AVF Group P6491 Manual

P6491 Leaflet No. 466042 rev00
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
STOP
Read through instructions before commencing installation.
If you have any questions about this product or issues with installation
contact the customer services helpline before returning this product to
the store.
ALL
CUSTOMER SERVICES HELP LINE NUMBER:
01952 670009
Please refer to AVF TV Mount
instructions for maximum
TV weight and size.
This adaptor is designed to
be used with all AVF TV Mounts.
This adaptor is designed for use
with 300mm x 200mm VESA
SONY KDL-32WxxxC TVs only

Tools Recommended
Boxed Parts
Cx4
A
Bx4
M6
16mm
Dx4
7mm and 8mm
Ex4 Fx4 Gx4
M4
M4M5M5
M6
Attaching the Adaptor to the TV Mount
1
If you are mounting your TV
using a product
please make sure you use
the holes highlighted.
OPTION 1 OPTION 2
100mm x 100mm VESA TV Mounts
Using OPTION 2 can
result in some TV
connectors being obscured
TV Mounts

TV Mounts shown are an example only. The adaptor is designed to fit all AVF TV Mounts
100mm x 100mm VESA TV Mounts TV Mounts
Fixings shown are valid for
OPTIONS 1 & 2
You can only use M5 or M4 screws to attach your
TV mount. These screws are provided with your
TV mount.
Use B+C if you are using a M5 screw to attach
TV mount
Use D+E if you are using a M4 screw to attach
TV mount
B
M5
x4 C
M5
x4 D
M4
x4 Ex4
M4
C/E
B/D
C
B
Use the instructions for
details of the correct fixings to use
Ensure you use the correct length
of screw and no clashes occur

F
M6
16mm
Fx4 Gx4
M6
G
2Attaching the Adaptor to the TV
Fixings shown are valid for
OPTIONS 1 & 2 and products
