Avaya WLAN 8100 Series User manual

Quick Start Overlay Deployment
Configuration for Avaya WLAN 8100
Release 3.0
NN47251-106
Issue 07.01
June 2014

© 2014 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts have been made to ensure that the
information in this document is complete and accurate at the time of
printing, Avaya assumes no liability for any errors. Avaya reserves
the right to make changes and corrections to the information in this
document without the obligation to notify any person or organization
of such changes.
Documentation disclaimer
“Documentation” means information published by Avaya in varying
mediums which may include product information, operating
instructions and performance specifications that Avaya may generally
make available to users of its products and Hosted Services.
Documentation does not include marketing materials. Avaya shall not
be responsible for any modifications, additions, or deletions to the
original published version of documentation unless such
modifications, additions, or deletions were performed by Avaya. End
User agrees to indemnify and hold harmless Avaya, Avaya's agents,
servants and employees against all claims, lawsuits, demands and
judgments arising out of, or in connection with, subsequent
modifications, additions or deletions to this documentation, to the
extent made by End User.
Link disclaimer
Avaya is not responsible for the contents or reliability of any linked
websites referenced within this site or documentation provided by
Avaya. Avaya is not responsible for the accuracy of any information,
statement or content provided on these sites and does not
necessarily endorse the products, services, or information described
or offered within them. Avaya does not guarantee that these links will
work all the time and has no control over the availability of the linked
pages.
Warranty
Avaya provides a limited warranty on Avaya hardware and software.
Refer to your sales agreement to establish the terms of the limited
warranty. In addition, Avaya’s standard warranty language, as well as
information regarding support for this product while under warranty is
available to Avaya customers and other parties through the Avaya
Support website: http://support.avaya.com or such successor site as
designated by Avaya. Please note that if you acquired the product(s)
from an authorized Avaya Channel Partner outside of the United
States and Canada, the warranty is provided to you by said Avaya
Channel Partner and not by Avaya.
Licenses
THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA
WEBSITE, HTTP://SUPPORT.AVAYA.COM/LICENSEINFO OR
SUCH SUCCESSOR SITE AS DESIGNATED BY AVAYA, ARE
APPLICABLE TO ANYONE WHO DOWNLOADS, USES AND/OR
INSTALLS AVAYA SOFTWARE, PURCHASED FROM AVAYA INC.,
ANY AVAYA AFFILIATE, OR AN AVAYA CHANNEL PARTNER (AS
APPLICABLE) UNDER A COMMERCIAL AGREEMENT WITH
AVAYA OR AN AVAYA CHANNEL PARTNER. UNLESS
OTHERWISE AGREED TO BY AVAYA IN WRITING, AVAYA DOES
NOT EXTEND THIS LICENSE IF THE SOFTWARE WAS
OBTAINED FROM ANYONE OTHER THAN AVAYA, AN AVAYA
AFFILIATE OR AN AVAYA CHANNEL PARTNER; AVAYA
RESERVES THE RIGHT TO TAKE LEGAL ACTION AGAINST YOU
AND ANYONE ELSE USING OR SELLING THE SOFTWARE
WITHOUT A LICENSE. BY INSTALLING, DOWNLOADING OR
USING THE SOFTWARE, OR AUTHORIZING OTHERS TO DO SO,
YOU, ON BEHALF OF YOURSELF AND THE ENTITY FOR WHOM
YOU ARE INSTALLING, DOWNLOADING OR USING THE
SOFTWARE (HEREINAFTER REFERRED TO
INTERCHANGEABLY AS “YOU” AND “END USER”), AGREE TO
THESE TERMS AND CONDITIONS AND CREATE A BINDING
CONTRACT BETWEEN YOU AND AVAYA INC. OR THE
APPLICABLE AVAYA AFFILIATE (“AVAYA”).
Avaya grants you a license within the scope of the license types
described below, with the exception of Heritage Nortel Software, for
which the scope of the license is detailed below. Where the order
documentation does not expressly identify a license type, the
applicable license will be a Designated System License. The
applicable number of licenses and units of capacity for which the
license is granted will be one (1), unless a different number of
licenses or units of capacity is specified in the documentation or other
materials available to you. “Software” means Avaya’s computer
programs in object code, provided by Avaya or an Avaya Channel
Partner, whether as stand-alone products, pre-installed , or remotely
accessed on hardware products, and any upgrades, updates, bug
fixes, or modified versions thereto. “Designated Processor” means a
single stand-alone computing device. “Server” means a Designated
Processor that hosts a software application to be accessed by
multiple users. “Instance” means a single copy of the Software
executing at a particular time: (i) on one physical machine; or (ii) on
one deployed software virtual machine (“VM”) or similar deployment.
License types
Designated System(s) License (DS). End User may install and use
each copy of the Software only on a number of Designated
Processors up to the number indicated in the order. Avaya may
require the Designated Processor(s) to be identified in the order by
type, serial number, feature key, location or other specific
designation, or to be provided by End User to Avaya through
electronic means established by Avaya specifically for this purpose.
CPU License (CP). End User may install and use each copy of the
Software on a number of Servers up to the number indicated in the
order provided that the performance capacity of the Server(s) does
not exceed the performance capacity specified for the Software. End
User may not re-install or operate the Software on Server(s) with a
larger performance capacity without Avaya’s prior consent and
payment of an upgrade fee.
Heritage Nortel Software
“Heritage Nortel Software” means the software that was acquired by
Avaya as part of its purchase of the Nortel Enterprise Solutions
Business in December 2009. The Heritage Nortel Software currently
available for license from Avaya is the software contained within the
list of Heritage Nortel Products located at http://support.avaya.com/
licenseinfo under the link “Heritage Nortel Products”. For Heritage
Nortel Software, Avaya grants Customer a license to use Heritage
Nortel Software provided hereunder solely to the extent of the
authorized activation or authorized usage level, solely for the purpose
specified in the Documentation, and solely as embedded in, for
execution on, or (in the event the applicable Documentation permits
installation on non-Avaya equipment) for communication with Avaya
equipment. Charges for Heritage Nortel Software may be based on
extent of activation or use authorized as specified in an order or
invoice.
Copyright
Except where expressly stated otherwise, no use should be made of
materials on this site, the Documentation, Software, Hosted Service,
or hardware provided by Avaya. All content on this site, the
documentation, Hosted Service, and the Product provided by Avaya
including the selection, arrangement and design of the content is
owned either by Avaya or its licensors and is protected by copyright
and other intellectual property laws including the sui generis rights
relating to the protection of databases. You may not modify, copy,
reproduce, republish, upload, post, transmit or distribute in any way
any content, in whole or in part, including any code and software
unless expressly authorized by Avaya. Unauthorized reproduction,
transmission, dissemination, storage, and or use without the express
written consent of Avaya can be a criminal, as well as a civil offense
under the applicable law.
Third Party Components
“Third Party Components” mean certain software programs or
portions thereof included in the Software or Hosted Service may
contain software (including open source software) distributed under
third party agreements (“Third Party Components”), which contain
terms regarding the rights to use certain portions of the Software
(“Third Party Terms”). As required, information regarding distributed
Linux OS source code (for those Products that have distributed Linux
OS source code) and identifying the copyright holders of the Third
Party Components and the Third Party Terms that apply is available
in the Documentation or on Avaya’s website at: http://
support.avaya.com/Copyright or such successor site as designated
by Avaya. You agree to the Third Party Terms for any such Third
Party Components

