AV TOOL AVT-3350 User manual

AVT-3350
Analog Video to PC/HD Scaler
Instruction Manual

Table of Contents
1.0 Introduction 2
2.0 Specifications 4
3.0 Checking Package Contents 5
4.0 Connecting the Hardware 5
5.0 Operating The Unit 6
6.0 Troubleshooting 7
7.0 Limited Warranty 7
8.0 Regulatory Compliance 8
9.0 Contact Information 9

2
1.0 INTRODUCTION
Thanks for purchasing this product from the AV Toolbox Division of TV One. The
AVT-3350 Analog Video to PC/HD Scaler is designed to convert interlaced NTSC
or PAL Video––S-Video or Composite Video format––to XGA, SXGA or UXGA
resolutions which allows the viewing of standard television images on your PC
monitor. The analog video input is also converted to HD resolutions of 480p to
1080p for viewing on an HD capable component television. In addition, 3D (frame
based) Motion Adaptive YNR/CNR noise reduction, Advanced 3D Motion
Adaptive De-Interlacing and Automatic 2:2 and 3:2 Film Mode Detection are all
standard features. AV Toolbox offers a wide range of video, audio and
multimedia products.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. AV
Toolbox cannot be held liable for the use of this hardware or any direct or indirect
consequential damages arising from its use. It is the responsibility of the user of
the hardware to check that it is suitable for his/her requirements and that it is
installed correctly. All rights reserved. No parts of this manual may be
reproduced or transmitted by any form or means electronic or mechanical,
including photocopying, recording or by any information storage or retrieval
system without the written consent of the publisher.
AV Toolbox reserves the right to revise any of its hardware and software
following its policy to modify and/or improve its products where necessary or
desirable. This statement does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The AV Toolbox logo is
a trademarks of AV Toolbox. All other trademarks are the property of their
respective holders.
1.2 Features
•Automatically detects either NTSC or PAL Television Inputs.
•Either Composite or S-Video (Y/C) Inputs
•High Res PC Video outputs: XGA, SXGA, UXGA
•Component HD resolutions of 480p to 1080p
•3D (Frame Based) Motion Adaptive YNR/CNR Noise Reduction
•3D Motion Adaptive de-interlace
•Automatic 2:2 & 3:2 Film Mode Detection
•50/60 Hz Frame Rate Conversion
•On Screen Display
•1 Year Parts and Labor Warranty
•Light Weight – Less than .20 pound
•Ergonomically Friendly Design

3
1.3 Getting the Best Results
There are many factors affecting the quality of results when scaling video signals.
Some basic precautions will ensure the best possible performance from your Up
Converter.
•Output display device – The quality of the output signal will depend
largely upon the type and quality of display device used. For instance,
some video projectors just look better than others.
•Distance between the Up Converter and the display device – This
plays a major role in the final result. Long distances are possible, but
special measures should be taken in order to avoid cable losses.
These include using high quality cables. Line amplifiers may also be
necessary.
•Input/Output connection cables – Low quality cables are susceptible
to interference. They degrade signal quality due to poor matching and
cause elevated noise levels. Therefore, cables should be of the best
quality. Coax-type computer cables are recommended because of
their superior internal shielding characteristics.
•Interference from nearby electrical devices – These can have an
adverse effect on signal quality. For example, an older computer
monitor often emits very high electromagnetic fields that can interfere
with the performance of video equipment in its proximity.

4
2.0 SPECIFICATIONS
Supported Inputs
Input Connectors 1x RCA, 1x S-Video Connector
Input Signal Types Composite Video or S-Video
Supported Output
Output Connector HD-15 VGA
Signal Characteristics
Input Types PAL or NTSC Analog Video
Input Formats 480i or 576i
Output Format Analog PC Video, HD Component Video
Output Signal Type XGA, SXGA, UXGA, 480p to 1080p
Human Interface
Device Control Via Top Mounted Buttons
Environmental
Operating Temperature 0° to +40° C (+32° to +104° F)
Operating Humidity 20% to 90%, Non-condensing
Storage Temperature -20° to +60° C (-4° to +140° F)
Storage Humidity 20% to 90%, Non-condensing
Warranty
Limited Warranty 1 Year Parts and Labor
Regulatory Approvals
Main Unit FCC, CE, RoHS
Power Supply UL, CUL, CE, PSE, GS, RoHS
Mechanical
Dimensions–HxWxD 0.9”x3.9”x2.5” (24x100x64mm)
Weight 0.19lbs (88g)
Power Requirement
External Power Supply 100~240VAC to 5VDC Adapter
Accessories Included
1x Power Adapter US, UK or Euro
1x User Manual
Model Number
AVT-3350 Analog Video to PC/HD Scaler

