User Guide
Avigilon™ ACC ES HD™ Recorder
VMA-RPO-4P2 and VMA-RPO-4P4

©2016,Avigilon Corporation. All rights reserved. AVIGILON, the AVIGILON logo, AVIGILON CONTROL CENTER,
ACC, and ACC ES HD are trademarks of Avigilon Corporation. Other product names mentioned herein may be
the trademarks of their respective owners. The absence of the symbols ™ and ® in proximity to each trademark in
this document is not a disclaimer of ownership of the related trademark. Avigilon Corporation protects its
innovations with patents issued in the United States of America and other jurisdictions worldwide:
http://www.avigilon.com/patents Unless stated explicitly and in writing, no license is granted with respect to any
copyright, industrial design, trademark, patent or other intellectual property rights of Avigilon Corporation or its
licensors.
This document has been compiled and published covering the latest product descriptions and specifications.
The contents of this document and the specifications of the products discussed herein are subject to change
without notice. Avigilon Corporation reserves the right to make any such changes without notice. Neither
Avigilon Corporation nor any of its affiliated companies guarantees the completeness or accuracy of the
information contained in this document and is not responsible for your use of, or reliance on, the information.
Avigilon Corporation shall not be responsible for any losses or damages (including consequential damages)
caused by reliance on the information presented herein.
Avigilon Corporation
http://www.avigilon.com
PDF-4Port-A
Revision: 2 - EN
20160115
This device is provided with a battery powered real-time clock circuit. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or equivalent type recommended by the manufacture. Discard
used batteries according to the manufacturer's instructions.
This equipment is to be connected only to PoE networks without routing to the outside plant.
ii

Table of Contents
Introduction 1
Overview 1
Front View 1
Rear View 2
System Requirements 2
Installing the Recorder 3
Supported Network Configurations 4
Configuring the Avigilon Control Center Software 5
Starting Up and Shutting Down the Avigilon Control Center Client Software 5
Starting Up the Client Software 5
Shutting Down the Client Software 5
Logging Into and Out of a Site 5
Logging In 5
Logging Out 6
Changing the Administrator Password 6
Connecting Cameras to the Avigilon Control Center System 7
Setting the Recording Schedule 8
Creating a Recording Template 8
Setting Up a Weekly Recording Schedule 8
Setting Data Aging 9
Adding Users and Groups 10
Adding Groups 10
Adding Users 11
Advanced Settings 11
Configuring the Recorder 13
Accessing the Web Interface 13
Status 13
Setup 14
ACC 14
Network 15
Users 16
System 16
Setting the Date and Time 16
Upgrading the Firmware 17
Restarting the Recorder 17
iii

Budgeting PoE Power 17
Assigning a PoE Power Budget 18
PoE Status 19
Device Log 19
Connecting to External Devices 21
LEDIndicators 22
Front Panel LEDs 22
Back Panel LEDs 22
Using the Reset Button 23
Restarting the Recorder 23
Restoring Factory Default Settings 23
Limited Warranty & Technical Support 24
iv

Introduction
The Avigilon Control Center™ ES HD Recorder is the all-in-one solution for network video recording. The
recorder features:
lA network switch to connect and power IP cameras.
lBuilt-in server to run the Avigilon Control Center Server Software.
lLocal video content storage that can be accessed remotely.
The ACC ES HD Recorder factory default settings allow you to use the recorder immediately after installation,
but if you have special requirements, you can use the Avigilon Control Center software or the web interface to
customize your settings.
Overview
Front View
1. Reset button
Use this button to physically restart the recorder or perform a factory reset.
2. Status LED
Provides information about the recorder operation. For more information, see LEDIndicators on page 22.
Introduction 1

Rear View
1. Corporate Network Uplink Port
Accepts a 1GbE Ethernet connection to the general network to allow users access to the web interface
and connected camera video.
2. Camera Network Uplink Port
Accepts a 1GbE Ethernet connection to the cameras that are connected to the PoE switch component.
Can be used to link to other PoE switches and cameras.
3. PoE Switch Component
Connect cameras to the 10/100 speed PoE switch component to power the cameras and record video.
4. Power Connector
Accepts power to the recorder.
5. I/O Connector
Provides connections to external input/output devices. For more information, see Connecting to External
Devices on page 21.
System Requirements
The ACC ES HD Recorder administration settings are managed through a web interface.
The web interface can be accessed from any Windows, Mac or mobile device using any of the following web
browsers:
lWindows Internet Explorer® browser version 7.0 or later
lMozilla Firefox® browser version 3.6 or later
lGoogle Chrome™ browser 8.0 or later
2Rear View

