Autonics CX Series User manual

User Manual
Counters/Timers
CX Series
Thank you for purchasing anAutonics product.
This user manual contains information about the product and its proper use,
and should be kept in a place where it will be easy to access.
www.autonics.com

ii © Copyright Reserved Autonics Co., Ltd.

Preface
© Copyright Reserved Autonics Co., Ltd. iii
Preface
Thank you for purchasing Autonics product.
Please familiarize yourself with the information contained in the Safety Considerations section
before using this product.
This user manual contains information about the product and its proper use, and should be kept
in a place where it will be easy to access.

User Manual Guide
iv © Copyright Reserved Autonics Co., Ltd.
User Manual Guide
Please familiarize yourself with the information in this manual before using the product.
This manual provides detailed information on the product's features. It does not offer any
guarantee concerning matters beyond the scope of this manual.
This manual may not be edited or reproduced in either part or whole without permission.
A user manual is not provided as part of the product package. Visit our web site
(www.autonics.com) to download a copy.
The manual's content may vary depending on changes to the product's software and other
unforeseen developments within Autonics, and is subject to change without prior notice.
Upgrade notice is provided through out homepage.
We contrived to describe this manual more easily and correctly. However, if there are any
corrections or questions, please notify us these on our homepage.

User Manual Symbols
© Copyright Reserved Autonics Co., Ltd. v
User Manual Symbols
Symbol Description
Supplementary information for a particular feature.
Failure to follow instructions can result in serious injury or death.
Failure to follow instructions can lead to a minor injury or product damage.
An example of the concerned feature's use.
※1 Annotation mark.

Safety Considerations
vi © Copyright Reserved Autonics Co., Ltd.
Safety Considerations
Following these safety considerations will ensure the safe and proper use of the product
and help prevent accidents, as well as minimizing possible hazards.
Safety considerations are categorized as Warnings and Cautions, as defined below:
Warning Failure to follow these instructions may result in serious
injury or death.
Caution Failure to follow these instructions may result in personal
injury or product damage.
Fail-safe device must be installed when using the unit with machinery that may cause
serious injury or substantial economic loss. (e.g. nuclear power control, medical equipment,
ships, vehicles, railways, aircraft, combustion apparatus, safety equipment, crime/disaster
prevention devices, etc.)
Failure to follow this instruction may result in fire, personal injury, or economic loss.
Install on a device panel to use.
Failure to follow this instruction may result in electric shock or fire.
Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in electric shock or fire.
Check ‘Connections’ before wiring.
Failure to follow this instruction may result in fire.
Do not disassemble or modify the unit.
Failure to follow this instruction may result in electric shock or fire.
When connecting the power input and relay output, use AWG 20 (0.50mm2) cable or over,
and tighten the terminal screw with a tightening torque of 0.74 to 0.90N.m.
Failure to follow this instruction may result in fire or malfunction due to contact failure.
Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
Use the unit within the rated specifications.
Failure to follow this instruction may result in shortening the life cycle of the unit, or fire.
Do not use the unit in the place where flammable/explosive/corrosive gas, humidity, direct
sunlight, radiant heat, vibration, impact, or salinity may be present.
Failure to follow this instruction may result in fire or explosion.
Keep metal chip, dust, and wire residue from flowing into the unit.
Failure to follow this instruction may result in fire or product damage.
The specifications and dimensions of user manual are subject to change and some
models may be discontinued without notice.
Be sure to follow cautions written in the instruction manual, user manual and the
technical descriptions (catalog, homepage).

Cautions during Use
© Copyright Reserved Autonics Co., Ltd. vii
Cautions during Use
Follow this instruction in ‘Cautions during Use’.
Otherwise, it may cause unexpected accidents.
In case of 24-48VDC, 24VAC model, power supply should be insulated and limited voltage/
current or Class 2, SELV power supply device.
Use the product, 0.1 sec after supplying power.
When supplying or turning off the power, use a switch or etc. to avoid chattering.
Install a power switch or circuit breaker in the easily accessible place for supplying or
disconnecting the power.
Keep away from high voltage lines or power lines to prevent inductive noise.
In case installing power line and input signal line closely, use line filter or varistor at power
line and shielded wire at input signal line.
Do not use near the equipment which generates strong magnetic force or high frequency
noise.
This unit may be used in the following environments.
①Indoors (in the environment condition rated in ‘Specifications’)
②Altitude max. 2,000m
③Pollution degree 2
④Installation category II

Cautions during Use
viii © Copyright Reserved Autonics Co., Ltd.