Preventing Toll Fraud
“Toll Fraud” is the unauthorized use of your telecommunications
system by an unauthorized party (for example, a person who is not a
corporate employee, agent, subcontractor, or is not working on your
company's behalf). Be aware that there can be a risk of Toll Fraud
associated with your system and that, if Toll Fraud occurs, it can
result in substantial additional charges for your telecommunications
services.
Avaya Toll Fraud Intervention
If you suspect that you are being victimized by Toll Fraud and you
need technical assistance or support, call Technical Service Center
Toll Fraud Intervention Hotline at [phone] for the United
States and Canada. For additional support telephone numbers, see
the Avaya Support Website: http://support.avaya.com/. Suspected
security vulnerabilities with Avaya products should be reported to
Avaya by sending mail to: [email protected].
Trademarks
The trademarks, logos and service marks (“Marks”) displayed in this
site, the Documentation, Hosted Service(s), and Product(s) provided
by Avaya are the registered or unregistered Marks of Avaya, its
affiliates, or other third parties. Users are not permitted to use such
Marks without prior written consent from Avaya or such third party
which may own the Mark. Nothing contained in this site, the
Documentation, Hosted Service(s) and Product(s) should be
construed as granting, by implication, estoppel, or otherwise, any
license or right in and to the Marks without the express written
permission of Avaya or the applicable third party.
Avaya is a registered trademark of Avaya Inc.
All non-Avaya trademarks are the property of their respective owners.
Linux® is the registered trademark of Linus Torvalds in the U.S. and
other countries.
Downloading Documentation
For the most current versions of Documentation, see the Avaya
Support website: http://support.avaya.com, or such successor site as
designated by Avaya.
Contact Avaya Support
See the Avaya Support website: http://support.avaya.com for Product
or Hosted Service notices and articles, or to report a problem with
your Avaya Product or Hosted Service. For a list of support telephone
numbers and contact addresses, go to the Avaya Support website:
http://support.avaya.com (or such successor site as designated by
Avaya), scroll to the bottom of the page, and select Contact Avaya
Support.

