SIREN MOUNTING:
1. Find a suitable spot to mount the siren in the engine
compartment (firewall, sidewall, etc.).
2. Using siren bracket as a template, drill (2) 1/8" diameter
holes in mounting surface.
Note: If mounting on the firewall, make certain there is no
interference on the other side of the firewall.
3. Secure bracket using screws provided with kit.
4. Secure siren to the bracket using bolts and lock washers
provided.
WARNING - Open end of siren must point downward to
prevent water collection in horn end of siren.
WIRING:
RED WIRE - Splice to +12 VDC battery source lead of existing
alarm.
BLACK WIRE - Splice to chassis ground lead of existing
alarm.
WHITE w/ BLACK STRIPE WIRE - Connect to the positive
siren output from the alarm module.
Printed in U. S. A. Form No. 128-4503
INSTALLATION GUIDE FOR:
Battery Back-Up
RED WIRE - SPLICE TO +12VDC BATTERY
SOURCE LEAD TO EXISTING ALARM.
WHITE w/BLACK STRIPE - CONNECT TO
THE POSITIVE SIREN OUTPUT FROM THE
ALARM MODULE.
BACK-UP SIREN
NOTE: BEFORE MAKING
CONNECTION, MAKE
SURE KEY IS IN THE "OFF"
POSITION AS SHOWN.
NOTE : MAKE SPLICE CONNECTIONS AS CLOSE TO
EXISTING ALARM AS POSSIBLE.


AA-9103N
BLACKWIRE-SPLICEINTOCHAS-
SIS GROUND LEAD OF
EXISTING ALARM.
OFF
ON
