Installation Guide/User manual
CarStream
INTEGRATION KIT
BLUETOOTH & SATELLITE RADIO
for selected Volkswagen / Audi vehicles
using Satellite Radio emulation

2
Copyrights and Trademarks
Copyright 2015 VOXX Electronics Corporation
All Trademarks and Logos are the property of their respective owners.
All rights reserved.

3
Warning and safety
Product registration
Kit contents ........................
DIP switch settings
Vehicle Bus connector
Note to Installer ............
Connection diagram - Bluetooth and AUX
Connection diagram - Bluetooth and Satellite
Installation
Controls and Indicators
Bluetooth / AUX operation
Satellite radio operation
Note for Navigation radios
Pairing Your Phone .......................................................18
Operation
Music Control
Audio Streaming
Optional remote controller
Troubleshooting
Firmware update
Auxiliary audio source
..........................................................4
.........................................................5
..............................................6
.........................................................7
..........................................................8
...................................................9
....................10
...............11
................................................................12-13
................................................14
............................................15
...............................................16
............................................17
.......................................................................... 19
....................................................20
...................................................................21
...............................................................22
......................................................23
...............................................24
.........................................................25-26
.........................................................27-28
.......................................................28
..........................................................................30
..............................................................31
Table of Contents
Managing Multiple calls
Auxiliary audio source
Warranty
FCC Compliance

4
Please read these instructions carefully before proceeding. Failure to follow instructions may result in
improper operation or injury. VOXX Electronics Corporation, its regional offices, distribuotrs or resellers
won’t take any responsibility for any damage or injury as a result of using the integration kit.
- Do not open, disassemble or alter the interface in any way.
- Do not insert anything into the casing.
- Do not cut or try to alter cables in any way and always use the correct connections.
- Only operate unit when stationary or ask passengers to operate it for you.
- Do not allow the Mobile Phone to distract you from driving.
- Exercise good judgement and keep your eyes on the road at all times.
- Do not expose unit to extreme temperatures, humidity or shock.
- Keep away from children! - Interface components may contain small parts, can be broken or disassembled
and components may become loose from vibration and heat. Small components and packaging materials
may be a choking hazard when handled by children.
Warning and safety!

5
Thank you for purchasing this integration kit. Please review this booklet before operating the unit. This
interface was designed and manufactured to seamlessly integrate with your vehicle’s factory audio system.
and have unlimited access to our online support system.
To register your Audiovox product, please complete the following steps:
1. Visit http://www.audiovoxoei.com
2. Look up and save the serial number of the product.
3. Complete the product registration form.
4. Submit the form.
5. Save the registration sheet in a safe place for future reference.
If you are unable to complete the registration via internet, please call VOXX Electronics at 1-800-645-4994.
Congratulations on your purchase!
Product registration
28

6
CarStream kit contents
Optional accessories (sold separately):
CarStream module
IR Receiver &
Remote controller
(AACC613RCK)
AUX connector
(AACC106AUX)
Vehicle Interface
Harness
For more accessories, visit
www.audiovoxoei.com
BCS1M Bluetooth
module
Clip and 2-sided mount
Adapter cable for
SXV200/300 tuner
(AACCSATCBL)

7
DIP switch settings
The following DIP switch settings are used to
configure the CarStream module to interface with
the various radio systems. Before installation, set
the DIP switch to the position shown for the
corresponding radios and desired features.
Use this setting if car is
equipped with base VW
radio or AUDI concert radio.
VW/ AUDI CONCERT
OFF OFF
AUDI SYMPHONY
Use this settig if car is
equipped with Audi
Symphony radio system
ON
OFF
AUDI NAV+
Use this setting if car is
equipped with AUDI Navi-
gation plus radio system.
ON ON
VW NAV
Use setting if car is
equipped with Volkswagen
Navigation system.
OFF
ON
CarStream module

8
Factory SAT
harness in vehicle
VW / AUDI
SATELLITE Tuner
To CarStream
Interface Module
CarStream BT103AVW Connector
Factory satellite radio tunner must be disconnected and cannot be retained with the CarStream BT103AVW integration kit.
The factory Satellite tuner connections must be accessed, for which the location varies depending on vehicle
(inside trunk panels, under passenger seat, etc). The harness provided with the kit is long enough to reach
from these locations. If there is a factory satellite tuner, unplug its two connections. This CarStream kit does not
support the retention of the factory satellite radio tuner at the time of printing this document.

9
Attention installer! Please read the following!
Audiovox strongly recommends that the unit be installed in an easily accessible location!
DO NOT PLACE IT BEHIND THE RADIO
AND DO NOT HIDE UNDER CARPET!
Whether the unit is professionally or self installed, put the module where you, the end user can get to it easily
in the future. (Have the installer show you where the interface module is installed.)
-Add possible future upgrades, changing software, adding new features, improving operation;
-Access the AUX input on the module to attach any audio device;
-Access the DIP switches located on the module;
-Remove the unit in case of failure.
Disconnect the vehicle harness from the module and set the ignition to the off position for
60 seconds after changing the switches then reconnect the module!

