AU INFOBAR A02 Installation guide

Basic Manual Safety
precautions
Getting ready
Basic
operations
au 災害対策
(au Disaster
Countermeasure) app
Calling
Function settings
Appendix

ii
Preface
Thank you for buying the INFOBAR A02 (simply
called the 'INFOBAR A02' or the 'product' from
here on).
Before using the product, be sure to read the
"Basic Manual" (this manual) to ensure correct
use. After you have finished reading this manual,
be sure to store it in a safe place so that you can
retrieve it whenever needed.
•In this manual, the term "Instruction Manual"
is used collectively for the Basic Manual (this
manual), Setting Guide and Full Instruction
Manual (Japanese) which can be downloaded
from the au homepage.
About operating instructions
■Basic Manual (This Manual)
The Basic Manual handles only basic operations
for main features.
For detailed descriptions of various functions,
refer to the "Instruction Manual" app that can be
used on the product or “Full Instruction Manual”
(Japanese) available on the au homepage:
http://www.au.kddi.com/notice/recycle/index.html
•Company names and product names referred
to in this manual are trademarks or registered
trademarks of their respective companies.

1
■"Instruction Manual" app
You can use the "Instruction Manual" app on
the product to confirm detailed operational
procedures.
1 On the iida Home, tap [取扱説明書] and
download the latest "Instruction Manual"
app by following the on-screen directions.
If you receive an Install blocked message, tap
'Settings' and make sure 'Unknown sources' box
is checked and then download the app again.
2 On the iida Home, tap [取扱説明書].
■Downloading manuals
You can download the "Basic Manual" (this
manual) and the "Setting Guide" or the "Full
Instruction Manual" (Japanese) in PDF format
from the au homepage.
http://www.au.kddi.com/torisetsu/index.html
Safety precautions
Before you start using the product, be sure to
read the 'Safety precautions' to ensure correct
use.
Before you assume that the product is
malfunctioning, check for possible remedies
in the following auお客様サポート (au Customer
Support) site on the au homepage:
http://cs.kddi.com/support/komatta/kosho/index.html

2
When using the product
•Communication is not possible even inside the
service area in places where the signal does
not reach (e.g. tunnels and basements). Also,
communication is sometimes not possible
in poor reception areas. Communication is
sometimes interrupted if you move into a poor
reception areas during communications.
•Since this product uses radio waves, the
possibility of communication intercepts by third
parties cannot be eliminated. (Though the LTE/
CDMA/GSM/UMTS system has highly secure
and confidential communication features.)
•This product is compatible with the international
roaming service. Each network service varies
depending on the area and service content.
•Since this product is a radio station under
the Radio Law, you may be asked to
temporarily submit the product for inspection in
accordance with the Radio Law.
•The IMEI information of your cell phone is
automatically sent to KDDI CORPORATION for
maintenance and monitoring operational status
of your cell phone.
•Take care not to inconvenience people around
you when you use the product in a public
place.
•Before using this product overseas, check on
the local applicable laws and regulations of the
country or region you visit.
•When the product is used by a child, parents
or guardians should thoroughly read the
"Instruction Manual" and teach the child how
to use it.

3
■Use of the product is not allowed in
the following places!
•Do not use a cell phone while driving a car
or riding a motorbike or bicycle. It may cause
a traffic accident. Use of a cell phone while
driving a car or motorbike is prohibited by law.
Use of a cell phone while riding a bicycle may
be punishable by some regulations.
•Be sure to turn off the product while you
are aboard an airplane. Use of electronic
devices transmitting radio waves in airplanes
is prohibited by law. Some airline companies,
however, allow their passengers to use
cell phones. For details, contact the airline
company you use.
■Be considerate of where you use
the cell phone and how loudly you
talk!
Do not make calls in theaters, museums, libraries
and other similar places. Turn power off or turn
on the manner mode so as not to disturb others
around you by ringtone.
•Do not use the cell phone on a street where you
might interrupt the flow of pedestrians.
•Move to areas where you will not inconvenience
others on trains, in hotel lobbies, etc.
•Refrain from talking in a loud voice.
•Obtain the permission of other people before
you take their photos with the cell phone's
camera.

4
■Be considerate of people around
you!
•Some people close to you in crowded places
such as packed trains may be using a cardiac
pacemaker. Turn the cell phone off in such
places.
•Abide by the rules of hospitals and other
medical institutions where it is forbidden to use
or carry cell phones.

