Atronic e-motion User manual

www.atronic.com
Rev. 2.2
June 2008
Atronic e-motion™
Installation Manual

2
April 2008
e-motion™ Installation
RELEASE INFO
Release Info:
Atronic e-motion™
Installation Manual
Rev. 2.2
June 2008
WARNING!
The e-motion™ / Hi(!)bility™ manual is intended to provide QUALIFIED TECHNICAL
PERSONNEL ONLY with the information necessary to routinely maintain, service, and
repair the Atronic e-motion cabinet and components. To avoid personal injury or damage
to the equipment, do not perform any serviceing other than that contained in this
manual.
Copyright Notice:
© 2008, Atronic. All rights reserved.
No part of this publication may be copied or distributed, transmitted, transcribed,
stored in a retrieval system, or translated into any human or computer language, in
any form or by any means, electronic, mechanical, magnetic, manual, or otherwise, or
disclosed to third parties without the express written permission obtained from a
properly authorized official of Atronic.
DISCLAIMER
Atronic makes no representation or warranties, express or implied, with respect to
this publication, or any product of Atronic, including but not limited to warranties of
merchantability or fitness for any particular purpose. Atronic reserves the right to
make changes, enhancements, revisions and alterations of any kind to this publication
or the product(s) it covers without obligation to notify any person, institution or
organization of such changes, enhancements, revisions and alterations.
TRADEMARKS
This document may contain trademarks of Atronic. All other brand and product names
are trademarks or registered trademarks of their respective companies.

3
April 2008
e-motion™ Installation
Introduction
About this Manual
Scope, Target Audience, Included Software Releases ....
Related Publications ...................................................
Safety Instructions .........................................................
Machine Components .......................................................
Dimensions ......................................................................
Technical Data ................................................................
Machine Installation
Overview ..........................................................................
Machine Mounting ............................................................
Drilling Template ...............................................................
Replace Shipping Locks .....................................................
Prepare Coin Acceptor .......................................................
Prepare Hopper .................................................................
Check Connectors ..............................................................
Check Commboard Settings ................................................
Apply Power ......................................................................
Switch On .........................................................................
Basic Setup (Overview only) ..............................................
Tests ...............................................................................
Technical Support Telephone Numbers ..............................
4
5
7
10
13
14
16
17
18
19
20
20
20
20
21
21
22
23
24
CONTENT

4
April 2008
e-motion™ Installation
ABOUT THIS MANUAL
Scope
This Installation Manual describes how to install an
Atronic e-motion™ gaming machines.
It describes how to mount the machine to a base
stand and relevant procedures to be carried out before
the machine can be put into operation. Further it
contains important safety instructions, technical data
and cabinet drawings.
Target Audience
We address qualified technical personnel, who are
involved in installation, setup and configuration of
Atronic gaming machines. With this user group we
assume that they are basically familiar with gaming
machinesand casino related terminology.
Please read this document and the contained safety
notes carefully before you start machine installation.
Included Software Releases
The installation procedures described in this manual
do not relate to a certain software version. However
the graphs included are taken from a C-Level software
releases (C5.1.x.x). Other software version may
support different features and options.
INTRODUCTION

5
April 2008
e-motion™ Installation
ABOUT THIS MANUAL
Related Publications
More detailed information about Atronic e-motion™
gaming machines may be found in the following
publications:
Software Manuals
•Manual HI Software (B1.2.x STD)
•Manual HI Software (C4.x.x.x STD)
•Manual HI Software (C5.x.x.x STD)
Operation Manuals
•Manual EMC HI Operating (B1.2.x STD)
•Manual EMC HI Operating (C4.x.x.x STD)
•Manual EMC HI Operating (C5.x.x.x STD)
Spare Parts
•Manual EMC Parts Catalogue
Linked Gaming Products
•Manual [ product ] - Setup and Configuaration
for a particular linked gaming product, such as
CASH FEVER™, King Kong Cash, The Game of
Life™, Mystery Magic™, Hot Link™, etc.
Peripherals
(Coin- and bill acceptors, hopper, printer, etc.)
•See folder "Peripherals" on the Atronic Service
Manual CD.
Note: All mentioned manuals can be found on a CD-
ROM titled "Atronic Service Manual 2008"
If this manual did not came with this CD-ROM, please
ask Atronic Technical Service for a free copy of the
latest revision.
INTRODUCTION

