Automatic Technology SecuraLift GDO-7V1 Quick start guide

GDO-7V1 SecuraLift®
Overhead Garage Door Opener
INSTALLATION INSTRUCTIONS | OWNERS COPY

2GDO-7V1 SecuraLift® Owner Installation Instructions
WARNING: It is vital for the safety of persons to follow all
instructions. Failure to comply with the installation instructions
and the safety warnings may result in serious personal injury
and/or property and remote control opener damage. Please
save these instructions for future reference.
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all
conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of
an Automatic Technology Australia Pty Ltd Garage Door Opener. Automatic Technology Australia Pty Ltd hereby further
expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person as a
result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener
in accordance with these installation instructions.

Owner Installation Instructions GDO-7V1 SecuraLift® 3
Safety Precautions 4
Opener Features 6
Operating Controls 6
Kit Contents 10
Installation 11
Tube Pipe Assembly 11
Determine Door Type 12
Mounting - Track Type Door 12
Using inbuilt antivibration brackets 14
Mounting - Spring Loaded Door 15
Mounting Door Bracket & Arms 16
Easy Access Transmitter 16
Programming the Opener 17
Setting Travel Limits - Control Pane 17
Setting Travel Limits - Transmitter 18
Safety Obstruction Force Test 19
Coding Transmitters 20
Door 20
Courtesy Light 20
Vacation Mode 20
Pet Mode 20
Storing Transmitter From Remote Location 21
Erasing Transmitter Codes 21
Accessories 22
Photo Electric Beam 22
Auto-Close 22
Final Set Up 23
Courtesy Light Time 23
Pet Mode Door Height 23
Transmitter Wall Bracket 23
Re-Initializing 23
Parameters 24
Door Status Indicators 24
System Specification 26
Factory Default Settings 26
Trouble Shooting Guide 28
Maintenance Record 29
Parts List 30
Warranty 32
GDO-8V1 SecuraLift®
Overhead Garage Door Opener

4GDO-7V1 SecuraLift® Owner Installation Instructions
CAUTION: If your garage has no pedestrian entrance door, an emergency access device should be installed.
This accessory allows manual operation of the garage door from outside in case of power failure.
For ADDITIONAL SAFETY protection we STRONGLY recommend the fitting of a Photo Electric
Beam. In most countries Photo Electric Beams are mandatory on all garage doors fitted with
automatic openers. For a small additional outlay ATA recommends that Photo Electric Beams be
installed with the automatic opener ensuring additional safety and peace of mind.
DO NOT operate the garage door opener unless the garage door is in full view and free
from objects such as cars and children/people. Make sure that the door has finished moving
before entering or leaving the garage.
DO NOT operate the garage door opener when children/persons are near the door.
Children must be supervised near the garage door at all times when the door opener
is in use. serious personal injury and/or property damage can result from failure to
follow this warning.
DO NOT allow children to operate the garage door opener. serious personal
injury and/or property damage can result from failure to follow this warning.
Regularly check to make sure that the safety obstruction force is working
correctly, and is tested (by placing a 50mm high object on the floor)
and set as per the Installation Instructions Manual. Failure to follow the
manual could result in serious personal injury and/or property damage.
This test must be repeated at regular intervals and the necessary
adjustments made as required.
DO NOT disengage the door opener to manual operation with
children/persons or any other objects including motor vehicles
within the doorway.
The door opener is not intended for use by young children
or infirm persons without adequate supervision. Children
should be supervised to ensure that they do not play
with the remote transmitters or the opener.
Keep hands and loose clothing clear of the door
and door opener at all times.
The unit should be installed so that it is protected
from the elements. It should not be exposed
WARNING: It is vital for the safety of persons to follow
all instructions. Failure to comply with the following
Safety Rules may result in serious personal injury and/or
property damage.
Important safety instructions

