Axxess AX-ADBOX1 series User manual

Installation instructions for AX-ADBOX1
REV. 9/14/2015 INSTAX-ADBOX1
CAUTION! Metra recommends disconnecting the negative bat -
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con-
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
axxessinterfaces.com •metraonline.com © COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
Axxess Integrate
Note: This is a general list for the AX-ADBOX1 lineup. Please see the individual
harnesses for exact features available.
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Used in amplified, non-amplified systems
• Retains chimes (GM)
• Turn signal click (GM)
• Provides NAV outputs (parking brake, reverse, mute, and V.S.S.)
• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)
• Retains OnStar/OE Bluetooth
• Adjustable gain control for overall volume (on amplified systems)
• Adjustable gain control for chimes and OnStar (GM)
• Retains SYNC in Ford (if equipped)
• Adjustable gain control for SYNC (Ford)
• Retains Blind spot detection system in Chrysler/Dodge/Jeep (if equipped)
• High level speaker input
• Micro “B” USB updatable
• Retains balance and fade
• Retains digital fade (excluding Ford and VW vehicles)
-,(;<9,:
• Cutting tool • Crimping tool • Tape • Connectors
(example: butt-connectors, bell caps, etc.)
;663:9,8<09,+
AX-ADBOX1
AX-ADBOX Series main interface control box
• AX-ADBOX1 interface
• 16-pin harness with stripped leads
05;,9-(*,*64765,5;:
(7730*(;065:
See application list inside

AX-ADBOX1
2
Applications
Interface must be used in conjunction of one of the
following harnesses:
Note: Applications are notated with characters to indicate which
harnesses needs to be used.
(a) AX-ADCH01
(b) AX-ADCH02
(c) AX-ADFD01
(d) AX-ADFD02
(e) AX-ADGM01
(f) AX-ADGM02
(g) AX-ADGM03
(h) AX-ADGM04
(i) AX-ADTY01
(with amplifier only)
(x) AX-ADVW01
*Indicates vehicle has a digital amplifier option.
** Indicates SONY/THX sound systems are digitally amplified.
*** These vehicles have a digital amp option. Please look at
the “Service Parts Identification” sticker in the glove box
for the RPO code listed in parenthesis.
† Indicates vehicle is standard for a digital amplifier.
6In 2012-up, if the vehicle is equipped with OE navigation,
you must use the GMOS-LAN-08 if non-amped;
GMOS-LAN-07 if amped.
BUICK
Allure (g) 2005-2009
Century (g) 2004-2005
Enclave (e) 2008-up
LaCrosse (g) 2005-2009
Lucerne (e) 2006-2011
Rainier***(UQA) (g) 2004-2007
Rendezvous (g) 2002-2007
Terraza (g) 2005-2008
CADILLAC
DTS †(e) 2006-2011
Escalade/
ESV/EXT †(g) 2003-2006
Escalade †(e) 2007-2011
SRX †(e) 2007-2009
CHEVROLET
Avalanche***
(Y91) (g) 2003-2006
Avalanche***
(STZ or Y91) 6(e) 2007-2013
Cavalier (g) 2000-2005
Cobalt (f) 2007-2010
Corvette (g) 2005-2013
Equinox (e) 2007-2009
Express (g) 2003-2007
Express
(without NAV) (e) 2008-up
HHR (f) 2006-2011
Impala (g) 2000-2005
Impala (e) 2006-2013
Kodiak (g) 2003-2009
Malibu (g) 2001-2003