lSafari® 5.0 or later
lChrome on Android™ 2.2 or later
lSafari® on Apple iOS 5 or later.
NOTE: Your web browser must be configured to accept cookies or the web interface will not function correctly.
Installing the Recorder
Complete the recommended procedure for installing the ACC ES HD Recorder:
1. Connect power to the recorder and wait for the recorder to start up.
Do not connect any other cables to the video recorder until instructed in this procedure.
The status LED turns green to indicate that the recorder is turned on.
2. Connect an Ethernet cable directly from a DHCP enabled port on your configuring laptop to the camera
network port on the recorder.
3. Open a web browser on the connected laptop and enter this IP address: https://169.254.100.100
When the recorder web interface loads, you are prompted to create a password for the administrator
username.
4. Enter a new password. The page refreshes and you are prompted to log in.
5. Enter administrator as the username and your new password.
The recorder Status page is displayed.
6. From the top of the page, select Setup.
7. On the ACC page, click Install ACC Client to download and install a copy of the Avigilon Control Center
Client software to the connected laptop.
8. In the left panel, click Network.
9. On the Network page, assign the recorder a new hostname and select how the recorder obtains an
IPaddress from the corporate network and the camera network. For more information, see Network on
page 15.
10. Connect an Ethernet cable from the video recorder to the corporate network.
11. Disconnect the configuring laptop from the recorder.
12. If required, mount the recorder on a wall using the supplied mounting brackets.
CAUTION — The recorder must be mounted as instructed or any issues that arise will not be
covered by the recorder warranty.
a. Attach the wall mount brackets to the lowest threaded holes on the sides of the recorder.
b. Position the recorder with the rear panel facing downwards.
c. Screw the wall mounting brackets to the wall.
Installing the Recorder 3

13. Connect the cameras to the PoE switch component.
NOTE: Allow the recorder 1 to 2 minutes to budget power to all connected devices. The front camera
status LEDs initially show that PoE is provided to all connected devices, but the status may change if the
system detects that the total power consumption exceeds the PoE limits.
14. If required, connect other switches and cameras to the camera network.
Now, you can configure the recorder and cameras for daily operation through the Avigilon Control Center Client
software. For more information, see Configuring the Avigilon Control Center Software on page 5.
Supported Network Configurations
NOTE: Camera Uplink Port does not support dynamically switching DHCP servers.
Network
Connections
Camera Web
Interface
Access
Supported IP Configurations
Corporate LAN
Uplink
Camera LAN
Uplink
Notes
Corporate LAN
Uplink only No Static or DHCP assigned
Unconnected
(leave as DHCP)
Camera LAN Uplink and
connected cameras will use
Zeroconf IP addresses.
Camera LAN
Uplink only Yes Unconnected (leave as DHCP)
Static, DHCP-
assigned, DHCP-
Zeroconf
Corporate and
Camera
LAN Uplink
via Camera
LAN Uplink
only
Static, DHCP-
assigned, DHCP-
Zeroconf
Static, DHCP-
assigned, DHCP-
Zeroconf
Corporate and Camera LAN
Uplinks must be on different
subnets.
4Supported Network Configurations

Configuring the Avigilon Control Center Software
The ACC Client software allows you to view live and recorded video, monitor events, set up alarms, and control
user access to the system.
The ACC Client software is the application that you would use on a daily basis. It is also where most of the
system configurations are made.
This section includes the recommended steps for setting up your ACC system for the first time.
Starting Up and Shutting Down the Avigilon Control Center Client
Software
After you install the Avigilon Control Center Client software, start the application and access the ACC ES HD
Recorder.
Starting Up the Client Software
Perform one of the following:
lIn the Start menu, select All Programs or All Apps > Avigilon > Avigilon Control Center Client.
lDouble-click the shortcut icon on the desktop.
When you are prompted, log in to your Site. You can only access cameras and video after you log in.
Once the application has started, it will automatically display a list of all the Sites that are connected to the same
network, including the ACC ES HD Recorder. You will be prompted to log in to all Sites.
Shutting Down the Client Software
1. In the top-right corner of the Client software, select > Exit.
2. When the confirmation dialog box appears, click Yes.
Logging Into and Out of a Site
After you start the Client software, you are immediately asked to log in to a Site. By default, the ACC ES HD
Recorder is automatically added to the system as a server within a Site of the same name.
The default username is administrator with no password.
Logging In
1. Open the Site Login tab. The Site Login tab is automatically displayed if you are launching the Client
software for the first time.
Configuring the Avigilon Control Center Software 5

