Atlantic Furniture FOUR TIER BOOK SHELF User manual

Page1of4
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Before assembling your four tier book shelf,please read through these
Thank you for choosing our new book shelf.
This practical design offers the utmost in versatility.
instructions carefully,familiarising yourself with the different parts.
FOUR TIER BOOK SHELF 55”FOUR TIER BOOK SHELF 55”
READY
Assembling by Adult
Phillips Head
Screw Driver
Please note that you will require a Phillips Head Screw-driver.
HARDWARE
AB
1 1/4” Wood Screw - 23 pcs 3/4” Wood Screw - 20 pcs
For Back Panel

PARTS LIST
01
02
03
04
05
06
SIDE PANEL LEFT 1 pcs
1 pcs
4 pcs
1 pcs
1 pcs
2 pcs
SIDE PANEL RIGHT
SHELF
BOTTOM RAIL
TOP PANEL
BACK PANEL
01
01
03
03
03
03
03
05
06
06
04
02
Attach Shelves (03) to Side Panel (01) using 1 1/4” wood screw ( A )
Tighten with Phillips Head screwdriver. Page2of4
A
A
Assembling by Adult
1 1/4” Wood Screw
Phillips Head
Screw Driver
Step 1
A

Page3of4
Step 2
Step 3
Attach Bottom Rail (04) to Side Panel (01) using 1 1/4” wood screw ( A )
Attach Shelves (03) and Bottom Rail (04) to Side Panel (02) using 1 1/4” wood screw ( A )
Tighten with Phillips Head screw driver.
Tighten with Phillips Head screw driver.
04
04
A
A
A
A
AA
A
02
Assembling by Adult
1 1/4” Wood Screw
Phillips Head
Screw Driver
A
Assembling by Adult
1 1/4” Wood Screw
Phillips Head
Screw Driver
A

Step 4
Step 5
Lay the Top Panel (05) on the floor,taking care to lay it on some cardboard to prevent scratching.
Stand the book shelf assembly upside down and attach 1 1/4” wood screw (A)
Lastly attach the Back Panel (06) to the Book Shelf using 3/4” wood screw(B)
Tighten with Phillips Head screw driver.
Tighten with Phillips Head screw driver.
05
06
06
05
Assembling by Adult
1 1/4” Wood Screw
Phillips Head
Screw Driver
A
A
B
A
A
Assembling by Adult
3/4” Wood Screw
Phillips Head
Screw Driver
B
Page4of4
