damage to the unit and will void the warranty.

2 of 4
Diagram 2 12 V to 24 V Conversion
Prepare Strike
1. SELECT the appropriate Plug In Connector that
matches system power and electrically connect as
illustrated in Diagram 2.
FOR 12 V AC/DC OR 16 V AC, the pigtail marked
“12 VDC” should be used.
FOR 24 V AC/DC, the pigtail marked
“24 VDC” should be used.
2. VERIFY that the strike is in the correct mode of
operation. This unit ships in Fail Secure mode. If
you need to convert to Fail Safe see Diagram 4.
3. If using LATCHBOLT MONITOR (LBM)
see Diagram 3 to complete wiring.
Prepare Frame
1. PREPARE frame using appropriate
template for your faceplate.
2. ATTACH faceplate to strike body.
Finish Installing
1. CONNECT wires from the power source to the strike.
2. INSTALL the electric strike unit in jamb cutout using
the screws provided with the faceplate option kit.
LBM WIRING
White Common
Orange Normally Open
Green Normally Closed
Convert Mode
1. LOOSEN the two #2-56 screws located on the back
of the strike as shown, but do not remove them.
2. MOVE screws from the top of the hole
(Fail Secure position) to the bottom hole
(Fail Safe position) as shown above.
3. TIGHTEN screws.
Verify
4. VERIFY the strike is now in the Fail Safe operation
mode. If the strike still operates as Fail Secure, be
sure screws are fully seated in the bottom position.
WHITE
ORANGE
GREEN
RED
RED/GREEN
BLACK
VIOLET
RED
BLACK
VIOLET
RED/GREEN
IF CONNECTOR IS MISSING
(+ 12 VDC)
(- NEG)
(+ 24 VDC)
(- NEG)
ELECTRIC
STRIKE
ELECTRIC
STRIKE
CONNECT
TOGETHER
CONNECT
TOGETHER
CONNECT
TOGETHER
Diagram 3 Latchbolt Monitor
Diagram 4 Fail Safe Conversion
Fail Safe Conversion
Installation Directions
Fail Safe Position
Fire rating only applies to Fail Secure Units.
Conversion to Fail Safe negates fire rating on 5300.

3 of 4
ANSI Metal Jamb Installations
501 Faceplate
Aluminum Jamb Installations
501A Faceplate
Aluminum Frame Installations
502 Faceplate
Diagram 5 501 Faceplate
4-7/8" x 1-1/4" Square Corner
Diagram 6
501A Faceplate
4-7/8" x 1-1/4"
Radius Corner
Diagram 7
502 Faceplate
7-15/16" x 1-7/16"
Radius Corner
3-3/8"
[85.7mm]
1-1/4"
[31.8mm]
4-7/8"
[124mm]
11/16"
[17.5mm]
[2.3mm]
3/32"
1 -1/4"
[31.8mm]
4 -7/8"
[124mm]
4 -1/8"
[104.8mm] 1 -7/16"
[36.6mm]
1-1/4"
[31.8mm]
4-7/8"
[124mm]
3-3/8"
[85.7mm]
11/16"
[17.5mm]
3/32"
[2.3mm]
4 -7/8"
[124mm]
4 -1/8"
[104.8mm]
1 -7/16"
[36.6mm]
1 -1/4"
[31.8mm]
R 1/8"
[3mm]
3-3/8"
[85.7mm]
11/16"
[17.5mm]
3/32"
[2.3mm]
1 -7/16"
[36.5mm]
7-15/16"
[201.6mm]
1-7/16"
[36.6mm]
7-15/16"
[201.6mm]
7-7/16"
[189mm]
1-7/16"
[36.6mm]
R 3/16"
[4.1mm]

4 of 4
Printed in the U.S.A.
Patent pending and/or patent www.assaabloydss.com/patents
Copyright © 2023, Hanchett Entry Systems, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Hanchett Entry Systems, Inc. is prohibited. 3019006.003_5