To manually access the Site Login tab, do one of the following:
lFrom the top-right corner of the window, select > Log In....
lFrom the top of the application window, click to open the New Task menu then click
2. On the left side of the Site Login tab, select one or more Sites.
If the Site you want to log into is not shown, click Find Site... to discover the Site.
3. Enter your username and password for the selected Sites.
4. Click Log In.
You are logged into the selected Sites.
If you want to be notified when new or disconnected Sites come online, select the Notify me when additional
sites become available check box.
If you want to see the login page each time you launch the Client software, select the Show this tab on startup
check box. If you prefer not to login each time, you can disable this option and configure automatic login from
the Client Settings... dialog box.
Logging Out
You can log out of one or all Sites at any time.
To... Do this...
Log out of one or select Sites lIn the System Explorer, select one or more Sites then right-click and
select Log Out.
Log out of all Sites 1. In the top-right corner of the Client, select > Log Out.
2. In the confirmation dialog box, click Yes.
Changing the Administrator Password
After you log in for the first time, it is recommended that you change the default administrator password.
NOTE: These login credentials are different from the web interface user name and password.
1. At the top of the application window, click to open the New Task menu. When the menu appears,
click .
2. In the Setup tab, click .
3. In the following dialog box, select the administrator user name and click .
4. Click Change Password....
5. In the following dialog box, enter a new password then confirm the new password.
6. Click OK.
6Logging Out

Tip: If you forget the default administrator password, resetting the password requires restoring the factory
default settings on every server in the Site. To avoid this issue, it is highly recommended that you create at least
one other administrator level user as a backup.
Connecting Cameras to the Avigilon Control Center System
After all the cameras in your system have been physically connected to the ACC ES HD Recorder, you need to
connect the cameras to the Avigilon Control Center system so that video can be recorded and indexed for
search.
1. In the Site Setup tab, click .
The Connect/Disconnect Cameras... tab is displayed.
2. In the Discovered Cameras area, select one or more devices then click Connect....
Tip: You can also drag the device to a server on the Connected Cameras list.
3. In the Connect Camera dialog box, select the server you want the device to connect to.
NOTE: If you are connecting multiple devices, all the cameras must use the same connection settings.
4. If you are connecting a third-party device, you may choose to connect the device by its native driver. In
the Camera Type: drop down list, select the device's brand name. If there is only one option in the drop
down list, the system only supports one type of driver from the device.
5. If the camera supports a secure connection, the Camera Control: drop down list is displayed. Select one
of the following options:
NOTE: The setting may not be displayed if the camera only supports one of the options.
lSecure — The system will protect and secure the camera's configuration and login details. This
option is selected by default.
lUnsecure — The camera's configuration and login details will not be secured and may be
accessible to users with unauthorized access.
Cameras with a secure connection are identified with the icon in the Status column.
6. If it is not displayed, click to display the Site View Editor and choose where the device appears in the
System Explorer.
lIf your Site includes virtual sub-sites, select a location for the device. The list on the right updates
to show what is stored in that directory.
lIn the Site directory, drag the device up and down to set where it is displayed.
lIf you are connecting multiple devices at the same time, the selected devices must be assigned to
the same sub-site
Tip: If the Site you want is not listed, you may need to connect the device to a different server. Make sure
the selected server is connected to the Site you want.
7. Click OK.
Connecting Cameras to the Avigilon Control Center System 7

8. If the device is password protected, the Camera Authentication dialog box appears. Enter the device's
username and password then click OK.
Setting the Recording Schedule
Once all the cameras have been connected, you can set when you want each camera to record video.
By default, all connected cameras are set to record when events are detected by the system. You can skip this
procedure if you prefer to keep the default settings.
Before you can assign a recording schedule, you must create a template. The template allows you to assign the
same schedule to multiple cameras.
Creating a Recording Template
The events that can be selected for the template depend on the licensed features in your system.
1. In the server Setup tab, click . The Recording Schedule dialog box is displayed.
2. Click Add Template below the Templates: list.
3. Enter a name for the New Template.
4. Click the Set Area button, then click or drag the cursor across the Recording Mode: timeline to set the
types of events that the cameras will record throughout the day. Individual rectangles on the Recording
Mode: timeline are colored when they have been selected.
The Recording Mode: options include:
lContinuous — record video constantly.
lMotion — Only record video when motion is detected.
5. To disable recording in parts of the template, click the Clear Area button then click or drag the cursor
across the timeline to remove the set recording areas.
6. If cameras are not recording in Continuous mode all day, you can set cameras to record reference images
between events in the recording schedule.
lSelect the Record a reference image every: check box then set the time between each reference
image.
Setting Up a Weekly Recording Schedule
You can set up a weekly recording schedule by applying templates to cameras for each day of the week.
1. In the server Setup tab, click . The Recording Schedule dialog box is displayed.
2. Select a template from the Templates: list.
8Setting the Recording Schedule