5
List of packaged items
Before you start using the product, make sure
that you have all the following items packaged
with the product.
■Main unit
INFOBAR A02
■Accessories
Battery pack
(HTX21UAA)※1
Battery cover※1※2
•Quick Start Guide (Japanese)
•Setting Guide (Japanese)
•Warranty card (main unit) (Japanese)

6
※1 The battery pack is pre-installed at the time of
purchase.
※2 The model number depends on the color.
Battery cover NISHIKIGOI (HTX21TRA)
Battery cover AOAO (HTX21TLA)
Battery cover ICE GRAY (HTX21TWA)
The following items are NOT included in the
package:
•AC adapter
•microUSB cable
•Earphones
•microSD memory card
memo
◎Purchase a specified charging equipment (sold
separately).
◎Illustrations of the product in this manual are only for
reference. They may look different from the actual
product.

7
Contents
Preface...............................................................ii
Safety precautions .............................................1
When using the product .....................................2
List of packaged items .......................................5
Contents.............................................................7
Safety precautions .............................................9
Regarding notations used in this manual .................10
Exemptions ...............................................................12
Safety precautions (observe strictly) ........................14
Handling precautions ...............................................32
Available security codes...........................................45
Notes on water-proof and dustproof properties .......48
Note on using Bluetooth®and wireless LAN (Wi-Fi®)
functions ...................................................................59
Notes on packet communication charge..................63
Application................................................................64
Getting ready....................................................65
Names and functions of parts ..................................66
Attaching/removing the battery pack .......................68
Opening/closing the connector cover ......................72
Installing/removing the au Micro IC Card (LTE)........74
Installing/removing a microSD memory card............77
Charging...................................................................79
Turning the power on/off ...........................................82
Unlock screen...........................................................83
Basic operations ..............................................85
Home screen ............................................................86
Monitoring the product's status ................................95
Displaying a menu....................................................97

8
au災害対策 (au Disaster Countermeasure) app ...99
Using the au災害対策
(au Disaster Countermeasure) app ........................100
Using the 災害用伝言板
(Disaster Message Board)......................................101
Using 緊急速報メール (Emergency Rapid Mail) .......102
Using the 災害用音声お届けサービス
(Disaster Voice Messaging Service).......................105
Calling............................................................107
Making calls............................................................108
Receiving calls........................................................110
Checking your phone number................................110
Function settings ............................................ 111
Viewing the setting menu........................................112
Appendix........................................................115
Peripheral equipment .............................................116
Troubleshooting ......................................................117
Updating software ..................................................119
After-sales service ..................................................122
Main specifications.................................................127
Specific Absorption Rate (SAR) of cell phones......130
FCC Notice .............................................................132
FCC RF exposure information.................................133
Body-worn operation ..............................................134
DECLARATION OF CONFORMITY .........................134
Export Administration Regulations .........................138
Intellectual property rights......................................139

9
Safety
precautions
Regarding notations used in this manual.....10
Exemptions...................................................12
Safety precautions (observe strictly)............14
Handling precautions...................................32
Available security codes ..............................45
Notes on water-proof and dustproof
properties .....................................................48
Note on using Bluetooth®and wireless LAN
(Wi-Fi®) functions..........................................59
Notes on packet communication charge .....63
Application ...................................................64

Safety precautions
10
Regarding notations used in
this manual
■Key indications used in this manual
In this manual, keys are represented by
simplified illustrations as shown below.
■Indications used for the operation
of selecting items/icons/keys, etc.
Notations used for operation procedures in this
manual are as follows.
Description in
this manual
Explanation of operation
On the iida
Home, tap
[Phone] →
'141' →[Call]
On the iida Home, tap 'Phone', then
tap '1', '4'. '1' in this order, and finally
tap 'Call'.

