Autel MaxiPro MP808 User manual

i
Trademarks
Autel®, MaxiSys®, MaxiDAS®, MaxiScan®, MaxiTPMS®, MaxiRecorder®, and
MaxiCheck®are trademarks of Autel Intelligent Technology Corp., Ltd., registered in
China, the United States and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise
without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the latest
information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While information of
this manual has been carefully checked for accuracy, no guarantee is given for the
completeness and correctness of the contents, including but not limited to the product
specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or any
economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying extra
attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
[email protected]
For technical assistance in all other markets, please contact your local selling agent.

ii
Safety Information
For your own safety and the safety of others, and to prevent damage to the device and
vehicles upon which it is used, it is important that the safety instructions presented
throughout this manual be read and understood by all persons operating or coming into
contact with the device.
There are various procedures, techniques, tools, and parts for servicing vehicles, as well
as in the skill of the person doing the work. Because of the vast number of test
applications and variations in the products that can be tested with this equipment, we
cannot possibly anticipate or provide advice or safety messages to cover every
circumstance. It is the automotive technician’s responsibility to be knowledgeable of the
system being tested. It is crucial to use proper service methods and test procedures. It
is essential to perform tests in an appropriate and acceptable manner that does not
endanger your safety, the safety of others in the work area, the device being used, or the
vehicle being tested.
Before using the device, always refer to and follow the safety messages and applicable
test procedures provided by the manufacturer of the vehicle or equipment being tested.
Use the device only as described in this manual. Read, understand, and follow all safety
messages and instructions in this manual.
Safety Messages
Safety messages are provided to help prevent personal injury and equipment damage.
All safety messages are introduced by a signal word indicating the hazard level.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury to the operator or to bystanders.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury to the operator or to bystanders.
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot know,
evaluate or advise you as to all of the possible hazards. You must be certain that any
condition or service procedure encountered does not jeopardize your personal safety.
DANGER
When an engine is operating, keep the service area WELL VENTILATED or attach a
building exhaust removal system to the engine exhaust system. Engines produce carbon
monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to
serious personal injury or loss of life.

iii
SAFETY WARNINGS
Always perform automotive testing in a safe environment.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or hot
engine parts.
Operate the vehicle in a well-ventilated work area, for exhaust gases are poisonous.
Put the transmission in PARK (for automatic transmission) or NEUTRAL(for manual
transmission) and make sure the parking brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle unattended while
testing.
Be extra cautious when working around the ignition coil, distributorcap, ignition wires
and spark plugs. These components create hazardous voltages when the engine is
running.
Keep a fire extinguisher suitable for gasoline, chemical, and electrical fires nearby.
Do not connect or disconnect any test equipment while the ignition is on or the
engine is running.
Keep the test equipment dry, clean, free from oil, water or grease. Use a mild
detergent on a clean cloth to clean the outside of the equipment as necessary.
Do not drive the vehicle and operate the test equipment at the same time. Any
distraction may cause an accident.
Refer to the service manual for the vehicle being serviced and adhere to all
diagnostic procedures and precautions. Failure to do so mayresult in personal injury
or damage to the test equipment.
To avoid damaging the test equipment or generating false data, make sure the
vehicle battery is fully charged and the connection to the vehicle DLC is clean and
secure.
Do not place the test equipment on the distributor of the vehicle. Strong electro-
magnetic interference can damage the equipment.

iv
CONTENTS
1USING THIS MANUAL ...............................................................................................1
CONVENTIONS...................................................................................................................1
Hyperlink.....................................................................................................................1
Illustrations..................................................................................................................1
2GENERAL INTRODUCTION ......................................................................................2
MAXIPRO MP808 TABLET.................................................................................................2
Function Description...................................................................................................2
Power Sources ...........................................................................................................3
Technical Specifications .............................................................................................4
OTHER ACCESSORIES........................................................................................................5
Main Cable..................................................................................................................5
Other Accessories.......................................................................................................5
3GETTING STARTED..................................................................................................6
POWERING UP..................................................................................................................6
Application Buttons.....................................................................................................7
Locator and Navigation Buttons..................................................................................9
System Status Icons...................................................................................................9
POWERING DOWN............................................................................................................10
Reboot System .........................................................................................................10
4DIAGNOSTICS.........................................................................................................11
GETTING STARTED ..........................................................................................................11
Vehicle Menu Layout ................................................................................................11
Top Toolbar Buttons .................................................................................................11
VEHICLE IDENTIFICATION ..................................................................................................12
Auto VIN Scan ..........................................................................................................12
Manual VIN Input......................................................................................................14
Automatic Selection..................................................................................................15
Manual Selection ......................................................................................................15
NAVIGATION....................................................................................................................15
Diagnostics Screen Layout.......................................................................................16
Screen Messages.....................................................................................................18
Making Selections.....................................................................................................18
MAIN MENU ....................................................................................................................18
DIAGNOSIS......................................................................................................................19
Auto Scan.................................................................................................................19

