Audiovox VOH802 - VOH 802 - LCD Monitor User manual

VOH802 DL
8” LCD
OVERHEAD
TV/MONITOR
OWNER’S
MANUAL

-1-
IMPORTANT NOTICE
It is unlawful in most jurisdictions for a person to drive a
motor vehicle which is equipped with a television viewe
r
or screen that is located in the motor vehicle at any point
forward of the back of the driver’s seat, or that is visible,
directly or indirectly, to the driver while operating the
vehicle. In the interest of safety, the VOH802 DL should
never be installed where it will be visible, directly o
r
indirectly, by the operator of the motor vehicle.
TELEVISION RECEPTION
This entertainment system is designed primarily fo
r
viewing pre-recorded movies or playing video games.
Television reception in a moving vehicle will be
limited and in some areas will not be possible due to
weak and variable signal strength. Television
viewing in a stationary vehicle will result in an
improvement, but may still be marginal due to
strength. The quality of the picture will not be
consistent with home TV reception. Reception may
be affected by the weather and distance from the TV
station. A weak signal may cause the picture to roll,
be snowy, or cause some color loss.

-2-
Congratulations on your purchase of the Audiovox
VOH802 DL drop down TV/Video Monitor. The
VOH802 DL has been designed to give you and you
r
family many years of video entertainment in the mobile
environment. Please read the directions that follow to
familiarize yourself with the product and to ensure that
you obtain the best results from your equipment.
NOTE: Installation options vary. See the individual
Owner’s Manuals for each component in your system to
obtain a full understanding of each component’s
operation.
SAFETY PRECAUTION
For safety reasons, when changing Video Media it is
recommended that the vehicle is not in motion, and that
you do not allow children to unfasten seat belts to
change Video Media or make adjustments to the
system. System adjustments can be accomplished
using the Remote Control while seat belts remain
fastened. Enjoy your Audiovox entertainment system
but remember safety of all passengers remains the
number one priority.
FEATURES
• 8” TFT (Thin Film Transistor) Active Matrix LCD
(Liquid Crystal Display) Monitor
• OSD (On Screen Display) For Control Of Picture
Quality And Functions
• Full Function Remote Control
• Television Tuner
• Remote Sensor Eye
• Three Audio / Video Sources
• Speaker Amplifier
• Back-Lit Controls For Low Light Operation
• Inferred Wireless RF Headphone Transmitter
• Dual Dome Light
• Optional Jack for RF Transmitter (for the Wireless
RF Headphones)

FRONT PANEL FEATURE
Figure 1
-3-
13456789
10
11
2
9

-4-
FRONT PANEL FEATURES – See Figure 1
1. SENSOR EYE –
A
llows the remote control to operate
the VOH802 DL’s OSD system (On Screen Display),
volume to Wired Headphone Jacks (and optional
external speakers), and for control of Video Media
Player and other accessories.
2. INFRARED TRANSMITTER – Used to transmit audio
to Wireless Headphones.
3. POWER BUTTON – (Bright red when system is ON,
dim when system is OFF).
4. PIX AND VOLUME UP/DOWN – Controls Volume to
Headphone Jacks and external Speakers i
f
connected. Also, used to adjust the picture control
setting when “contrast”, “bright”, “color” or “tint” is
displayed on the screen.
5. PICTURE SELECT – Each time this button is
pressed, the screen picture adjustment display cycles
through “adjustment bars” for CONTRAST,
BRIGHTNESS, COLOR, and TINT. Once the desired
adjustment bar is displayed, use the VOLUME
UP/DOWN buttons to adjust the setting. The display
will automatically turn off if no adjustments are made
wi
t
hin
6
seco
n
ds,
o
r if
a
n
y
ot
h
e
r
butto
n i
s
dep
r
essed
.
6. SELECT – Used to select one of the Three A/V
sources.
7. CHANNEL UP/DOWN – Changes the TV channel.
8. AUTO PROGRAM SWITCH (AP) –
A
uto Program
used to program local channels into TV memory.
Press when vehicle is in a new location.
9. DOME LIGHTS – Provide additional illumination.
10. THREE POSITION DOME LIGHT SWITCH
• Auto – Automatically switched on the dome lights
in conjunction with the vehicle’s interio
r
illumination.
• Off – The Dome lights will not turn on in this
position.
• On – Turns on the Dome lights.
11. SCREEN RELEASE – Slides in the direction of the
arrow to release the drop down screen.