10
Connection diagram - Bluetooth and AUX inputs
* Do not connect the Bluetooth module under any circumstance to the SIRIUS module
connector! Improper connection can cause permanent damage to Bluetooth/Interface module.
(front)
CarStream module
(back)
Bluetooth module
Vehicle Inter-
face Cable
Auxiliary device
(not included)
AUX cable
(optional)
CarStream module
Upgrade Port
USB to PC
or MAC computer

Connection diagram - Bluetooth and Satellite inputs
11
*Do not connect the Bluetooth module under any curcumstance to the SIRIUS connector!
Improper connection will cause permananet damage to the Bluetooth / Interface module.
IR Receiver
(optional)
CarStream Module
(front)
CarStream Module
(back)
Bluetooth Module
Vehicle Connector
Use Legacy SIRIUS
SCC1 Tuner
or
VEHICLE TUNER
SiriusXM Vehicle Tuner
(Not included)
Adapter cable
AACCSATCBL
(optional)
Upgrade Port
USB to PC
or MAC computer

12
Installation
1. Verify compatibility 5. Route kit to glove box or other accessible location
2. Disconnect battery
3. Locate factory Satellite Radio harness
4. Set DIP switches to match factory radio
type and install car specific harness
6. Connect Bluetooth module
ON
OFF
Continue on next page.

13
Optimal Stickey Mount
Acceptable Stickey Mount
Clip Mount
Avoid
7. Mount the microphone in a suitable location as per the illustration.
Use the included 2-sided tape or the clip. Make sure the microphone
is directly facing the drivier.
8. Complete install

14
Controls and Indicators
1
3
2
4
1. Light Ring
Unlit - unit is off.
Red - unit is disconnected.
Blue - unit is connected.
Alternating red and blue - unit is in pairing mode.
2. Multi-Function Button
3. Built-In Microphone
4. Off / On / (Bluetooth) Switch
Slide down to OFF to turn the unit off.
Slide up to ON to turn the unit on.
Slide up to to initiate pairing mode.

15
Bluetooth / AUX operation:
Much like the radio’s AM/FM tuner or CD player, CarStream is integrated to be part of the factory audio system.
1. Select SAT mode using the source selector button. The display will show ‘BCS1’.
At this time the AUXILIARY INPUT PORT OF THE CARSTREAM MODULE is enabled. Phone call or Bluetooth
music streaming will automatically take over the AUX input.
Pickup / Hang-up
LOAD EJECT
BASS MIDDLE TREBLE BALANCE FADER
SCAN
TUNE
ON
VOL
FM
AM
CD
SAT
CAT
FLDR
SEEK
TRACK
XM 1 001
001 002 003 004 005 006
*
BCS1

16
Satellite operation:
While the factory Satellite radio retention is not supported with this model, it is possible to add a Sirius SCC1
or a SiriusXM SXV200 / SXV300 vehicle tuner to the CarStream kit. Here’s how to access satellite radio:
Select the SAT input source. Use your radio as described below and also in its owner’s manual for Satellite
Radio operation. Using the seek buttons or knob will change stations, the CAT button will change categories.
The presets can store and recall saved channels. Phone calls or Bluetooth streaming will automatically
interrupt the Satellite Radio source.
LOAD EJECT
BASS MIDDLE TREBLE BALANCEF ADER
SCAN
TUNE
ON
VOL
FM
AM
CD
SAT
CAT
FLDR
SEEK
TRACK
XM 1 56
001 002 003 004 005 006
Blake Shelton - Neon Light
The Highway

17
Important Note:
Adding SiriusXM SXV200/300 vehicle tuner to Audi NAV+ and Volkswagen
Navigation units is not supproted at the time of printing.
Only Bluetooth calling and music streaming will function on these Navigation units.
If retention of the factory satellite radio tuner is desired, we recommend using
the CarStream BT101AVW or BT102AVW kit.

18
Pairing Your Phone
Your mobile phone can initiate a search for the BCS1M.
Note: The following procedures are generic. Procedures for pairing mobile phones may vary. Please
refer to the manual that came with your mobile phone.
1. Turn the BCS1M on and slide the button slider up to the (Bluetooth) position.
2. Access the mobile phone’s Bluetooth function and turn the function on.
3. Set the mobile phone’s Bluetooth discover mode to on.
4. Use the mobile phone’s add new device feature. “Bluetooth car kit” will appear on your mobile
phone’s device list.
5. A prompt to pair should appear on your mobile phone. Accept the request to initiate the process.
6. Some mobile phones require a PIN to connect. If asked, enter “0000”.
7. A message stating that pairing is successful should appear on your mobile phone. A prompt
asking you to connect should also appear. Accept the request to initiate the connection.
8. Once connected, the light bar will turn a solid blue.
The light bar will flash red and blue alternatively.

19
Operation
Activating Voice Assistant (Siri / Google Voice / Voice Dial)
To activate the Voice Assistant feature of the mobile phone (if available), press and hold the multi-function
button for 2-3 seconds and then release it. Compatible Apple iPhone 4S or later model will trigger a
Siri session. Google Voice may be available on select Android phones. Feature must be enabled on phone.
.
Managing Phone Calls
To make a call:
Place calls as you normally do on your phone. The call audio will be heard through your car stereo.
To make a call using voice-dialing:
If your phone supports voice-dialing, press and hold the multi-function button for 2–3 seconds, and
then release the multi-function button. You should hear your phone prompt you for a command.
To answer a call:
When an incoming call is detected, the light ring will blink blue.
Tap the multi-function button to answer the call. The light ring will return to solid blue.

20
Managing Multiple Calls/Call-Waiting
To answer a second incoming call:
Tap the multi-function button three times to reject the call.
To switch between two calls:
Double-tap the multi-function button.
To end the call on hold:
Tap the multi-function button three times.
To end the second call:
Double-tap the multi-function button.
Tap the multi-function button to end the current call.
Multi-Function button
