Ateis IDA8 Global-Net User manual

IDA8TM
Highly Integrated, Networked
Public Address and Voice Alarm System
Installation Guide
Global-Net
Revision History
v1.02
www.ateis.com© 2021, ATEÏS, member of PAX ProAV Group

IDA8 Installation Guide2
© 2021, ATEÏS, member of PAX ProAV Group
Hardware installation & connection
Rack mounting
Mount the IDA8C/IDA8C-SW/IDA8SAB/IDA8SL
unit in any standard 19-inch 2U audio equipment
rack using the supplied mounting brackets and
screws. Installing a IDA8S unit is similar to
installing a IDA8C, except the IDA8S unit is
installed in 19-inch 1U rack-mounting.
Consider leaving enough ventilation space above
and below the unit. Do not mount the controller
directly above the heat generating devices like
power supplies or power amplifiers.
Power supply
Use the supplied AC power cable to connect the
IDA8C/IDA8C-SW/IDA8SAB/IDA8SL unit to he
power outlet, and IDA8S unit by 24VDC. The
Power LED on the front panel will glow green
when power is applied.
If 24VDC power and AC mains power are
connected at the same time, IDA8C/IDA8C-SW/
IDA8SAB/IDA8SL will use AC power first, and
switch to DC power if there AC mains is not
present.
Ethernet (RJ45)
Use the supplied Ethernet cable (CAT5/6) to
connect the IDA8C processor to a computer.
The PC-based Ateis Studio software shall provide
all the necessary tools to setup, configure,
control and monitor the entire system.
ATEIS network
Local-net
Connect 1 IDA8C with another IDA8SAB unit
via Ateis local-net.

Hardware installation & connection 3
Connect 1 IDA8C and 2 IDA8SAB units via
Ateis local-net.
Global-net
Connect 2 IDA8C units together via Ateis
global-net and each IDA8C connects to
another 1 IDA8SAB unit via Ateis local-net.
External power amplifier
Connect the power amplifiers and loudspeakers on IDA8C processor, see the picture below.
In a case of IDA8C processor, it has 8 speaker zone outputs (Z1 to Z8). Each zone output consists of
2 redundant loudspeaker lines (line A and line B). Normally, the paging calls and BGM are distributed
to a zone over both loudspeaker lines. If one of the loudspeaker lines of a zone fails, it is still possible
to distribute the paging calls and BGM to the zone over the remaining loudspeaker line.
We recommend that the IDA8 controller connects to the floating output amplifier.
E.g. built-in transformer output for driving 70V and 100V loudspeakers such as BPA and DPA.
E.g. the amplifier module's AC/DC power supply and ground is floating ground from IDA8.

IDA8 Installation Guide4
© 2021, ATEÏS, member of PAX ProAV Group
If the IDA8 controller is connecting to non-floating output amplifier, please disable the leakage monitor
function on Ateis Studio software > Monitoring > Global Setting > Enable Leakage.
Digital paging console
To connect one or several remote devices such as PPM-AS/CD-8AS/CD-16AS on IDA8C, they require to
add an external power supply via Junction Box (JB). For the first three remote devices and/or the first
300m of cable run, the power can be delivered by IDA8C. If the distance between IDA8C and JB is more
than 300m, the JB requires to add an external power supply.
Connect with one device
1. Connect the JB to IDA8C processor via 8-
pin STP CAT5/6 cable.
2. Connect the PPM-AS to JB via 10-pin
CAT5/6 with metal shielded connector.
3. Switch to [MASTER] switch on JB.
Connect the PPM-AS/CD-8AS/CD-16AS to multiple JB for longer distance:
1. Connect the JB to IDA8C processor via 8-pin STP CAT5/6 cable.
2. Connect the PPM-AS to JB via 10-pin CAT5/6 with metal shielded connector.
3. Switch to [MASTER] switch on JB which is connected to the PPM-AS, and switch to [SLAVE]
switch on the rest of JB.
4. If using the additional power supply, switch the [Power Switch] selection to the [External Power].

Hardware installation & connection 5
Cascade with multiple devices
Cascade with multiple PPM-AS/CD-8AS/CD-16AS/URC-150AS devices:
To know the 8-pin STP CAT5/6 pinout using on URC-150AS, see 8-pin STP CAT5/6 cable for details.
Up to ten PPM-AS units can be connected via junction boxes on one IDA8.
8-pin STP CAT5/6 cable
8-pin STP CAT5/6 cable with metal shielded connector
Pin1
RS-485 B
Pin2
RS-485 A
Pin3
Line in -
Pin4
24VDC
Pin5
Ground
Pin6
Line in +
Pin7
Line out -
Pin8
Line out +
IDA8C LCD panel
The LCD touch panel on IDA8C processor provides system programming, control, paging, monitoring and
system status display.
Login & network settings
1. Set the IP, subnet mask and gateway address from LCD touch panel of IDA8C.
The default factory setting of the IP address is 192.168.100.236.
2. You need to login the menu on IDA8C first, then continue to set the IP/Subnet Mask/Gateway.
3. Press [SYSTEM SETTING] in [MAIN MENU] page.
4. Press [LOGIN] in [SYSTEM SETTING MENU-1] page.