Contents
Chapter 1: Introduction............................................................................................................ 5
Purpose.................................................................................................................................. 5
Related Resources.................................................................................................................. 5
Documentation.................................................................................................................. 5
Training............................................................................................................................ 5
Viewing Avaya Mentor videos............................................................................................. 6
Support.................................................................................................................................. 6
Chapter 2: New in this release................................................................................................. 7
Features................................................................................................................................. 7
Other changes........................................................................................................................ 8
Chapter 3: Wireless LAN (WLAN) 8100 configuration overview.......................................... 9
Avaya WLAN 8100 system components.................................................................................. 10
WLAN network design........................................................................................................... 10
Configuration requirements.................................................................................................... 11
Configuration options............................................................................................................. 12
Configuration workflow........................................................................................................... 12
Chapter 4: Completing preliminary controller configuration............................................. 15
Applying a license file to a wireless controller.......................................................................... 18
Chapter 5: Configuring the Wireless Controller — using the CLI...................................... 21
Chapter 6: Configuring the Wireless Controller — using the WMS................................... 50
Chapter 7: Configuring the Wireless Controller — using the EDM.................................... 76
Appendix A: DHCP server configuration for access points............................................. 105
Appendix B: Obtaining licenses from the Avaya Data Licensing portal......................... 108
Appendix C: Installing the WLAN Management System software................................... 110
Launching the WMS Installer on a Linux platform................................................................... 114
Variable definitions........................................................................................................ 115
Uninstalling the WLAN Management System (WMS) software................................................ 115
4 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Chapter 1: Introduction
Purpose
Use this Quick Start Guide to configure the Avaya WLAN 8100 system to provide basic Wireless
LAN services using Open Authentication.
This document covers the basic configuration for Wireless LAN services. This document does not
cover all the functionality required for a typical enterprise network and is intended to be used in a
demo/test environment. For configuration workflows in a typical enterprise network, see Configuring
an Overlay Deployment on Avaya WLAN 8100, NN47251-305.
Related Resources
Documentation
For a list of the documentation for this product, see Documentation Reference for Avaya WLAN
8100, NN47251-100.
Training
Ongoing product training is available. For more information or to register, see http://avaya-
learning.com/.
Enter the course code in the Search field and click Go to search for the course.
Course Code Course Title
6769X Avaya Wireless LAN 8100 Implementation and Management
4D00045V Avaya VENA Unified Access Implementation
Wireless LAN 8100 AIPS credential
7D00060A Wireless LAN 8100 Implementation Assessment (online test)
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 5
Comments? [email protected]

