Autel MaxiPRO MP808K User manual

i
Trademarks
Autel®, MaxiSys®, MaxiDAS®, MaxiScan®, MaxiTPMS®, MaxiRecorder®, and
MaxiCheck®are trademarks of Autel Intelligent Technology Corp., Ltd.,
registered in China, the United States and other countries. All other marks
are trademarks or registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise without the prior written permission of
Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on
the latest information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While
information of this manual has been carefully checked for accuracy, no
guarantee is given for the completeness and correctness of the contents,
including but not limited to the product specifications, functions, and
illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or
any economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully,
paying extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
[email protected]
For technical assistance in all other markets, please contact your local
selling agent.

ii
Safety Information
For your own safety and the safety of others, and to prevent damage to the
device and vehicles upon which it is used, it is important that the safety
instructions presented throughout this manual be read and understood by
all persons operating or coming into contact with the device.
There are various procedures, techniques, tools, and parts for servicing
vehicles, as well as in the skill of the person doing the work. Because of the
vast number of test applications and variations in the products that can be
tested with this equipment, we cannot possibly anticipate or provide advice
or safety messages to cover every circumstance. It is the automotive
technician’s responsibility to be knowledgeable of the system being tested.
It is crucial to use proper service methods and test procedures. It is
essential to perform tests in an appropriate and acceptable manner that
does not endanger your safety, the safety of others in the work area, the
device being used, or the vehicle being tested.
Before using the device, always refer to and follow the safety messages and
applicable test procedures provided by the manufacturer of the vehicle or
equipment being tested. Use the device only as described in this manual.
Read, understand, and follow all safety messages and instructions in this
manual.
Safety Messages
Safety messages are provided to help prevent personal injury and
equipment damage. All safety messages are introduced by a signal word
indicating the hazard level.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury to the operator or to bystanders.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury to the operator or to bystanders.

iii
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot
know, evaluate or advise you as to all of the possible hazards. You must be
certain that any condition or service procedure encountered does not
jeopardize your personal safety.
DANGER
When an engine is operating, keep the service area WELL VENTILATED or
attach a building exhaust removal system to the engine exhaust system.
Engines produce carbon monoxide, an odorless, poisonous gas that causes
slower reaction time and can lead to serious personal injury or loss of life.
SAFETY WARNINGS
Always perform automotive testing in a safe environment.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc. away from all
moving or hot engine parts.
Operate the vehicle in a well ventilated work area, for exhaust gases
are poisonous.
Put the transmission in PARK (for automatic transmission) or
NEUTRAL (for manual transmission) and make sure the parking brake
is engaged.
Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
Be extra cautious when working around the ignition coil, distributor cap,
ignition wires and spark plugs. These components create hazardous
voltages when the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and electrical
fires nearby.
Do not connect or disconnect any test equipment while the ignition is on
or the engine is running.
Keep the test equipment dry, clean, free from oil, water or grease. Use
a mild detergent on a clean cloth to clean the outside of the equipment
as necessary.
Do not drive the vehicle and operate the test equipment at the same

iv
time. Any distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and adhere
to all diagnostic procedures and precautions. Failure to do so may
result in personal injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data, make
sure the vehicle battery is fully charged and the connection to the
vehicle DLC is clean and secure.
Do not place the test equipment on the distributor of the vehicle. Strong
electro-magnetic interference can damage the equipment.

v
CONTENTS
1 USING THIS MANUAL...........................................................................................1
CONVENTIONS............................................................................................................1
2 GENERAL INTRODUCTION.................................................................................3
MAXIPRO MP808 DISPLAY TABLET........................................................................ 3
OTHER ACCESSORIES............................................................................................... 7
3 GETTING STARTED..............................................................................................9
POWERING UP........................................................................................................... 9
POWERING DOWN....................................................................................................13
4 DIAGNOSTICS......................................................................................................14
GETTING STARTED.................................................................................................. 14
VEHICLE IDENTIFICATION.........................................................................................15
NAVIGATION............................................................................................................. 20
MAIN MENU..............................................................................................................24
DIAGNOSIS............................................................................................................... 25
HOT FUNCTIONS...................................................................................................... 39
GENERIC OBD II OPERATIONS...............................................................................41
EXITING DIAGNOSTICS.............................................................................................45
5 MAXIFIX................................................................................................................. 47
NAVIGATION............................................................................................................. 47
OPERATIONS............................................................................................................ 50
6 SHOP MANAGER.................................................................................................57
VEHICLE HISTORY....................................................................................................58
WORKSHOP INFORMATION...................................................................................... 60
CUSTOMER MANAGER.............................................................................................61
7 DATA MANAGER................................................................................................. 65
OPERATIONS............................................................................................................ 65
8 SETTINGS............................................................................................................. 70
UNIT..........................................................................................................................70
LANGUAGE............................................................................................................... 71

