Ayra ALO 030 MKII User manual

ALO 030 MKII
30 Watt DMX LED scanner
User manual
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

Safety instructions
This unit must be operated by, or under the supervision of an adult. This device is not suitable for children.
Every person involved with the installation, operation and maintenance of this device has to:
- Be qualified
- Follow the instructions of this manual
- Ma e sure there is no damage caused by transport. If the device seems damaged from the outside, do not
use it and contact your dealer for more information and consultation.
- To ma e sure the device maintains in perfect condition and for safe operation, it is necessary for the user to
follow the instructions and warning notes of this user manual.
- Damage caused by improper use or modifications to the device are not covered by warranty.
- This device does not have any user-serviceable parts inside. Servicing of this device needs to be done by
qualified technicians.
Important notes regar ing safety an health:
- Never let the power cord come in contact with other cables. Handle the power cord and all connectors with
the mains with caution.
- Never remove any warning or informative labels from the unit
- The ground contact always needs to be connected. Do not cover or remove the ground contact.
- Never leave cables lying around
- Do not open the device and do not modify any hard- or software of this unit.
- Do not insert this object into air vents.
- Do not connect this device to a dimmerpac .
- Do not switch the system on and off frequently as this will reduce the lifespan of the device.
- Do not drive the inputs of the fixture with a signal larger than required to wor at full performance.
- Only use this device indoor, avoid contact with water, moist or other liquids. Do not place items filled with
liquids on top of the unit.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV
WARNING!
Always keep this evice away from moisture an rain! Hazar ous electrical shocks may occur!
WARNING!
Only connect this evice to a matching power outlet. This evice is inten e to work on a
specifie AC currency. Connecting this evice to power outlets with other voltages may result in
permanent amage an possible hazar ous situations, such as fire or electrical shocks!
WARNING!
Be careful with every operation of this evice. Touching live wires insi e an outsi e the unit
may cause hazar ous electrical shocks!

- Avoid nearby flames or heat sources, do not place this device near flammable liquids, gas or flammable
items.
- Always disconnect the device when it is not in use for a longer period or time, when servicing is needed or
when the device needs cleaning.
- Only handle the power cord by its connectors. Never pull the cable to remove a connector from its soc et,
as this could lead to damage and electrical shoc s.
- Always operate this device with a stable AC current.
- Always operate this device with the AC ground wire connected to the electrical system's ground.
- Never use other types of cables than specified in the manual, do not use defective or bad functioning
cables. Contact your dealer when the included or required cables do not wor properly with this device.
- When the device has been exposed to large temperature differences (for example, transport from outdoor
to indoor), do not connect the device immediately. Do not activate the unit until it has reached room
temperature, as moist might build up inside the unit, which may cause shortcuts and/or electrical shoc s.
Gui elines an types of use:
- This device is intended to be used by professionals on stage, in theaters, clubs and other equal venues.
- This device is not suitable for children and always needs to be operated by an adult.
- Only use the device when the environment is suitable and will not cause any damage. Do not use the
product in moist or dusty environments, or where long-term damage may occur such as:
- indoor swimming pools where chlorine is used.
- Beaches, where sand and salt are present.
- Outdoor, without roof protection
- Indoor areas where intense heat sources are present or where the temperature exceeds levels
which are comfortable for humans.
- Only use the included power adapter and only connect the device to a suitable power outlet with the correct
output voltage. Connecting the device to a power outlet with the wrong type of voltage or using the product
with a wrong type of power supply may cause permanent damage to the device.
- Avoid shoc s and collision during use and transport. Do not transport the device while in use. Avoid brute
force during the installation and operation of this device.
- Familiarize yourself with the functions of the device before use. Do not allow operation of the device by
uns illed or unqualified people.
- Use of the device in other ways than described in this user manual may cause damage and injury. Ayra can
not be held responsible for any damage or injury caused by improper use.
Storage an transport:
- This device is intended for mobile use. When transported, use the original pac aging of the product, or a
fitting flightcase, preferably filled with foam.
- This device is not intended for permanent use. Operation brea s will ensure that the lifespan of the device
remains unchanged.
- If the device is not used for a longer period of time, disconnect it from its power source and store it in its
original pac aging, or in a fitting flightcase.
- Store the device indoor, dry and do not expose the device to extreme temperature differences.
Housing:
- Inspect the housing of the device frequently. Severe dents, crac s and missing screws should be avoided
at all costs. Do not use the device when the housing is not in optimal condition. Contact your dealer or a
s illed technician when in doubt about the state of the device
- Chec the fixture and screws for corrosion. Corrosion should not be present on the fixture. Contact your
dealer or a s illed technician when corrosion is found on the fixture
- Every power or signal chassis/connector should be mounted tightly. Do not use the device when connectors
are loose.
- Do not use the power cord when the cores are visible. Contact your dealer for a replacement if needed.
- Avoid the buildup of dust and dirt. Clean the exterior of the fixture every month with a dry or damp cloth.
When using the device intensively, the cleaning frequency needs to be increased.
Fuses:
- The main fuse of this device is to be found on the rear of the device. In most cases, directly next to the
power inlet.
- Only replace a fuse for a new one with the same type and rating! Do not use a fuse with a higher or lower
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

