AUSSIE TONNEAU ATB01002 Install guide

TONNEAU COVER FITTING INSTRUCTION
FORD FALCON
XD XE XF XG XH SINGLE CAB
1979 –1999
PART NO: ATB01002
BASIC TOOLS REQUIRED
Drill, 4mm Drill Bits, Rivet Gun, Marking Pencil/ Pen
CONTENTS
-1 x Tonneau Cover - 4 x Bar Brackets
-2 x Support Bars - 8 x Rivets
-1 x Fitting Instruction
1. INSTALLATION PROCEDURE
NOTE Read entire instructions prior to start.
STEP 1 Fit the front of the Tonneau to the front of the Ute tub placing the LTD clips (Fitted on the
Tonneau Cover) on to the LTD posts already fitted on the body.
(Behind rear windscreen).
STEP 2 Fit your tonneau cover support bar/s into position (Refer to the instructions below)
STEP 3 Drape cover over support bars.
STEP 4 Fit Bunji Loops to Body Hooks, starting at the rear then fitting the side’s bunjis.
STEP 5 Your Tonneau Cover is now fitted.
2. MULTI-FIT SUPPORT BAR
The Aussie Tonneau Multi - Fit Support Bar is designed to fit almost all Utes on the Market, from Suburu Brumbys
to Cab Chassis aluminium trays.
2.1 BASIC TOOL REQUIRED
- Drill, 4mm drill bit
2.2 MULTI-FIT SUPPORT BAR CONTENTS
-1 x hollow bar centrepiece - 2 x grub screws
-2 x solid bar end piece

2.3 FITTING MULTI-FIT BAR
1. Insert solid bar pieces into either end of hollow tube. Adjust bar so it fits between bar bracket holders
with the holes facing to the ground (so the grub screws don’t rub against the tonneau), as shown above
and then with a white pencil make a mark through the small holes of the hollow bar onto the solid ends.
This is where you will drill a hole to the depth of about 1-2mm (do not go any further)
2. Join the pieces back together and screw grub screws through the hollow bar into the holes that you
drilled. Make sure you do not over tighten the grub screws. Refit the bar. You may kink the bar in the
middle to give it some extra height to assist with water runoff.
