Avaya S8700 Series User manual

Quick Start
for Hardware Installation
Avaya S8700-Series Servers
555-245-703
Issue 8
January 2008
700436827

© 2008 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts were made to ensure that
the information in this document was complete and
accurate at the time of printing, Avaya Inc. can
assume no liability for any errors. Changes and
corrections to the information in this document may
be incorporated in future releases.
For full support information, please see the
complete document, Avaya Support Notices for
Hardware Documentation, document number
03-600759.
To locate this document on our Web site,
simply go to http://www.avaya.com/support and
search for the document number in the search
box.
Documentation disclaimer
Avaya Inc. is not responsible for any modifications,
additions, or deletions to the original published
version of this documentation unless such
modifications, additions, or deletions were
performed by Avaya. Customer and/or End User
agree to indemnify and hold harmless Avaya,
Avaya's agents, servants and employees against
all claims, lawsuits, demands and judgments
arising out of, or in connection with, subsequent
modifications, additions or deletions to this
documentation to the extent made by the Customer
or End User.
Link disclaimer
Avaya Inc. is not responsible for the contents or
reliability of any linked Web sites referenced
elsewhere within this documentation, and Avaya
does not necessarily endorse the products,
services, or information described or offered within
them. We cannot guarantee that these links will
work all of the time and we have no control over the
availability of the linked pages.
Warranty
Avaya Inc. provides a limited warranty on this
product. Refer to your sales agreement to establish
the terms of the limited warranty. In addition,
Avaya’s standard warranty language, as well as
information regarding support for this product, while
under warranty, is available through the following
Web site:
http://www.avaya.com/support.
Copyright
Except where expressly stated otherwise, the
Product is protected by copyright and other laws
respecting proprietary rights. Unauthorized
reproduction, transfer, and or use can be a criminal,
as well as a civil, offense under the applicable law.
Avaya support
Avaya provides a telephone number for you to use
to report problems or to ask questions about your
product. The support telephone number
is 1-800-242-2121 in the United States. For
additional support telephone numbers, see the
Avaya Web site: http://www.avaya.com/support.

Issue 8 January 2008 3
Process and Specifications
1 Verifying the Equipment
2 Installing the SNMP Module in the UPS
3 Installing the Optional Second Hard Drive
4 Installing the DAL2 Card
5 Installing the Hardware in the Rack
6 Connecting the Cables
7 Configuring the UPS and the Ethernet Switch
8 Connecting the Laptop
9 Connecting to the G650 Media Gateway
10 Troubleshooting
Hardware Specifications
Weight Dimensions
Equipment English (lb) Metric (kg) English (in) Metric (cm) Us
S8730, S8720, or
S8710 Server
60 27 3.4 x 17.5 x 26 8.6 x 45 x 66 2
UPS >34 >15 3.5 x 17 x 19 9 x 43 x 48 2
Ethernet switch
C363T
C364T
11
11
5
5
1.75 x 17 x 14.5
1.75 x 17 x 14.5
4.5 x 43 x 36.5
4.5 x 43 x 36.5
1
1

4 Quick Start for Hardware Installation: Avaya S8700-Series Servers
Legend
2
DH/C
Documentation
87qslgnd KLC 021605
Avaya technician
or business partner Customer Product
documentation
Green
straight-through
CAT5 cable
Red
straight-through
CAT5 cable
Crossover
CAT5 cable Services
laptop
Customer
network
Sequence step Duplex
reliability
High/Critical
reliability
Nonswitched
electrical outlet System
administration
Anti-static wrist
ground strap
required
Warning!
Use 2 people
to lift equipment
Filled-out Electronic
Pre-Installation
Worksheet (EPW)

Issue 8 January 2008 5
1Verifying the Equipment
Documentation
Off
On
1 2
SimplexDuplexchch2
0
1
1
1
0
3
23
2
5
45
4
disc
COMPACT
UID
2
1
S1 S2
ROUT SYS PWR
LNK COL Tx Rx FDX Hspd LAG PoE
1357911 13 15 17 19 21 23
24681012 141618202224
10/100bT
ETHERNET
10/100bT
ETHERNET
Compact flash
reader and
flashcard
Product
documentation Modem (2) Services
laptop
CAT5 CAT5
CAT5
CAT5
(1) (4 -68) (4 - 68) (1) (1) (2)
Fiber
cable
IPSI control network cables Duplication
cable
Laptop to
server cable
Modem cable
Cross-point screwdriver
IPSI adapter
(1 - 128)
SNMP module
and cable (2)
Screws
Server (2) Ethernet switch * (1 or more) UPS* (2)
8720qseq2 LAO 102605
S1 S2
ROUT SYS PWR
LNK COL Tx Rx FDX Hspd LAG PoE
1357911 13 15 17 19 21 23
24681012 141618202224
Customer network
Screws
Ethernet switch*
(1 or more)
UPS*
System administration
and filled-out Electronic
Pre-Installation Worksheet
19 in. (48 cm)
data rack (1)
*Optional
(2)