v
Control Unit...............................................................................................................21
HOT FUNCTIONS..............................................................................................................30
Oil Reset Service......................................................................................................30
Tire Pressure Monitor System (TPMS) Service ........................................................30
Electric Parking Brake (EPB) Service.......................................................................31
ABS/SRS Services....................................................................................................31
Steering Angle Sensor (SAS) Service.......................................................................31
DPF Regeneration Service.......................................................................................31
GENERIC OBDII OPERATIONS ..........................................................................................31
General Procedure....................................................................................................31
Function Descriptions ...............................................................................................33
EXITING DIAGNOSTICS......................................................................................................36
5MAXIFIX ...................................................................................................................37
NAVIGATION....................................................................................................................37
The Header...............................................................................................................38
Select Vehicle Button................................................................................................38
Terminology..............................................................................................................38
OPERATIONS...................................................................................................................39
Home........................................................................................................................40
Search Fix.................................................................................................................40
Ask............................................................................................................................40
My MaxiFix................................................................................................................41
My Messages............................................................................................................42
Support.....................................................................................................................44
6SHOP MANAGER.....................................................................................................45
VEHICLE HISTORY............................................................................................................46
Historical Test Record...............................................................................................46
WORKSHOP INFORMATION................................................................................................48
CUSTOMER MANAGER......................................................................................................48
7DATA MANAGER.....................................................................................................50
OPERATIONS...................................................................................................................50
Image........................................................................................................................50
Report.......................................................................................................................52
PDF...........................................................................................................................53
Review Data .............................................................................................................53
Apps Uninstall...........................................................................................................54

vi
Vehicle Management................................................................................................55
Data Logging ............................................................................................................55
8SETTINGS................................................................................................................56
UNIT...............................................................................................................................56
LANGUAGE......................................................................................................................56
PRINTING SETTINGS.........................................................................................................57
Printing via APP........................................................................................................57
Printing via PC..........................................................................................................57
REPORT SETTINGS ..........................................................................................................58
MULTITASK .....................................................................................................................58
FIRMWARE UPGRADE.......................................................................................................58
AUTO UPDATE.................................................................................................................58
CAR ORDER....................................................................................................................59
SYSTEM SETTINGS...........................................................................................................59
ABOUT............................................................................................................................60
9UPDATE ...................................................................................................................61
10 SUPPORT ................................................................................................................63
PRODUCT REGISTRATION .................................................................................................63
SUPPORT SCREEN LAYOUT...............................................................................................64
MY ACCOUNT..................................................................................................................64
Personal Info.............................................................................................................64
Update Info...............................................................................................................65
Service Info...............................................................................................................65
COMMUNITIES .................................................................................................................65
User Profile...............................................................................................................66
DATA LOGGING................................................................................................................66
TRAINING........................................................................................................................66
FAQ ..............................................................................................................................67
11 ACADEMY................................................................................................................68
12 REMOTE DESK........................................................................................................69
13 QUICK LINK .............................................................................................................70
14 FUNCTION VIEWER................................................................................................71
15 DIGITAL INSPECTION.............................................................................................73
ADDITIONAL ACCESSORIES ...............................................................................................73
Inspection Camera....................................................................................................74
IMAGER HEAD ACCESSORIES ............................................................................................74

vii
ACCESSORY ASSEMBLY ...................................................................................................75
TECHNICAL SPECIFICATIONS.............................................................................................77
OPERATIONS...................................................................................................................77
16 MAINTENANCE AND SERVICE...............................................................................79
MAINTENANCE INSTRUCTIONS...........................................................................................79
TROUBLESHOOTING CHECKLIST ........................................................................................79
ABOUT BATTERY USAGE ..................................................................................................80
SERVICE PROCEDURES ....................................................................................................81
Technical Support.....................................................................................................81
Repair Service ..........................................................................................................82
Other Services..........................................................................................................82
17 COMPLIANCE INFORMATION................................................................................83
18 WARRANTY .............................................................................................................85