Table of Contents
© Copyright Reserved Autonics Co., Ltd. ix
Table of Contents
Preface .............................................................................................................................iii
User Manual Guide ......................................................................................................... iv
User Manual Symbols ...................................................................................................... v
Safety Considerations ..................................................................................................... vi
Cautions during Use....................................................................................................... vii
Table of Contents............................................................................................................ ix
1Product Overview .....................................................................................13
1.1 Features.............................................................................................................13
1.2 Components and Accessories...........................................................................13
1.2.1 Components ............................................................................................. 13
1.2.2 Sold separately ......................................................................................... 14
1.3 Ordering information..........................................................................................15
1.4 Unit description ..................................................................................................16
1.4.1 CXS Series ............................................................................................... 16
1.4.2 CXM Series............................................................................................... 16
2Specifications............................................................................................19
3Dimensions................................................................................................23
3.1 CXS Series ........................................................................................................23
3.2 CXM Series........................................................................................................23
3.3 Panel cut-out dimension ....................................................................................24
3.3.1 CXS Series ............................................................................................... 24
3.3.2 CXM Series............................................................................................... 24
3.4 Bracket...............................................................................................................25
3.4.1 CXS Series ............................................................................................... 25
3.4.2 CXM Series............................................................................................... 25
4Connection Method...................................................................................27
4.1 Connection.........................................................................................................27
4.1.1 CXS Series ............................................................................................... 27
4.1.2 CXM Series............................................................................................... 30
4.2 Input and Output connection .............................................................................32
4.2.1 Input connection ....................................................................................... 32
4.2.2 Output connection..................................................................................... 33
5Counter mode............................................................................................35
5.1 Basic Operations ...............................................................................................35
5.1.1 Operations and functions.......................................................................... 35
5.1.2 Function setting mode .............................................................................. 36
5.1.3 Changing SV mode................................................................................... 37
5.1.4 Checking SV of TOTAL counter ............................................................... 38
5.1.5 Function setting check mode

Table of Contents
x © Copyright Reserved Autonics Co., Ltd.
(only for free voltage input model (CX6□-□□F))........................................ 38
5.1.6 Switching display of the setting value display component........................ 38
5.1.7 Display HOLD output mode for counter.................................................... 38
5.1.8 RESET ...................................................................................................... 38
5.2 Parameter setting ..............................................................................................39
5.2.1 Counter/Timer ........................................................................................... 41
5.2.2 Input mode ................................................................................................ 41
5.2.3 Output mode ............................................................................................. 41
5.2.4 Max. counting speed................................................................................. 41
5.2.5 OUT2 output time...................................................................................... 41
5.2.6 OUT1 output time...................................................................................... 42
5.2.7 Decimal point ............................................................................................ 43
5.2.8 Min. reset time .......................................................................................... 43
5.2.9 Input logic.................................................................................................. 43
5.2.10 Prescale .................................................................................................... 44
5.2.11 Prescale decimal point.............................................................................. 45
5.2.12 Prescale value .......................................................................................... 45
5.2.13 TOTAL Counter......................................................................................... 45
5.2.14 Start point value ........................................................................................ 46
5.2.15 Memory protection .................................................................................... 47
5.2.16 Key lock .................................................................................................... 47
5.3 Input mode.........................................................................................................48
5.4 Output mode ......................................................................................................52
5.5 Output operation for other conditions................................................................ 55
5.5.1 Start point value is larger than setting value
(UP, UP-1, UP-2, UP-3, UD-A, UD-B, UD-C mode) .............................. 55
5.5.2 When SET1 is larger or equal than SET2 at down mode......................... 56
6Timer mode................................................................................................57
6.1 Basic Operations ...............................................................................................57
6.1.1 Operations and functions .......................................................................... 57
6.1.2 Function setting mode............................................................................... 58
6.1.3 Changing SV mode................................................................................... 59
6.1.4 Changing SV operation............................................................................. 59
6.1.5 Switching display of the setting value display component........................ 59
6.1.6 RESET ...................................................................................................... 60
6.1.7 Display type of the setting value display component by output mode...... 60
6.1.8 Timer display operation............................................................................. 60
6.1.9 Zero blanking display................................................................................ 60
6.2 Parameter setting ..............................................................................................61
6.2.1 Counter/Timer ........................................................................................... 63
6.2.2 UP/DOWN mode....................................................................................... 63
6.2.3 Output mode ............................................................................................. 63
6.2.4 Time range................................................................................................ 64
6.2.5 OUT2 (OUT) output time........................................................................... 64
6.2.6 OUT1 output time...................................................................................... 65
6.2.7 Input logic.................................................................................................. 65
6.2.8 Input signal time........................................................................................ 65
6.2.9 Memory protection .................................................................................... 66
6.2.10 Key lock .................................................................................................... 66