6 Quick Start for Hardware Installation: Avaya S8700-Series Servers
2a Installing the SNMP Module in the UPS
2b UPS and Ethernet Switch Mounting Brackets
COMM PORT
IOIOI
ISOLATED
ALARM PORT
COMM PORT
IOIOI
ISOLATED
ALARM PORT
2
3
COMM PORT
IOIOI
ISOLATED
ALARM PORT
1
Off
On
1 2
Off
On
1 2
4
Off
On
1 2
87qs2a KLC 010605
8720qs2b LAO 102005
2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
18
17
20
19
22
21
24
23S1 S2
ROUT SYS PWR
LNK COL Tx Rx FDX Hspd LAG PoE

Issue 8 January 2008 7
3 Installing an optional second hard drive (S8730)
Note:
Note: To use RAID, available on the S8730 Server only, install an optional second
hard drive.
8730qsxf LAO 083007
3
2
1
4
UID 12
FANS
INTER
LOCK
OVER
TEMP
I-PPM
DIMMSDIMMS
POWER
SUPPL
Y
POWER
SUPPL
Y
PCI
RISER
CAGE
PPM
PROC PROC

8 Quick Start for Hardware Installation: Avaya S8700-Series Servers
4a Installing the DAL2 Card: Removing the Cover
(S8720 Server shown)
8720qsxa LAO 101206
UID
2
1
01
1
0
disc
COMPACT
5
45
4
SimplexDuplexchch2
1
3
23
2
2
1

Issue 8 January 2008 9
4b Installing the DAL2 Card: Removing the PCI Riser Cage
(S8720/S8710)
2
3
VDCI
1
2
3
133 MGz
100MGz
100MGz
8720qsxb LAO 101206
2
1
1

10 Quick Start for Hardware Installation: Avaya S8700-Series Servers
4c Installing the DAL2 Card: Removing the DAL1 Card
(S8710/ S8720)
Note:
Note: Communication Manager 5.0 requires removing the DAL1 card and
replacing it with the DAL2 card.
3
8710qsd1 LAO 083007
2
1
DAL1
DUP
MEMORY
RECEIVE
MODE
LINC
SYNC
TRANS
MODE
LINC
ACTIVE

Issue 8 January 2008 11
4d Installing the DAL2 Card: Inserting the DAL2 Card
(S8720/S8710)
8720qsxc LAO 101206
DAL1
DUP
MEMORY
RECEIVE
MODE
LINC
SYNC
TRANS
MODE
LINC
ACTIVE
2
1
3
4
5

12 Quick Start for Hardware Installation: Avaya S8700-Series Servers
4e Installing the DAL2 Card: Replacing the PCI Riser Cage
(S8720/S8710)
2
3
VDCI
1
2
3
133 MGz
100 MGz
100 MGz
8720qsxd LAO 101206
DAL1
DUP
MEMORY
RECEIVE
MODE
LINC
SYNC
TRANS
MODE
LINC
ACTIVE
2
2
1

Issue 8 January 2008 13
4f Installing the DAL2 Card: Removing the PCI Riser Cage
(S8730)
8730qsxb LAO 081307
1
2
PCIe 1PCIe 2
3
4
5
DAL1
DUP
MEMORY
RECEIVE
MODE
LINC
SYNC
TRANS
MODE
LINC
ACTIVE
1
2
23

14 Quick Start for Hardware Installation: Avaya S8700-Series Servers
4g Installing the DAL2 Card: Inserting the DAL2 Card
(S8730)
DAL1
DUP
MEMORY
RECEIVE
MODE
LINC
SYNC
TRANS
MODE
LINC
ACTIVE
8730qsxc LAO 081607
1
2
3

Issue 8 January 2008 15
4h Installing the DAL2 Card: Replacing the PCI Riser Cage
(S8730)
8730qsxd LAO 101807
2
PCIe 2
3
4
5
1
4
1
3
DAL1
DUP
MEMORY
RECEIVE
MODE
LINC
SYNC
TRANS
MODE
LINC
ACTIVE
3
2

16 Quick Start for Hardware Installation: Avaya S8700-Series Servers
4i Installing the DAL2 Card: Replacing the Cover
(S8720 Server shown)
8720qsxe LAO 101306
UID
2
1
01
1
0
disc
COMPACT
5
45
4
SimplexDuplexchch2
1
3
23
2
2
1

Issue 8 January 2008 17
5a Installing the Hardware in the Rack: Attaching Rails to
the Server
(S8720 Server shown)
2
1
UID
UID
2
1
01
1
0
disc
COMPACT
5
45
4
SimplexDuplexch ch2
1
3
23
2
87qs2c KLC 010605

18 Quick Start for Hardware Installation: Avaya S8700-Series Servers
5b Installing the Hardware in the Rack: Attaching Rails to the
Rack (S8730/S8720)
8720qs2f LAO 092
7

Issue 8 January 2008 19
5c Installing the Hardware in the Rack: Attaching Rails to
the Rack (S8710)
Note:
Note: For racks with screw holes, see instructions included with the rail kit.
87qs2d KLC 010605

20 Quick Start for Hardware Installation: Avaya S8700-Series Servers
5d Installing the Hardware in the Rack: Inserting the Server Rails
into the Rack Rails
(S8720 shown)
1
1
8720qs2h LAO 092805
UID
2
1
01
1
0
disc
COMPACT
5
45
4
SimplexDuplexch ch2
1
3
23
2