1
1 Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional equipment
that are not included in your system. Contact your sales representative for availability of
other modules and optional tools or accessories.
Conventions
The following conventions are used.
Bold Text
Bold text is used to highlight selectable items such as buttons and menu options.
Example:
Tap OK.
Notes and Important Messages
Notes
A NOTE provides helpful information such as additional explanations, tips, and
comments.
Important
IMPORTANT indicates a situation which, if not avoided, may result in damage to the test
equipment or vehicle.
Hyperlink
Hyperlinks are available in electronic documents. Blue italic text indicates a selectable
hyperlink and blue underlined text indicates a website link or an email address link.
Illustrations
Illustrations used in this manual are samples, the actual testing screen may vary for each
vehicle being tested. Observe the menu titles and on-screen instructions to make correct
option selection.

2
2 General Introduction
Based on the Android operating system, MaxiPRO MP808 is featured with an extensive
coverage of OE-level diagnostics. Installed with a fast quad-core processor, MP808
offers maximum convenience and efficiency for your diagnosis and analysis. Theintuitive
user interface makes using the device effortless through a 7-inch LCD touchscreen that
displays at 1024 x 600 quality.
This manual describes the construction and operation of the device and how it works to
deliver diagnostic solutions.
MaxiPRO MP808 Tablet
Function Description
Figure 2-1 MaxiPRO MP808, Front View
1. 7.0”LCD Capacitive Touchscreen
2. Ambient Light Sensor —detects ambient brightness.
3. Power LED —indicates battery level & charging or system status.
4. Vehicle Communication LED —flashes green when the tablet is
communicating/linking with the vehicle’s systems.
The power LED displays green, yellow or red depending on power level and operating
state.
A. Green
Illuminates green when the tablet is charging and the battery level is above 90%.
Illuminates green when the tablet is powered on and the battery level is above
15%.

3
B. Yellow
Illuminates yellow when the tablet is chargingand the battery level is below90%.
C. Red
Illuminates red when the tablet is powered on and the battery level is below 15%.
Figure 2-2 MaxiPRO MP808, Back View
5. Collapsible Stand —extends from the back to allow hands-free viewing of the tablet.
6. Heat Sink
7. Built-in Battery
Figure 2-3 MaxiPRO MP808, Top View
8. Mini USB OTG Port
9. Micro SD Card Slot —holds the micro SD card.
10. DB15-Pin Port —connects the main cable.
11. USB Port
12. Lock/Power Button —turns the device on & off with long press, or locks the screen
with short press.
Power Sources
The tablet can receive power from any of the following sources:
Internal Battery Pack
Vehicle Power
External Power Supply

4
Internal Battery Pack
The tablet can be powered with the internal rechargeable battery, which if fully charged
can provide sufficient power for about 4.5 hours of continuous operation.
Vehicle Power
When the tablet is connected to the test vehicle via the main cable, the tablet
automatically receives power from the vehicle.
External Power Supply
The tablet can be powered from a wall socket using the mini USB cable and the USB
external power adapter. The external power supply also charges the internal battery pack.
Technical Specifications
Table 2-1 Specifications
Item
Description
Recommended Use
Indoor
Operating System
AndroidTM 4.4.4
Processor
Cortex-A9 processor (1.5 GHz)
Memory
64 GB
Display
7-inch LCD capacitive touchscreen with
1024x600 resolution
Connectivity
Mini USB 2.0
USB 2.0
Wi-Fi
Micro SD card (supports up to 32 GB)
Sensors
Ambient light sensor for brightness auto
changing
Audio Output
Buzzer
Power and Battery
3.7 V/5000 mAh lithium-polymer battery
Charges via 5 V DC power supply
Tested Battery Life
Around 4.5 hours of continuous use
Battery Charging Input
5 V/1.5 A

