Autel MaxiIM KM100 User manual

i
Trademarks
Autel®, MaxiIM®, MaxiCOM®, MaxiDAS®, MaxiScan®, MaxiTPMS®,
MaxiRecorder®, and MaxiCheck®are trademarks of Autel Intelligent Technology
Corp., Ltd., registered in China, the United States and other countries. All other
marks are trademarks or registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise without the prior written permission ofAutel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the
latest information available at the time ofprinting. Autel reserves the right to make
changes at any time without notice. While information of this manual has been
carefully checked for accuracy, no guarantee is given for the completeness and
correctness of the contents, including but not limited to the product specifications,
functions, and illustrations.
Autel will not be liable for any direct damages or for any special, incidental, or
indirect damages or for any economic consequential damages (including the loss
of profits).
IMPORTANT:Before operating or maintaining this unit, please read this manual
carefully, paying extra attention to the safety warnings and precautions.
For Services and Support:
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
[email protected]
For technical assistance in all other markets, please contact your local distributor.

ii
Safety Information
For your own safety and the safety of others, and toprevent damage to the device
and vehicles upon which it is used, it is important that the safety instructions
presented throughout this manual be read and understood by all persons
operating or coming into contact with the device.
There are various procedures, techniques, tools, and parts for servicing vehicles,
as well as in the skill of the person doing the work. Because of the vast number
of test applications and variations in the products that can be tested with this
equipment, we cannot possibly anticipate or provide advice or safety messages
to cover every circumstance. It is the automotive technician’s responsibility to be
knowledgeable of the system being tested. It is crucial to use proper service
methods and test procedures. It is essential to perform tests in an appropriate
and acceptable manner that does not endanger your safety, the safety of others
in the work area, the device being used, or the vehicle being tested.
Before using the device, always refer to and follow the safety messages and
applicable test procedures provided by the manufacturer of the vehicle or
equipment being tested. Use the device only as described in this manual. Read,
understand, and follow all safety messages and instructions in this manual.
Safety Messages
Safety messages are provided to help prevent personal injury and equipment
damage. All safety messages are introduced by a signal word indicating the
hazard level.
DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury to the operator or to
bystanders.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury to the operator or to
bystanders.

iii
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot
know, evaluate or advise you as to all of the possible hazards. You must be
certain that any condition or service procedure encountered does not jeopardize
your personal safety.
DANGER: When an engine is operating, keep the service area WELL
VENTILATED or attach a building exhaust removal system to the engine
exhaust system. Engines produce carbon monoxide, an odorless,
poisonous gas that causes slower reaction time and can lead to serious
personal injury or loss of life.
Do Not Turn the Volume Up Too Loud When Using Headphones
Listening at high volumes that over-stimulate the ear for long periods of
time may result in loss of hearing.
SAFETY WARNINGS:
Always perform automotive testing in a safe environment.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc., away from all
moving or hot engine parts.
Operate the vehicle in a well-ventilated work area.
Put the transmission in PARK (for automatic transmission) or
NEUTRAL (for manual transmission) and make sure the parking
brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
Be extra cautious when working around the ignition coil, distributor
cap, ignition wires and spark plugs. These components create
hazardous voltages when the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and
electrical fires nearby.
Do not connect or disconnect any test equipment while the ignition
is on or the engine is running.

iv
Keep the test equipment dry, clean, and free from oil, water, and
grease. Use a mild detergent on a clean cloth to clean the outside
of the equipment as necessary.
Do not drive the vehicle and operate the test equipment at thesame
time. Any distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and
adhere to all diagnostic procedures and precautions. Failure to do
so may result in personal injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data,
make sure the vehicle battery is fully charged and the connection
to the vehicle DLC is clean and secure.
Do not place the test equipment on the distributor of the vehicle.
Strong electro-magnetic interference can damage the equipment.
Do not place the device in a strong electromagnetic environment
for strong electromagnetic interference may damage the device.