Owner Installation Instructions GDO-7V1 SecuraLift® 5
to water or rain. It is not to be immersed in water or sprayed directly by a hose or other water carrying device.
The garage door must be well balanced. Sticking or binding doors must be repaired by a qualified garage
door installer prior to installation of the opener.
Frequently examine the installation, in particular cables, springs and mountings for signs of wear,
damage or imbalance. DO NOT use if repair or adjustment is needed since a fault in the installation
or an incorrectly balanced door may cause injury. DO NOT attempt to repair the door yourself as
hardware is under extreme tension.
Remove or disengage all garage door locks and mechanisms prior to installation of the opener.
Connect the garage door opener to a properly earthed general purpose 240V mains power
outlet installed by a qualified electrical contractor.
Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the garage
door opener.
When using auto close mode, a photo electric beam must be fitted correctly
and tested for operation at regular intervals. extreme caution is recommended
when using auto close mode. all safety rules must be followed.
In order for the garage door opener to sense an object obstructing the
door way, some force must be exerted on the object. As a result the
object, door and/or person may suffer damage or injury.
If the power supply cord is damaged, it must be replaced by an ATA
service agent or suitably qualified person.
Make sure that the door is fully open before driving in or out of
the garage and fully closed before leaving the driveway.
Make sure that remote controls are kept out of reach of
children.
Install the wall switch or wall mounted
transmitter in a location where it is out of
reach of children and the garage door is
visible.
Important safety instructions

6GDO-7V1 SecuraLift® Owner Installation Instructions
Operation
To open or close the door simply press the hand held transmitter, the wall mounted
transmitter, or optional wall switch for two seconds. During an open or close cycle
the door can be stopped by pressing the button while the door is in motion. The
next actuation will move the door in the opposite direction.
Hopping code
Every time a transmission is made from the remote transmitter a new security
code is generated. The number of possible code combinations is over 4.29
billion. This greatly enhances the security of the system. Code “grabbing” is made
a thing of the past.
S-alps (semi automatic limits positioning system)
The ALPS system does away with manual adjustment of the doors’ limits position using
mechanical parts, such as cams and micro switches. During installation the hand held
transmitter can be programmed to set the door limits positions.
Anti travel electronic brakes
opener has anti travel electronic brake mechanism which ensure the opener stops the door at
exact location
ISS (intelligent safety obstruction system)
While the door is performing a close cycle, should it hit an obstacle or be restricted in some manner, it will
automatically reverse. The amount of force the door should encounter before reversing is automatically
adjusted by the doors control system during the initial installation of the automatic door opener. The door
will also stop if restricted whilst opening. The Safety Obstruction Force should be checked at least once a
month. See installation manual for instructions.
Security code store
The SecuraLift® Garage Door Opener uses state of the art technology in storing your selected transmitter
security code. Up to 24 different transmitters can be stored in the openers memory.
Features
Thank you for purchasing the ATA SecuraLift® Automatic
Garage Door Opener. This opener is designed to suit
sectional overhead and one piece tilt up doors. The
components and materials used in this opener are of
the latest technology and highest quality. Listed
below are some of the many features.

Owner Installation Instructions GDO-7V1 SecuraLift® 7
Over load indicator
When the maximum opening and closing capacity of the opener is exceeded the red and
green Limits LEDs flash alternately to indicate that an overload has occurred.
Auto courtesy light
The courtesy light on the opener comes on automatically whenever the door is
activated. The light can also be switched on and off without operating the door.
This is done by pressing the button on any hand held or wall mounted transmitter
which has been stored with the light code.The light will stay on for approximately
three minutes then switch off. This time is also adjustable.
Anti vibration brackets
opener has inbuilt antivibration brackets hang the opener by using anti vibration
brackets where noise is the problem.
Vacation mode
A hand held transmitter can be programmed to lock and unlock all other
transmitters that have been programmed into the openers’ memory. The vacation
mode can be used when the door is left idle for long periods of time.
Pet (pedestrian) mode
The hand held transmitter can be programmed to open the door partially so that the
family pet can enter and exit the garage at any time. You may also wish to open the
door to a height suitable only for pedestrian access. The door opening position is also
programmable.
Auto close mode
The opener can be programmed to automatically close after an open cycle. The auto close time
is adjustable. It is compulsory to install a Photo Electric Beam if this mode is selected, otherwise the
door may cause personal injury or damage to property.
Photo electric beam (optional)
The opener has an input for a photo electric beam to be connected for extra safety protection and use of the
auto close mode.
Manual operation
The opener is equipped with a unique manual disengaging device. If the power to the opener is disrupted for
any reason the door can be put into manual mode by pulling down on the string handle on an angle towards
the door. This will allow you to manually open or close the door. To re-engage the opener pull the string
handle away from the door.
Features