Viewing Avaya Mentor videos
Avaya Mentor videos provide technical content on how to install, configure, and troubleshoot Avaya
products.
About this task
Videos are available on the Avaya Support website, listed under the video document type, and on
the Avaya-run channel on YouTube.
Procedure
•To find videos on the Avaya Support website, go to support.avaya.com and perform one of the
following actions:
• In Search, type Avaya Mentor Videos to see a list of the available videos.
• In Search, type the product name. On the Search Results page, select Video in the
Content Type column on the left.
• To find the Avaya Mentor videos on YouTube, go to www.youtube.com/AvayaMentor and
perform one of the following actions:
•Enter a key word or key words in the Search Channel to search for a specific product or
topic.
• Scroll down Playlists, and click the name of a topic to see the available list of videos posted
on the website.
Note:
Videos are not available for all products.
Support
Go to the Avaya Support website at http://support.avaya.com for the most up-to-date
documentation, product notices, and knowledge articles. You can also search for release notes,
downloads, and resolutions to issues. Use the online service request system to create a service
request. Chat with live agents to get answers to questions, or request an agent to connect you to a
support team if an issue requires additional expertise.
Introduction
6 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Chapter 2: New in this release
The following sections detail what's new in Quick Start Overlay Deployment Configuration for Avaya
WLAN 8100, NN47251-106, for release 3.0.
Related Links
Features on page 7
Other changes on page 8
Features
See the following sections for information about the feature changes:
•Support for External Captive Portal on page 7
•Support for Link Layer Discovery Protocol (LLDP) on page 7
•Bonjour Gateway support on page 8
For information on the WMS enhancements and on Avaya Command Line Interface (CLI)
commands, see Using WMS and EDM on Avaya WLAN 8100, NN47251-108 and ACLI Commands
Reference for Avaya WLAN 8100, NN47251-107 respectively.
For more information on feature fundamentals, see Feature Overview for Avaya WLAN 8100,
NN47251-102.
Support for External Captive Portal
Wireless LAN Cotroller 8100 can support external captive portal with patented floating CPIP
mapping method and RFC 5176 Change of Authorization (CoA) to achieve a linearly scaling
standalone external captive portal solution that is designed for both large and small deployment.
WLAN 8100 users can provide their own external captive portal based on design guideline from
Avaya.
The WLAN controller leverages RFC 5176 CoA (Change of Authorization) to support small, medium,
and large scale deployments.
Support for Link Layer Discovery Protocol (LLDP)
The Link Layer Discovery Protocol (LLDP) is a data link layer protocol in the Internet Protocol Suite
used by network devices for neighbor identity and capability discovery. Avaya AP advertises its
status to the neighbors and relays the information and status about the LLDP neighbors to its
managing wireless controller.
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 7
Comments? [email protected]

LLDP support on AP can advertise its status, capabilities, and process information from other LLDP
neighbors. Eg. PoE switches.
Bonjour Gateway support
Bonjour is a service discovery protocol of Apple. Bonjour locates devices such as printers, other
computers, and the services that those devices offer on a local network using multicast domain
name system (mDNS) service records. Bonjour can be extended across subnets by using Avaya
WLAN 8100 Bonjour Gateway feature, which selectively relays service discovery packets across
networks without using external gateway or custom router configuration.
Related Links
New in this release on page 7
Other changes
There are no other changes to this document for release 3.0.
Related Links
New in this release on page 7
New in this release
8 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Chapter 3: Wireless LAN (WLAN) 8100
configuration overview
The wireless LAN (WLAN) 8100 solution supports the following deployment models:
•Avaya Overlay:
In this deployment, the Wireless Controller 8180 (WC) controls/manages Access Points (AP)
over a control channel and data is tunneled between APs and the WC over an access tunnel.
Two or more WCs in the domain form a cluster, with a mesh of control channels and data
tunnels between each other.
•Avaya VENA Unified Access:
In this deployment, the Wireless Controller is deployed in the control-plane only mode of
operation of the 8180 platform. This device then hosts only wireless control function and is
called a wireless control point (WCP). A switch such as the Avaya ERS 8600/8800 introduced
into the network, tunnels traffic (data) and is known as the wireless switching point (WSP). The
APs and WSPs tunnel traffic between each other over an access tunnel and the WSPs tunnel
traffic between each other over a mobility tunnel.
For more information about these deployment models and the complete solution, see the WLAN
8100 product documentation suite at http://www.avaya.com.
Important:
This document describes the WLAN configuration for the Overlay deployment only. For
information on wireless LAN configuration for Unified Access deployments, see Quick Start
Unified Access Deployment Configuration for Avaya WLAN 8100, NN47251-111.
Related Links
Avaya WLAN 8100 system components on page 10
WLAN network design on page 10
Configuration requirements on page 11
Configuration options on page 12
Configuration workflow on page 12
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 9
Comments? [email protected]