REMOTE CONTROL OPERATION
-5-
BATTERY INSTALLATION
Before attempting to operate the Remote Control,
install the batteries as described below.
1) Turn the Remote Control face down. Press
down on the ridged area of the battery cover, and
slide it off.
2) Install Two “AAA” batteries as shown. Make sure
that proper polarity (+ or -) is observed.
3) Slide the cover back until it clicks into position.
The Remote Control will operate the VOH802 DL,
Audiovox Televisions and Video Media Players. It is
not a universal remote control and will not control
equipment from other manufacturers.
If a universal Remote Control is used with the
VOH802 DL, choose the remote control encoding
scheme for Audiovox Televisions when
programming the remote.
1
2
3
4
5
6
8
9
10
11
12
14
13
16
15

-6-
REMOTE CONTROLLED TV FUNCTIONS
1. POWER ON/OFF
Press this button to turn the VOH802 DL on. The
channel number or current video source will be
displayed on screen, and the picture will appear in
a few seconds. Press the button again to turn the
VOH802 DL off.
2. DIRECT ACCESS (0-9) BUTTONS
Use these buttons to make a direct channel
selection. The channel number chosen will be
displayed on the screen for about 4 seconds. The
direct access is carried out with 0-9 keys (0-99CH).
The “1__” key will not function as it is only used fo
r
cable channels above 99.
3. CHANNEL UP/DOWN BUTTONS
Use these buttons to advance to the next higher o
r
lower channel. See also: SKIP/SEARCH BUTTON.
4. VOLUME UP/DOWN BUTTONS
Use these buttons to raise or lower the volume
level of the Wired Headphones or External
Speakers if installed. They are also used to make
adjustments in the picture select mode.
NOTE: These buttons will not affect the volume o
f
wireless headphones or a wired RF modulator.
When using these devices the volume must be
adjusted with the headphone volume control or with
your radio’s volume control. (See page 10,
Headphones, or page 11, Wired FM Modulator).
5. PICTURE SELECT BUTTON
Each time this button is pressed, the screen picture
adjustment display cycles through “adjustment
bars” for CONTRAST, BRIGHTNESS, COLOR,
and TINT. Once the desired adjustment bar is
displayed, use the VOLUME UP/DOWN buttons to
adjust the setting. The display will automatically
turn off if no adjustments are made within 6
seconds, or if any other button is depressed.
6. MUTE BUTTON
Press this button to shut off the sound to the
Wired Headphones and External Speakers i
f
installed. The screen will display the volume
adjustment bar for 6 seconds, indicating that the
sound has been turned off. Pressing the button
again restores sound to the previously set level.
The mute feature may also be released by pressing
the VOLUME UP/DOWN buttons.
7. TV / VIDEO BUTTON
A
ny video equipment connected to the
A
UDIO/VIDEO inputs can be used with the TV by
pressing this button. Each time the button is
pressed, the Audio/Video source will change in the
following sequence VIDEO1, VIDEO2, and TV.