8GDO-7V1 SecuraLift® Owner Installation Instructions
Operating controls
P. E. Shunt. The shunt has to be removed when connecting a Photo Electric Beam.
NOTE: P.E. Shunt must not be removed otherwise the opener will not function correctly. Remove only
when a P.E beam is to be connected. PROG INPUT is used for the connection of the ATA Handheld
Programmer for the purpose of editing control and receiver functions.
Terminal Block. 24V PWR is used to power devices such as photo electric beams.
PE (Input) for photo electric beam for safety and auto-close function.
LGT (Input) allow hard wired external trigger for the opener’s courtesy light.
O/S/C INPUT is used for the connection of a wired switch (momentary contact). This switch can then be
used to open, stop or close the door. Install the wall switch in a location where the switch is out of reach
of children and the garage door is visible.
Set button (yellow) is used during the installation phase together with the Open and Close buttons to set
the door limit positions. The Set button is also used to re-initialize the Opener.
Operate button (Yellow) is used during installation to test the open, stop and close cycles for the opener.
The opener has to be initialized by the Reset button before the O/S/C button becomes operable.
Plus (+) button (green) is used during installation to help set the open limit position. Pressing and
holding this button will move the door in the open direction. Movement stops when the button is
released.
NOTE: The open safety obstruction detection is inoperable whenever the Open or Close Drive button is
used to move door.
Open limit led (green) the led is very helpful during installation. It illuminates and flashes when the door
is opening and remains steady on when the open limit position has been reached.
Force margin set Button The obstruction force pressure is set automatically by the opener during
installation. The pressure can be adjusted manually using the Force Margin Set button (White). Holding
the Force Margin Set button and pressing the Plus (+) or Minus (-) button will increase or decrease the
amount of force. The Force Margin Set is only ever used if other environmental factors (wind, etc.) effect
the operations of the door/opener.
Light code button (white) is used for storing or erasing the transmitter button (code) you wish to use to
switch the courtesy light on the opener on or off.
Coding led (red) light flashes when a code is being stored or when a transmitter button is pressed.
Door code button (blue) is used for storing or erasing the transmitter button you wish to use to
command the door to open, stop or close.
Door status LED (Yellow)
Minus (-) button (red) is used during installation to help set the close limit position. Pressing and holding
this button will move the door in the close direction. Movement stops when the button is released.
NOTE: The close safety obstruction detection is inoperable whenever the Open or Close Drive button is
used to move door.
Close limit LED (red) the led is very helpful during installation. It illuminates and flashes when the door is
closing and remains steady on when the close limit position has been reached.
01
02
03
04
05
06
07
08
09
10
11
12
13

Owner Installation Instructions GDO-7V1 SecuraLift® 9
01 02
03 04 05 06 07
08
09
10
11
Operating controls
Datum adjust screw is used during limits set up to indicate the mid point of the door’s travel.
Auto close time button (White) is used to adjust the auto close time. While holding in the auto close
button and then pressing the open button the time is increased. Each press will increase the time by 5
seconds. Pressing the close button will decrease the time.
Engage/disengagement cord when pulled down and released this will select manual mode on the
opener, particularly when there is a power failure. Pulling down and again releasing will select automatic
mode on the opener. The length of the string is adjustable.
Easy access transmitter The “manual release” engage/disengagement handle has within its housing a
14
15
16
17
12 13
14
15
16

10 GDO-7V1 SecuraLift® Owner Installation Instructions
Package contents
GDO-7 Securalift® drive unit 1
Securacode® key ring transmitter pack 1
Pack includes two keyring transmitters two batteries
and one wall mount bracket for ptx4 transmitter
Easy access transmitter - EAT-1 (not available some models) 1
Tubes 5
Tube inserts 4
Pipe support assembly 1
Chain 1
Shuttle assembly 1
Door attachment arms 2
Accessory pack 1
Installation manual 1