Table of Contents
© Copyright Reserved Autonics Co., Ltd. xi
6.3 Output operation mode......................................................................................67
6.4 Timer ‘0’ time setting .........................................................................................77
6.4.1 Timer output mode for ‘0’ time setting ...................................................... 77
6.4.2 Operations by output mode (‘0’ time setting)............................................ 77
7Factory Default..........................................................................................85
7.1 Common ............................................................................................................85
7.2 Counter ..............................................................................................................85
7.3 Timer ..................................................................................................................86

Table of Contents
xii © Copyright Reserved Autonics Co., Ltd.

© Copyrig
1
1.1
1.2
1.2.1
ht Reserve
d
Prod
u
Featu
[Commo
n
 Impr
o
 Input
: volt
a
Fre
e
 Setti
n
 Mou
n
[Counter]
 Setti
n
 Vari
o
 Start
 TOT
A
: Dis
p
[Timer]
 Vari
o
 Wid
e
 '0' ti
m
Com
p
Comp
o
Make sur
e
If a comp
o
d
Autonics C
u
ct O
v
res
n
]
o
ved visibilit
y
method
a
ge input (P
N
e
voltage in
p
n
g range of
o
n
ting space
s
n
g range of
p
o
us input/out
p
point (coun
t
A
L counter d
p
lays the pr
e
o
us output m
o
e
time setting
m
e setting fu
n
p
onents
o
nents
e
all of the a
o
nent is mis
s
o., Ltd.
v
ervie
w
y
with LCD d
N
P)/no-volt
a
p
ut model
o
ne-shot out
p
s
aving with
c
p
rescale val
u
p
ut mode (in
ing value re
s
i
splay mode
e
sent value
a
o
de (15 typ
e
range: 0.00
n
ction
and A
c
bove compo
s
ing or dam
a
w
d
ispla
y
a
ge input (N
P
put time: 0.
0
c
ompact des
i
u
e: 0.00001
t
put: 11 type
s
s
e
t
) setting
a
nd the integ
e
s)
1 sec to 99
9
c
cesso
r
o
nents are in
c
a
ged, pleas
e
P
N) selectab
1 sec to 99.
9
i
gn (back le
n
t
o 99999.9
s
, output: 11
rated value
s
9
99.9 hour
r
ies
c
luded with
y
e
contact Aut
o
l
e model (by
9
9 sec by 0.
0
n
gth: 64.5m
m
types)
s
imultaneou
s
y
our product
o
nics or you
r
1 Prod
u
y
parameter
s
0
1 sec unit
m
)
s
ly.
t
package b
e
r distributor.
u
ct Overvie
w
1
3
s
etting),
e
fore use.
w
3

1 Product Overview
14 © Copyright Reserved Autonics Co., Ltd.
1.2.2 Sold separately
(1) Terminal cover
1) RSA-COVER (48×48mm)
2) RMA-COVER (72×72mm)

1 Product Overview
© Copyright Reserved Autonics Co., Ltd. 15
1.3 Ordering information
CX 6 S - 1P 4 F
① ② ③ ④ ⑤ ⑥
Item
Description
①Item CX LCD Display Counter/Timer
②Display digit 6 999999 (6-digit)
③Size S DIN W48 × H48mm
M DIN W72 × H72mm
④Output
1P 1-stage setting
2P 2-stage setting
⑤Power supply
2 24VAC 50/60Hz, 24-48VDC
4 100-240VAC 50/60Hz
⑥Signal input method
No mark Voltage input (PNP)/no-voltage input (NPN)
selectable type
F Free voltage input

1 Product Overview
16 © Copyright Reserved Autonics Co., Ltd.
1.4 Unit description
1.4.1 CXS Series
1.4.2 CXM Series
(1) Counting value display component (red)
RUN mode: Displays counting value for counter operation or time progress value for timer
operation.
Function setting mode: Displays parameter.
(2) Setting value display component (green)
RUN mode: Displays setting value.
Function setting mode: Displays setting content.

