Ateis PENTON RNS Series User manual

RNS5/T
CEILING LOUDSPEAKER
Page 1/2
The RNS product line includes one-piece standard Ceiling
speaker in a metal version. The three Models of this line t
visually very well in our existing product lines. Two metal
retaining springs allow a safe and even t of these built-in
loudspeakers in the ceiling. The speaker broadband chassis and
the 100 V transformer form a unit with the front grille.
RNS5T_datasheet_AE_en_vn1.0_web
Electrical
Rated power, Watts 6
Tappings 100 volt line, Watts 6/3/1.5/0.75/0.25
Transformer Impedance, Ohms 100V 1.67k/3.33k/6.66k/13.3k/39.9k
Tappings 70.7 volt line, Watts 3/1.5/0.75/0.375/0.125
Driver impedance, Ohms 8
Eective Frequency Range, Hz (BSEN60268-5) 120 - 17,500
S.P.L. @ 1m, 1 watt, dB, Test Signal Bandwidth 100Hz-10 kHz 90
S.P.L. @ Full power Octave Bandwidth, dB 97
Dispersion at 1kHz, Degrees 180
Directivity Axial Q factor, 1kHz 2.3
Environmental
IP Rating n/a
Min/Max amb temp n/a
Relative Humidity n/a
Mechanical
Dimensions, mm Ø180
Net weight, kg 0.80
Colour/Finish White RAL9016
Material Steel, Powder coated
Mounting 2 Fast Tension Springs
Cut-out, mm Ø155
ATEÏS Europe B.V.
Celsiusstraat 1, 2652 XN Lansingerland, Netherlands
Phone [phone], www.ateis-europe.com, [email protected]

Page 2/2RNS5T_datasheet_AE_en_vn1.0_web
Disclaimer: We reserve the right of changes and errors.
INSTALLATION GUIDE
RNS5/T
ATEÏS Europe B.V.
Celsiusstraat 1, 2652 XN Lansingerland, Netherlands
Phone [phone], www.ateis-europe.com, [email protected]
Circuit Diagram
125 250 500 1k 2k 4k 8k
70
75
80
85
90
95
100
Effective Frequency Range 120Hz - 17.500Hz
Sensitivity (1W, 1m) dB
Frequency Hz
Average SPL 92dB
6W 3W
1.5W
0.75W 0.25W
100V COMMON
1) The ceiling cut required for the RNS5/T is 155 mm / diameter.
2) Connect the loudspeaker in phase to the existing cable network and connect the required or desired output (6, 3, 1.5, 0.75, 0.25W)
to the transformer using the cable lug.
3) Press one spring slightly upwards and push the loudspeaker with this side rst into the opening.
4) Now press the opposite spring upwards (over 90 degrees / angle) and now lead the housing slowly and carefully into the opening,
the loudspeaker now pulls itself into the opening.
Please be careful when handling the springs, as these may cause minor injuries if accidentally slipped when cocked.
Frequency response
59
6
ø
155 (Cutout)
180
ø
Side view
(unit: mm)
Front view
(unit: mm)