Avaya WLAN 8100 system components
System components for the WLAN 8100 Overlay deployment solution:
•WLAN Controller 8180
• WLAN Access Points (AP)
The supported AP models are:
- AP 8120 (indoor AP)
- AP 8120–E (indoor AP with external antenna)
- AP 8120 with Outdoor Antenna (AP 8120–O)
• WLAN Management Software 8100
Important:
The Wireless Controller (WC) 8180 requires licenses to manage the Access Points. The license
activation code for the controller, and the instructions to generate the license file are in the
paper package that is included as part of the controller shipment.
Related Links
Wireless LAN (WLAN) 8100 configuration overview on page 9
WLAN network design
The following is a sample network design for configuration in an Overlay deployment.
Note:
The configuration procedures in this document are based on this network design.
Wireless LAN (WLAN) 8100 configuration overview
10 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Figure 1: WLAN 8100 Overlay network design example
Related Links
Wireless LAN (WLAN) 8100 configuration overview on page 9
Configuration requirements
The following components are required to achieve the configuration described in this document:
•Wireless Controller (WC) 8180
• Access Points (AP)
Access Points can be of one the following models:
- AP 8120 (indoor AP)
- AP 8120–E (indoor AP with external antenna)
- AP 8120–O (outdoor AP )
• Power over Ethernet (PoE) switch or power injector for AP
Configuration requirements
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 11
Comments? [email protected]

• DHCP server
•wireless client
• WLAN Management System (WMS) software server (optional)
• wired client (optional for WMS or EDM use)
Related Links
Wireless LAN (WLAN) 8100 configuration overview on page 9
Configuration options
Use one of the following tools to configure the WLAN 8100:
• Command line interface (CLI)
• WLAN Management System 8100 (WMS) software
• Enterprise Device Manager (EDM)
Related Links
Wireless LAN (WLAN) 8100 configuration overview on page 9
Configuration workflow
The following workflow describes the procedures to configure wireless LAN services on the WLAN
8100.
Wireless LAN (WLAN) 8100 configuration overview
12 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Figure 2: Configuration of Wireless LAN services on the WLAN 8100
Navigation
•Completing preliminary controller configuration on page 15
Important:
Preliminary configuration on the WLAN Controller (WC) 8180 must be completed using the
command line interface (CLI).
You can complete the remainder of the configuration using the either the CLI, the WLAN
Management System (WMS) or the Enterprise Device Manager (EDM).
•Configuring the Wireless Controller — using the CLI on page 21
•Configuring the Wireless Controller — using the WMS on page 50
•Configuring the Wireless Controller — using the EDM on page 76
Configuration workflow
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 13
Comments? [email protected]

Related Links
Wireless LAN (WLAN) 8100 configuration overview on page 9
Wireless LAN (WLAN) 8100 configuration overview
14 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Chapter 4: Completing preliminary
controller configuration
Use this procedure to complete preliminary configuration on the Wireless Controller (WC) 8180.
Important:
You must complete the preliminary controller configuration using the command line interface
(CLI).
Before you begin
•Ensure that you have read and understood the fundamentals of WLAN configuration for
wireless services. See Wireless LAN (WLAN) 8100 configuration overview on page 9.
For further information, see Feature Overview for Avaya WLAN 8100, NN47251-102.
• Remove the WC 8180 device from its packaging. Ensure you have the following hardware
components and materials:
- Wireless Controller (WC) 8180 device
- console cable
• Ensure that you have obtained a license and have applied it to the WLAN controller WC 8180.
For more information on applying the controller license file, see Applying the Wireless
Controller license file on page 18.
Procedure
1. Power on the WC 8180.
2. When the WC 8180 is up, connect the console cable.
3. Verify that the baud rate and other console parameters are properly configured. You can
view console parameters using the PuTTY application.
a. Open a PuTTY session.
b. On the left-hand-side tree view, click Serial.
c. Verify that the parameters are configured as follows:
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 15
Comments? [email protected]