vi
PRINTING SETTING.................................................................................................. 71
FIRMWARE UPGRADE.............................................................................................. 74
NOTIFICATION CENTER............................................................................................74
AUTO UPDATE..........................................................................................................75
SYSTEM SETTINGS.................................................................................................. 77
ABOUT...................................................................................................................... 78
9 UPDATE................................................................................................................. 79
10 SUPPORT.............................................................................................................. 81
PRODUCT REGISTRATION........................................................................................81
SUPPORT SCREEN LAYOUT.................................................................................... 82
MYACCOUNT...........................................................................................................82
USER COMPLAINT....................................................................................................83
DATA LOGGING........................................................................................................ 85
COMMUNITIES.......................................................................................................... 86
USER PROFILE.........................................................................................................87
TRAINING CHANNELS...............................................................................................88
FAQ DATABASE.......................................................................................................88
11 ACADEMY..............................................................................................................89
12 REMOTE DESK.................................................................................................... 90
13 QUICK LINK...........................................................................................................92
14 FUNCTION VIEWER............................................................................................93
15 MAINTENANCE AND SERVICE........................................................................ 96
MAINTENANCE INSTRUCTIONS................................................................................ 96
TROUBLESHOOTING CHECKLIST............................................................................. 97
ABOUT BATTERY USAGE.........................................................................................97
SERVICE PROCEDURES...........................................................................................98
16 COMPLIANCE INFORMATION........................................................................101
17 WARRANTY........................................................................................................ 104
LIMITED ONE YEAR WARRANTY........................................................................... 104

1
1Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional
equipment that are not included in your system. Contact your sales
representative for availability of other modules and optional tools or
accessories.
Conventions
The following conventions are used.
Bold Text
Bold text is used to highlight selectable items such as buttons and menu
options.
Example:
Tap OK.
Notes and Important Messages
Notes
ANOTE provides helpful information such as additional explanations, tips,
and comments.
Example:
NOTE
New batteries reach full capacity after approximately 3 to 5 charging and
discharging cycles.
Important

2
IMPORTANT indicates a situation which, if not avoided, may result in
damage to the test equipment or vehicle.
Example:
IMPORTANT
Keep the cable away from heat, oil, sharp edges and moving parts. Replace
damaged cables immediately.
Hyperlink
Hyperlinks, or links, that take you to other related articles, procedures, and
illustrations are available in electronic documents. Blue italic text indicates a
selectable hyperlink and blue underlined text indicates a website link or an
email address link.
Illustrations
Illustrations used in this manual are samples, the actual testing screen may
vary for each vehicle being tested. Observe the menu titles and on-screen
instructions to make correct option selection.

3
2General Introduction
Based on the Android operating system, MaxiPRO MP808 is featured with
an extensive coverage of OE-level diagnostics. Installed with a fast
quad-core processor, MP808 offers maximum convenience and efficiency
for your diagnosis and analysis. The intuitive user interface makes using the
device effortless through a 7-inch LCD touchscreen that displays at 1024 x
600 quality.
This manual describes the construction and operation of the device and
how it works to deliver diagnostic solutions.
MaxiPRO MP808 Display Tablet
Functional Description
Figure 2- 1 Display Tablet Front View
1. 7.0” LCD Capacitive Touchscreen
2. Ambient Light Sensor – detects ambient brightness.
3. Power LED – indicates battery level & charging or system status.
4. Vehicle Communication LED – flashes green when the Display Tablet

