Aztech DSL 300P Product information sheet

 Windows® 98 Second Edition and Windows® 2000 are registered trademarks of Microsoft Corp.
 All other company or product names are trademarks or registered trademarks or service marks of their
respective owners.
ADSL
Modem Card
DSL300P
Easy Start
Read Me First
Version 0.61

2
Modem Card Easy Start
About this
Easy Start This booklet contains information on setting up the ADSL
modem card DSL300P. It touches on the key installation
procedures to help you setup your modem in a breeze!
Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.
Installation Notes
•The graphics and screens illustrations shown in this easy start may differ from
what you see from your system, but the steps still apply.
•A Philips Screwdriver is required for the card installation.
•The documentation for your computer should come in handy during the card
installation. Have it ready by your side.
•It is recommended that any existing modem card be removed before installing your
new modem card.
Safety Precaution
•Do not remove your card from its protective bag until you are ready to install it.
•Always try to hold your card by its edges. Avoid touching any electronic components
on your card.
•Static electricity can cause permanent damage to your card. To prevent such a
damage, you must ground yourself while installing the card:
» Use a grounding strap, which is a coiled wire with a clip at one end and an
elastic strap at the other. Wear the strap around your wrist and attach the
clip to any non-painted metal surface of the computers chassis. OR
» If you do not have a grounding strap, touch any non-painted surface of the
computers chassis before you begin installation, and again every minute or
so until the installation is completed.

3
Modem Card Easy Start
Installing the Modem Card
Ê
Mounting Screw
Modem Card
Cover
Plate PCI-bus Slot
Ë
After removing the cover of your
computer, locate any available
PCI-Bus slot and remove its cover
plate.
1. Insert the modem card
firmly into the PCI-Bus
slot.
2. Secure the modem card
with the mounting screw
and replace the cover of
your computer.
Power off your computer and any connected devices before connecting your
modem card!
Connecting the Modem Card
The connection for the Telephone set is optional. The Phone jack provides
convenience to users who share the same telephone point for the modem and the
telephone set.

4
Modem Card Easy Start
Installing the Modem Drivers in
Windows®98 Second Edition (SE)
1. Power on your computer to
start Windows. It will detect
the newly-installed modem
card and prompt for its drivers.
Place the DSL300P
Installation CD into your
CD-ROM drive and click
Next.
Have the Windows Installation CDready during installation, as it may be required.
Depending on the protocol you use, there are 2 sets of drivers provided in the Installation
CD. If you are using the RFC1483 protocol, the drivers are found in the LAN directory.
IfyouareusingtheRFC2364 protocol, the drivers are found in theWANdirectory.The
followingscreenshots shows theRFC2364protocol being used.
Telephone set
Telephone
Wall Socket
Telephone
extension cord
from Telephone set
to Telephone Wall Socket
DSL300P

5
Modem Card Easy Start
2. Click the option "Search for
the best driver for your
device. (Recommended)." and
click Next.
3. Select Specify a location and click Browse...
For LAN users, navigate to the \LAN directory
on your CD-ROM and click OK.
For WAN users,navigate to the \WAN
directory on your CD-ROM and click OK.
Click Next.
4. Click Next again to proceed
with installation of the
driver found.
5. Click Finish when Windows
has finished installing the
driver.

6
Modem Card Easy Start
8. After restarting, check that the drivers
have been installed properly by right-
clicking My Computer and selecting
Properties. Click on the Device
Manager tab.
9. If the drivers were not installed
properly, a yellow exclamation mark
will appear beside the installed
device. In this case, uninstall the
drivers before attempting another
installation.
6. When prompted for the Windows®98 SE CD, remove the Installation CD in
your CD-ROM drive and replace with your Windows CD.
7. Click Yes when prompted to
restart your system.
10. Proceed to set the Virtual Circuit Identification in order to establish an ADSL
connection.

7
Modem Card Easy Start
Installing the Modem Drivers in Windows®2000
1. Power on your computer to start Windows. It will detect the newly-installed
modem card and prompt for its drivers.
2. Place the DSL300P
Installation CD into your
CD-ROM drive and click
Next.
3. Select "Search for a
suitable driver for my
device
(recommended)" and
click Next.
Depending on the protocol you use, there are 2 sets of drivers provided in the
Installation CD. If you are using theRFC1483 protocol, the drivers are found in the
LAN directory. If you are using theRFC2364 protocol, the drivers are found in the
WANdirectory. The following screen shots are taken from the RFC1483 protocol.

8
Modem Card Easy Start
7. Click Finish.
8. A Digital Signature Not
Found Window may
appear twice. Click Yes.
This prompt is displayed
due to different driver
versions.
6. Windows will prompt that a
driver has been found. Click
Next. If prompted for the
Installation CD, click OK.
4. Select
"Specify a
location" and
click Next.
5. Click Browse...
For LAN users,
navigate to the \LAN
directory on your CD-
ROM and click OK.
For WAN users,navigate to the \WAN directory on your CD-ROM and click OK.

9
Modem Card Easy Start
9. To verify that the drivers have been installed properly, right-click My Computer
and select Properties. Click on the Hardware tab and then Device Manager....
If the drivers were not installed properly, a yellow exclamation mark will
appear beside the installed device. In this case, uninstall the drivers before
attempting another installation.
10. Proceed to set the Virtual Circuit Identification in order to establish an ADSL
connection.

10
Modem Card Easy Start
Monitoring the ADSL Line / Setting the Virtual
Circuit Identification
To set the Virtual Path Identifier (VPI) and the Virtual Connection Identifier (VCI)
and monitor the ADSL line, double-click on the Conexant AccessRunner ADSL
icon in the Control Panel.
Under the General tab, the ADSL Line Information shows the status of the line.
When the connection is established, information such as the numbers and rates of
bytes received/transmitted are displayed.

11
Modem Card Easy Start
To set the Virtual Path Identifier (VPI) and the Virtual Connection Identifier (VCI),
press Alt+C. The Advanced tab is displayed. Set the values of the VPI's and VCI's
Virtual Circuit 0 and then click Apply and OK.
You need to restart your system for the values to take effect!

12
Modem Card Easy Start
Uninstalling the ADSL Modem Drivers in
Windows®98 SE/2000
1. From your Windows taskbar, click Start > Settings > Control Panel. Double-click
the (Add/Remove Programs) icon.
2. From the Add/Remove Programs Properties Window, under the Install/Uninstall
tab, select DSL300P ADSL Network Modem and click Add/Remove... .
3. Follow the instructions to start the uninstallation.
4. Click the OK button on the Add/Remove Programs Properties Window.
5. Restart your system.
P/N: 040-511413-xx6 (Oct 2000)
