Asus ROG PHONE ZS660KL User manual

ZS660KL
User Guide

2
Care and safety
Guidelines
Road safety comes rst. We strongly recommend not to use your device when
driving or operating any type of vehicle.
This device should only be used in environments with ambient temperatures
between 0°C (32°F) and 35°C (95°F).
Turn o your device in restricted areas where the use of mobile devices is prohibited.
Always obey rules and regulations when in restricted areas, such as, in aircraft, movie
theater, in hospitals or near medical equipment, near gas or fuel, construction sites,
blasting sites and other areas.
Use only AC adapters and cables approved by ASUS for use with this device. Refer to
the rating label on the bottom of your device and ensure that your power adapter
complies with this rating.
Do not use damaged power cables, accessories, and other peripherals with your
device.
Keep your device dry. Do not use or expose your device near liquids, rain, or
moisture.
You can put your device through x-ray machines (such as those used in conveyor
belts for airport security), but do not expose the device to magnetic detectors and
wands.
The device screen is made of glass. If the glass gets broken, stop using the device
and do not touch the broken glass parts. Immediately send device for repair to
ASUS-qualied service personnel.
Do not listen at high volume levels for long periods to prevent possible hearing
damage.
Disconnect the AC power before cleaning your device. Use only a clean cellulose
sponge or chamois cloth when cleaning your device screen.
Send device for repair to ASUS-qualied service personnel only.
E15441
August 2019
First Edition
Notify the customer of a change of premises
We, ASUS Computer International, will move to a new location on August 1st, 2018.
New address and telephone number are shown as follows:
New Address: 48720 Kato Rd., Fremont, CA 94538
Telephone Number: [phone]
Kindly forward your contacts to the above address after the date.

3
Proper disposal
Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
DO NOT throw the battery in municipal waste. The symbol of the crossed out
wheeled bin indicates that the battery should not be placed in municipal waste.
DO NOT throw this product in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. The symbol of the crossed out wheeled
bin indicates that the product (electrical, electronic equipment and mercury-
containing button cell battery) should not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw this product in re. DO NOT short circuit the contacts. DO NOT
disassemble this product.
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)
WARNING
Cancer and Reproductive Harm-
www.P65Warnings.ca.gov
NOTE: The app descriptions shown in this manual are for reference purposes only, and may not
exactly match what you see on your device.
NOTE: For more legal and e-labelling information, check on your device from Settings > About > Legal
information / Regulatory labels.

4
1 Basics
Welcome!.................................................................................................................................................. 7
Get your ROG Phone ready!............................................................................................................... 8
AeroActive Cooler (optional) feature ............................................................................................. 9
Attaching the Footstand to the AeroActive Cooler ................................................................10
Starting for the rst time ..................................................................................................................18
Using the touchscreen.......................................................................................................................19
2 There’s no place like Home
Zen Home features .....................................................................................................22
Home screen .........................................................................................................................................22
Quick settings.......................................................................................................................................23
Notications..........................................................................................................................................24
Personalizing your Home screen...............................................................................25
Widgets ..................................................................................................................................................25
Wallpapers .............................................................................................................................................26
Setting up the date and time..........................................................................................................27
Setting up your ringtone and alert sounds................................................................................27
Lock Screen .................................................................................................................28
Customizing your lock screen.........................................................................................................28
Fingerprint ID sensor..................................................................................................29
Starting your ROG Phone for the rst time................................................................................29
Setting up ngerprint ID from Settings ......................................................................................30
Face Unlock .................................................................................................................31
Setting up face unlock from Settings...........................................................................................31
3 Work hard, play harder
Chrome ........................................................................................................................34
Launching Chrome .............................................................................................................................34
Sharing pages.......................................................................................................................................35
Bookmarking pages ...........................................................................................................................35
Clearing the browsing data .............................................................................................................35
Gmail............................................................................................................................36
Google Calendar .........................................................................................................37
Creating events ....................................................................................................................................37
Editing or removing events .............................................................................................................37
Creating reminders.............................................................................................................................38
Editing or removing reminders ......................................................................................................38
File Manager................................................................................................................39
The Cloud.....................................................................................................................40
ASUS WebStorage ...............................................................................................................................40
Armoury Crate.............................................................................................................41
Contents

5
4 Keeping in touch
Call in style ..................................................................................................................42
Dual SIM feature...................................................................................................................................42
Making calls...........................................................................................................................................44
Receiving calls ......................................................................................................................................46
Other call options................................................................................................................................47
Answering another call .....................................................................................................................48
Recording calls .....................................................................................................................................48
Managing contacts .....................................................................................................49
Contacts Settings ................................................................................................................................49
Setting up your prole ......................................................................................................................49
Adding contacts...................................................................................................................................50
Marking your favorite contacts ......................................................................................................51
Social networking with your contacts.........................................................................................52
Send messages and more ..........................................................................................53
Messages................................................................................................................................................53
5 Fun and entertainment
Using a headset...........................................................................................................54
Connecting the audio jack...............................................................................................................54
Google Play Music ......................................................................................................55
6 Your precious moments
Capture moments .......................................................................................................56
Launching the Camera app .............................................................................................................56
Using the Gallery ........................................................................................................58
Sharing les from the Gallery..........................................................................................................58
Deleting les from the Gallery........................................................................................................58
Editing images......................................................................................................................................58
7 Staying connected
Mobile network...........................................................................................................59
Enabling the mobile network .........................................................................................................59
Wi-Fi .............................................................................................................................59
Enabling Wi-Fi.......................................................................................................................................59
Connecting to a Wi-Fi network.......................................................................................................60
Disabling Wi-Fi......................................................................................................................................60
Bluetooth®...................................................................................................................60
Enabling Bluetooth®...........................................................................................................................60
Pairing your ROG Phone to a Bluetooth® device......................................................................61
Unpairing your ROG Phone from the Bluetooth® device......................................................61
Tethering .....................................................................................................................62
Wi-Fi Hotspot .........................................................................................................................................62
Bluetooth Tethering............................................................................................................................63