4
is communicating/linking with the vehicle’s systems.
The power LED displays green, yellow or red depending on power level and
operating state.
A. Green
Illuminates green when the Display Tablet is charging and the
battery level is above 90%.
Illuminates green when the Display Tablet is powered on and the
battery level is above 15%.
B. Yellow
Illuminates yellow when the Display Tablet is charging and the
battery level is below 90%.
C. Red
Illuminates red when the Display Tablet is powered on and the
battery level is below 15%.
Figure 2- 2 Display Tablet Back View
5. Collapsible Stand – extends from the back to allow hands-free viewing
of the Display Tablet.
6. Heat Sink
7. Built-in Battery

5
Figure 2- 3 Display Tablet Top View
8. Mini USB OTG Port
9. Micro SD Card Slot – holds the micro SD card.
10. DB15-Pin Port – connects the main cable.
11. USB Port
12. Lock/Power Button – turns the device on & off with long press, or locks
the screen with short press.
Power Sources
The Display Tablet can receive power from any of the following sources:
Internal Battery Pack
Vehicle Power
External Power Supply
Internal Battery Pack
The Display Tablet can be powered with the internal rechargeable battery,
which if fully charged can provide sufficient power for about 4.5 hours of
continuous operation.
Vehicle Power
When the Display Tablet is connected to the test vehicle via the main cable,
the Display Tablet automatically receives power from the vehicle.
External Power Supply
The Display Tablet can be powered from a wall socket using the mini USB
cable and the USB external power adapter. The external power supply also
charges the internal battery pack.

6
Technical Specifications
Table 2- 1 Specifications
Item
Description
Recommended Use
Indoor
Operating System
AndroidTM 4.4.4
Processor
Cortex-A9 processor (1.5 GHz)
Memory
32GB
Display
7-inch LCD capacitive touchscreen with
1024x600 resolution
Connectivity
Mini USB 2.0
USB 2.0
Wi-Fi
Micro SD card (supports up to 32GB)
Sensors
Ambient light sensor for brightness auto
changing
Audio Input/Output
Input: N/A
Output: buzzer
Power and Battery
3.7 V/5000 mAh lithium-polymer battery
Charges via 5 VDC power supply
Tested Battery Life
Around 4.5 hours of continuous use
Battery Charging Input
5 V/1.5 A
Power Consumption
500 mA (LCD on with default brightness, Wi-Fi
on) @3.7 V
Operating Temp.
-10 to 60°C(14 to 140°F)
Storage Temp.
-20 to 70°C (-4 to 158°F)
Operating Humidity
5% - 95% non-condensing

7
Dimensions (W x H x D)
237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm
(1.4”)
Net Weight
788 g (1.74 lb.)
Supported Automotive
Protocols
ISO9141-2, ISO14230-2,ISO15765, K/L-Line,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, ISO11898(Highspeed, Middlespeed,
Lowspeed and Singlewire CAN,fault-tolerant
CAN), SAE J2610,GM UART,UART Echo Byte
Protocol, Honda Diag-H Protocol, TP2.0, TP1.6
Other Accessories
Main Cable
The Main Cable connects the Display Tablet to the vehicle’s data link
connector (DLC).
Other Accessories
Mini USB Cable
Connects the Display Tablet to the PC or USB
external power adapter.
USB External Power Adapter
Together with the mini USB cable, connects the
Display Tablet to the external DC power port for power
supply.
Figure 2- 4 Main Cable

8
User Manual
Tool operations instructions.
Quick Reference Guide
Devices connection and diagnostic software update
instructions.

9
3Getting Started
Ensure the Display Tablet is sufficiently charged or is connected to the
external power supply (see Power Sources on page 5).
NOTE
The images and illustrations depicted in this manual may differ slightly from
the actual ones.
Powering Up
Long press the Lock/Power button on the top right of the tablet to power on
the unit. The power LED light will illuminate green. The system boots up and
displays the lock screen. Slide the Lock icon to the left to enter the
MaxiPRO Job Menu or slide to the right to unlock.
1. Application Buttons
2. Locator and Navigation Buttons
3. Status Icons
Figure 3- 1 Sample MaxiPRO MP808 Job Menu