3. In the Default Week area, click the days of the week this template applies to for each camera.
Figure 1: The Recording Schedule dialog box: Default Week
4. Click OK.
Setting Data Aging
Data aging defines how long recorded video is stored and the quality of the video as it ages over time. In the
Avigilon Control Center system, the recorded image rate is slowly reduced so that recorded video can be
viewed over a longer period of time while still making room for new recordings. You can adjust how long the full
image rate video is kept, so that you have the best quality video when you need it.
The amount of data aging that is available depends on the camera you have connected to your system:
lFor JPEG2000 or JPEG compression cameras, Data Aging is available at three rates:
lFull Image Rate and Resolution keeps recordings at their original quality.
lHalf Image Rate discards half of the recorded data to make room for new recordings.
lQuarter Image Rate keeps 1/4 of the original recorded data so that you can still see older video.
lFor H.264 cameras that support Data Aging, Data Aging is available at two rates:
lFull Image Rate and Resolution keeps the original high quality video and the secondary stream of
low resolution video.
lLow Resolution only keeps the secondary stream of low resolution video.
NOTE: The Data Aging can only occur when the secondary stream is enabled.
lFor H.264 cameras that do not support Data Aging, only the Full Image Rate and Resolution video is kept.
By default, the system is set to keep recorded video for the maximum amount of time based on the available
storage.
NOTE: The listed Total Record Time is an estimate only.
1. In the server Setup tab, click .
The Recording and Bandwidth dialog box is displayed.
The Data Aging column shows an estimate of the recording time that is available at each image rate,
given the amount of space on the recording device.
Setting Data Aging 9

2. In the Data Aging column, move the sliders to adjust the amount of time video is stored at each image
rate.
lTo change the data aging settings for all linked cameras, move the slider for one linked camera
and all linked cameras will be updated.
lTo change the data aging setting for one camera, break the camera's link to other cameras by
clicking the icon to the left of its name, then make your changes.
3. In the Max. Record Time, manually enter a maximum record time or select one of the options from the
drop down list for each camera.
NOTE: If the time estimated in the Total Record Time column is shorter than what is set in the Max. Record
Time column, the camera's actual recording time will be shorter than the Max. Record Time.
4. Click OK.
Adding Users and Groups
If there will be other people using the system, you may want to add them as separate users rather than giving
them access through the default administrator account.
Before you can add individual users, you will need to add permission groups that define what users have access
to. By default, the system has the following groups:
lAdministrators — has access to everything in the system.
lPower Users — has access to most features in the system except for the ability to import and export
settings.
lRestricted Users — has access to live video only and can control audio and digital outputs.
lStandard Users — has access to live and recorded video, but cannot make any Setup changes.
It is highly recommended that you add at least one other user to the Administrators group. In the event you
forget the default administrator password, the second administrator user can be used to reset the password. If
you do not have a second administrator user, you may need to completely reset the system.
Adding Groups
1. In the Site Setup tab, click .
2. In the following dialog box, select the Groups tab and click .
3. In the pop-up dialog box, select an existing group to use as a template for your new group, then click OK.
4. In the Edit Group dialog box, complete the following:
a. Give the new group a name.
b. Select a rank for the group from the Rank: drop down list. To edit or view the entire Corporate
Hierarchy, click .
c. Select the required Group Privileges: and Access Rights: for the group. Clear the check box of any
feature or device that you do not want the group to have access to.
10 Adding Users and Groups

