AVF Group JML8650 User manual

0333 320 0463
CUSTOMER SERVICES HELPLINE NUMBER:
STOP
Read through ALL instructions before commencing installation.
If you have any questions about this product or issues with installation, contact
the customer services helpline before returning this product to the store.
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
JML8650
jl.avfgroup.com
471687 rev00
55kg
120lb

Assembly Overview
Fitting the Wall Bracket
Fit Screen Hangers to TV
Hanging the TV
This product comes with screws to fit a huge range
of TVs. You will have a lot of screws left over. We
recommend keeping them in a safe place in case you
change your TV in the future.
The JML8650 is suitable for attaching to plasterboard,
wood and metal stud, brick, dot and dab, concrete, or
any combination of these wall types. Establish which
wall type you are mounting to and follow the
corresponding steps.
This product comes with fixings for all the wall types
mentioned above. You will have lots of wall fixings
left over. We recommend keeping them in a safe
place in case you want to move your TV to a different
wall type in future.

Index
Marking Wall for Drill Points
3
Measure the TV fixing holes Width and Height
1
Retain all packaging in case the product needs to be returned.
Contents may vary from photography / illustrations.
You will not need all these parts, so expect there to be some left over depending upon the
specification of your TV.
This product is intended for indoor use only. Use of this product outdoors could lead to
failure and personal injury.
It is the responsibility of the installer to ensure that the mounting wall is of a suitable
standard and void of any services (eg gas, electricity, water etc).
AVF accept no responsibility for any damage or loss caused by installing this product in a
substandard wall.
Fitting the Wall Brackets
4
Hanging the TV
5
Fit Screen Hangers to TV
2
The JML8650 is suitable for attaching to plasterboard,
wood and metal stud, brick, dot and dab, concrete, or
any combination of these wall types. Establish which
wall type you are mounting to and follow the
corresponding steps.
This product comes with fixings for all the wall types
mentioned above. You will have lots of wall fixings
left over. We recommend keeping them in a safe
place in case you want to move your TV to a different
wall type in future.
You Will Need
Stud Finder
Ø3mm (1/8”) Wood
Ø10mm (25/64”) Masonry
Ø
5.5mm (7/32”) Masonry
Ø
3.5mm (9/64”) Metal

Boxed Parts
A1
A
B1
B
C2
C1
Dx2
Hx4 Ix4 Kx4
Jx8 RL x2
U1
U2

T
3mm
SQ x2 Ox2 Px2 Mx4 Nx4
G1
x4
G2
x4
G3
x4
G4
x4
G5
x4
G6
x4
G7
x4
G8
x4
F1
x4
F2
x4
E1
x12
E2
x4
E3
x4
55mm
40mm
20mm
M4’s M6’s M8’s
TV Screws, Reducers and Spacers

Measure the TV fixing holes Width and Height
1
Determine which diameter TV Screws
fit your TV and put them to one side.
M4, M6 or M8
We will select the correct length later.
If width ais less than 200mm or height bless than 100mm
STOP installation now and contact the customer helpline.
200mm to infinity
a
b
100mm to infinity

F1
G1- G2
G3- G5
F2
G6- G8
D
C1
C2
Do you need F1 or F2?
G1- G8
TV TV TV
Select the correct length TV screw.
E1
E2
TV
You may need to use Spacers E1 or E2
if the screws are too long or the back of
your TV is not flat.
You can also use longer screws and the
spacers to help avoid cabling or plug
sockets on your wall.
If required
Fit Screen Hangers to TV
2
Top

Marking Wall for Drill Points
3
U1
U2
The centre line of the
template U2 represents
the centre of your TV.
Line up with top
of the screen.
Top
Top Row Holes
Place the top row of holes on
template U1 over hangers C.
Mark off the top fixing centres.
Cut the template U2 so it is flush with
the bottom of your TV so that when the
template is on the wall you can see
exactly where your TV will be vertically
(distance from the floor and ceiling).
If hangers Cdo not line up with any holes on the template then ensure template is
firmly in position and punch 2 holes to match your top fixing centres with a pencil or
sharp object.
Lay the template on the back of the TV and follow the instructions below.
U1
U2
C
Assemble the Positioning Template.
i
Determine Bracket Holes Centres.
ii