rating.
- Do not bridge the fuse with electrical wires, aluminum foil, as the fuse is used for protection against
electrical shoc s and short circuit.
- Always mount the fuse cover bac to the fuse compartment.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

Box contents
Box contents
1x ALO 030 fixture
1x power cable IEC C13 to Schu o
1x power cable IEC C13 to UK connector
Unit an accessory inspection
- Always use the supplied power cable to connect the unit to a power supply. If the cable appears bro en or
has visible damage, do not use it.
- If the unit is not going to be used for a longer period of time, disconnect it from the power supply and store it
in a dust-free environment.
- Always chec the unit for possible damage before use. If you suspect that something is wrong with the unit,
do not connect it to a power source! When you suspect that your unit is bro en or damaged, contact your
local dealer or a certified technician to inspect the unit.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

Device overview
1. Moving mirror
2. Beam output with manual focus
3. Stan ing/hanging a justable bracket
4. Ventilation slots
5. IEC Power inlet with integrate fuse hol er
6. IEC Power outlet (use to link several fixtures)
7. Control panel isplay with MENU, UP an DOWN buttons
8. Soun sensitivity potentiometer
9. Safety eye, for optional safety cable
10. Built-in microphone for soun active mo e
11. DMX input (3P XLR)
12. DMX output (3P XLR)
This unit is equipped with an adjustable focus, which ma es it possible to sharpen the beam when used at
small or large distance. The focus is positioned just underneath the mirror, around the lens. Turn the focus
slightly left or right and see if the sharpness of the beam increases or decreases.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV
1
2
34
6
7
8
5
4
11
10
9
12