5. Select the Members tab to add users to the group.
If a user is added to the group through the Add User dialog box, the user is automatically added to the
group's Members list.
a. Click .
b. Select the users that should be part of this new group. Only users that have been added to the Site
are displayed.
Tip: Enter the name of a user in the Search... field to locate specific users.
c. Click Add. The users are added to the Members list.
6. Click OK to save the new group.
Adding Users
1. In the Site Setup tab, click .
2. In the Users tab, click .
3. When the Add User dialog box appears, complete the User Information area.
4. If you don’t want this user to be active yet, select the Disable user check box. Disabled users are in the
system but cannot access the Site.
5. In the Login Timeout area, select the Enable login timeout check box to set the maximum amount of time
the Avigilon Control Center Client software can be idle before the user is automatically logged out of the
application.
6. In the Password area, complete the following fields:
lPassword: — enter a password for the user.
lConfirm Password: — re-enter the password.
lRequire password change on next login — select this check box if the user must replace the
password after the first login.
lPassword Expiry (Days): — specify the number of days before the password must be changed.
lPassword never expires — select thischeck box if the password never needs to be changed.
7. In the Member Of tab select the check box beside each access group the user belongs to.
The other columns display the permissions that are included in the selected groups.
8. Click OK. The user is added to the Site.
Repeat this procedure to add all the users that are required.
Advanced Settings
The following list include some advanced settings that you can use to further customize your system. See the
application Help files for details about how to configure these settings.
Adding Users 11

lAdjust camera settings
lIf camera video looks slightly blurry or unclear, you can adjust the camera's Image and Display
settings.
lIf you want the camera to record at a different image rate, you can adjust the camera's
Compression and Image Rate settings.
lTo reduce the amount of ambient motion detection for a specific camera, you can adjust the
Motion Detection settings.
lTo maintain the privacy of certain areas, you can set Privacy Zones in the camera's field of view so
that private spaces are never recorded.
lConfigure digital inputs and outputs
lThe digital I/O connector on the recorder can be configured as an independent digital I/O device.
lUse the Digital Inputs and Outputs dialog box to configure the recorder's I/O settings. Once
configured, you can use the digital inputs and outputs in alarms and other system actions.
lAlarms
lUse the Alarms dialog box to create and manage alarms. Once an alarm has been created, you can
monitor alarm events in the Alarms tab and in the Avigilon Control Center Mobile App.
lSelf-Learning Video Analytics
lIf you have an Avigilon™ self-learning video analytics device, use the Video Analytics Configuration
dialog box to configure classified object motion detection. Once configured, you can receive
events, trigger alarms, define rules, and record video when specific object motion requires your
attention.
lEmail notifications
lYou can set up an SMTP email server to send you messages when system events occur.
12 Advanced Settings

Configuring the Recorder
The ACC ES HD Recorder can be configured through a web interface that is accessible from any browser on the
network. The web interface allows you to configure the recorder server settings like the Avigilon Control Center
Admin Tool.
The web interface allows you to configure the recorder network settings, set how the system keeps time, and
allows you to remotely restart or upgrade the recorder.
Accessing the Web Interface
During the installation process, you connected a laptop directly to the recorder and used a special IP address to
access the web interface. Once the recorder has been set up and is connected to the corporate network, you
can access the web interface following these steps:
1. On a computer with network access to the ACC ES HD Recorder, enter the recorder’s IP address into a
web browser:
https://<ACC ES HD Recorder IP address >/
For example: https://192.168.1.40/
Tip: If you forgot the IPaddress that was configured for the recorder during the installation process, the
recorder IP address is listed in the ACC Client software, in the server Setup tab.
2. When you are prompted, enter the web interface username and password.
The username is always administrator. The password was configured when you logged in to the
recorder for the first time. For more information, see Installing the Recorder on page 3.
Status
After you log in to the web interface, the first page you see is the Status page. The Status page shows your
current system status details.
Tip: Refresh the web browser to see the latest status.
Feature Description
Avigilon Control Center Information
ACC Site Name The name of the Site that the recorder is connected to.
ACC Server Name The name of the recorder in the Site.
ACC Server Status The status of the Avigilon Control Center Server software.
ACC Server Version The version of the ACC Server software.
HDD Information
Disk The name of the hard drive disk.
Configuring the Recorder 13