Figure 3: Console configuration
4. Press Ctrl+Y to start.
5. On the MENU screen, select Command Line Interface to go to the CLI.
You are now connected to the WC 8180 device.
6. Configure the VLAN.
The following example uses VLAN 20 as the VLAN to provide management and wireless
services.
WC8180>en
WC8180#configure t
Enter configuration commands, one per line. End with CNTL/Z.
WC8180(config)#vlan create 20 name mgmt-wireless type port
WC8180(config)#vlan members remove 1 1-26
WARNING: STP configuration may be lost on selected ports. You may
need to reconfigure the ports manually.
WC8180(config)#vlan members add 20 1-4
WC8180(config)#vlan mgmt 20
Important:
Before you create the management interface IP, you must create the management
VLAN. After you create the interface IP, you cannot make further changes to the
management VLAN.
7. Configure an IP interface for the VLAN.
WC8180(config)#interface vlan 20
WC8180(config-if)#ip address 20.20.20.45 255.255.255.0
WC8180(config-if)#exit
WC8180(config)#ip route 0.0.0.0 0.0.0.0 20.20.20.1 1
WC8180(config)#ip route 0.0.0.0 0.0.0.0 20.20.20.1 enable
Completing preliminary controller configuration
16 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

WC8180(config)#ip routing
WC8180(config)#show ip route
===============================================================================
Ip Route
===============================================================================
DST MASK NEXT COST VLAN PORT PROT TYPE PRF
-------------------------------------------------------------------------------
0.0.0.0 0.0.0.0 20.20.20.1 10 20 12 S IB 5
20.20.20.0 255.255.255.0 20.20.20.45 1 20 ---- C DB 0
Total Routes: 2
-------------------------------------------------------------------------------
TYPE Legend:
I=Indirect Route, D=Direct Route, A=Alternative Route, B=Best Route, E=Ecmp Route,
U=Unresolved Route, N=Not in HW
WC8180(config)#
Verify creation of the VLAN IP interface.
WC8180(config)#show vlan ip
==============================================================================
Vid ifIndex Address Mask MacAddress Offset Routing
==============================================================================
Primary Interfaces
------------------------------------------------------------------------------
20 10020 20.20.20.45 255.255.255.0 00:24:B5:1F:7F:80 1 Enabled
------------------------------------------------------------------------------
% Total of Primary Interfaces: 1
WC8180(config)#
8. Enable TELNET and SNMP access.
WC8180(config)#
WC8180(config)#telnet-access enable
WC8180(config)#
WC8180(config)#snmp-server enable
WC8180(config)#
9. Verify controller connectivity with the L2 switch.
WC8180#ping 20.20.20.1
Host is reachable
WC8180#
10. Configure the Wireless system interface.
Use VLAN 20 for the Management interface, Wireless system interface and Wireless client
connectivity. In large enterprise networks, these can be separate VLANs to isolate network
management traffic from wireless traffic.
WC8180#conf t
Enter configuration commands, one per line. End with CNTL Z.
WC8180(config)#wireless
WC8180(config-wireless)#interface-ip 20.20.20.45
11. Enable the wireless system interface configured in Step 9, using the following command
input.
WCP8180(config)#wireless
WCP8180(config-wireless)#enable
Verify that wireless system interface is configured and enabled.
WCP8180#show wireless
Operation Mode : WC
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 17
Comments? [email protected]