1 Product Overview
© Copyright Reserved Autonics Co., Ltd. 17
(3) Time unit indicator (h:m:s): Turns ON for time unit for timer.
(4) Key lock indicator ( ):Turns ON for key lock setting.
(5) Reset input indicator (RST)
: Turns ON for reset key input or reset signal input.
(6) INH indicator (INH)
: For the voltage input (PNP)/no-voltage input (NPN) selectable model (CX6□-□□),
it turns ON for INHIBIT signal input. (In case of CX6S Series and timer mode, it turns ON
for INB/INH signal input.)
For free voltage input model (CX6□-□□F), it turns ON for INB/INH signal input for timer.
(7) Output indicator (OUT1, OUT2)
: Turns ON for the dedicated control output ON.
(8) SV checking and changing indicator (SET, SET1, SET2) (green)
: Turns ON when checking and changing SV.
(9) COUNTER indicator (COUNTER)
: Turns ON for counter operation.
(10) TOTAL indicator※1(TOTAL)
: In case of TOTAL counter display mode, it turns ON with the COUNTER indicator.
(11) TIMER indicator(TIMER)
: Flashes (progressing time) or Turns ON (stopping time) for timer operation.
(12) key
RUN mode, Function setting mode: Press the key to reset the counting value and
turn OFF the output.
TOTAL counter display mode※1: Press the key to reset the counting value of
TOTAL counter.
(13) key
RUN mode
: Hold the key over 3 sec to enter function setting mode.
Press the key to select SV2 (SET2)/ SV1 (SET1)/TOTAL counter※1display for
counter operation.
Function setting mode
: Hold the key over 3 sec to return RUN mode. Press the key to save the SV
and enter the next setting.
Function setting check mode: Hold the key over 1 sec to return RUN mode.
Changing SV mode: Press the key to save SV and return RUN mode.
(14) , key
1) key
RUN mode: Press the Press the key to change SV and move SV
(SET, SET1, SET2) digits.
Changing SV mode: Press the key to change digits.
2) key
Changing SV mode: Increases SV.
Function setting mode: Changes the settings.

1 Product Overview
18 © Copyright Reserved Autonics Co., Ltd.
※1: This is for the voltage input (PNP)/no-voltage input (NPN) selectable model (CX6□-□□).

2 Specifications
© Copyright Reserved Autonics Co., Ltd. 19
2Specifications
Series
CXS
CXM
Model
CX6S-1P
□□
CX6S-2P
□□
CX6M-1P
□□
CX6M-2P
□□
Display digits 6-digit
Display method
7-segment (1st, 2nd digits of counting value display: white,
setting value display: green) LCD method,
11-segment (the other digits of counting value display: white) LCD method,
Operation display part: yellow LCD method
Character
size
(W×H)
Counting value 4.1×10.1mm 6.2×15.2mm
Setting value 3.3×8.1mm 5×12.3mm
Power
supply
AC voltage 100-240VACЖ50/60Hz
AC/DC voltage 24VACЖ50/60Hz, 24-48VDCЗ
Permissible voltage range 90 to 110% of rated voltage
Power
consump
tion
AC
voltage
CX6□-□□ Max. 6.4VA Max. 6.7VA Max. 7.1VA Max. 7.5VA
CX6□-□□F Max. 4.2VA Max. 4.9VA Max. 4.7VA Max. 5.4VA
AC/DC
voltage
CX6□-□□ AC: max. 5.5VA
DC: max. 3.5W
AC: max. 5.6VA
DC: max. 3.6W
AC: max. 6.2VA
DC: max. 4W
AC: max. 6.3VA
DC: max. 4.1W
CX6□-□□F AC: max. 3.6VA
DC: max. 2.5W
AC: max. 4.0VA
DC: max. 2.8W
AC: max. 3.9VA
DC: max. 2.9W
AC: max. 4.5VA
DC: max. 3.3W
Counter
Max.
INA/INB
counting
speed
CX6□-□□ Selectable among 1cps/30cps/300cps/1kcps/5kcps
CX6□-□□F 20cps
Counting range -99999 to 999999
Scale Decimal point up to fifth digit
Min.
signal
width
CX6□-□□ RESET, TOTAL RESET signal: selectable among 1ms/20ms
CX6□-□□F RESET signal: 25ms
Timer
Time range 999.999s, 9999.99s, 99999.9s, 999999s, 99m59.99s, 999m59.9s, 9999m59s,
99999.9m, 999999m, 99h59m59s, 9999h59m, 99999.9h
Operation mode Up, Down
Min.
signal
width
CX6□-□□ INA, INHIBIT, RESET, TOTAL RESET signal: selectable among 1ms/20ms
CX6□-□□F INA, INH, RESET signal: 25ms
Repeat error [CX6□-□□] – In case of power ON start: max. ±0.01% ±0.05s
In case of signal ON start: max. ±0.01% ±0.03s
[CX6□-□□F] - In case of power ON start: max. ±0.01% ±0.08s
In case of signal ON start: max. ±0.01% ±0.06s
SET error
Voltage error
Temperature error

