Avalue Technology EPD-42T User manual

Part No. E2017E4T0A0R
EPD-42T
42" Communication Board
Quick Reference Guide
1st Ed –02 June 2020
Copyright Notice
Copyright 2020 Avalue Technology Inc., ALL RIGHTS RESERVED.

EPD-42T
2 EPD-42T Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "B" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
EPD-42T Quick Reference Guide
3
Content
1. Getting Started ........................................................................................................4
1.1 Safety Precautions....................................................................................................4
1.2 Packing List...............................................................................................................4
1.3 System Specifications...............................................................................................5
1.4 System Overview......................................................................................................7
1.5 System Dimensions ..................................................................................................8

EPD-42T
4 EPD-42T Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x EPD-42T 42" Communication Board
1 x Power Adapter
1 x US Power cord
1 x Wall mounting bracket
1 x Wall locking bracket
1 x Pan head screws (D6.8, M4*10mm) with washer (D8.1)
4 x Thumb screws (M4*10L)
2 x Pan head screws (D6.85, M4*6mm)
.

Quick Reference Guide
EPD-42T Quick Reference Guide
5
1.3 System Specifications
System
CPU
NXP i.MX 7Dual Processor
Dual Arm® Cortex® -A7 Cores And Cortex-M4
SBC
EMX-IMX7
System Chipset
NXP MCIMX7D7DVM10SD
GPIO Chip
PCA9555
System Memory
On-Board 2GB DDR3L
Battery
Wide Temperature RTC Battery
Expansion
1 x M.2 E-Key Socket for WiFi module
Storage
Combination
On-Board 8GB eMMC
microSD Socket
External I/O
USB Port
2 x USB 2.0, 1 x Micro USB slot (USB OTG)
Others
2 x Antenna with dust cover, 5 x membrane function key
LED
1 x Stack LED for PWR
LAN
1 x LAN RJ-45 port supports 10/100/1000 Base-T
Display
Chipset
NXP i.MX 7Dual Processor
Dual Arm® Cortex® -A7 Cores And Cortex-M4
Resolution
2160 x 2880@50Hz (E Ink: ED420TT1)
Touch Screen
Ilitek ILI2325 controller chip with PCAP touch
Ethernet
Ethernet Interface
10/100/1000 Base-Tx compatible
Audio
Chipset
Cirrus Logic WM8960
Audio Interface
2 x 8Ω/2W Speakers
Mechanical &
Environmental
Power Connector
Lockable DC Jack
Power Requirement
DC +12V / 5A
Power Type
AT/ATX (AT is default)
Dimension
918.8 x 704.6 x 37.6mm
Weight
6.5 KG
Color
Black
Mounting Kit
VESA Wall mount holes (100 x 100)

EPD-42T
6 EPD-42T Quick Reference Guide
Reliability
Vibration Test
With On-Board 8GB eMMC/On-Board 1GB DDR3L: 0.5Grms, IEC
60068-2-64, Random, 5 ~ 500Hz, 1hr/axis (Only for Z-axis)
Drop Test
Avalue Standard Test Criteria (Change to use ISTA-1A)
Operating
Temperature
0°C ~ 40°C (w/SSD, mSATA) ambient with air flow
Operating Humidity
5% ~ 90% relative humidity, non-condensing
Storage Temperature
-20°C ~ 60°C
Certification
CE/FCC Class B
OS Supported
Android/Linux
Note:
Specifications are subject to change without notice.

Quick Reference Guide
EPD-42T Quick Reference Guide
7
1.4 System Overview
Connectors
Label
Function
Note
LAN
RJ-45 Ethernet connector
USB2.0
2 x USB2.0 connector
USB OTG
USB OTG connector
Micro SD socket
Micro SD socket
DC IN
DC Power-in connector
PCB WiFi antenna
2 x PCB WiFi antenna
Membrane keypad
Membrane keypad

EPD-42T
8 EPD-42T Quick Reference Guide
1.5 System Dimensions
(Unit: mm)