Owner Installation Instructions GDO-7V1 SecuraLift® 11
Tube/pipe assembly
Check operation of door before beginning
the installation of the securalift®� automatic
opener check the operation of the door.
Step 1.
Slide shuttle assembly onto tube (one piece only) and
locate it in approximately half way position.
PLEASE NOTE: Arrow on shuttle must point towards
garage door. To assemble the rest of the tubes, always
slide short insert tube half way into the long tube, then
slide other tube onto remaining portion of insert tubes.
Continue this process with remaining tube until desired
length is achieved.
Step 2.
The opener is supplied with an 8 teeth drive sprocket
on the drive unit. If the opener is to be fitted to a
one piece door without track, exchange the 8 teeth
sprocket on drive unit, with a 7 teeth drive sprocket
available as an option from Automatic Technology.
Step 3.
Attach one end of chain to chain index screw, nearer
to drive unit, using one joint link. (Fig. 1). Proceed
to wrap chain around drive unit sprocket and chain
spreader, then follow along the pipe to the idler wheel
on support pipe assembly, finally attach to the other
end of the chain index screw.
NOTE: Make certain that the teeth of the drive
sprocket are engaged in the chain and that the chain is
not twisted. Make sure that the chain is engaged in the
chain spreader and the idle wheel on the support pipe
assembly.
Step 4.
Disengage trolley from chain index by swinging lever
downward (Fig. 2), then slide trolley away from chain
index along pipe track. Loosen locking nuts on chain
index screws. To tighten chain, turn chain index in
anticlockwise direction, looking from support pipe
assembly to drive unit. Do not over-tighten chain as
it has to sag 6-12mm. Check before locking screw
with locking nuts that chain is not twisted. When the
tension is finalized, tighten lock nuts at both ends of
chain index.
IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION
Warning: Incorrect installation can lead to severe injury.
Follow ALL installation instructions.
01
fig
02
fig
02
fig
Second
chain joint link
Locking nuts
a
First chain
joint link
Shuttle
assembly
Disengaged
position
Engaged
position

12 GDO-7V1 SecuraLift® Owner Installation Instructions
Determine the door type
Determine which type of garage door you have as
illustrated below. (Fig. 3 -5). �
• For a sectional (panel) door on tracks (Fig. 3) proceed
with the installation from Step 5. �
• For a one piece door on tracks (Fig. 4) proceed with
the installation from Step 5. � For a one piece door
without tracks (on springs) (Fig. 5) proceed with the
installation from Step 9.
- 9 -
©Copyright 2006 Automatic Technology
03
fig
04
fig
05
fig
Door
Sectional door with track
Door
Track
One piece door with
track
One piece door
without track

Owner Installation Instructions GDO-7V1 SecuraLift® 13
Mounting on a track type door
Step 5.
Open the door and find the highest point of travel of
the top door panel. Using a level, transfer this height to
the wall above the floor (Fig. 6) and mark a line 60mm
above it. Determine the centre of the location on the
wall above and on top of the door. Then draw two (2)
lines 21.5mm on each side of the door centre. (Fig. 7).
Step 6.
The intersection of line at 21.5mm from door centre
and line 60mm above highest point of travel are centre
points, where holes for mounting of wall bracket should
be drilled. (Fig. 7)
If the wall bracket is mounted onto concrete or brick
wall, use 8mm or 5/16” loxins or dynabolts. If mounting
onto wooden lintel or beam, use wood screw #20 or
equivalent minimum 50mm long.
WARNING: make sure concrete, brick wall or
timber lintels are solid and sound so as to
form a secure mounting platform.
Step 7.
When the wall bracket is firmly secured in its proper
position, attach the support pipe assembly to wall
bracket with 90 mm long clevis pin and secure with
supplied spring clip, (Fig. 8) leaving drive unit in its
packing box for protection during installation.
Step 8a. (Method one)
Raise the drive unit from the packing box and support
it in a horizontal position with a step ladder, then open
the garage door. Rest the opener on the open door
and use a scrap piece of wood to bring it to horizontal
level. Line up the track with the centre line on top
of the door. Secure to the ceiling above drive unit
mounting holes, with perforated angle (not supplied).
A representative mounting is shown. (Fig. 9)
Connect angle and drive unit with 2 flat perforated
strips of angle (not supplied) with M8 x 20mm screws,
nuts and washer. Strips should not extend more than
18mm below centre of drive unit mounting holes.
(Fig. 9).
WARNING: the opener must be securely fastened
to a structural support of the garage. Failure
to fasten the operator correctly will lead
to possible opener failure causing serious
personal injury and/or property damage.
06
fig
08
fig
09
fig
07
fig
Track
Door
Door
Track
Drilled holes
Pin
Snap
pin 12
Support
pipe assembly