v
CONTENTS
1. USING THIS MANUAL..............................................................................1
1.1 CONVENTIONS......................................................................................1
2. GENERAL INTRODUCTION.....................................................................3
2.1 MAXIIMKM100 ...................................................................................3
2.2 MAXIVCI V200 —VEHICLE COMMUNICATION INTERFACE.........................6
3. GETTING STARTED .................................................................................8
3.1 POWERING UP......................................................................................8
3.2 POWERING DOWN...............................................................................12
4. UNIVERSAL KEY....................................................................................13
4.1 CONFIRMING VEHICLE INFORMATION.....................................................13
4.2 OPERATION........................................................................................15
5. READING/CLONING...............................................................................17
5.1 TRANSPONDER READING.....................................................................17
5.2 TRANSPONDER CLONING .....................................................................18
5.3 TRANSPONDER EDITING ......................................................................20
6. TRANSPONDER FUNCTION..................................................................22
6.1 TRANSPONDER GENERATION ...............................................................22
6.2 TRANSPONDER SIMULATION.................................................................24
6.3 CONVERSION BETWEEN ID63 AND ID83................................................26
7. FREQUENCY DETECTION.....................................................................27
8. IMMO.......................................................................................................28
8.1 GETTING STARTED..............................................................................28

vi
8.2 VEHICLE IDENTIFICATION .....................................................................29
8.3 IMMOSCREEN LAYOUT......................................................................31
8.4 SCREEN MESSAGES............................................................................32
8.5 MAKING SELECTIONS ..........................................................................33
8.6 IMMO...............................................................................................33
9. SPECIAL FUNCTION..............................................................................41
9.1 IMMODATA PROCESSING...................................................................41
9.2 KEY UNLOCKING.................................................................................44
9.3 TOYOTA SMART UNLOCKING................................................................46
9.4 UNIVERSAL KEY INFORMATION DETECTION............................................46
9.5 BUTTON CUSTOMIZATION.....................................................................47
9.6 IGNITION COIL DETECTION...................................................................48
10. SETTINGS...............................................................................................50
10.1 MARKET...........................................................................................50
10.2 FEEDBACK .......................................................................................50
10.3 VCI MANAGER .................................................................................51
10.4 SYSTEM SETTINGS............................................................................54
10.5 UNITS..............................................................................................54
10.6 ABOUT.............................................................................................55
11. UPDATES................................................................................................56
12. DATA MANAGER....................................................................................58
12.1 TEST RECORDS................................................................................58
12.2WORKSHOP INFORMATION .................................................................59
12.3 IMAGES............................................................................................60

vii
12.4 PDFS..............................................................................................61
12.5 UNINSTALL APPS ..............................................................................61
12.6 DATA LOGGING.................................................................................61
13. REMOTE DESKTOP ...............................................................................63
14. TOOL REGISTRATION...........................................................................65
15. ACADEMY...............................................................................................66
16. MAINTENANCE AND SERVICE.............................................................67
16.1 MAINTENANCE INSTRUCTIONS ............................................................67
16.2 TROUBLESHOOTING CHECKLIST .........................................................68
16.3 ABOUT BATTERY USAGE....................................................................68
16.4 SERVICE PROCEDURES .....................................................................69
17. COMPLIANCE INFORMATION...............................................................73
18. WARRANTY............................................................................................75
18.1 LIMITED ONE-YEAR WARRANTY .........................................................75

1
1.Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional
equipment that are not included in your system. Contact your sales
representative for availability of other modules and optional tools or accessories.
1.1 Conventions
The following conventions are used.
1.1.1 Bold Text
Bold text is used to highlight selectable items such as buttons and menu options.
Example:
Tap OK.
1.1.2 Notes
A NOTE provides helpful information such as additional explanations, tips, and
comments.
1.1.3 Important
IMPORTANT indicates a situation which, if not avoided, may result in damage to
the test equipment or vehicle.
1.1.4 Hyperlinks
Hyperlinks or links that take you to other related articles, procedures, and
illustrations are available in electronic documents. Blue italic colored text
indicates a selectable hyperlink.

2
1.1.5 Procedures
An arrow icon indicates a procedure.
To power down the tool
Press and hold the Power/Lock button.
Tap Power off.
Tap OK. The tool will turn off in a few seconds.

3
2.General Introduction
The MaxiIM KM100 is a professional intelligent key tool that integrates such
functions as universal key generation, transponder reading/cloning, and IMMO
learning in a compact and easy-to-use design. Equipped with the MaxiVCI V200
vehicle communication interface device, this professional key tool easily offers
you one-stop service from universal key generation to key learning. It is
undoubtedly an ideal choice for professional locksmiths.
2.1 MaxiIM KM100
2.1.1 Product Overview
Figure 2-1 KM100 Front/Back View
1. 5.5-inch Touchscreen
2. Ambient Light Sensor —detects ambient brightness
3. Status LED
4. Low Frequency Detection Collector —collects low frequency data
5. Transponder Slot —reads and writes transponder