Setting up the unit
To activate the unit, connect the included power supply with the unit and a suitable 230V, 50 Hz power outlet.
The unit will activate directly after it is plugged in to a wall outlet or other power source.
Give the scanner time to calibrate the stepping motors, which are used to determine the position of the
mirror. You may hear and see some sha ing, which is normal. The stepping motors use an end point to
determine the beginning and end of their movement.
The status of the scanner is shown on the display. Certain values determine the current status and will
change when you push buttons on the control panel. The buttons each have their own function, for easy
navigation in the control panel.
Press the ‘MENU’ button to switch modes, so you can easily select the built-in master/slave, music controlled
or DMX mode.
Display co es:
DMX-Mo e: A001:
This value represents the DMX channel where the scanner is currently set to. 001 stands for channel 1, but
can be changed with the UP and DOWN buttons to a value from 001 to 255.
When receiving DMX data, a small red dot on the display will blin continuously, regardless of what function
is being used.
Music controlle mo e:
When no DMX-signal is detected in DMX-mode, or when you select the master-mode, the unit will turn itself
into music controlled mode. Use the microphone sensitivity potentiometer to adjust the sensitivity of the
internal microphone for optimal light to sound functionality. When no music is detected, the scanner will play
a slow automatic program until a beat or loud sound is detected.
Master/Slave mo e: S-1- / D 1:
The D-value stands for the master-unit, which will use the internal microphone to perform music-controlled.
This fixture will send out a signal for slave fixtures, which you may connect using standard XLR male to XLR
female cables (not included).
The slave units show S-1- on the display, but a value of 0-4 can be chosen, using the UP and DOWN
buttons. These values represent certain setting, for example pan/tilt invert, so your fixtures wor
synchronized while the mirror movements are inverted.
Pan an tilt mo e: P 0 / T 0
The pan and tilt values of every fixture can be reversed. This ma es synchronized, but movement-mirrored
lightshows possible. The pan and tilt of every fixture can be mirrored individually.
P 0 represents the Pan mode. The default is set to 0, which means a normal wor ing mode. By using the UP
and DOWN buttons you are able to select 0 or 1, where 1 is the inverted mode.
T 0 represents the Tilt mode. The same settings apply here as described above.
LED isplay mo e: d 0
The LED display of the unit can be turned off during use, which ma es your light-show more attractive,
especially if the display is visible for your audience. When using the menu-buttons the display will be lit, but
after several seconds inactivity the display will be turned off. When pressing one of the menu buttons the
display will activate itself again. The 0 value means display OFF, the 1 value means display ON. The DMX
indicating dot will not turn off.
DMX control mo e:
This fixture can be controlled using a DMX-controller and standard XLR male to XLR female cable. When
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

doing so, ma e sure your DMX-controller is capable of controlling your fixture. When in doubt, contact your
local dealer for advice.
Set the correct address on the digital display, you are able to choose a value between 001 and 255. When a
DMX-signal is received, a blin ing red dot on the display is active.
This unit has the following DMX-channels and DMX-values:
Channel 1: Horizontal movement (pan)
Channel 2: Vertical movement (tilt)
Channel 3: Colours:
Start
value
En
value
Function
0 14 White
15 29 Orange
30 33 Blue
45 59 Green
60 74 Yellow
75 89 Pin
90 104 Light blue
105 119 Light green
120 127 Light yellow
128 255 Rainbow effect slow-fast
Channel 4: Gobos:
Start
value
En
value
Function
0 7 Open
8 14 Gobo 1
15 21 Gobo 2
22 28 Gobo 3
29 35 Gobo 4
36 42 Gobo 5
43 49 Gobo 6
50 56 Gobo 7
57 63 Gobo 8
64 70 Gobo Sha e Open
71 77 Gobo Sha e Gobo 1
78 84 Gobo Sha e Gobo 2
85 91 Gobo Sha e Gobo 3
92 98 Gobo Sha e Gobo 4
99 105 Gobo Sha e Gobo 5
106 112 Gobo Sha e Gobo 6
113 119 Gobo Sha e Gobo 7
120 127 Gobo Sha e Gobo 8
128 255 Gobo Wheel rotation effect slow-fast
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

Channel 5: Shutter/Strobe:
Start
value
En
value
Function
0 7 Blac out
8 15 Shutter open
16 131 Strobe slow-fast (variable)
132 139 Shutter open
140 180 Shutter slow open -> fast close
181 189 Shutter open
190 231 Shutter fast open -> slow close
232 239 Shutter open (235 = reset function when the value is selected
for 3-5 seconds)
240 247 Random strobe
248 255 Shutter open
Channel 6: Dimmer: 0-255 (variable)
Channel 7: Movement macros:
Start
value
En
value
Function
0 7 No function
8 25 Movement macro 1
26 43 Movement macro 2
44 61 Movement macro 3
62 79 Movement macro 4
80 97 Movement macro 5
98 115 Movement macro 6
116 133 Movement macro 7
134 151 Movement macro 8
152 169 Movement macro 9
170 187 Movement macro 10
188 205 Movement macro 11
206 223 Movement macro 12
224 241 Movement macro 13
242 255 Movement macro 14
Channel 8: Macro movement speed, slow – fast (variable).
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