10
NOTE
The tablet screen is locked by default when first powered on. It is
recommended to lock the screen to protect the information in the system
and reduce the power consumption.
The touch screen navigation is menu driven, enabling quick access to
functions and features by tapping on options headings and answering dialog
windows. Detailed descriptions of the menu structures are found in
application chapters.
Application Buttons
Descriptions of the tool applications are displayed in the table below.
Table 3- 1 Applications
Button
Name
Description
Diagnostics
Accesses diagnostic function menu. See
Diagnostics on page 14 for details.
MaxiFix
Launches the MaxiFix platform which provides the
most compatible and abundant repair techniques
and diagnostics database. See MaxiFix on page
47 for details.
Shop
Manager
Accesses Shop manager database to store
workshop, customer information and vehicle test
history. See Shop Manager on page 57 for details.
Data
Manager
Accesses the organization system for saved data
files. See Data Manager on page 65 for details.
Settings
Accesses MaxiPRO system settings menu and
general tablet menu. See Settings on page 70 for
details.
Update
Checks for the latest update available for the
MaxiPRO system and performs updates. See
Update on page 79 for details.

11
Button
Name
Description
Support
Launches the Support platform which
synchronizes Autel’s on-line service base station
with the MaxiPRO tablet. See Support on page 81
for details.
Academy
Accesses technical tutorials and training articles
about the device or vehicle diagnostic techniques.
See Academy on page 89 for details.
Remote
Desk
Configures the unit to receive remote support
using the TeamViewer application program. See
Remote Desk on page 90 for details.
Quick Link
Provides associated website bookmarks to allow
quick access to product update, service, support
and other information. See Quick Link on page 92
for details.
Function
Viewer
Provides quick search for the supported functions
and vehicles of Autel diagnostic tools . See Function
Viewer on page 93 for details .
Locator and Navigation Buttons
Operations of the Navigation buttons at the bottom of the screen are
described in the table below:
Table 3- 2 Locator and Navigation Buttons
Button
Name
Description
Locator
Indicates the location of the screen. Swipe the
screen left or right to view the previous or next
screen.
Back
Returns to the previous screen.
Android Home
Returns to Android System’s Home screen.

12
Button
Name
Description
Recent Apps
Displays a list of applications that are currently
in use. Tap an App icon to launch. To remove
an app, swipe it to the top or bottom.
Chrome
Launches the Android built-in browser.
Screenshot
Takes a screenshot when you want to save
the displayed information.
MaxiPRO
Home
Returns to MaxiPRO Job Menu from other
Android applications.
Diagnostic
Shortcut
Returns to the Diagnostic screen from other
operations.
System Status Icons
As the Display Tablet is working with the Android operating system, you
may refer to Android documents for more information.
By tapping the bottom right corner, a Shortcuts Panel will be displayed, on
which you are allowed to set various system settings of the tablet.
Operations of each button on the panel are described in the table below.
NOTE
The shortcuts buttons will be highlighted when enabled and dimmed when
disabled.
Table 3- 3 Shortcuts Panel Buttons
Button
Name
Description
Calculator
Launches calculator when pressed.
Clock
Launches clock when pressed.
Wi-Fi
Enables/disables Wi-Fi when pressed.
Airplane
Mode
Enables/disables Airplane Mode when
pressed.

13
System
Settings
Launches the Android System Settings
screen when pressed.
Powering Down
All vehicle communications must be terminated before shutting down the
Display Tablet. A warning message displays if you attempt to shut down the
Display Tablet when it is communicating with the vehicle. Forcing a
shut-down while communicating may lead to ECM problems on some
vehicles. Please exit the Diagnostics application before powering down.
To power down the display tablet
1. Long press the Lock/Power button.
2. Tap Power off option.
3. Tap OK and the tablet will turn off in a few seconds.
Reboot System
In case of system crash, long press the Lock/Power button and tap Reboot
option to reboot the system.

14
4Diagnostics
The Diagnostics application can retrieve ECU information, read & erase
DTCs, and view live data. The Diagnostics application can access the
electronic control unit (ECU) for various vehicle control systems including
engine, transmission, antilock brake system (ABS), airbag system (SRS).
Getting Started
Ensure a communication link is established between the test vehicle and
the Display Tablet via the main cable.
Vehicle Menu Layout
When the tablet is properly connected to the vehicle, the platform is ready to
start vehicle diagnosis. Tap on the Diagnostics application button on the
MaxiPRO MP808 Job Menu to access the Vehicle menu.
1. Top Toolbar Buttons
2. Vehicle Manufacturer Buttons
Figure 4- 1 Sample Vehicle Menu