6
8 Travel and Maps
Weather .......................................................................................................................64
Launching the Weather app............................................................................................................64
Weather home screen........................................................................................................................65
Clock ............................................................................................................................66
World Clock............................................................................................................................................66
Alarm clock ............................................................................................................................................67
Stopwatch ..............................................................................................................................................67
Timer........................................................................................................................................................68
9 Zen Everywhere
Special Zen Tools.........................................................................................................69
Sound Recorder ...................................................................................................................................69
AirTriggers..............................................................................................................................................71
10 Maintain your Zen
Keeping your device up-to-date................................................................................75
Updating your system .......................................................................................................................75
Storage....................................................................................................................................................75
Backup.....................................................................................................................................................75
Reset.........................................................................................................................................................75
Securing your ROG Phone................................................................................................................76
Appendix
Safety information......................................................................................................79
Notices .........................................................................................................................81
Index

7
Chapter 1: Basics
Basics 1
1 Basics
Welcome!
Explore the intuitive simplicity of ASUS ZenUI!
ASUS ZenUI is a charming and intuitive interface exclusively for ROG Phones. It provides you with
special apps, which are integrated in or with other apps, to t your unique individual needs and
make your life easier while letting you have fun with your ROG Phone.
Camera
With PixelMaster technology, capture those precious moments in vivid and high-quality
photos and videos.
File Manager
File Manager allows you to easily locate and manage your data on the internal storage
of your ROG Phone and its connected external storage devices.
NOTE: Availability of ASUS ZenUI apps vary per region and ROG Phone model. Swipe up from the
lower part of your Home screen to check the apps available on your ROG Phone.

8 Chapter 1: Basics
Get your ROG Phone ready!
Parts and features
Take a hold of your device and have it running in a jiy.
WARNING!
• Toavoidnetworkconnectionandbatteryissues:
 • DONOTplaceametallicstickerontheantennaarea.
 • DONOTuseametallicprotectiveframe/caseonyourROGPhone.
 • DONOTcovertheantennaareawithyourhandsorotherobjectswhileusingsomefunctionssuch
as making calls or using the mobile data connection.
• WerecommendthatyouuseASUS-compatiblescreenprotectors.Usingnon-ASUS-compatible
screen protectors may cause your ROG Phone's sensor to malfunction.
NOTES:
• The USB Type-C port supports USB 2.0 transfer rate. The Side Mount connector Type-C port supports
USB 3.1 Gen1 transfer rate.
• Go to Settings > Advanced > AirTriggers to set AirTriggers.
IMPORTANT!
• Wedonotrecommendusingascreenprotectorasitcaninterferewiththeproximitysensor.Ifyou
want to use a screen protector, ensure that it does not block the proximity sensor.
• Keepthedevice,particularlythetouchscreen,dryallthetime.Waterorotherliquidscancausethe
touch screen to malfunction.
USB Type-C port
Speaker
LED indicator
Touch screen
display
Front camera
Receiver & Speaker
Proximity sensor
and light sensor
Nano SIM card
tray eject hole
Audio jack
Power key
Volume key
Camera ash
Rear cameras
Microphone
NFC detection
area
Microphone
Nano SIM
card slot
Side Mount
connector Microphone
Air Trigger
touch sensor
Air Trigger
touch sensor
Aura light
Rear cover
Fingerprint sensor
Microphone
Bumper RGB LED
802.11ad
antenna area

9
Chapter 1: Basics
AeroActive Cooler (optional) feature
Use the optional AeroActive Cooler to keep your ROG Phone working at a high frequency during
heavy workloads by providing a better thermal solution, and oering the ultimate user experience.
To install the AeroActive Cooler:
1. Place your smartphone in a horizontal position.
2. Place the AeroActive Cooler on the back side of your phone with the ROG logo facing outwards.
3. Insert the USB plug of the AeroActive Cooler into the Side Mount connector of your Phone.
4. Push the top part of the AeroActive Cooler and snap the clip on the top side.
Fan
Aura light
Audio jack USB Type-C port
NOTES:
• ConnectyourAeroActiveCoolertotheSideMountconnectorofyourROGPhone.
• Werecommendthatyouputyoursidemountconnectorcoverintothesidemountconnectorcover
storage to avoid missing while connecting the side mount connector.
• You can use your AeroActive Cooler while using the optional ROG Phone II Case.
Side mount
connector cover
storage

10 Chapter 1: Basics
NOTES:
• It is not recommended that you connect other devices to your ROG Phone when you install the
phone on the AeroActive Cooler.
• Docking your ROG Phone on an accessory with fan(s) will impact the audio quality when making
phone calls and recording.
Attaching the Footstand to the AeroActive Cooler
The Footstand lets you stand your AeroActive Cooler on a surface.
To attach the Foodstand to the AeroActive Cooler:
1. Remove the double sided tape from the Footstand.
2. Stick the Foodstand onto the bottom of the AeroActive Cooler.