5
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain
the following items are contained in the shipping carton:
•1x AVT-3350 Video to PC Up Converter
•1x 100~240VAC to 5VDC Power Adapter
•1x User Manual
•1X HD-15 to 3 RCA Cable
Note: Please retain the original packing material should the need ever arise to
return the unit. If you find any items are missing, contact your reseller or TV One
immediately. Have the Model Number, Serial Number and Invoice available for
reference when you call.
4.0 CONNECTING THE HARDWARE
Connect a Video Source to the input of the AVT-3350 Analog Video to PC/HD
Scaler, connect its output to a PC monitor or HD capable component TV and
lastly connect the AC to DC Power Adapter. The drawing below shows the
locations of the input, outputs, power switch and power connector.
The Input Select
Switch and Input
Indicator LED are
located on the top
of the unit.
The input side
of the AVT-3350
is where the
Composite
Video, S-Video
and the 5VDC
Power Adapter
connectors are
located.
The output side of the
AVT-3350 is where the
HD-15 PC Video con-
nector and the Output
Resolution Switch are
located.
The remaining switch,
labeled “MODE”, controls
the timing aspect of the
output signal type: PC or
HD.

6
4.1 Connecting the Monitor to the AVT-3350
To make certain your PC monitor or HD component TV is working properly,
check that a PC or HD component source device can produce a picture on it
before attempting to use it with the AVT-3350. If all is well, connect the monitor or
HD component TV to the output of the AVT-3350 using a high quality cable.
Note: If you do not know the maximum resolution that your monitor is capable of
accepting, set the AVT-3350 to XGA resolution using the three position switch
located on the output side of the unit initially. By the same token, if you are
unsure how high of a HD resolution your component HD TV can reproduce, set
the three position switch to 480p.
4.2 Connecting the Input to the AVT-3350
You can connect either a NTSC or a PAL input signal to the AVT-3350. The unit
will automatically determine which type signal it is receiving. For the signal cable
type, you’ll want to use S-Video if possible because it will produce the best
picture in most cases. With either input always use a high quality cable, as short
a length as possible, for best results.
4.3 Connecting Power to the AVT-3350
The AVT-3350 is shipped with a Power Adapter to convert 100~240VAC@50-
60Hz to 5VDC. Connect the DC Output Cable from the Power Adapter to the
back of the unit and then plug the Power Adapter into an AC Receptacle. The
AVT-3350 has no power switch. As soon as the Power Adaptor is connected, the
unit will receive power.
5.0 OPERATING THE AVT-3350
The AVT-3350 can output either PC type signals or HD component type signals
however you must set the MODE switch correctly to ensure the AVT-3350 will
operate properly. If you are using a PC monitor, place the MODE switch in the
PC position. If you are using a component HD television, place the switch in the
HD position. This is necessary because the two signal types do not have the
same timing sequences.
Note: some component HD televisions have an HD-15 connector for the input
whereas others have three RCA type connectors for the inputs. If your
component HD television has RCA connectors, you will need to purchase an HD-
15 to Component adapter.
Next, if you have connected a Composite Video signal to the AVT-3350, press
the input switch on the top of the unit until the LED indicator turns Yellow. If you
have connected an S-Video (Y/C) signal, press the input switch until the LED