6
April 2008
e-motion™ Installation
- blank page -

7
April 2008
e-motion™ Installation
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Note!
This installation module of the e-motion™ Hi(!)bility
includes only information relating to the installation
of the e-motion™ cabinet. For other machine or cabinet
types please refer to the relevant manuals.
Follow the safety precautions below
and on the next page, to ensure safe
operation.
Caution! High Voltage
Power cable must be disconnected from the main
power socket, so that the machine is free from
electrical current. The power switch is intended for
service purposes only.
Caution! Tipping Hazard
The machine must be fastened to an appropriate base,
to prevent tipping over. Use the Atronic Installation
Station (AIS) for machine mounting.
-> see also page 17-18.
Caution! Moving Parts
Make sure to disconnect the hopper, when working
on it.
Caution!
The machine must not be cleaned using a high
pressure cleaner or a vapor jet and must not be
installed or operated in areas where high pressure
cleaners or vapor jets are used. Use in dry conditions
only.
Continues on next page

8
April 2008
e-motion™ Installation
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Further safety precautions during Installation,
Service and Maintenance
•The machine weight is approx. 120kg. Always use
appropiate equipment for transportation.
•Disconnect the power cable from the socket, befo-
re working at the machine.
•The machine may only be operated in dry conditi-
ons and must be connected to a grounded mains
power socket.
•Check that all connectors are seated correctly. Fal-
se connections can cause irreparable damage, not
covered by warranty.
•For power cable routing remove the knock-out pla-
te on the appropriate side of the cabinet. Edge-
protection must be mounted once the knock-out
plate has been removed.
•Only qualified service personnel should perform
repairs.
•Electronic assemblies should only be changed with
the power switched off.
•Use only original Atronic parts for replacement.
•Atronic commboard and mainboard
Danger of explosion if battery is incorrectly repla-
ced! Check for correct polarity and replace with
the same or equivalent type only!
•The machine must not be cleaned using a high pres-
sure cleaner or a vapor jet and must not be instal-
led or operated in areas where high pressure clea-
ners or vapor jets are used. Use in dry conditions
only.
•Please refer to relevant Atronic service manuals
for further instructions on setup, operation and
maintenance.

9
April 2008
e-motion™ Installation
- blank page -

10
April 2008
e-motion™ Installation
MACHINE COMPONENTS
MACHINE COMPONENTS
Toplights
Top Glass
Online System Module
(optional)
Voucher Printer
(optional)
Coin Entry
Coin Decal
Functional Button Panel
Mechanical Meters
Main Door Lock
Jackpot Key Switch
Audit Key Switch
Hopper Drawer Lock
Bill Entry / Bill Acceptor
Name Plate
Atronic Installation
Station (AIS)
(Baseplate for mounting)
Speakers
Framelights
Upper Display
Main Display
Playfield Height
Adjustment
Button Panel
Hopper Drawer
Coin Bowl
Bill Decal

11
April 2008
e-motion™ Installation
MACHINE COMPONENTS
Logicbox
Logic Door
Logic Door Lock
Reset Button
Service Button
Multimedia Board
Cover
Maindoor Switch
Coin Unit
Assembly
Coin Acceptor
Coin Optics
Bill Acceptor
Front Bezel
Cashbox
Bill Acceptor
Filterboard
Signal
Filterboard
Power
Top Glass
Release Lever
Power Switch
(auxiliary)
AC Output
Power Supply
Door Motor
Decal Lighting
Button Panel
Release Lever
MACHINE COMPONENTS

12
April 2008
e-motion™ Installation
MACHINE COMPONENTS
Logic Box
MACHINE COMPONENTS
Logicbox Switch
Backplane
Commboard
Mainboard
DVD-ROM Drive
Graphic Card
(VP11)
Release Lever for
Multimediaboard
Cover
Multimediaboard
Multimediaboard
Cover

