AXIOMTEK AX92324 User manual

AX92324
2-Port 10GbE PoE PCI Express
Card
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or rights of any
third party, or any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.


 Copyright 2020 Axiomtek Co., Ltd.
All Rights Reserved
October 2020, Version A1
Printed in Taiwan

iii
ESD Precautions
The boards have integrated circuits sensitive to static electricity. To avoid damaging chipsets
from electrostatic discharge, observe the following precautions:
 Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
 Before handling a board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. This will help to discharge any static electricity on a
human body.
 When handling boards and components, wear a grounding wrist strap available from
most electronic component stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows
®
is a trademark of Microsoft Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel
®
is a trademark of Intel Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
ESD Precautions...........................................................................................iii
Section 1 Introduction ............................................. 1
1.1 General Description............................................................................1
1.2 Features...............................................................................................1
1.3 Specifications......................................................................................2
1.4 Dimensions..........................................................................................3
Section 2 Connectors .............................................. 5
2.1 Connectors..........................................................................................5
2.1.1 12/24V Power Input (ATX1) ........................................................................ 5
2.1.2 4-pin Molex Male connector (ATX2)............................................................ 6
2.1.3 RJ-45 Connector (LAN1 & 2) ...................................................................... 6
2.1.4 Jumper1 (JP1)............................................................................................. 7
Chapter 3 Po Manager Software ............................ 9
3.1 Management software.........................................................................9
3.2 AMSIO PoE Manager.........................................................................10
3.3 Menu Bar............................................................................................11
3.3.1 File..............................................................................................................11
3.4 Menu List ...........................................................................................12
3.5 Features.............................................................................................13
3.5.1 Information ................................................................................................ 13
3.5.2 Control....................................................................................................... 15

AX92324 2-port 10GbE PoE PCI Express Card
Introduction 1
Section 1
Introduction
This section contains general information and detailed specifications of the AX92324 2-port
10Gigabit PCI Express LAN Card with IEEE802.3at compliant PoE capabilities, including the
following sections:
 General Description
 Features
 Specifications
 Dimensions
1.1 General Description
The AX92324 is a dual-port 10GbE PCI Express LAN card based on the Intel® Ethernet
Controller X550-AT2. To meet the demands of the next-generation 10GbE cameras with
high resolution and high-speed transmission over one single Ethernet cable, the AX92324
features the combination of 10GbE and IEEE802.3at compliant PoE capabilities. It also
supports PoE power on/off and power budget settings via management software or API.
The AX92324 is suitable for high bandwidth, high-speed data transmission and low latency
requirements for machine vision, intelligent surveillance and network applications.
1.2 Features
 Intel
®
Ethernet Controller X550-AT2, up to 10 Gbps data rate
 Supports 15.5KB Jumbo Frame and IEEE 1588
 Compliant with IEEE802.3at to deliver 25.5W per port
 PCI Express x4 compliant
 PoE power on/off via Power Manager software and API
 Operating temperature range from 0°C to 55°C

AX92324 2-port 10GbE PoE PCI Express Card
2 Introduction
1.3 Specifications
 LAN Chip
 Intel
®
X550-AT2 Controller
 10Gbps/*5Gbps/*2.5Gbps/1Gbps/100Mbps (*Linux only)
 Bus Type
 Gen.3 PCI Express x4 interface
 PoE Capability
 IEEE 802.3at compliant; each port delivers up 30W at 52VDC
 Port Connector
 8-pin RJ-45
 Power Requirements
 Power from PCIe slot: (Max. 20W POE power output)
2.1A @ +12V
1.2A @ +3.3V
 Power from the ATX power connector: (Max. 60W POE power output)
6A @ +12V or 3A @ +24V* (*24V power is for Axiomtek’s products)
1.2A @ +3.3V (from PCIe slot)
 30W@54VDC power output (per port)
 Environmental
 Operating temperature: 0°C ~ 550°C (+32 °F to +131°F) (with air flow)
 Operating humidity 10% ~ 95% non-condensing
 Storage temperature: -20°C ~ 80°C (-4 °F to +176°F)
 Dimensions
 W 168 mm x D 111 mm
 OS Support
 Windows
®
7/10 64bit, Linux
 Certifications
 CE compliance

AX92324 2-port 10GbE PoE PCI Express Card
Introduction 3
1.4 Dimensions
Component Side
Solder Side

AX92324 2-port 10GbE PoE PCI Express Card
4 Introduction
This page is intentionally left blank.

AX92324 2-port 10GbE PoE PCI Express Card
Connectors 5
Section 2
Connectors
2.1 Connectors
Connectors connect the board with other parts of the system. Loose or improper connection
might cause malfunctions. Make sure all connectors are properly and firmly connected.
The following table lists the function of each connector on the AX92324.
Connectors Label
12/24V Power Input (ATX1) 2.1.1
4-pin Molex Male connector (ATX2) 2.1.2
RJ-45 Connector (LAN1 & 2) 2.1.3
Jumper (JP1) 2.1.4
Note: ATX1, ATX2 and JP1 are available in the PoE version ofAX92324 only.
2.1.1 12/24V Power Input (ATX1)
The power connector is used for PoE function when total power of powered device is
over 20 watts.
Pin Signal
1 +12V / +24V*
2 +12V / +24V*
3 +12V / +24V*
4 Ground (GND)
5 Ground (GND)
6 Ground (GND)
Note:
* 24V power is for Axiomtek’s products only.
*12V power is for 6-pin ATX power supply.