Feature Description
Capacity The capacity of the hard drive disk.
Status The status of the hard drive disk.
Device Information
Part Number The part number of the ACC ES HD Recorder.
Model Name The name of the ACC ES HD Recorder model.
Serial Number The serial number of the ACC ES HD Recorder.
Device UUID The UUIDof the ACC ES HD Recorder.
System Information
Firmware Version The system firmware version.
MAC Address (LAN Corporate)
The MAC address for the corporate network.
Users would typically connect to the recorder through this network port from
the Avigilon Control Center Client software.
MAC Address (LAN Camera)
The MAC address for the camera network.
This is the network port that allows you to connect to other cameras
License Information
Server ID The Avigilon Control Center Server software ID.
Edition The Avigilon Control Center license edition.
Camera Channels The number of camera channels included in the license.
Max Clients The maximum number of client connections allowed by the license.
POE Port Status
Port The port number in the PoE switch component.
Link Status The network status of the device that is connected to the port.
Power Status The power status of the device that is connected to the port.
Uplink Status
Uplink The name of the network port that the uplink is connected to.
Speed The speed of communication on the network.
Status The status of the network connection.
Setup
To configure your device, click the Setup link.
ACC
When you click Setup, the first page you see is the ACC page. Use the left link pane to navigate through the
Setup screens.
14 Setup

The ACC page allows you to control how the recorder communicates with network clients. You can perform any
of the following tasks:
To... Do this...
Install the Avigilon Control Center Client
software.
Click Install ACC Client to download and install the software to the
computer you are using to access the web interface.
Shut down the Avigilon Control Center
Server software.
Click Stop ACC Services.
NOTE: The recorder must be powered to use this feature.
Start up the ACC Server software. After the ACC Server has shut down, click Restart ACC Services.
Format the recorder disk drives. Click Reinitialize Storage to delete all configuration and recorded
video data.
Change the UDPand TCP ports used to
communicate with the ACC Server
software.
In the Service Ports and RTP Ports area, change the Base Port that
is used to access the recorder. Click Apply to save your changes.
When the browser displays a pop-up message to ask if you want to
restart the ACC server, click OK.
Network
On the Network page, you can change how the recorder connects to the network. The recorder supports two
network connections: one for a corporate network and one for a camera network.
The corporate network is the network that typically provides users with access to the recorder. Users who
monitor video through the Avigilon Control Center Client software would connect to the recorder through this
network.
The camera network is a closed network that typically only contains cameras. This reduces the amount of
interference with video recording.
For more information about the network connections, see Supported Network Configurations on page 4.
On the Network page, you can perform any of the following:
To... Do this...
Change the recorder hostname.
At the top of the page, enter a new name in the Host Name
field then click Apply.
The default hostname is provided in this format:
<Recorder Model>-<Recorder Serial Number>.AVIGILON
e.g. VMA-PRO-4P2-KFO0004731.AVIGILON
Set how the recorder obtains an IP address for
each network.
NOTE: The Corporate Network Uplink Port and
the Camera network Uplink Port must be on
different subnets.
In the Uplinks area, select one of the following for the LAN:
Corporate and LAN: Camera network connections:
lObtain an IPaddress automatically: select this option to
connect to the network through an automatically
assigned IP address.
lUse the following IP address: select this option to
manually assign a static IP address.
Network 15

To... Do this...
Enter the appropriate values in the following fields: IP
Address:,Subnet Mask: and Default Gateway.
Click Apply to save your changes.
Set how the recorder obtains a named address
from a DNS server
In the DNS Lookup area, select one of the following options:
lObtain DNS server address automatically select this
option to allow the system to automatically select DNS
server and receive a named address.
lUse the following DNS server addresses: select this
option to assign specific DNS servers for addressing the
recorder.
Restore system default network settings. At the bottom-right corner of the page, click Restore Defaults.
Users
The Users page allows you to change the default administrator password.
NOTE: You cannot change the default administrator username on the web interface, only the password.
1. To change your password, confirm your identity by entering your current password in the Old Password:
field.
2. Enter the new password in the New Password: field.
3. Re-enter the new password in the Confirm New Password: field.
4. Click Apply to save the new password.
NOTE: If you forget your password, you must reset the recorder to the factory default settings to reset the
administrator password. This will also format the hard drives and delete the configuration data and recorded
video. For more information on performing a factory restore, see Restoring Factory Default Settings on page 23.
System
On the System page, you can change your time settings, upgrade firmware and reboot the device.
Setting the Date and Time
In the Device Time and NTP Settings area, you can customize how the recorder keeps time.
lIt is recommended that the recorder keeps time through a Network Time Protocol (NTP) server. To use
this option, select the Use NTP Server option.
lDHCP — select this option to automatically use an existing NTP server in the network.
lManual: — select this option then enter the address of the NTP server in the NTP Server: field.
NOTE: If you have multiple ACC systems running on the network, make sure they all synchronize with the
same NTP server.
lSelect the Set date and time from browser time option to sync the recorder time with your browser time
whenever you access the web interface.
lSelect the Change timezone check box then select the local time zone.
16 Users