Safety precautions
11
Description in
this manual
Explanation of operation
→tap app
to start up Tap to display the most recently used apps. Flick up or down to select
the app you want to start up and then
tap the displayed app.
※Tapping is the action to lightly touch a key, an icon or
any other item displayed on the screen to select it.
■Illustrations/screen displays used
in this manual
Screen illustrations shown in this manual may
look different from the actual screens. In some
cases, minor details or a part of a screen may be
omitted.
In the illustration,
the icons at the
top of the screen
are omitted.
Actual screen An example of illustration
in this manual
memo
◎The explanations in this manual are based on the
initial default settings for the 'NISHIKIGOI' model.
Note that the fonts and shapes of the actual keys,
button and screens on the product may be different
from those shown here. Also, some elements may
be omitted in this manual. Please also note that
illustrations of the product in this manual may differ
from the actual appearance of the product.

Safety precautions
12
◎Unless specifically stated otherwise, all operations
in this manual are performed based on portrait
(vertical) screen orientation. Note that menu items,
icons, on-screen buttons, and other elements may
be different when landscape (horizontal) screen
orientation is being used.
◎In this manual, 'microSD™ memory card' and
'microSDHC™ memory card' are abbreviated as
'microSD memory card' or 'microSD'.
◎This manual uses the abbreviation 'app' in place of
'application'.
Exemptions
◎The Company is not liable for any damages
arising from earthquakes, lightning, storms,
floods or other natural disasters, as well as
fires, actions by third parties, other accidents,
intentional or mistaken misoperation by
the customer, or use under other unusual
conditions outside the responsibility of the
Company.
◎The Company is not liable for any incidental
damages (change/disappearance of recorded
content, loss of business income, disruption of
business, etc.) arising from use of or inability
to use the product.
◎The Company is not liable for any damages
arising from failure to observe the described
content of the 'Instruction Manual'.
◎The Company is not liable for any damages
arising, for example, from malfunction caused
by combination with connected devices or
software not related to the Company.

Safety precautions
13
◎Captured image data or downloaded data
may sometimes be altered or lost due to faults,
repair or other mishandling of the product. The
Company is not liable for any damage or lost
income resulting from recovery of these data.
◎It is recommended you keep a copy of
important data in your PC's hard disk, etc.
Whatever the cause of fault or malfunction may
be, the Company assumes no responsibility
for alteration or loss of saved information.
◎The Company does not provide any type of
data restoration or recovery services for data
that is lost or corrupted through the use of this
phone.
※'The Company' as appears in this manual refers to the
following companies:
Sold by: KDDI CORPORATION •OKINAWA CELLULAR
TELEPHONE COMPANY
Imported by: HTC NIPPON Corporation
Manufactured by: HTC Corporation
■Information
◎Reproduction of the content of this manual in part or
in whole is prohibited.
◎The content of this manual is subject to change
without notice.
◎Every effort has been made in the preparation of
this manual. Should you notice any unclear points,
omissions, etc., feel free to contact us.
◎Wrong page order or missing pages will be replaced.

Safety precautions
14
Safety precautions (observe
strictly)
■Before using this product, thoroughly read
these 'Safety precautions' for proper use. After
reading, store the precautions in a safe place.
●These 'Safety precautions' describe
instructions that should be observed to
prevent damage to property or injury to the
customer or others using the product.
●These instructions are divided into the
following categories.
■Explanation of indications used in
this manual
This symbol indicates the potential and
imminent danger of death or serious
injury (※1) to a person.
This symbol indicates the possibility of
death or serious injury (※1) to a person.
This symbol indicates the possibility
of personal injury (※2) to a person or
physical damage (※3).
※1 Serious injury: This refers to loss of sight, injury,
burns (high- and low-temperature), electric shock,
broken bones, injuries with residual aftereffects
from poisoning, etc., and injuries requiring hospital
admission for treatment or longterm hospital
attendance as an outpatient.
※2 Injury: This refers to injuries, burns (high- and
low-temperature), electric shock, etc. that do not
require hospital admission for treatment or long-term
hospital attendance as an outpatient.
※3 Physical damage: This refers to extended damage
to buildings, furniture, livestock, or pets.

Safety precautions
15
■Explanation of graphic symbols
used in this manual
Prohibited
Indicates an action that is not allowed.
Wet hands
prohibited
Indicates that handling with wet hands is not
allowed.
Disassembly
prohibited
Indicates that disassembly is not allowed.
Wetting with
water prohibited
Indicates that use in a place where the
product is likely to get wet or allowing the
product to get wet is not allowed.
Instruction
Indicates an action that must be done.
Disconnect plug
from power outlet
Indicates that the power plug must be
disconnected from the power outlet.
■Precautions common to the main
unit, battery pack, battery cover,
charging equipment, au Micro
IC Card (LTE) and peripheral
equipment
Be sure to read the following
before use.
Instruction
Be sure to use only the specified peripheral
devices. Use of other peripheral devices might
cause overheating, fire, electric shock, rupture,
fault, or leakage of liquid.