14 GDO-7V1 SecuraLift® Owner Installation Instructions
Step 8b. (Method two)
Raise the drive unit from the packing box and support
it in a horizontal position with a step ladder, then open
the garage door. Rest the opener on the open door and
use a scrap piece of wood to bring it to horizontal level.
Line up the track with the centre line on top of the door.
Secure to the ceiling above drive unit mounting holes,
with perforated angle (not supplied). A representative
mounting is shown. (Fig. 9) Connect angle and vibration
brackets on drive units 2 flat perforated strips of angle
(not supplied) Use the M6 X 16 Flanged Head Bolts (2)
and M6 Flanged Head Nuts (2) and secure the hanger
straps to the anti vibration brackets as per the diagrams .
The brackets may have to be pushed lightly on an angle
to allow the bolts to be fitted. Strips should not extend
more than 18mm below centre of drive unit mounting
holes. (Fig. 9).
IMPORTANT: Make sure that the head of the M6 bolt
is facing the outside edge of the opener so that the
threaded part of the bolt does not come into contact
with the right angled return running along the edge
of the metal chassis..
WARNING: the opener must be securely fastened
to a structural support of the garage. Failure
to fasten the operator correctly will lead
to possible opener failure causing serious
personal injury and/or property damage
Using anti vibration brackets

Owner Installation Instructions GDO-7V1 SecuraLift® 15
Step 9.
Determine the centre of the door and mark this
location on the wall above and on top of the door.
Then draw two (2) lines 21.5mm on each side of the
door. (Fig. 10).
WARNING: make sure concrete, brick wall or
timber lintels are solid and sound so as to
form a secure mounting platform.
Step 10.
Raise the door to open position. Rest the opener on
the top edge of the door with end of the pipe/tube
against the header wall and drive unit support level
with the lowest point of the open door. (Fig. 11).
NOTE: Do not slide opener tube/pipe on face of the
door when it is open.
Secure the opener to the ceiling above drive unit
mounting holes, with perforated angle (not supplied).
A representative mounting is shown. (Fig. 9) Connect
angle and drive unit with 2 flat perforated strips of
angle (not supplied) with M8 x 20mm screws, nuts and
washer. Strips should not extend more than 18mm
below centre of drive unit mounting holes. (Fig. 9).
Do not lock screws at this stage.
Step 11.
Close the door slowly. The opener pipe/tube will be
elevated by the top edge of the door as it moves.
Stop the door when it is at its highest point of travel.
(Fig. 12) Allow 25mm additional height for clearance
between the door and the track. Support pipe / tube in
this position and the close the door. (Fig. 12) This will
be the height to mount the wall bracket. Top of door
must not touch tube.
WARNING: the opener must be securely fastened
to a structural support of the garage. Failure
to fasten the operator correctly will lead
to possible opener failure causing serious
personal injury and/or property damage.
Step 12.
With the centre point of the door located, mark a line
through the centre of the wall bracket onto the header
wall (above the door). Using the bracket as a template
mark a minimum of two holes and drill with appropriate
size bit. If necessary the wall bracket can be anchored
using more than two holes for a more secure fitting.
If the wall bracket is mounted onto concrete or brick
wall, use M8 or 5/16” loxins or dynabolts. If mounted
onto wooden lintel or beam, use wood screws #20
or equivalent, minimum 50mm long. Attach the wall
bracket to the support pipe assembly with 90mm long
clevis pin (Fig. 13) and securely spring clip.
Mounting on a spring loaded door
10
fig
12
fig
13
fig
11
fig
Centre of Door
Step ladder
Tube
25mm highest
point
of door
travel
Door
Step ladder
Pipe support assembly

