Aztech DSL5028EN Instructions for use

MODEL
DSL5028EN(1T1R)
The following items are included in your DSL5028EN(1T1R)
package.
Step 1 : Package Contents
Step 2 : Setting Up Your Hardware
Connect the microlter to the telephone outlet.
Using a telephone cable, connect your modem router to the
microlter.
Using an Ethernet cable, connect your modem router to the
desktop using each devices’ Ethernet port.
Connect the power adapter to your modem router.
Switch ON your modem router.
This Easy Start Guide will help you set up your DSL5028EN(1T1R) modem router and connect it to the Internet. Before proceeding with the
installation, please prepare your internet account settings given by your Internet Service Provider (ISP). This device’s User Manual, which
provides a more advanced guide to this product, can be downloaded from this link : www.aztech.com/support/bayan5028/um
DSL5028EN(1T1R)
Power Adapter
DSL Microlter Ethernet Cable Telephone Cable
Easy Start Guide Leave Behind Card
A.
B.
C.
D.
Hardware Setup
Diagram
A
B
D
C
E
Power Adapter
Desktop / PC
DSL Microfilter
DSL5028EN(1T1R)
Step 3: Setting Up Your Internet Connection
Once you complete the hardware setup, proceed to the steps below in
establishing a connection with your Internet Service Provider.
Launch any web browser and input http://192.168.1.1 on the
address bar then press Enter. You will be redirected to the
login page of your DSL5028EN(1T1R). Simply enter guest as its
username and bayanDSLWIFI as its password then click Login.
A
E.
STEP 1
Package Contents
STEP 2
Setting Up Your
Hardware
STEP 3
Setting Up Your
Internet Connection

Click the Wizard menu, then click Next to start the step by step
guide in setting up your Internet Connection.
B
Select the Timezone and NTP Server that you would like to set on
your modem router then click Next to proceed.
C
Correctly Input the WAN Connection type provided by your Internet
Service Provider then click Next to continue.
D
On the next page, you may congure your wireless settings such
as the Wireless SSID and Wireless Password then click Next.
NOTE: The default SSID and Password can be found on the device
label located underneath your modem router.
E
Double-check the congured settings. Once done, click the Apply
button for the settings to take effect.
F
TROUBLESHOOTING TIPS
Having internet problems? Just follow the troubleshooting steps
below to continue having that high-speed connection that you need!
START DO YOU HAVE
INTERNET CONNECTION?
Congratulations! Enjoy your
surfing experience!
Check for Power.
ON/OFF Button should be ON.
Reinsert both ends of Power Adapter.
Check if power outlet is working.
Are the LED lights OFF?
Wait for 2-3 minutes.
Reinsert telephone jack cable at both
ends (if needed).
Are there any red LED lights?
Sorry, it’s time to ask for
help. Please contact our
Bayantel Customer Care.
Go back to START. Are you connected
wirelessly?
Did you reboot the
modem already?
Did you reset the
modem already?
Power OFF and
ON the modem.
Go back to START.
Disable/Enable Wireless on
client and modem.
Move client closer to modem.
Connect to correct SSID.
Enter the correct Username
and Password.
Did you restart your client?
Reinsert both ends of
the Ethernet cable to
different ports.
Did you restart your
client?
Power OFF and ON the client
(e.g. mobile or PC).
Go back to START.
Press the Reset button
for 10 seconds.
Go back to START.
NO
POWER IS OFF POWER IS ON YESPOWER IS ON
NO
YES
NO
YES NO
YES NO
NO
NO
A
B B
A
B
A