2 Specifications
20 © Copyright Reserved Autonics Co., Ltd.
Series
CXS
CXM
Model CX6S-1P□□
CX6S-2P□□ CX6M-1P□□ CX6M-2P□□
Input
method
CX6□-□□
Selectable among voltage input (PNP) / no-voltage input (NPN)
[Voltage input (PNP)] – input impedance: 10.8kΩ,
[H]: 5-30VDCЗ, [L]: 0-2VDC
[No-voltage input (NPN)] - short-circuit impedance: max. 1kΩ
short-circuit residual voltage: max. 2VDC
CX6□-□□F
[Free voltage input] – INA (START), INB (INHIBIT) input
[H]: 24-240VDCЗ/24-240VACЖ 50/60Hz,
[L]: 0-10VDC/VAC
[No-voltage input] - RESET input
short-circuit impedance: max. 1kΩ,
short-circuit residual voltage: max. 2V
One-shot output time 0.01 to 99.99s setting
Control
output
Contact Type SPDT (1c): 1 SPST (1a): 2 SPDT (1c): 1 SPDT (1c): 2
Capacity Max. 250VACЖ3A, 30VDCЗ3A resistive load
Solid
state
Type
-
NPN open
collector: 1
NPN open collector:
2
Capacity Max. 30VDCЗ100mA
External power supply※1Max. 12VDCЗ±10%, 100mA
Memory retention Approx. 10 years (non-volatile memory)
Insulation resistance Over 100MΩ(at 500VDC megger)
Dielectric strength 3,000VAC 50/60Hz for 1 min
Noise immunity
AC voltage Square-wave noise by noise simulator (pulse width 1µs) ±2kV
AC/DC voltage Square-wave noise by noise simulator (pulse width 1µs) ±500V
Vibration
Mechanical 0.75mm amplitude at frequency 10 to 55Hz (for 1 min) in each X, Y, Z
direction for 1 hour
Malfunction 0.5mm amplitude at frequency 10 to 55Hz (for 1 min) in each X, Y, Z direction
for 10 minutes
Shock
Mechanical 300m/s²(approx. 30G) in each X, Y, Z direction for 3 times
Malfunction 100m/s²(approx. 10G) in each X, Y, Z direction for 3 times
Relay life cycle Mechanical Min. 5,000,000 operations
Malfunction Min. 100,000 operations
Protection structure Front part: IP50 (IEC standard)
Environment Ambient temp. -10 to 55℃, storage: -25 to 65℃
Ambient humi. 35 to 85%RH, storage: 35 to 85%RH
Approval
Weight
※2
AC
voltage
CX6□-□□ Approx. 157g
(approx. 112g)
Approx. 162g
(approx. 117g)
Approx. 235g
(approx. 170g)
Approx. 240g
(approx. 175g)
CX6□-□□F Approx. 155g
(approx. 110g)
Approx. 160g
(approx. 115g)
Approx. 233g
(approx. 168g)
Approx. 238g
(approx. 173g)
AC/DC
voltage
CX6□-□□ Approx. 156g
(approx. 111g)
Approx. 161g
(approx. 116g)
Approx. 234g
(approx. 169g)
Approx. 239g
(approx. 174g)
CX6□-□□F Approx. 154g
(approx. 109g)
Approx. 159g
(approx. 114g)
Approx. 232g
(approx. 167g)
Approx. 237g
(approx. 172g)