16 GDO-7V1 SecuraLift® Owner Installation Instructions
Step 13.
The door bracket comes in two parts. The bottom plate
with two mounting holes is used on its own for any one
piece doors. The top plate is placed over the bottom
plate and uses 4 mounting holes for extra strength. This
is used on sectional doors. (See Fig. 14). Mount the
door bracket to the centre line of the door using M6 or
equivalent screws (not supplied) Alternatively it can be
welded on steel doors.
NOTE: As various types of doors exist, if in doubt about
the strength of the door, reinforcement may need to be
added to the frame or panel where necessary. Damage
to the door panel may occur if the bracket is installed
incorrectly on a panel with insufficient strength. The
door opener warranty does not cover damage caused
by the opener to the door and/or door panel.
Step 14.
Assemble bent and straight arm with screws, and hex
nuts supplied in accessory pack. (Fig. 15) Then connect
assembled arm to the door bracket and the shuttle by
clevis pin and spring clip. shuttle must be in disengage
position. use the bend & straight arm. If installing on a
door with bad wave action, lengthening the arm even
further will assist the door operation by reducing the
wave action.
The easy access transmitter
The Easy Access Transmitter is prepared ready for use
with the battery pre-installed. Before the transmitter can
be operational, the Transmitter Code has to be stored
into the openers memory. To store the code please
follow the instructions in Step 18.1 on page 20.
Removing the cover to replace battery
1. Rotate the cover Clockwise to ‘CLOSE’
2. Rotate the cover Anti-clockwise to ‘OPEN’
Removing the battery
(Battery Type: 3V Lithium Battery CR1220). Use a non
- metallic object (e.g Pen) to remove the battery.
(see Fig. 18)
WARNING: Metallic objects used to remove the
battery may DAMAGE the circuit board or the
battery.
Replacing the battery
Place one side of the battery into the battery holder,
then press the battery down firmly until it clicks into a
flat position.
NOTE: The length of the manual release cord is user
adjustable simply by sliding the plastic toggle along the
cord to achieve the desired length. Adjust the length of
the cord so that it can be easily reached by an adult of
average height (ie. less than 1.8m tall).
Mounting door bracket and arms
14
fig
16
fig
18
fig
15
fig
17

Owner Installation Instructions GDO-7V1 SecuraLift® 17
Step 15. Setting travel limits positions
method one: via the control panel
IMPORTANT NOTE: The OPERATE button
will not function until the open and close limits
positions are set.
15.1. Setting datum position
1. Move the door manually to engage the
shuttleassembly onto the chain index.
2. Turn power on - the Close Limit LED should
beflashing.
3. Press and hold Minus (-) or Plus (+) button to
movethe door to half way open position.
4. Using a small blade screw driver turn the
datumadjust screw slowly until the yellow status
LED just illuminates.
NOTE: If the status LED is already illuminated when
the door is half way up then turn the datum adjust
screw until the LED goes off then turn back one notch
to illuminate again.
15.2. Setting limits positions
NOTE: The door and shuttle must be engaged into the
chain index and should be open approximately half way.
1. Press red Minus (-) button and hold it, the door will
start closing. Release the button once you have
reached your desired closed limit position. (Fig. 21)
2. Press the set button. This action will store
intomemory the closed limit position.
3. Press the green Plus (+) button, the door will
startopening. Release the button once you have
reached your desired open limit position.
IMPORTANT WARNING: Please be aware that
the garage door will start closing automatically
once step 4 is performed. The door will also
automatically re-open after fully closing with
a small pause between the cycles.
4. Press the Set button. This action will store into
memory the door limit position. The door will now
automatically close to its limit position then fully
open to calculate the safety obstruction forces (ISS).
Please be aware of the above warning.
The opener can now be operated via the operate button.
WARNING: DO NOT TURN DATUM ADJUST
SCREW AFTER LIMIT SETTING, OTHERWISE
OPENER WILL NOT FUNCTION CORRECTLY.
Setting limits
19
fig
20
fig
21
fig
15.3. Resetting door limit positions
The door travel limit positions can be deleted for
new positions by the following steps below:
1. Press and hold the Close button (Fig. 21) for
six (6) seconds until you hear three beeps and
the red Close Limit LED starts to flash. Release
the button.
2. Follow STEPS 15.1 and 15.2 to set new travel
limit positions.
Go to STEP 17 and test the Safety Obstruction
Force.

