YES – invert tilt
TEST Test mode This mode tests all the functions displayed to
make sure they are orking properly.
HOUR Time registration 0000 – 9999 usage in hours
VER Firm are version number Display of firm are version number (can not be
updated by user)
RSET Reset function Restart the device (as if the po er has been
turned off and back on)
You'll find an explanation of the various functions belo :
ADDR: With this function, you can determine the DMX start address of the device. Set it channel 001, and
the device ill respond from DMX channel 1. Set it to channel 003, then the device ill respond from DMX
channel 3, etc.
CHND: This device is equipped ith various DMX channel modes. With this function, you can choose a
concise channel mode if your DMX circle is full and you do not require complete control over the functions. It
is also possible to use the most comprehensive channel mode, hich makes more channels available, each
ith its o n separate function.
RCND: The Remote Control mode is a practical feature hich helps addressing multiple fixtures, combined
ith a special controller hich supports this mode.
SLND: The Master-Slave mode is designed to sync multiple devices. A copy of the internal program is sent
to the daisy-chained devices so that each one projects the same effect. The master-slave function orks by
means of standard 3-pin XLR cables. The only difference is that the first device in the chain does not receive
DMX input. In Slave 1 mode, the device ill copy the exact signal directly from the Master.
PLEASE NOTE: When Slave mode is activated, the device ill ait for a signal from the Master device. In
this case it is not possible to simply select an automatic or sound-controlled mode! To cancel this, select
'NAST' mode in the SLND menu, so the device goes to Master mode. Then, all standalone functions can be
activated.
SHND: This mode consists of automatic programs, designed for sound-controlled operation. In sound-
controlled mode, the device uses the built-in microphone that can be activated by means of the SOUN
setting and adjusted in sensitivity. Any time the microphone detects sound, the device ill change movement
and/or colour in a ay that syncs perfectly ith your light sho . If no sound is detected, the device ill move
slo ly and change colour gradually until sound is detected again.
AUTO: With this mode, you can select the same automatic programs as in the SHND mode, but they run at
an automatic speed. The user can adjust the speed bet een 1 and 9, here 1 is the slo est and 9 is the
fastest speed.
SPLC: This device has a colour heel ith 8 colours (7 colours + open). By activating the Split Colour
option, it's possible to mix the colours in bet een. This ay, a figure can have 2 colours, like half red and half
hite, half purple and half blue, etc. The Split Colour function is available in all modes, as ell as via DMX.
PPOS / TPOS: This product is virtually the only one of its kind that allo s the user to correct the pan and tilt
range. This gives you more control over the freedom of movement of the moving head, should it be
positioned near a all for instance, preventing unnecessary light projection that ould other ise go
unnoticed.
The pan range can be set to 540, 360 and 180 degrees. The tilt range can be set to 180, 90 or 70 degrees.
SOUN: This setting sho s if the microphone function is activated or not, hich you can see in the display as
ON or OFF.
SENS: This mode allo s you to determine the sensitivity of the internal microphone. The further the device is
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials:18-02-2017 RV Revision date and author's initials: -