IDA8 Installation Guide6
© 2021, ATEÏS, member of PAX ProAV Group
5. Press [USER NAME] in [LOGIN] page.
6. Enter the ID "ADMIN" which is the default user ID of IDA8C, keep the password field empty and click
"OK".
7. And there will be a message indicates as "Login successful".
8. Go back to [SYSTEM SET MENU-2] page and click [ETHERNET].
9. There are three fields: [IP ADDRESS], [SUBMASK] and [GATEWAY]. Change the settings to fit your
network. In this example, we changed the IDA8C's IP to 192.168.100.79.

Hardware installation & connection 7
The settings will be applied after the rebooting the system.

IDA8 Installation Guide8
© 2021, ATEÏS, member of PAX ProAV Group
Ateis Studio software
Ateis Studio is a user-friendly GUI software designed for intuitive system setup. The PC-based software
allows hardware update, full system configuration and generates the user interface for day-to-day system
operation.
Step 1: network settings
Install and operate the Ateis Studio software, and assign the network card on Ateis Studio.
Click [Tools > Communication] to open the
Network Adapter Setting window.
Select the network card in your PC/laptop, then
click "OK".
Step 2: search devices
Search the Ateis device and connect to It.
Before searching the Ateis devices in LAN, the device list will be shown in blank.
Now click [Auto Search] button under the Devices tab, then click [Clear] button, the device list will
appear after few seconds.
The gird on the left side shows which device has been connected, and the grid on the right side
shows the system function items the user can configure.

Ateis Studio software 9
Step 3: check/update firmware version
Click [Read version] button to check the compatibility between IDA8C and Ateis Studio. Click [Read] to
see the information about the firmware version.
If all the firmware units are compatible (shown in black text) with Ateis Studio, please go to step 4,
otherwise continue the following steps to update the firmware. The figure below shows an
incompatible version of the firmware which is marked in red.
To update the firmware, go back to [Device Management] window, and click [Update] button.
After its setting window appears, select the IDA8C and choose the firmware file (.asu) from IDA8
directory. See the picture as below,
Please find the update file from C:\Program Files\ATEIS\ATEIS Studio vx.x.x.x\Update file. This
path shall include the firmware update file of all the IDA8 units.

IDA8 Installation Guide10
© 2021, ATEÏS, member of PAX ProAV Group
When the Update process has completed, please follow the indication on the pop-up window to
reboot the IDA8C, click [Yes] to restart the device.
Step 4: system building-create a new file
Create a new file.
Create a new file by clicking the button on the
upper-left of the Ateis Studio software.
Connect the device and create an IDA8C block in
the device editor window.
Now 'Drag N Drop' the device/system into the
configuration window.
The [Set Audio Module] window will appear, click
[Create] button to continue.

Ateis Studio software 11
Then a IDA8C block will be created.
Step 5: system building-DSP compoment
Add a Tone component and connect it to the
Output component.
Double click the IDA8C icon to open the [IDA8C
DSP Configuration - IDA8C1].
Users can drag and drop the DSP components
which are listed on the left to the DSP
configuration window.
And start to design the internal signal paths for
each component via ''drag and drop''.
Element adjustment
Set the element of Tone Generator:
oLevel (dB) = -10
oTone Button = On
oTone freq. (Hz) = 2.00k
Now you can see the channel 1 meter and hear a
2k tone from the speaker connected to the
Amplifier Zone Output (zone1) on the rear panel of
the IDA8C.
Step 6: system building-compile and store
Compile and Store

IDA8 Installation Guide12
© 2021, ATEÏS, member of PAX ProAV Group
Once the design is done, click [Compile All]
icon, then the Compiling window will be
appeared afterwards.
Click [Store All] to store your design into the
IDA8 system.
Meanwhile, the system will ask you to turn on
the audio, click [Yes].
Then the system will ask you whether the
system shall go online, click [Yes]. The
settings could be modified and activated under
Online mode.
Please read the IDA8 global-net user manual to know the advanced configuration such as audio
routing, event and bell scheduler, master/sub-preset, 3rd party control, EVAC paging, paging with
priority management, monitor, DSP parameter adjustment, level control, fault list, user management
etc. on www.ateis.com.
Data are subject to change without notice. For latest update, please refer to the English online version
available on www.ateis.com.