Malibu (classic) (g) 2004-2005
Malibu (f) 2008-2012
Malibu (h) 2013-up
Monte Carlo (g) 2000-2005
Monte Carlo (e) 2006-2007
Silverado***
(Y91) (g) 2003-2006
Silverado (classic)***
(Y91) (g) 2007
Silverado (new body)***
(Y91) 6(e) 2007-2013
Silverado 2500/3500***
(Y91) 6(e) 2014
SSR***(UQA) (g) 2003-2006
Suburban***(Y91) (g) 2003-2006
Suburban***
(STZ or Y91) 6(e) 2007-2013
Tahoe***(Y91) (g) 2003-2006
Tahoe***
(STZ or Y91) 6(e) 2007-2013
Trailblazer***(UQA) (g)
2002-2006
Trailblazer (g) 2007-2009
Traverse (e) 2009-up
Uplander (g) 2005-2008
CHRYSLER
200*(b) 2011-2014
300*(a) 2005-2007
300*(b) 2008-2010
Aspen*(a) 2007
Aspen*(b) 2008-2009
Sebring*(b) 2007-2010
Town & Country*(b) 2008-up
DODGE
Avenger*(b) 2008-2014
Caliber*(a) 2007-2008
Caliber*(b) 2009-2010
Challenger*(b) 2008-up
Charger*(a) 2005-2007
Charger*(b) 2008-2010
Dakota*(a) 2005-2007
Dakota*(b) 2008-2011
Durango*(a) 2004-2007
Durango*(b) 2008-2013
Grand Caravan*(b) 2008-up
Journey*(b) 2009-2010
Magnum*(a) 2005-2007
Magnum*(b) 2008-2009
Nitro*(b) 2007-2011
Ram 1500*(a) 2006-2008
Ram 1500*(b) 2009-2011
Ram 2500/3500*(a) 2006-2009
Ram 2500/3500*(b) 2010-2011
Ram Chassis
Cab*(a) 2006-2010
Ram Chassis
Cab*(b) 2011
FORD
Edge**(c) 2007-2010
Edge (d) 2011-2014
Escape**(c) 2008-2012
(Continued on the next page)

AX-ADBOX1
3
Applications
Expedition**(c) 2007-2014
Explorer(c) 2008-2010
Explorer (d) 2011-up
Explorer Sport Trac (c)
2008-2010
F-150**(c) (with monochromatic
screen) 2009-2014
F-250/350/
450/550**(c) 2011-2012
F-250/350/450/550 (c) (with
monochromatic screen) 2013-up
Fiesta (d) (without
MyFord Touch) 2011-up
Five Hundred (c) 2005-2007
Focus (c) 2008-2011
Focus (d) (without
MyFord Touch) 2012-2014
Fusion**(c) 2008-2012
Taurus (c) 2008-2009
Taurus**(c) 2010-2012
Taurus X (c) 2008-2009
GMC
Acadia (e) 2007 -up
Envoy***(UQA) (g) 2002-2006
Envoy (g) 2007-2009
Savana (g) 2003-2007
Savanna (e) 2008-up
Sierra***(Y91) (g) 2003-2006
Sierra (classic)***(Y91) (g) 2007
Sierra***
(STZ or Y91) 6(e) 2007-2013
Sierra 2500/3500***
(STZ or Y91) 6(e) 2014
Yukon***(Y91) (g) 2003-2006
Yukon***
(STZ or Y91) 6(e) 2007-2014
HUMMER
H2 †(g) 2003-2007
H2 †(e) 2008-2009
H3/H3t (g) 2006-2010
ISUZU
Ascender (g) 2003-2008
H-Series (g) 2005-2009
I Series (g) 2006-2008
JEEP
Commander*(a) 2006-2007
Commander*(b) 2008-2010
Compass*(a) 2007-2008
Compass*(b) 2009-up
Grand Cherokee*(a) 2005-2007
Grand Cherokee*(b) 2008-2013
Liberty*(b) 2008-2012
Patriot*(a) 2007-2008
Patriot*(b) 2009-up
Wrangler*(b) 2007-up
LEXUS
ES330 †(i)
(with multi disc) 2002-2006
GS300 †(i) 2001-2005
GS430 †(i) 2001-2005
IS300 †(i) 2002-2005
LS430 †(i) 2001-2006
RX330 †(i) 2004-2006
RX350 †(i) 2007-2009
RX400h †(i) 2006-2008
SC430 †(i) 2002-2010
LINCOLN
MKX**(c) 2008-2010
MKZ**(c) 2008-2009
Navigator**(c) 2007
Navigator † 2008-2014
MAZDA
CX-7 (h) 2007-2012
CX-9 (h) 2007-up
MERCURY
Mariner**(c) 2008-2011
Milan**(c) 2008-2011
Mountaineer(c) 2008-2010
Sable(c) 2008-2009
MITSUBISHI
Raider* (a) 2006-2007