AX92324 2-port 10GbE PoE PCI Express Card
6 Connectors
2.1.2 4-pin Molex Male connector (ATX2)
The power connector is used for PoE function when total power of powered device is
over 20 watts.
Pin Signal
1 +12V
2 GND
3 GND
4 NC
2.1.3 RJ-45 Connector (LAN1 & 2)
Pin Description
J1 MDI0+
J2 MDI0-
J3 MDI1+
J4 MDI2+
J5 MDI2-
J6 MDI1-
J7 MDI3+
J8 MDI3-
Left LED
Speed LED：
10G (Green)
1G (Orange)
100M (No light)
Right LED Active LED (Green)

AX92324 2-port 10GbE PoE PCI Express Card
Connectors 7
2.1.4 Jumper1 (JP1)
Default board ID setting is 1.
Note:
If using only one piece of AX92324 on your system, you can ignore this setting.
When using two or more pieces of AX92324 on your system, you must set a different
board ID for each piece.
Function Setting
Board ID=1 1-2 close
Board ID=2 3-4 close
Board ID=3 5-6 close
Board ID=4 7-8 close
Board ID=5 9-10 close
Board ID=6 11-12 close
Board ID=7 13-14 close
Board ID=8 15-16 close

AX92324 2-port 10GbE PoE PCI Express Card
8 Connectors
This page is intentionally left blank.

AX92324 2-port 10GbE PoE PCI Express Card
PoE Manager Software 9
Chapter 3
PoE Manager Software
3.1 Management software
AMSIO PoE Manager is a highly integrated software management system that provides an
easy-to-use application programming interface.
Software Structure
AMSIO PoE Manager is an intelligent software tool for managing PoE (Power over Ethernet)
devices, ranging from physical layer connectivity and communication layer protocols to
middleware API and high level software for management. AMSIO PoE Manager is ideal for
integration with specific embedded systems, and comes with powerful PoE managerial abilities
suited for various vertical applications.
Layer structure

AX92324 2-port 10GbE PoE PCI Express Card
10 PoE Manager Software
3.2 AMSIO PoE Manager
AMSIO PoE Manager is a software program that helps to monitor and manage PoE
(Power over Ethernet) operations. The major task of PoE manager is to routinely
monitor each PoE port’s power consumption and status. If any problem happens to a
port, it will display info imagery for the user.
PoE Manager interface

AX92324 2-port 10GbE PoE PCI Express Card
PoE Manager Software 11
3.3 Menu Bar
On the top of the main screen is the menu bar. Select the tab in this bar to go to the
submenus.
3.3.1 File
Polling rate
Set the polling rate to monitor PoE power consumption and port status. Polling rates
include the following
 5 sec
 10sec
 30 sec
 60 sec
Exit
Close the PoE manager program.

AX92324 2-port 10GbE PoE PCI Express Card
12 PoE Manager Software
3.4 Menu List
The menu list is located on the left frame of the screen and contains all monitoring and control
functions. It has two submenus: “Information” and “Control”.
PoE Manager menu list
Information
The information menu includes the "General" and "PowerChart" options. "General" is
responsible for showing each port's status, and "PowerChart" is responsible for showing the
power consumption chart.
Control
The control menu contains the ”Chip” option, which provides the functions including each
port’s control switch, max power budget display and user-defined power budget, as well as a
Save button for saving configurations.

AX92324 2-port 10GbE PoE PCI Express Card
PoE Manager Software 13
3.5 Features
3.5.1 Information
 General
General page
Board ID: The board ID displays the board number and the module’s name. The user
can click the drop-down list to display other module information.
Port1-2: The tab sort shows all available device ports.
Port Status: The port status option displays the word "Enable" with a lit port icon
to indicate an enabled port, whereas it displays the word “Disable” with a dim
port icon to indicate a disabled port. (The user can control port status using the
“Chip” function. Refer to “Chip” in section 3.5.2.)
Link Status: The link status can display connection status with a powered device (PD).
The green icon indicates a normal connection with PD. The red icon warns of a
connection problem with PD, and the user can search the port error code in the “Event
Log” txt file to understand what has caused the problem. If the icon turns gray, it shows
the system hasn’t connected to PD or has connected to an undefined device.
POE Class: The POE class describes PD‘s classification, which follows the 802.3 af/at
protocol to define.
Event Message: It displays detailed information on a port’s link status. If the link status
icon turns red to indicate a connection problem, the event message will report more
detailed information.

AX92324 2-port 10GbE PoE PCI Express Card
14 PoE Manager Software
 Power Chart
PowerChart page
Chart: The chart describes power consumption by each port and total amount of unused
power. It uses percentage to represent ratio of each port.
User Defined Power Budget: The power budget shows the upper limit of power
consumption defined by the user. The user can go to the “Chip” option to set power
budget, which cannot exceed the max power budget. Refer to “Chip” in section 2.5.2.
Total Consumption: The function displays total power consumption value of all ports by
adding up every port’s power in use.

AX92324 2-port 10GbE PoE PCI Express Card
PoE Manager Software 15
3.5.2 Control
 Chip
Chip page
Max Power Budget: This function shows the module’s max power value. The user
cannot set power budget higher than max power budget.
User Defined Power Budget: The user can define any power budget value, which
cannot exceed max power budget.
Port1 & 2 Switch: The user can turn on a port by selecting “Enable”, or turn off port by
selecting “Disable”. Each port’s status can be monitored in the “General” menu.
Save Button: Click the “Save” button to save all user set values into the module’s chip.
All user defined settings will be reserved when the system is shut down or restarted.