13
April 2008
e-motion™ Installation
e-motion™ Cabinet
Weight: approx. 120 Kg / 264 lbs.
Overall dimensions closed cabinet
Height: max. 1350 mm / 53.2"
Width: 610 mm / 24"
Depth: max. 590 mm / 23.2"
DIMENSIONS
adjustable 1230 mm - 1350 mm / 48.4” - 53.2”
1055 mm / 41.5”
1643 mm / 64.7”
575 mm - 590 mm / 22.6” - 23.2” 550 mm / 21.7”
610 mm / 24”
~420 mm - 540 mm / 16.5” - 21.3”
e-motion™ Cabinet
with Topper
Weight: approx. 129 Kg / 284 lbs.
Overall dimensions closed cabinet
Height: 1643 mm / 64.7"
Width: 610 mm / 24"
Depth: max. 590 mm / 23.2"
DIMENSIONS
adjustable 1230 - 1350
575 - 590
550
685 (mm)
905 (575 )opened closed
610
1055
135

14
April 2008
e-motion™ Installation
TECHNICAL DATA
Electrical Specifications
Required Voltage: 100V to 240V AC
50Hz / 60Hz
The mains power cable must be pluged into a earthed
power outlet labled 8 Amps.
Power Consumption
Idle Mode: approx. 200W
1.8 A / 115V, 0.9 A / 230V
Payout Mode: approx. 300W
2.6 A / 115V, 1.3 A / 230V
Power Supply
Secondary Voltage:+ 24V / 4A
+ 12V / 12A
- 12V / 0.3A
+ 5V / 11A
+ 3.3V / 7A
Fuses
Power Supply:T 8A / 250V
Filterboard F2: +12V T 6.3A / 250V (UL fuse)
Filterboard F3: +24V T 4A / 250V (UL fuse)
Lamps
Fluorescent Lamp TL8W/33
300mm, 410 lumen,
4100K (cool white)
Button Lighting LED 12V
Environmental specifications
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Operating Humidity: 0% - 85% (non condensing)
(same limits for storage)
Primary Voltage
(The power supply features
voltage autoswitching)
Secondary Voltage
Primary Fuses
Secondary Fuse
Lamps
Suggested Limits
TECHNICAL DATA

15
April 2008
e-motion™ Installation
- blank page -

16
April 2008
e-motion™ Installation
MACHINE INSTALLATION
MACHINE INSTALLATION - OVERVIEW
This section should only be carried out by
Qualified Technical Service Personnel.
Review the list below and perform as needed.
Explanations are located on the following pages and
in additional manuals.
Inspect the machines for transport damage. Any
transport damage should be noted and witnessed
by the freight forwarder. The manufacturer accepts
no responsibility for transport damage.
Check the machines for correct software and
hardware configuration. Check that all EPROMs are
correctly seated on the boards.
Prepare the machine bases by drilling the mounting
holes. Use the Atronic drilling template for proper
mounting hole placement.
Place and mount the machine to the base, using
the Atronic Installation Station (AIS). The power
cable must be inside the cabinet.
Replace shipping locks with casino specific locks.
Install and connect accounting system components.
Check that all internal and external connections
are seated correctly.
Prepare coin acceptor and hopper.
Apply power to the machine.
Load paper into the Printer.
Execute basic machine setup (Initial Setup)
Configure game.
Test bill and coin handling.
Note:
Depending on machine
configuration or jurisdictional
requirements, additional tasks
may have to be carried out
before the machine can be put
into operation (e.g. acceptance
inspection, logicbox sealing,
etc.).