Raider* (b) 2008-2009
OLDSMOBILE
Alero (g) 2001-2004
Bravada***(UQA) (g) 2002-2004
Intrigue (g) 2002
Silhouette (g) 2000-2004
PONTIAC
Aztec (g) 2001-2005
G5 (f) 2007-2009
G6 (f) 2009-2010
Grand Am (g) 2001-2005
Grand Prix (g) 2004-2008
Montana SV6 (g) 2005-2006
Torrent (e) 2007-2009
Solstice (f) 2006-2009
Sunfire (g) 2000-2005
Torrent (g) 2007-2009
RAM
1500/2500/3500* (b) 2012
Chassis Cab 3500/
4500/5500* (b) 2012
C/V Tradesman* (b) 2012-up
SAAB
9-7x (g) 2005-2009
SATURN
Aura (f) 2006-2009
Outlook (e) 2007-2010
Relay (g) 2005-2009
Sky (f) 2007-2009
Vue (e) 2008-2010
SUZUKI
XL-7 (e) 2007-2009
TOYOTA
4-Runner (i) 2003-2013
Avalon (i) 2005-2012
Avalon (w/o NAV) (i) 2013-2015
Camry (i) 2007-2011
Camry (w/o NAV) (i) 2012-2013
Corolla (i) 2005-2011
FJ Cruiser (i) 2011-2014
Highlander (i) 2008-2013
Matrix (i) 2005-2012
Prius (i) 2004-2011
Prius (without NAV)
(3rd Gen., PHV) (i) 2012-up
Rav-4 (i) 2004-2014
Sequoia (i) 2005-2012
Sequoia (w/o NAV) (i) 2013
Sienna (i) 2004-2014
Solara (i) 2004-2008
Tacoma (i) 2005-2013
Tundra (i) 2004-2013
Venza (i) 2009-2012
Venza (w/o NAV) (i) 2013-2014
Yaris (i) 2007-2011
VOLKSWAGEN
Beetle* (x) 2012-up
CC (x) 2009-up
EOS (x) 2007-up
Golf (DDIN only) (x) 2002
Golf, Golf R (x) 2003-2009
Golf, Golf R* (x) 2010-2014
GTI (x) 2002-2014
Jetta (DDIN only) (x) 2002
Jetta, Jetta GLI* (x) 2003-up
Jetta SportWagen (x) 2010-2014
Passat (x) 2002-2011
Passat* (x) 2012-up
R32 (x) 2007-2008
Rabbit (x) 2007-2009
Routan (b) 2009-2013
Tiguan* (x) 2009-up

Installation instructions for AX-ADBOX1
REV. 9/14/2015 INSTAX-ADBOX1
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
IMPORTANT
If you are having difficulties with the
installation of this product, please call our
Tech Support line at 1-800-253-TECH.
Before doing so, look over the instructions a
second time, and make sure the installation
was performed exactly as the instructions
are stated. Please have the vehicle apart
and ready to perform troubleshooting steps
before calling.
axxessinterfaces.com •metraonline.com © COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
Axxess Integrate
Connections to be made
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the (2) Red wires to the ignition/accessory wire.
• Connect the Orange/White wire to the illumination wire. If the aftermarket radio does not have
an illumination wire, tape off the Orange/White wire.
• Connect the Blue/White wire to the amp turn on wire (this wire must be connected to hear sound
from the factory amplifier).
• Connect the Brown wire to the mute wire. If the aftermarket radio does not have a Mute wire,
tape up the Brown wire.
For aftermarket radios with navigation built-in
• Connect the Light Green wire to the parking brake wire
• Connect the Blue/Pink wire to the V.S.S. or speed sense wire
• Connect the Green/Purple wire to the reverse wire.
Note: For the remaining wires, please refer to the instructions supplied with the required
wiring harness.