Before marking the wall, determine the wall type that you have (i.e. Solid Wall/
Dot & Dab/Plasterboard/Wood Stud/Metal Stud). Ensure the drilling area is free
from mains services (Gas/Electric/Water).
Before you drill make sure you are happy with the position and ensure all markings are
correct and level.
Represents the
top of your TV.
Represents the
centre of your TV.
Represents the
bottom of your TV.
Use your template to mark
two points on the wall that
correspond with the top
fixing centres of your TV.
Next, use the Wall Brackets Aand Bas a template and position them over the appropriate
PENCIL MARKS you have made, so that the mark is in the middle of the CENTRAL HOLE of the
Wall Bracket. Ensure the bracket is level and mark the three DRILL POINTS with a pencil. Repeat
for other bracket.
Pencil Mark
Central Hole
Pencil Mark
Central Hole
Drill Points
Drill Points
Represents the
centre of your TV.
A B
Marking the Wall.
iii

Fitting the Wall Brackets
4
Wall Bracket Covers A1and B1are removed in the same way.
i
ii
Take care
Remove the Wall Bracket Covers.

Solid Wall
10mm (25/64")
75mm (3")
40mm (1 ")
9/16
5.5mm (7/32")
12.5 mm (½") MAX
M
Q
M
N
O
N
A/B
Remove Dust from Holes.
Lubricate screw thread with soap.
DO NOT overtighten screws.
Tighten screws by hand only
i
ii
iii
This product is designed to be fitted to many different types of wall.
Identify your wall type and follow the relevant instruction. Make sure you use
the correct fixings for your wall.

If gap is above 40mm (1 ") use
plasterboard fixing method.
9/16
Self drilling
9/1640mm (1 ")
MAX gap.
10mm (25/64")
108mm (4 ")
1/4
Dot and Dab
I
P
I
K
O
K
A/B
Remove Dust from Holes.
Lubricate screw thread
with soap.
DO NOT overtighten screws.
Tighten screws by hand only
i
ii
iii
If you have trouble fitting P
you can drill a 3mm pilot hole.

Self drilling
Plasterboard
9/1640mm (1 ")
MAX gap.
P
O
A/B
Jx2
K
a
b
c
H
S
R
18mm (3/4")
R
Remove Dust from Holes.
Lubricate screw thread
with soap.
DO NOT overtighten screws.
Tighten screws by hand only
i
ii
iii
If you have trouble fitting P
you can drill a 3mm pilot hole.

18mm (3/4")
R
Self drilling
Use Plasterboard
fixing H
Wood Stud
3mm
(1/8")
75mm (3")
Ensure hole is in
the middle of the
wood stud.
P
O
N
J
A/B
Lubricate screw thread
with soap.
DO NOT overtighten screws.
Tighten screws by hand only
i
ii
iii
If you have trouble fitting P
you can drill a 3mm pilot hole.
Only one fixing will be in the
wood stud. The other fixings
will be in plasterboard (see
Plasterboard installation
instruction).

Self drilling
18mm (3/4")
R
3.5mm
(9/64")
Metal Stud
Use Plasterboard
fixing H
P
O
L
J
A/B
DO NOT overtighten screws.
Tighten screws by hand only
i
ii
iii
If you have trouble fitting P
you can drill a 3mm pilot hole.
Only one fixing will be in the
metal stud. The other fixings
will be in plasterboard (see
Plasterboard installation
instruction).

On the Wall Bracket Covers A1and B1there are three retaining tabs. These locate onto
three retaining lips on the Wall Brackets A and B and lock the Wall Bracket Covers in
position.
A 1+ B 1
Retaining tab
Retaining tab
Retaining tab
A + B
Retaining lip
Retaining lip
Retaining lip
A
1+
B
1
A
+
B
A
1+
B
1
A
+
B
Replace the Wall Bracket Covers.

Hanging the TV
5
Make sure Screen Hangers
C1and C2are fully closed
before hanging the TV.
Line must be horizontal before attempting
to hang the TV.
Check Hangers C1and C2are on the correct
side before hanging TV.
C1C2
Top
Top
Back of TV

Present Hangers C1and C2(on the back of the TV) to the opening on Brackets A
and B. Slide down and across into place. Ensure both Hangers are fully engaged. If
cables from the TV prevent the TV resting against the wall then an alternative
Hanger configuration will be required (see Section 2). TV must be parallel to wall.
View “through” TV from the front.
AB
C1
C2
C2
C1

i
ii
iii
Removing the TV
To remove the TV reverse the movements as shown above.
DO NOT release TV until it is secure and level.
View “through” TV from the front.

A1+B1A1+B1
A1+B1
Removing the Wall Bracket Covers
i ii
Take care
Should you want to remove the Wall Bracket Covers please follow the steps below.
iii
Keep screwdriver level
as you pull downwards
Cable Access
For easy cable access, gently pull the bottom of the TV away from the wall using two hands. Hold
the TV in position while accessing cables. When finished gently lower the TV back to against the
wall.
Stop before the top of
the TV touches the wall.