DMX lighting troubleshooting
If you have any problems with DMX lighting, consult this troubleshooting section to solve any difficulties with
your product. If this troubleshooting section does not solve your problem, contact your dealer for more
information and help.
This troubleshooting section contains the most frequent problems and is not a complete collection of possible
faults, defects and solutions. The troubleshooting section applies for DMX controllers, DMX cabling and DMX
lighting fixtures. It is possible that not all described problems, causes and solutions apply to your situation as
product details may vary from product to product.
Problem Possible Cause Solution
The fixture does not activate itself Blown fuse Chec the fuse compartiment for
blown fuses and replace it if
necessary.
No power cable plugged in Plug in the power supply to a
matching power outlet
Power switch is not in the ON
position
Turn on the device by switching
the ON/OFF switch to the ON
position, if available
The fixture does not respond to
DMX signals
Wrong DMX address Set the DMX address to the right
value
DMX controller blac out function
activated
Deactivate the blac out function of
your DMX controller
Faulty positioning of the DMX
polarity switch on the controller
flip the polarity switch on your
DMX controller
No response or DMX activity
signal LEDs active
Chec your DMX cables for
possible connection brea s and
replace them if necessary.
The fixture does not respond to
sound
Wrong wor ing mode selected. Chec if the sound activated mode
of the fixture is activated.
Microphone sensitivity level is set
too low
Increase the microphone
sensitivity of the built-in
microphone
Spea er placed too far away or
lac of bass
Place your lighting effect closer to
your spea ers (or vice versa)
and/or increase low frequency
volumes. The microphone will not
be triggered with high pitched
sounds.
The beam output is very low Dirty/dusty optics Clean the lens and/or other optics
with a dry or damp cloth
Dimmer is not set to full output Set all dimmer levels to 100% on
your DMX console
Sometimes the DMX signal is lost
and/or some fixtures are
flic ering / behaving odd
sometimes
Faulty/bro en DMX cables Chec your DMX cables for
possible connection brea s and
replace them if necessary.
Power cable interference on your Avoid installing the DMX and
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

DMX signal (high) power cables parallel to
each other.
No DMX terminator Apply a DMX terminator at the end
of your DMX-chain
Signal loss or distortion in DMX
values
Apply a DMX booster in your DMX
chain after 32 fixtures or less. After
a maximum of 32 fixtures the DMX
signal needs to be refreshed.
Moving parts are not functioning
well, values do not match and/or
rattling sounds are noticed
Faulty stepping motor positioning Possible value loss of stepping
motors. Activate the reset function,
or unplug the power supply and
plug it bac in to activate the reset
program. This will reset all values
to the original 0-point.
The fixture does not respond fast
enough to the set speed on my
DMX controller
Moving parts can not eep up with
the set speed
Decrease the chase speed of your
DMX controller, as the stepping
motors of your fixture need some
time to move from one point to
another.
The fixture does not respond to all
DMX-channels
Wrong DMX channel mode Chec the DMX channel mode of
the fixture. If the wrong value is
set, change the channel mode to a
different setting and try again.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV

Technical specifications
- Compact scanner with LED light source
- LED module: 1x 30W LED chip
- 8 DMX-channels
- 3-pin XLR in- and output
- Music controlled mode with internal microphone
- Microphone sensitivity adjustable
- Maximum flash rate: 18 Hz
- Maximum ambient temperature: 45 degrees Celsius
- Maximum distance from flammable surfaces: 0.5m
- Power consumption: 50W max.
- Fuse: 2A 250V 20mm glass fast blow
- Power supply: 230V AC, 50 Hz
- Dimensions: 370 x 200 x 150 mm (without brac et)
- Weight: 4 g
Connectors:
- DMX: 3p XLR male and female
- Power: IEC C14 power inlet/ C13 outlet connector
Inclu e accessories:
- Power cable IEC C13 to Schu o
- Power cable IEC C13 to UK plug
Connectors an wiring schematics:
DMX-connections: Electrical wiring:
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 2.0 Creation date + author initials: 21-11-2013 RV Revision date + author initials: 17-11-2014 RV