Status : Enabled
Interface IP : 20.20.20.45
TCP/UDP base port : 61000
Base MAC Address : 00:24:B5:1F:9F:00
WCP8180#
12. Configure the controller to be Mobility Domain Controller (MDC) capable.
WCP8180(config-wireless)#controller mdc-capable
% Domain password should be between 10-15 characters long.
% Password must contain a minimum of 2 upper, 2 lowercase letters
% 2 numbers and 2 special characters like !@#$%^&*()
Enter domain password: **********
Verify Domain password: **********
WCP8180(config-wireless)#
Verify that the controller is MDC-capable.
WCP8180#show wireless controller info
MDC-Capable : Enabled
WCP8180#
The WC 8180 is now provisioned for wireless services and to act as a wireless control point
(WCP) in the mobility domain.
13. Create a mobility domain and join the controller with the mobility domain.
In this example, you create a mobility domain named AVAYA.
WCP8180#wireless controller join-domain domain-name AVAYA mdc-address 20.20.20.45
Enter Domain Secret: *****
Use 'show wireless controller domain-membership' to see join status.
WC8180#show wireless controller domain-membership
Domain Name : AVAYA
Domain Role : Active MDC
Domain Action Status : Join Success
Action Failure Reason : None
WCP8180#
Next steps
Continue configuration using one of the following interfaces:
•CLI: See Configuring the Wireless Controller — using the CLI on page 21
•WLAN Management System (WMS): See Configuring the Wireless Controller — using the
WMS on page 50
•Enterprise Device Manager (EDM): See Configuring the Wireless Controller — using the
EDM on page 76
Related Links
Applying a license file to a wireless controller on page 18
Applying a license file to a wireless controller
Use this procedure to apply a license file to the Wireless Controller (WC) 8180.
Completing preliminary controller configuration
18 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 June 2014
Comments? [email protected]

Before you begin
• Ensure that you have obtained the license file(s) for all controller(s) in your mobility domain,
from Avaya Data Licensing portal. To obtain a license from the Avaya Data Licensing portal,
see Obtaining licenses from the Avaya Data Licensing portal on page 108.
• Ensure that you have copied the license file(s) on to a TFTP server that the WC can reach, or
you have stored the file(s) on a USB stick. This procedure provides the appropriate commands
to apply the license file using the command line interface (CLI).
Procedure
1. Use Telnet or the console port on the WC to connect to the WLAN 8100 Controller CLI.
2. Log in as the Administrator if the user name and password is configured.
3. On the MENU screen of the WC 8180, select Command Line Interface to go to the CLI.
4. Apply the license file from a TFTP server. Execute the following command from the WLAN
8100 CLI in privExec (#) mode.
copy tftp license address <IP Address> filename <License filename>
where <IP Address> is the IP address of the TFTP server.
Note:
The correct license file contains the MAC address of the controller that the license file is
being copied onto. After you download the licence file onto the WC, you must reboot the
WC using the boot command.
5. Alternatively, execute the following command to apply the license file from a USB stick.
copy usb license filename <License filename>
6. Verify that the license is installed correctly.
WC8180#show wireless controller license-info
Platform AP Capacity : 512
Licensed AP Capacity : Unlimited
AP License Count : 64
AP License Used Count : 0
WC8180#
If the license is installed correctly, the AP License Count indicates the correct number of
licensed access point (s) (AP) that can connect to the controller.
7. Read the WLAN 8100 online documentation for more detailed information and store your
License Certificate in a secure place for future reference.
Example
In the following example, 640024B51F7F00.lic is the 64 AP license file downloaded for the
controller.
Use the following command to download the license file from a TFTP server (with IP address
20.20.20.9).
WC8180#copy tftp license address 20.20.20.9 filename 640024B51F7F00.lic
License successfully downloaded.
NOTE: system must be rebooted to activate license.
WC8180#boot Reboot the unit(s) (y/n) ? y Rebooting . . .
Applying a license file to a wireless controller
June 2014 Quick Start Overlay Deployment Configuration for Avaya WLAN 8100 19
Comments? [email protected]

Use this command to download the license file from a USB stick.
WC8180#copy usb license filename 640024B51F7F00.lic
License successfully downloaded.
NOTE: system must be rebooted to activate license.
WC8180#boot Reboot the unit(s) (y/n) ? yRebooting . . .