7
indicator turns Red. The unit will automatically determine if the input signal is
NTSC or PAL format. As previously noted, unless you know for certain that your
PC monitor or component HD television will accept one of the available higher
resolutions, you should start with the lowest resolution by moving the Output
Resolution switch on the side of the unit to the XGA/480p position. Once you
have an image on the monitor or receiver, you can then experiment with the
higher resolutions to improve the image quality.
5.1 OSD Display
Your AVT-3350 has an On Screen Display (OSD) which will show the basic
operating conditions of the unit. To display this information, press and hold the
input switch on the top of the unit for 3 seconds. When in the PC mode, the
display will show Input format and output timing, source type (CV or SV), the PC
monitor’s recovered EDID data (resolution) and the AVT-3350 firmware version.
When the unit is operating in the HD mode, the display will show input format and
output timing, frame rate conversion, video system (CV, SV and either NTSC or
PAL) and the unit’s firmware version. You should make a note of the firmware
version in case you ever need to contact technical support.
6.0 TROUBLESHOOTING
Other than checking for faulty cables, the only common problem would be
choosing a resolution setting that your monitor does not support or having the
MODE switch in the wrong position for the signal type in use. Also, make certain
you have a good NTSC/PAL input signal and the Power Adapter is securely
plugged in both to the AC receptacle and to the AVT-3350. After trying the
above suggestions should the problem still persist, contact your dealer for
additional suggestions before contacting AV Toolbox. Should the dealer’s
technical personnel be unable to assist you, contact AV Toolbox via the TV One
support website: http://tvone.crmdesk.com. Create a technical support request
on the site and our support team will respond within a short period of time.
7.0 LIMITED WARRANTY
LIMITED WARRANTY – AV Toolbox warrants the original purchaser that the
equipment it manufactures will be free from defects in materials and
workmanship for a period of one year from the date of purchase. Should this
product, in AV Toolbox’s opinion, prove defective within this warranty period, AV
Toolbox, at its option, will repair or replace this product without charge. Any
defective parts replaced become the property of AV Toolbox. This warranty does
not apply to those products which have been damaged due to accident,
unauthorized alterations, improper repair, modifications, inadequate maintenance
and care, or use in any manner for which the product was not originally intended.

8
If repairs are necessary under this warranty policy, the original purchaser must
obtain a Return Authorization Number from AV Toolbox and return the product to
a location designated by AV Toolbox, freight prepaid. After repairs are complete,
the product will be returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in
lieu of all other warranties for this product, expressed or implied, and is strictly
limited to one year from the date of purchase. AV Toolbox assumes no liability to
distributors, dealers or end-users for any loss of use, revenue or profit.
AV Toolbox makes no other representation of warranty as to fitness for the
purpose or merchantability or otherwise in respect of any of the products sold.
The liability of AV Toolbox with respect to any defective products will be limited to
the repair or replacement of such products. In no event shall AV Toolbox be
responsible or liable for any damage arising from the use of such defective
products whether such damages be direct, indirect, consequential or otherwise,
and whether such damages are incurred by the reseller, end-user or any third
party.
8.0 REGULATORY COMPLIANCE
The AVT-3350 has been tested for compliance with appropriate FCC and CE
rules and regulations. The Power Adaptor/Supplies have been tested for
compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or
Guidelines. These Products and Power Adapters are RoHS Compliant.

9
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas not
covered by this manual, please contact TV One at the appropriate location.
AV Toolbox
A division of TVOne
2791 Circleport Drive
Erlanger, KY 41018
USA
Tel [phone]
Fax [phone]
[email protected]
www.avtoolbox.com
AV Toolbox
A division of TV One Ltd
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax [phone]
[email protected]
www.avtoolbox.co.uk
AV Toolbox Latin America
A division of TV One L.A.
6991 NW 82 Avenue #8
Miami, FL 33166
USA
Tel [phone]
Fax [phone]
[email protected]
www.avtoolboxla.com
TV One Mercosur
Av. Diaz Velez 3965 #PB
(1200) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
TV One Asia
16F-4, NO.75, Sec. 1
Hsin Tai Wu Road, Hsichih
Taipei Hsien 22101
Taiwan R.O.C.
Tel [phone]
Fax [phone]
[email protected]
www.tvoneasia.com
TV One China
Rm. 1007, Golden Peach Bldg.
No. 1900 Shangcheng Road
Pudong, Shanghai
China 200120
Tel [phone]
Fax [phone]
Email: [email protected]
www.tvonechina.com
End of Manual