17
April 2008
e-motion™ Installation
MACHINE INSTALLATION
MACHINE INSTALLATION
Machine Mounting
Caution! Tipping Hazard
Do not operate the machine unless it has
been properly secured with an Atronic In-
stallation Station (AIS). The machine can
tip over, if it is not properly mounted.
1. Use the Atronic Installation Station (AIS), supplied
by Atronic, to mark the holes on the base before
drilling. Make sure to leave min. 180mm (7.1")
distance to the next machine or a wall on both
sides of the cabinet.
If an AIS is not at hand, use the drilling template
on the next page.
2. Drill four holes 10mm (3/8") for the AIS mounting
(drillings a) and one out of three holes 10mm (3/8")
for the machine securing bolt (drillings d) into the
base. It is not important which of the 3 holes for
the securing bolt is used, if at least one securing
bolt is mounted. If the base stand has braces or
struttings placed below one mounting hole, simply
use another one.
3. Drill or cut out one 55mm (2¼") hole for running
the main cable into the base (drilling b).
4. Cut out the 60 x 50 mm (3¼") recess for coin
drop into the base stand (recess c)
5. Secure the AIS to the base using 4 mounting bolts
(delivered with the machine) and fasten with
wingnuts and washer.
Make sure that the boltheads are completely
lowered into the counterbores.
bc
a
d

18
April 2008
e-motion™ Installation
50
117.5
307.5
50
105.5
270.5
394
491
41.5
181
6060
55
60
50
357.5
541
Baseplate (AIS)
Cabinet
Footprint
550
Ø 10mm
Ø 10mm
(drill 1 out of 3 for securing bolt)
Backside
DRILLING TEMPLATE
Make sure to leave min. 180mm (7.1") distance to the next machine or
a wall on both sides of the cabinet. Do not cover the ventilation slots
at the backside of the cabinet.
MACHINE INSTALLATION

19
April 2008
e-motion™ Installation
MACHINE INSTALLATION
Machine Mounting (continued)
6.Make sure that the mains power cable is comple-
tely inside the machine and that hopper drawer
and maindoor are closed and locked.
Two forceful persons (one on each side) should lift
the machine and then slide it onto the AIS. The
baseplate of the machine will grasp into the gui-
des of the AIS. If available, use a lift truck.
Caution!
The machine weighs 120 kg (264 lbs)!
Make sure that the main power cable is
completely inside the cabinet and not
threaded through the AC hole, before sliding
the machine onto the AIS! Otherwise the
cable will be damaged!
7. Use at least one securing bolt (delivered with the
machine) to secure the machine to the AIS and
the base stand. Fix the bolt with wingnut and
washer.
It is not important which of the 3 holes is used, if
at least one securing bolt is mounted. If the base
stand has braces or struttings placed below one
mounting hole, simply use another one.
Replace Shipping Locks
If not ordered otherwise, Atronic machines are
equipped with shipping locks for easy commisioning.
These locks have to be replaced by casino specific
locks to provide appropriate security.
MACHINE INSTALLATION

20
April 2008
e-motion™ Installation
MACHINE INSTALLATION
MACHINE INSTALLATION continued
Prepare Coin Acceptor (CC-16 / MC-16)
•Slide holder for reference coin rightwards, remove
(plastic) transport chip and replace it with appro-
priate reference coin.
•Check reference coin for proper (parallel) seating.
-> See manuals Peripherals / Coin Acceptor for details.
Prepare Hopper
The hopper high level switch detects the filling level
of the hopper by the weight of the coins. If the switch
is activated, further accepted coins are separated to
the drop box. The switching threshold can be altered
with an adjustment srew.
•Fill the hopper with that amount of coins/tokens at
which you want the switch to be activated.
•Adjust switching threshold with the adjustment
screw that operates the high level switch.
-> See manuals Peripherals / Hopper for details.
Check cables and connectors
Check that all connectors are seated correctly, prior
to first power up. False connections can cause irre-
parable damage, not covered by warranty.
Check Commboard Settings
The commboard DIP switches and rotary switches
configure SAS address, APL address, progressive
mode and SAS (dual) channel allocation.
Use the DIP switch tables within manual "Software /
Basic Setup" for a particular software version (e.g.
C5.1.x) to check or alter the commboard settings.
Then connect to the online system components.
Commboard
Logicbox
Cover
