AX-FD-SSO
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 7/26/19 INSTAX-FD-SSO
Product Info
INTERFACE FEATURES
INTRODUCTION
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Zip ties • Cutters (for zip ties)
• Micro-B USB cable
(Axxess part number USB-MINI-CAB)
TABLE OF CONTENTS
Programming .........................................................2
Connections ............................................................3
Operation ................................................................4
Ford Stop/Start Override Interface
2015-up
APPLICATIONS
• Allows the override of the STOP/START engine feature
• The factory STOP/START button can resume the STOP/START feature
• Can be used with either a factory or aftermarket radio
•
Vehicle type configured through the Axxess Updater software program
• Simple plug n’ play installation, no wiring required
The AX-FD-SSO is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been
cycled. The AX-FD-SSO will work with either an aftermarket radio, or a factory radio. A simple plug n’ play installation is all that is required to install
the device in the vehicle, and programming through a Windows 10 computer via the Axxess Updater software program.
Ford
Edge 2015-up
Escape 2017-up
F-150 2015-up
Focus 2016-up
Fusion 2015-up
• AX-FD-SSO interface
• AX-FD-SSO harness (qty. 2)

2
PROGRAMMING
(Figure A) (Figure B) (Figure C)
1.
2.
3.
4.
Download and install the Axxess Updater software program from:
axxessinterfaces.com/resources/updater-software
On the next screen that opens, select the year, make, and model of the
vehicle, then press Program Interface. (Figure B)
Connect the micro-B USB cable (sold separately) to the computer and
AX-FD-SSO interface. Open the Axxess Updater software program and
wait until the word Ready is shown in the bottom left of the screen.
Select Stop / Start. (Figure A)
When the Configuration Successful box pops up, the programming
process is complete. (Figure C)
Continue to Installation

3
REV. 7/26/2019 INSTAX-FD-SSO
I N S TAL L ATI O N
These vehicles will connect to the wiring harness located at the climate control location .
Ford
F-150 2015-up
• Disassembly instructions: metraonline.com/part/99-5834CH
Fusion 2015-up
• Disassembly instructions: metraonline.com/part/99-5841B
Edge 2015-up
• Disassembly instructions: metraonline.com/part/99-5851CH
From the wiring harness in the vehicle behind the radio:
1. Unplug the connector behind the climate control.
2.
Plug the AX-FD-SSO harness in between the climate control and climate
control harness.
3. Plug the AX-FD-SSO harness into the AX-FD-SSO interface.
These vehicles will connect at the OBD2 connector, inside the driver’s side dashboard .
Ford
Focus 2016-up
Escape 2017-up
From the OBD connector in the dash
1. Unclip the factory OBD connector from the dash.
2. Plug the AX-FD-SSO harness to the OBD connector.
3. Clip in the AX-FD-SSO harness to the dash.
4. Plug the AX-FD-SSO harness into the AX-FD-SSO interface.
5. Zip tie the harness securely under the dash to avoid it from coming down.
To OBD
Harness
To
Vehicle
To Climate
Control
To Climate
Control Harness

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 7/26/19 INSTAX-FD-SSO
INSTALLATION INSTRUCTIONS
AX-FD-SSO
Having difficulties? We’re here to help.
Contact our Tech Support line at:
1-800-253-TECH
Or via email at:
[e-mail]
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
OPERATION
Re-engaging the STOP/START feature
A
1. Press the factory STOP/START button to re-engage the STOP/START feature.
