avertX HD920 User manual

This guide is a quick reference that offers users basic information regarding
installation and operation of the HD920 Night Vision Indoor / Outdoor High
Definition IP Camera. For further details on installation and operation, please
refer to the User Manual at avertx.com.
Before proceeding, please conrm that the box contains the items listed here. If
any item is missing or has defects, DO NOT install or operate the product and
contact AvertX for assistance.
About this Guide
CONTENTS OF CAMERA BOX
HD920 QUICK START GUIDE
The HD920 bullet camera can be installed
directly onto a wall or ceiling. Be sure that
the structure is strong enough to support the
camera.
1. Remove the HD920 bullet camera from
the packaging.
2. Connect the camera cable from the ceiling
or wall to the dongle on the camera. If
using the waterproof cable connector,
attach it now. See instructions below.
3. Loosen the set screw on the camera
bracket mount using the included wrench.
Aim the camera down to access screw
holes
4. A󰀩x the camera base to the ceiling or
wall with the included self-tapping screws.
When mounting on an unprotected wall,
the cable notch should be positioned
downward.
5. Adjust the position of your camera. Be
careful not to damage the cable when
moving the camera.
6. Tighten the set screw to secure your
camera.
INSTALLATION
Align Holes on Wall
Adjust Aim
35077AA
4MP IP BULLET CAMERA
Screws
Waterproof Cable
Connector
Documents &
Desiccant
Anchors
Note: If mounting outside, seal the opening at the wall and the base of the
camera with silicone caulking.
Improper installation may cause damage to your camera and void the warranty.
HD920 Bullet Camera

Copyright © 2016 AvertX. All rights reserved. Information contained in this document is subject to
change without prior notice. AvertX does its best to provide accurate information, but cannot be held
responsible for typos or mistakes.
NETWORK CABLE INSTALLATION
A 100’ Cat5e non-plenum UTP camera cable is included with your camera. It is
important to consider how the network cable is attached to the camera.
• If passing the cord through a wall or ceiling, drill a 7/8” hole.
• For outdoor installations, ensure the connection between your network cable
and the camera jack is housed within a wall or indoors or use the waterproof
cable connector.
• For outdoor installations, use silicone caulking to seal any holes in the wall or
ceiling to protect against leaks.
• If your installation is in a commercial building, consult local re codes. Plenum
rated cable may be required.
WATERPROOF CABLE
CONNECTOR
This camera features an IP66-rated waterproof cable connector for unprotected
outdoor connections. You do not need to re-terminate the cable to use the
waterproof cable connector.
• Slide all pieces of the waterproof cable connector over the cable plug in this order:
1. Small plastic ring
2. Flexible silicone seal ring. You will need to stretch the silicone seal over
the RJ-45 plug.
3. Large plastic ring
• Connect the camera cable to the plug on the dongle. Screw the large plastic
ring into the dongle.
• Insert the exible silicone seal into the “crown” section of the large plastic ring
• Screw the small plastic ring into the large plastic ring
AUTOFOCUS ZOOM LENS
The HD920 Bullet Camera is equipped with an Auto Focus Zoom lens. Do not try
to manually focus this camera. Access focus and zoom functions through the +, -
and AF buttons on your recorder.
1-855-2AVERTX (1-855-228-3789)
www.avertx.com
CONNECTING TO THE CAMERA
If you are using this camera with an AvertX recorder, follow the instructions in
the recorder user manual to connect to your camera. You can also set up your
camera using your PC.
1. Type the IP address 192.168.0.250 in the address bar of your browser
2. Enter username and password. The username and password are case sensitive.
AvertX strongly recommends changing the password after the initial setup to
prevent unauthorized access to the camera.
Username – admin
Password – 1234
3. Viewer software may need to be installed on your PC the rst time you connect to the
camera. Download and install the viewer software when prompted.
4. Supported browsers: Chrome, Firefox, Edge, Internet Explorer. Please consult
the user manual for additional browser support.
MICRO SD CARD
Your HD920 camera is equipped with a slot for a microSD card. To access this,
you must open the access cover of the HD920 camera.
If you have purchased a microSD card to be used for video backup, insert the
formatted card into the slot. Refer to manual for compatible cards and how to
properly format your microSD Card.
For more information on installing your AvertX camera, see the user manual
or view instructional videos at avertx.com/videos.
For Further Instruction
microSD Slot
35077AA
Access Cover