18 GDO-7V1 SecuraLift® Owner Installation Instructions
NOTE: If the status LED is already illuminated when the
door is half way up then turn the datum adjust screw
until the LED goes off then turn back one notch to
illuminate again.
16.2. Coding transmitter for setting limits
1. Press and hold the Door Code button (Fig. 24).
2. Press button 1 on the transmitter for two seconds.
Release and pause for two seconds. Press the same
button again on the transmitter for two seconds.
3. Release Door Code button.
16.3. Setting limits
NOTE: The door and shuttle must be engaged
into the chain index and the door should be open
approximately half way.
1. Press button 4 (Fig. 22), the door will start closing,
release the button once you are 1 to 2 cm from your
desired closed limit position. Press button 3 for two
seconds then release.
2. Press button 4, each press will enable you to fine inch
the door to your desired closed position.
3. Once you are happy with the position press button
2, this action will store into memory the closed limit
position.
4. Press button 1, the door will start opening. Release
the button once you are 1 to 2 cm from your desired
open limit position. Press button 3 for two seconds then
release.
5. Press button 1. Each press will enable you to fine inch
the door to your desired open position.
IMPORTANT WARNING: Please be aware that
the garage door will start closing automatically
once step 6 is performed. The door will also
automatically re-open after fully closing with
a small pause between the cycles.
6. Once you are happy with the position press button
2, this action will store into memory the door limit
position. The door will now automatically close to its
limit position then fully open to calculate the safety
obstruction forces (ISS). Please be aware of the above
warning.
16.4. Resetting door limits positions
The door travel limit positions can be deleted for new
positions by the following below:
1. Press and hold the Minus (-) button (Fig. 24) for six (6)
seconds until you hear three beeps and the red Close
Limit LED starts to flash. Release the button.
2. Follow STEP 16.1 and 16.3 to set new travel limit
IMPORTANT: Their is no need to re-code the
transmitter used for setting the limit positions. After
the limits are set the transmitter automatically resets
to normal operation.
Go to STEP 17 and test the Safety Obstruction Force.
Setting limits
22
fig
24
fig
23
fig
Step 16. Setting travel limit positions
method two: via the transmitter
IMPORTANT NOTE: The OPERATE button will
not function until the open and close limits
positions are set.
16.1. Setting datum position
1. Move the door manually to engage the shuttle
assembly onto the chain index.
2. Turn power on - the Close Limit LED should be
flashing.
3. Press and hold Minus (-) or Plus (+) button to
move the door to half way open position.
4. Using a small blade screw driver turn the datum
adjust screw slowly until the yellow status LED
just illuminates.
Inch open button 1
Inch close
button 4
Set button 2
Switch
between
fast ans slow
inching button