5
Item
Description
Power Consumption
500 mA (LCD on with default brightness, Wi-Fi
on) @3.7 V
Operating Temp.
0 to 50 °C (32 to 122 °F)
Storage Temp.
-10 to 60 °C (14 to 140 °F)
Operating Humidity
5 % to 95 % non-condensing
Dimensions (W x H x D)
237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm
(1.4”)
Net Weight
788 g (1.74 lbs.)
Supported Automotive
Protocols
ISO9141-2, ISO14230-2,ISO15765, K/L-Line,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, ISO11898(Highspeed, Middlespeed,
Lowspeed and Singlewire CAN,fault-tolerant
CAN), SAE J2610,GM UART,UART Echo Byte
Protocol, Honda Diag-H Protocol, TP2.0, TP1.6
Other Accessories
Main Cable
The Main Cable connects the tablet to the vehicle’s data link connector (DLC).
Other Accessories
Mini USB Cable
Connects the tablet to the PC or USB external power
adapter.
USB External Power Adapter
Together with the mini USB cable, connects the tablet
to the external DC power port for power supply.
Figure 2-4 Main Cable

6
3 Getting Started
Ensure the tablet is sufficiently charged or is connected to the external power supply
(see Power Sources).
NOTE
The images and illustrations depicted in this manual may differ slightly from the actual
ones.
Powering Up
Long press the Lock/Power button on the top right of the tablet to power on the unit. The
power LED light will illuminate green. The system boots up and displays the lock screen.
Slide the Lock icon to the left to enter the MaxiPRO Job Menu or slide to the right to
unlock.
1. Application Buttons
2. Locator and Navigation Buttons
3. Status Icons
Figure 3-1 Sample MaxiPRO MP808 Job Menu

7
NOTE
The tablet screen is locked by default when first powered on. It is recommended to lock
the screen to protect the information in the system and reduce the power consumption.
The touch screen navigation is menu driven, enabling quick access to functions and
features by tapping on options headings and answering dialog windows. Detailed
descriptions of the menu structures are found in application chapters.
Application Buttons
Descriptions of the tool applications are displayed in the table below.
Table 3-1 Applications
Button
Name
Description
Diagnostics
Accesses diagnostic function menu. See
Diagnostics for details.
MaxiFix
Launches the MaxiFix platform which provides the
most compatible and abundant repair techniques
and diagnostics database. See MaxiFix for details.
Shop
Manager
Accesses Shop manager database to store
workshop, customer information and vehicle test
history. See Shop Manager for details.
Data
Manager
Accesses the organization system for saved data
files. See Data Manager for details.
Settings
Accesses MaxiPRO system settings menu and
general tablet menu. See Settings for details.
Update
Checks for the latest update available for the
MaxiPRO system and performs updates. See
Update for details.
Support
Launches the Support platform which synchronizes
Autel’s on-line service base station with the
MaxiPRO tablet. See Support for details.

8
Button
Name
Description
Academy
Accesses technical tutorials and training articles
about the device or vehicle diagnostic techniques.
See Academy for details.
Remote
Desk
Configures the unit to receive remote support using
the TeamViewer application program. See Remote
Desk for details.
Quick Link
Provides associated website bookmarks to allow
quick access to product update, service, support
and other information. See Quick Link for details.
Function
Viewer
Provides quick search for the supported functions
and vehicles of Autel diagnostic tools . See Function
Viewer for details .
Digital
Inspection
Configures the unit to operate as a video scope
device by connecting to an Imager head cable for
close vehicle inspections. See Digital Inspection.

9
Locator and Navigation Buttons
Operations of the Navigation buttons at the bottom of the screen are described in the
table below:
Table 3-2 Locator and Navigation Buttons
Button
Name
Description
Locator
Indicates the location of the screen. Swipe the
screen left or right to view the previous or next
screen.
Back
Returns to the previous screen.
Android Home
Returns to Android System’s Home screen.
Recent Apps
Displays a list of applications that are currently
in use. Tap an App icon to launch. To remove
an app, swipe it to the top or bottom.
Chrome
Launches the Android built-in browser.
Screenshot
Takes a screenshot when you want to save the
displayed information.
MaxiPRO
Home
Returns to MaxiPRO Job Menu from other
Android applications.
Diagnostic
Shortcut
Returns to the Diagnostic screen from other
operations.
System Status Icons
As the tablet is working with the Android operating system, you may refer to Android
documents for more information.
By tapping the bottom right corner, a Shortcuts Panel will be displayed, on which you are
allowed to set various system settings of the tablet. Operations of each button on the
panel are described in the table below.