Safety precautions
16
Prohibited
Do not use, store or leave the product in hot
places (e.g. by the fire, near a heater, under
a kotatsu, in direct sunlight, in a car in the hot
sun). Doing so might cause ignition, rupture,
fault, fire or injury.
Instruction
Before entering an area where flammable gas
is generated such as a gas station, be sure to
turn off the product. Do not charge the battery.
Failure to observe these precautions might
cause the gas to catch fire. In addition, when
using NFC/Osaifu-Keitai®at a gas station, be
sure to turn off the power in advance.
(If the 'NFC/Osaifu-Keitai®Lock' is turned on,
unlock it and then turn off the product.)
Prohibited
Do not put the product in a cooking apparatus
such as microwave oven or a pressure vessel.
Doing so might cause ignition, rupture, fault,
fire or injury.
Prohibited
Do not throw the product into a fire or heat it.
Doing so might cause ignition, rupture or fire.
Prohibited
Do not short-circuit the connection terminals.
Do not allow conductive foreign objects (metal
fragments, pencil leads, etc.) to come into
contact with or get inside the connection
terminals. Doing so might cause fire or a fault.
Prohibited
When using a metal accessory, make sure the
metal parts do not come in contact with the
connection terminals or power outlet. Doing so
might cause electric shock, fire, injury or a fault.
Prohibited
Do not expose the camera lens to direct
sunlight for an extended period. Doing so might
cause ignition, rupture or fire by the light-
collecting mechanism of the lens.

Safety precautions
17
Disassembly
prohibited
The customer is not allowed to disassemble,
modify or repair the product. Doing so might
cause a fault, fire, electric shock, or injury.
The Company is not liable even in the event of
any nonconformities arising on the product or
peripheral devices as a result of modification,
etc. Modification of the product is in violation of
the Radio Law.
Be sure to read the following
warnings before use.
Prohibited
Do not drop the product or subject it to strong
impact, such as by throwing it. Doing so might
cause rupture, overheating, fire, or a fault.
Prohibited
Do not use outside when you can hear thunder.
Doing so may result in lightning strikes and
electric shock.
Prohibited
Do not let your hands, fingers or other parts
of your body touch the connection terminals.
Doing so might cause electric shock, injury or
a fault.
Prohibited
If the product is damaged because it is
dropped or something, and its display is
cracked or internal parts are exposed, do not
touch the cracked display or exposed parts
with your hands. Doing so might cause electric
shock or injury from damaged parts. Contact an
au shop or Secure cell phone support center.
Wetting with
water prohibited
Although the product has waterproof property,
stop use if liquid such as water gets inside the
main unit from the connector cover or battery
cover. Continued use of the product in this state
may cause overheating, ignition or a fault.

Safety precautions
18
Prohibited
When removing the battery cover, do not exert
more than necessary force. The battery pack
might jump out, for example, and cause injury
or fault.
Prohibited
Do not operate the product while driving an
automobile or motorized bicycle, riding a
bicycle or walking. Doing so may compromise
traffic safety and cause an accident.
Prohibited
If charging is not complete after the specified
charging time, stop charging. Failure to do so
might cause leakage of liquid, overheating,
rupture or fire.
Prohibited
Do not leave in places within the reach of small
children. Small children might swallow small
parts, etc. by mistake and choke on them,
or might drop them by mistake and cause
accidents or injury.
Be sure to read the following
cautions before use.
Prohibited
Do not store the product in places subject to
direct sunlight (e.g. in automobiles), places that
get hot, places that get extremely cold, and in
humid or dusty places. Doing so might cause
overheating, fire, deformation or a fault.
Prohibited
Do not leave the product on unstable places such
as rocky stands or tilting surfaces. Dropping the
product may cause injury or damage. Be careful
especially when the vibration mode is set. Also,
pay sufficient attention to impact, etc.
Prohibited
Do not cover or wrap the product with bedding,
etc. while using or charging the product. Doing
so might cause fire, fault or injury.
