Axxess ABTI-GM1 User manual

ABTI-GM1
ABTI-GM1
1-800-221-0932
©COPYRIGHT 2007-2008 METRA ELECTRONICS CORPORATION
www.axxessonline.com
GM CLASS II
INTERFACE
FOR HANDSFREE
BLUETOOTH CAR KITS
The ABTI-GM1 is designed to integrate a Handsfree Bluetooth Car Kit into General Motors vehi-
cles that have the Class II data system. The OEM radio will mute when a call comes in and the
audio will be heard through the front speakers. The ABTI-GM1 is Plug-N-Play for the Motorola
IHF1000 and Parrot car kits, and it can be used with other car kits with modifications.
*READ IMPORTANT WARNING ON PAGE 1 BEFORE ATTEMPTING ANY INSTALLATION
A
AP PP PL LI IC CA AT TI IO ON NS S: :
BUICK
Allure 2005-07
Century 2004-05
Lacrosse 2005-08
Regal 2004
Rendezvous 2002-07
CADILLAC
Escalade/EXT 2003-06
CHEVROLET
Avalanche 2003-06
Blazer 2003-05
Cavalier 2003-05
Colorado 2004-08
Equinox 2005-06
Express Van 2003-07
Impala 2002-05
Malibu (Classic) 2001-04
Monte Carlo 2002-05
S-10 2003-05
Silverado (Classic) 2003-07
SSR 2003-06
CHEVROLET
Suburban 2003-06
Tahoe 2003-06
Trailblazer 2002-08
Uplander 2005-08
Venture Van 2000-05
GMC
Canyon 2004-08
Envoy 2002-08
Savanna Van 2003-07
Sierra (Classic) 2003-07
Sonoma 2003-05
Yukon 2003-06
HUMMER
H2 2003-07
H3 2006-08
ISUZU
Ascender 2003-06
I-Series Pickups 2006-08
OLDSMOBILE
Alero 2002-04
Bravada 2002-05
Intrigue 2002
Silhouette 2001-04
PONTIAC
Aztec 2002-05
Grand Am 2002-05
Grand Prix 2004-07
Montana 2002-05
Sunfire 2002-05
Torrent 2006
SATURN
Relay 2005-07

ABTI-GM1
1
* READ IMPORTANT WARNING BEFORE ATTEMPTING ANY INSTALLATION
* IMPORTANT WARNING
THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH MUST BE
CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED IN SUCH A MANNER TO
ASSUME THAT THE INSTALLER IS CAPABLE OF COMPLETING THESE TYPE OF ELEC-
TRONICINSTALLATIONS. IF YOU ARE UNCLEAR AS TO WHAT YOU ARE INSTRUCTED
TO DO OR BELIEVE THAT YOU DO NOT UNDERSTAND THE INSTRUCTIONS SO AS TO
PROPERLY AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD CONSULT A
TECHNICIAN WHO DOES HAVE THIS KNOWLEDGE AND UNDERSTANDING.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY AND TO INSTALL THE
INTERFACE AS DESCRIBED COULD CAUSE HARM TO THE VEHICLE OR TO SAFE-
TY SYSTEMS ON THE VEHICLE. INTERFERENCE WITH CERTAIN SAFETY SYS-
TEMS COULD CAUSE HARM TO PERSONS AS WELL. IF YOU HAVE ANY QUES-
TIONS IN THIS REGARD PLEASE CALL THE HELP LINE OR THE METRA AT :
1-800-221-0932 FOR ASSISTANCE.
K NOWLEDGE IS P OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.

ABTI-GM1
2
INSTALLING THE ABTI-GM1 WITH THE MOTOROLA IHF1000
Note: 8-Way to 8-Way connector harness is used in this application.
NOTE: The ISO to 8 way connector harness will NOT be used in this application.
INSTALLATION PROCEDURE
1) Disconnect the vehicle battery.
2) Remove the radio from the dashboard, and disconnect any cables connected to the radio.
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug
INSTALLATION COMPONENTS
1) ABTI-GM1 interface
2) ABTI-GM1“T” harness
3) 8-Way connector to 8-Way connector harness
4) ISO to 8-way connector harness
TOOLS REQUIRED
1) Tools to remove the OEM radio
2) Wire ties

ABTI-GM1
3
3) Insert the 24 pin plug on the Class 2 cable into the rear of the radio.
4) Insert the 12 pin plug on the Class 2 cable into the rear of the radio.
ABTI-GM1
Class IIcable harness
8 pin
IHF-1000 keypad
plug
White
RE-PLUG EXISTING
FROM CAR
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
24 pin plug
12 pin plug
RE-PLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug
ABTI-GM1
Class IIcable harness
8 pin
IHF-1000 keypad
plug
White
RE-PLUG EXISTING
FROM CAR
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
24 pin plug
12 pin plug
RE-PLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug

ABTI-GM1
4
5) Connect the 24 pin cap on the Class 2 cable to the 24 pin plug connected to the vehicle (the
connector that was removed from the back of the radio).
6) Connect the 12 pin cap on the Class 2 cable to the 12 pin plug connected to the vehicle (the
connector that was removed from the back of the radio).
ABTI-GM1
Class IIcable harness
8 pin
IHF-1000 keypad
plug
White
RE-PLUG EXISTING
FROM CAR
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
24 pin plug
12 pin plug
RE-PLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug
ABTI-GM1
Class IIcable harness
8 pin
IHF-1000 keypad
plug
White
RE-PLUG EXISTING
FROM CAR
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
24 pin plug
12 pin plug
RE-PLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug
7) Connect the white 10-pin plug on the Class 2 cable to the ABTI-GM1 module.
ABTI-GM1
Class IIcable harness
8 pin
IHF-1000 keypad
plug
White
RE-PLUG EXISTING
FROM CAR
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
24 pin plug
12 pin plug
RE-PLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug

ABTI-GM1
5
8) Connect the white 8-pin plug on the IHF-1000 cable to the power cable, and connect the
other end of the power cable to the ABTI-GM1 module.
9) Install the IHF-1000 keypad on the dashboard of the vehicle, and route the wire to the IHF-
1000 harness. Attach the keypad connector to the harness.
ABTI-GM1
Class IIcable harness
8 pin
IHF-1000 keypad
plug
White
RE-PLUG EXISTING
FROM CAR
UNPLUG EXISTING
UNPLUG EXISTING
FROM CAR
24 pin plug
12 pin plug
RE-PLUG EXISTING
FROM CAR
FROM CAR
24 pin plug
12 pin plug
OPERA
TION
Refer to the Motorola IHF1000 manual for operation. Adjust the volume of the handsfree kit by
turning the volume knob of the radio. Audio from any source will be muted when a call comes
in or a call is made.
INSTALLING THE ABTI-GM1 WITH PARROT
HANDSFREE CAR KITS
*Note: The ISO to 8 way connector harness will be used in this application.
*Note: The 8 way to 8 way connector harness will NOT be used in this application.
Compatible Parrot kits: CK3000, CK3000 Evolution, CK3100, CK3300, CK3500, 3200LS,
3400LS-GPS, MK6000, MK6100
(Installation will be the same as the Motorola Handsfree kit steps 1-7)
8) Plug the 8 way side of the ISO to 8 way harness into the 8 way connector on the ABTI-GM1.
10) Install the IHF-1000 microphone in an appropriate location (see IHF-1000 instructions), route
the wire to the IHF-1000 harness, and attach the microphone connector to the harness.
11) Secure all components, and reinstall the radio.
12) Reconnect the vehicle battery.

6
ABTI-GM1
9) Plug the ISO side of the ISO to 8 way harness into the mating Parrot connectors.
10) Take the Mute wire of the Parrot kit and plug it into the “Mute 1” wire in the Parrot ISO
harness.
11) Finish installing the rest of the Parrot handsfree kit and reinstall the OEM radio.
12) Reconnect the vehicles battery.
OPERATION
OTHER HANDSFREE KITS
Refer to the Parrot manual for operation. Adjust the volume of the handsfree kit by turning the
volume knob of the radio. Audio from any source will be muted when a call comes in or a call
is made.
Other handsfree kits can be used with the ABTI-GM1. Follow the steps below to wire the
handsfree kit:
1) Using the ISO to 8 way connector harness cut the ISO ends off.
2) The Yellow wire will go to the Battery wire of the handsfree kit.
3) The Red wire will go to the 12 volt accessory wire of the handsfree kit.
4) The Black wire will go to the ground of the handsfree kit.
5) The Purple wire will go to the Mute wire of the handsfree kit.
6) The White wire will go to the (+) speaker output of the handsfree kit.
7) The White/Black wire will go to the (-) speaker output of the handsfree kit.
Handsfree kits may have more then one speaker output on their harnesses however the
ABTI-GM1 needs only one speaker output to use.

ABTI-GM1 INSTRUCTIONS
1-800-221-0932
REV. 09/02/08 © COPYRIGHT 2007-2008 METRA ELECTRONICS CORPORATION INSTABTI-GM1
www.axxessonline.com