10
NOTE
The shortcuts buttons will be highlighted when enabled and dimmed when disabled.
Table 3-3 Shortcuts Panel Buttons
Button
Name
Description
Calculator
Launches calculator when pressed.
Clock
Launches clock when pressed.
Wi-Fi
Enables/disables Wi-Fi when pressed.
Airplane
Mode
Enables/disables Airplane Mode when
pressed.
System
Settings
Launches the Android System Settings
screen when pressed.
Powering Down
All vehicle communications must be terminated before shutting down the tablet. A
warning message displays if you attempt to shut down the tablet when it is
communicating with the vehicle. Forcing a shut-down while communicating may lead to
ECM problems on some vehicles. Please exit the Diagnostics application before
powering down.
To power down the tablet
1. Long press the Lock/Power button.
2. Tap Power off option.
3. Tap OK and the tablet will turn off in a few seconds.
Reboot System
In case of system crash, long press the Lock/Power button and tap Reboot option to
reboot the system.

11
4 Diagnostics
The Diagnostics application can retrieve ECU information, read & erase DTCs, and view
live data. The Diagnostics application can access the electronic control unit (ECU) for
various vehicle control systems including engine, transmission, antilock brake system
(ABS), airbag system (SRS).
Getting Started
Ensure a communication link is established between the test vehicle and the tablet via
the main cable.
Vehicle Menu Layout
When the tablet is properly connected to the vehicle, the platform is ready to start vehicle
diagnosis. Tap on the Diagnostics application button on the MaxiPRO MP808 Job Menu
to access the Vehicle menu.
1. Top Toolbar Buttons
2. Vehicle Manufacturer Buttons
Top Toolbar Buttons
The operations of the toolbar buttons at the top of the screen are listed and described in
the table below:
Figure 4-1 Sample Vehicle Menu

12
Table 4-1 Top Toolbar Buttons
Button
Name
Description
Home
Returns to the MaxiPRO Job Menu.
VIN Scan
Provides a fast way to identify the test vehicle.
See Auto VIN Scan for details.
All
Displays all the vehicle makes in the vehicle
menu.
History
Displays the stored test vehicle history records.
See Vehicle History.
USA
Displays the USA vehicle menu.
European
Displays the European vehicle menu.
Asia
Displays the Asian vehicle menu.
Search
Searches for a specific vehicle make.
Cancel
Exits the search screen or cancels an operation.
Vehicle Manufacturer Buttons
To begin, select the manufacture button of the test vehicle, followed by the vehicle model
and year.
Vehicle Identification
The MaxiPRO diagnostic system supports four methods for Vehicle Identification.
1. Auto VIN Scan
2. Manual VIN Input
3. Automatic Selection
4. Manual Selection
Auto VIN Scan
The MaxiPRO diagnostic system features the latest VIN-based Auto VIN Scan function
to identify vehicles and scan all the diagnosable ECUs and run diagnostics on the
selected system. This function is compatible with 2006 and newer vehicles.
To perform Auto VIN Scan
1. Tap the Diagnostics application button from the MaxiPRO Job Menu. The
Vehicle Menu displays.

13
2. Tap the VIN Scan button on the top toolbar to open the dropdown list.
3. Select Auto Detect. Once the test vehicle is identified, the screen will display
the vehicle VIN. Tap OK at the bottom right to confirm the vehicle VIN. If the VIN
does not match with the test vehicle’s VIN, enter VIN manually or tap Read to
acquire VIN again.
4. Tap Yes to confirm the vehicle profile or No if the information is not correct.
Figure 4-2 Sample Auto VIN Screen
Figure 4-4 Sample Vehicle Profile Screen
Figure 4-3 Sample Auto Detect Screen