Owner Installation Instructions GDO-7V1 SecuraLift® 19
Step 17. Safety obstruction test
Please take care when testing the Safety Obstruction
Force. Excessive force may cause SERIOUS PERSONAL
INJURY and/or PROPERTY DAMAGE can result from
failure to follow this warning.
17.1. Testing close cycle
1. Open the door by pressing the Yellow Operate
button (Fig. 25).
2. Place a length of timber approximately 50mm high
on the floor directly under the door (Fig. 25a).
3. Press the Operate button to close door. The door
should strike the object and start to re-open.
17.2. Testing open cycle
1. Close the door by pressing the Operate button.
2. Press again to open the door. When the door
reaches half the opening distance, grab the bottom
rail of the door firmly, the door should stop. If the
door does not reverse readily when closing, or stop
when opening, the force may be excessive and need
adjusting, refer to STEP 17.4.
IMPORTANT WARNING: If the door is closing
and is unable to re-open when obstructed,
discontinue use. Do not use a door with faulty
obstruction sensing. Repair fault and re-test
before using.
Adjusting safety obstruction force
The Safety Obstruction Force is calculated
automatically and set in memory on the SecuraLift®
opener. It is usually not necessary to adjust the Safety
Obstruction Force. The only time the force may need
to be increased is due to environmental conditions, for
example, windy or dusty areas, and areas with extreme
temperature changes.
17.3. To increase force pressure
1. Press and hold the Force Margin Set button (Fig. 25)
2. While holding down the Force Margin button, press
the Plus (+) button. Each press increases the force
margin. The Open Limit LED will flash each time
the Plus button is pressed to indicate an increase in
force. Test the force again as per step 17.1 and 17.2
above. If the Open Limit LED flashes continuously
when the Plus button is being pressed, this indicates
that the maximum force pressure setting has been
reached.
Setting safety obstruction force
25
fig
25
fig
17.4. To decrease force pressure
1. Press and hold the Force Margin Set button
(Fig. 25).
2. While holding down the Force Margin
button, press the Minus (-) button. Each press
decreases the force margin. The Close Limit
LED will flash each time the Minus button is
pressed. Test the force again as per step 17.1
and 17.2 above. If the Close Limit LED flashes
continuously when the Minus button is being
pressed, this indicates that the maximum force
pressure setting has been reached.
17.5. To recall factory set force
1. While holding down the Force Margin Set
button, press the SET button (Fig. 22) for
two seconds.
2. Release both buttons. The default setting
should now be recalled.
a
Wood (50mm high)

20 GDO-7V1 SecuraLift® Owner Installation Instructions
18.3. Setting the transmitter to
operate pet (pedestrian) mode
1. Press and hold Door Code button and the Close
button (Fig. 26).
2. Press the button on the transmitter you would like
to use to control pedestrian mode for two seconds,
pause for two seconds. Press the same button again
on the transmitter for two seconds.
3. Release all buttons to store the transmitter in
memory.
4. Press the transmitter button to test if it operates
the pedestrian mode To change the default pet
(pedestrian) door opening position, refer step 24 on
page 19.
18.4. Setting the transmitter to
operate vacation mode
1. Press and hold Light Code button and the Close
button (Fig. 26).
2. Press the button on the transmitter you would like to
use to control vacation mode for two seconds, pause
for two seconds. Press the same button again on the
transmitter for two seconds.
3. Release all buttons to store the transmitter in
memory.
4. To test, press and hold the transmitter button set
for vacation mode for five seconds to set Vacation
Mode.
To reset Vacation Mode press the same button for
two seconds. Please note that when vacation mode is
activated all stored transmitters will be locked out. This
mode can only be deactivated by a transmitter which
has been stored to activate this mode.
Coding transmitters
26
fig
Step 18. Setting transmitters codes
Make sure to connect the battery to the
transmitters. The memory in the openers receiver
can store up to 24 different remote control
transmitters.
18.1. Storing the transmitters code
1. Press and hold the Door Code button (Fig. 26).
2. Press the button (one of four) on the transmitter
you would like to use to control the door for
two seconds, pause for two seconds. Press the
same button again on the transmitter for two
seconds.
3. Release the Door Code button.
4. Press the transmitter button to test if it operates
the door.
18.2. Setting the transmitter
to operate the courtesy light
The transmitter can be programmed to operate
the courtesy light on the door opener.
1. Press and hold Light Code button (Fig. 26).
2. Press the button on the transmitter you would
like to use to switch on the light for two
seconds, pause for two seconds. Press the
same button again on the transmitter for two
seconds.
3. Release all buttons to store the transmitter in
memory.
4. Press the transmitter button to test if it switches
on the light.