-7-
8. AUTO MEMORY BUTTON
When the AUTO MEMORY BUTTON is depressed,
all channels in TV mode are searched and tuned; all
channels with strong signals detected are
automatically stored.
9. SKIP/SEARCH BUTTON
This button selects between SKIP and SEARCH
mode. In “SKIP mode” the TV only stops on
channels that are programmed into memory when
the CHANNEL UP/DOWN buttons are used. When
the SKIP is turned off, the TV keep only stop on all
keep channels.
10. ERASE/WRITE BUTTON
When tuned to a channel press this button to store
or erase the channel from memory. The stored
channel numbers are displayed in “GREEN” on the
screen, and the erased channels are in “RED”.
When skip mode is on, the VOH802 DL will tune to
only the stored channels when using the CHANNEL
UP/DOWN buttons.
REMOTE CONTROLLED VCP FUNCTIONS
These features can only be used with an Audiovox Video
Tape Player, if this option was installed with your video
package. For more information consult the Audiovox
VCP Owner’s Manual.
11. POWER BUTTON
This button is used to turn the VCP on and off.
12. “REW” REWIND BUTTON
If this button is pushed while the tape is stopped, the
Video Tape will rewind. If this button is pushed while
the tape is playing, the VCP will go into rewind search
mode.
13. PLAY BUTTON
Press this button to activate play mode while a Video
Tape is loaded into the VCP. This button may also be
used to disengage search and pause modes.
14. “FFWD” FAST FORWARD BUTTON
If this button is pushed while the tape is stopped, Video
Tape will fast forward. If this button is pressed while
the Video Tape is playing, the VCP will go into fast
forward search mode.
15. REPLAY BUTTON
Pressing this button will rewind the Video Tape and
immediately begin playback when the Video Tape is
fully rewound.
16. STOP BUTTON
Press this button to stop the Video Tape.

-8-
CHANNEL TUNING SETUP
In order to easily access all available channels, it may
be necessary to perform the channel Auto-
Programming procedure whenever the vehicle’s
geographic location has changed, i.e. city-to-city,
weak signal area.
1. Press the AUTO MEMORY button on the remote
control unit or the AUTO PROGRAM button on the
flip down video unit. You will see the TV cycle
through all its channels. The built-in
microprocessor will automatically note each
channel that is actively broadcasting in your area.
(A)To tune only strong clear channels with the
CHANNEL UP/DOWN buttons, press the
SKIP/SEARCH button on the Remote Control
Unit until “SKIP MODE ON” is displayed on the
bottom of the screen. The TV will now tune
only to strong active channels when the UP o
r
DOWN buttons are used on the monitor or the
remote control.
(B)To tune to weak or marginal channels with the
CHANNEL UP/DOWN buttons, press the
SKIP/SEARCH button on the Remote Control
Unit until “SKIP MODE OFF” is displayed on the
bottom of the screen. Tune to the desired
channel using the CHANNEL UP/DOWN
buttons or go directly to the channel by using
the 0-9 buttons on the Remote Control.
2. To ERASE a channel, press the ERASE/WRITE
button on the Remote Control Unit until “MANUAL
MEMORY XX ERASE” is displayed on screen. To
STORE a channel, press the button until the
MANUAL MEMORY XX ADD is displayed on
screen.
TURNING THE VOH802 DL ON AND OFF
1 Sliding the screen release lock forward viewing will
unlock the screen and it will drop down slightly.
(Pivot the screen downward until a comfortable
angle is reached). After the unit has been turned
on and is displaying a picture, adjustment to the
viewing angle can be made by pivoting the screen
to optimize the picture quality. The internal friction
detent will hold the screen in position while the
system is in use.
2 Pressing the power button on the pod or remote will
alternately turn the system on or off. When in use
the internal back lighting will illuminate the controls.
3 Remember to turn the unit off and pivot the display
screen to the locked position when not in use.

-9-
REMOTE INFERRED SENSOR/REPEATER
The VOH802 DL incorporates a Remote Infrared
Sensor, which relays the signals from the Remote
Control to allow the VOH802 DL and VCP to be
controlled simply by pointing it’s Remote Control at the
remote sensor. This provides control of auxiliary
equipment such as an Audiovox VCP or DVD Player.
The Remote Infrared Sensor can relay signals from
most manufacturers Remote Control to its respective
component connected to the Video 1 and 2 inputs. In
this case you must use the Remote Control supplied
with the other manufacturers component.
Remote Inferred Sensor
OPERATION
OVERHEAD DOME LIGHTS
A three-position slide switch controls the Dome
Lights on the VOH802 DL. Sliding the switch to the
ON position will turn the Dome Lights ON. The OFF
position will prevent the Dome Lights from turning
ON at all times and the auto position will allow the
Dome Lights to turn ON and OFF with the vehicle’s
interior lighting. Do not leave the vehicle
unattended with the Dome Lights switch in the ON
position, as this could result in a discharged battery.
Dome Light Switch
Dome Light
Dome Light
